Infinite Transtector ACP 100DR2 Series User manual

Thank you for your recent purchase of our surge protection solution.
Your satisfaction with our product and service is important to us.
If you have any questions, comments or concerns, please contact us
at 800.882.9110 or visit our website at www.transtector.com.
We look forward to continuing to serve your protection needs.
800.882.9110 | 208.772.8515 | www.transtector.com
1. IMPORTANT SAFETY INSTRUCTIONS
2. Read and understand all instructions.
3. SAVE THESE INSTRUCTIONS
ACP 100DR2 Series

800.882.9110 | 208.772.8515 | www.transtector.com
ACP 100 DR2 Series
1. These products are intended for use only on 15 or 20A 120VAC circuits.
2. Warning! Disconnect power upstream from the device when wiring to
avoid potential shock hazard.
3. Mounting the ACP 100 DR2 Series
3.1 35mm Din Rail Mount (4 possible orientations): To install,
exert force on one of the traveling tabs until opposite clip
engages rail; to uninstall, exert force on one of the traveling
tabs until the opposite clip disengages from the rail.
3.2 Panel Mount: It is recommended that the DIN foot connector
be uninstalled by removing the two Philips head screws when panel
mounting. Remove terminal block plug and install screws (#8 hard
ware recommended) through four provided mounting holes (dimensions
shown).
4. Wiring the ACP 100 DR2 Series: Install 10-14 AWG into input and
output terminal block positions as shown. A wiring diagram label is
also provided to ensure proper wiring of the device.
