Infinite TRANSTECTOR ACP 100MN User manual

Thank you for your recent purchase of our surge protection solution.
Your satisfaction with our product and service is important to us.
If you have any questions, comments or concerns, please contact us
at 800.882.9110 or visit our website at www.Transtector.com.
We look forward to continuing to serve your protection needs.
800.882.9110 | 208.772.8515 | www.transtector.com
1. MPORTANT SAFETY INSTRUCTIONS
2. Read and understand all instructions.
3. SAVE THESE INSTRUCTIONS
ACP 100MN & ACP 200MN

800.882.9110 | 208.772.8515 | www.transtector.com
ACP 100MN & ACP 200MN
1. These products are intended for use only on 15A 120Vac & 10A 240Vac
circuits as specied in Section 4.
2. Warning! Disconnect power upstream from the device when wiring to
avoid shock hazard.
3. Mounting the ACP 100MN & ACP 200MN Series: See Figure 1.
Mount unit as close as possible to the equipment to be protected.
4. Wiring the ACP 100MN & ACP 200MN
4.1 Wiring the ACP 100MN: Connect the source 120Vac phase
wire to the provided lead marked LINE (Black). Connect the
120Vac phase wire of the equipment to be protected to the
provided lead marked LOAD (Red). Connect the source and
equipment neutral wires to the provided lead marked NEUTRAL
(White).
4.2 Wiring the ACP 200MN: Connect the source 240Vac phase
wire to the provided lead marked LINE (Black). Connect the
240Vac phase wire of the equipment to be protected to
the provided lead marked LOAD (Red). Connect the source and
equipment neutral wires to the provided lead marked NEUTRAL
(White).
1200-140 REV C
