Infiniton CMP-HT90C1 User manual

User Manual for your
Range Hood
CMP-HT90C1
NOTE: This User Instruction Manual contains important information, including safety
& installation points, which will enable you to get the most out of your appliance.
Please keep it in a safe place so that it is easily available for future reference; for you
or any person not familiar with the operation of the appliance.

CONTENTS
1.Specification of your cooker hood….……………………………2
2.Important Safety Information………………………..…………3-5
3.Using your cooker hood………………………….……………5-6
4.Cleaning and Maintenance…………………..……………...….6-9
5.Installation…………………………………………………10-15
5.1. Electrical Connection……………………………….…10
5.2. Before Beginning Installation……………….…......10-11
5.3. Installing your cooker hood………………..………11-14
5.4. Extraction Mode & Recirculation Mode………...…14-15
6.Trouble Shooting………………………………….……...….16-17
7.Electrical Connection…………….………………….…….……17
8.After-sales Services.………………………………….…………17

1
1. SPECIFICATION OFYOUR COOKER HOOD
Before using your cooker hood, please know more about your product specification,
including the safety advice and operational instructions. Meanwhile, your cooker
hood will be installed correctly if it is in accordance with this method mentioned in
the user manual.
Dimension
Length (Cover) 600mm
Width (Cover) 500mm
Height (Cover) 845mm
Dimension of Chimney Section:
150mmX2000mm
Your stainless steel Cooker Hood is fitted with:
⚫High extraction tangential motor
⚫Button control operation
⚫3 Speeds
⚫3 Metallic grease filter
⚫2 LED lights
Extraction capacity: 1050 ㎥/hr
Extendable portion: a pair of air circulating activated carbon filters.

2
2. IMPORTANT SAFETY INFORMATION
Your safety is of the utmost importance to us. Please make sure that
you read this instruction booklet before attempting to install or use the
appliance. If you are unsure of any of information contained in this
booklet, please contact the Technical Department.
IMPORTANT:Any installation work must be carried out by a
qualified electrician or competent person.
⚫The cooker hood must be installed in accordance with the installation instruction
and all measurements followed.
⚫If the cooker hood is installed for use above a gas appliance then the provision for
ventilation must be in accordance with the Gas Safety Regulations.
⚫It is dangerous to alter the specifications or to modify this product in any way. Do
not tamper with it or attempt to modify the appliance in any way.
⚫When installing the cooker hood, ensure that the following recommended
distances are being observed between the cooker top and the bottom of the cooker
hood:
✓Electric cookers：700mm
✓Gas cookers：700mm
✓Coal/oil cookers：800mm
IMPORTANT: DO NOT SET YOUR COOKER HOOD LESS THAN 700mm
ABOVE YOUR COOKER.
⚫When installed between adjoining wall cabinets, the cabinets must not overhang
the hob.
⚫The edges of the cooker hood are sharp –be mindful for this as you handle your
appliance, especially during installation and cleaning. DO NOT CLEAN IN
BEHIND THE GRESE FILTERS!
⚫If the room where the cooker hood is to be used contains a fuel burning appliance
such as a central heating boiler then its flue must be of the sealed or balanced type.

3
⚫If other types of flue or appliance are fitted, ensure that there is an adequate
supply of air in the room.
⚫When the cooker hood is being used in its extractor function, make sure the
ventilation smoke duct is of fireproof materials, and the bent corners is greater
than 90 degrees, otherwise it will affect the normal function of the cooker hood.
⚫Ensure the ducting for the extractor function has the same
diameter as the outlet hole all the way through.
⚫Keep young children from using, playing with or tampering
with the cooker hood. Older children and inform persons
should be supervised if they are using the cooker hood.
⚫Your cooker hood is for domestic use only.
⚫Please dispose of the packing material carefully –children
are especially vulnerable to it.
⚫Dirty oil is an even greater fire risk.
⚫Always put lids on pots and pans when cooking on a gas
cooker.
⚫The manufacturer refuses to accept any responsibility for damages arising to the
hood or it catching on fire for failure to observe fire safety advice in these
instructions.
⚫Remember that when in extraction mode, your cooker hood is removing air from
your room. Ensure that proper ventilation measures are being observed. Note that it
removes odors form your room, not steam.

4
⚫WARNING: ALWAYS ENSURE THAT THE COOKER
HOOD HAS BEEN DISCONNECTED FROM THE POWER
SUPPLY BEFORE CARRYING OUT ANY WORK ON THE
HOOD, INCLUDING REPLACING LIGHT BULBS.
⚫Do not connect the ducting system of this appliance to any existing ventilation
system which is being used for any other purpose.
⚫Do not install above a cooker with a high level grill.
⚫Never leave frying pans unattended during use as overheated
fats and oils might catch fire.
⚫Do not attempt to use the cooker hood if it is damaged in any way. Never attempt
to use it without the grease filters fitted or if the filters are excessively greasy!
⚫Never flambé cook under this cooker hood.
THE MANUFACTURER DECLINCESALLRESPONIBILITYIN THE EVENT OF FAILURE TO OBSERVE THE
INSTRUCTIONS GIVEN HERE, FOR INSTRALLATION, MAINTENANCEAND SUITABLE USE OFTHE HOOD.
⚫This appliance can be used by children aged from 8 years and above and persons
with reduced physical, sensory or mental capabilities or lack of experience and
knowledge if they have been given supervision or instruction concerning use of
the appliance in a safe way and understand the hazards involved. Children shall
not play with the appliance. Cleaning and user maintenance shall not be made by
children without supervision.
⚫If the supply cord is damaged, it must be replaced by the manufacturer, its service
agent or similarly qualified persons in order to avoid a hazard.
⚫Never flambé cook under this cooker hood.
⚫There shall be adequate ventilation of the room when the range hood is used at the
same time as appliances burning gas or other fuels
⚫There is a fire risk if cleaning is not carried out in accordance with the
instructions;
⚫CAUTION: Accessible parts may become hot when used with cooking appliances.
⚫The range hood is only intended to be installed over a hob with no more than four
hob elements.
⚫Warning: Failure to install the screws or fixing device in accordance with these
instructions may result in electrical hazards.
⚫The power of LED should not exceed 2W. the voltage range of LED for
AC220-240V or DC12V.
The power of the single lamp (E14 lampholder) should not exceed 28W. the voltage
range of lamp for AC220-240V .The lamp bulb (E14) is should be replaced by it
must be replaced by the manufacturer or the maintenance department or a similar
professional to avoid danger.
IBA/C-15-220/240-E14-22
⚫Warning: Failure to install the screws or fixing device in accordance with these
instructions may result in electrical hazards

6
3. USINGYOUR COOKER HOOD
1. Please ensure your cooker hood has been installed correctly.
2. Find the control panel, and see the buttons below.
3. Different buttons have different functions. Please know the buttons and their
functions before suing.
4.
IMPORTANT: IDEALLY YOU SHOULD TURN ON YOUR HOOD TEN
MINUTES BEFORE YOU START TO COOK.
➢Touch the power key, and the Power button indicating light and LED display will
be on,and the motor runs at low speed.
➢Touch the lessen key, and the motor runs at lower speed.
➢Touch the incerase key, and the motor runs at higher speed.
➢Touch the light key, and the right and left lighting lamps will come. Touch it
again and lamps will turn off.
IMPORTANT: IDEALLY YOU SHOULD TURN ON YOUR
HOOD TEN MINUTES BEFORE YOU START TO COOK. OR
AT THE VERY LEAST WHEN YOU BEGIN COOKING. YOU
SHOULD ALSO RUN YOUR HOOD FOR TEN MINUTES
AFTER YOU HAVE FINISHED COOKING.

7
4.CLEANINGAND MAINTENANCE
IMPORTANT: BEFORE CLEANING, MAKE SURE THE
POWER IS CUT OFF, AND UNPLUGTHE PLUG FROM
THE OUTLET.
CLEANING
⚫Clean the external parts of your cooker hood with mild liquid detergent and
new damp cloth.
⚫Never use abrasive powder, corrosive solvents or brushes.
⚫Never insert pointed objects into the cooker hood’s protective grid.
⚫Only clean control panel and grease filter with mild liquid detergents and a
new damp cloth.
⚫If you are using the appliance in recirculation mode, then be sure to replace
the carbon filter at the recommended interval (see section on “Fitting the
carbon filter”). A build up of grease could cause a fire hazard.
⚫Never attempt to clean the area above the grease filters.
⚫Your cooker hood includes a grease filter which helps to absorb grease
particles to protect your kitchen & furniture from greasy residues.
⚫To prevent this fire hazard, the filter should be cleaned regularly.
⚫Depending on use, this should be done every 10-15 days or at least once a
month, using hot water and normal washing-up detergent.
⚫DO NOT WASH THE GREASE FILTER IN ADISHWASHER.

8
MAINTENANCE
⚫First remove the grease filter by pulling down on it.
⚫Undo the side catches.
⚫Soak the grease filter in hot water and washing up liquid for about an hour.
⚫Rinse them off thoroughly with hot water.
⚫Repeat the process or change the grease filter if required.
⚫Refit the grease filters once they have dried.
IMPORTANT: LET THE GREASE FILTERS DRY THOROUGHLY BEFORE
REFITTINGTHEM IN THE COOKER HOOD.
CHANGING A LIGHT BULB
IMPORTANT: BEFORE ATTEMPTING TO CHANGE A LIGHT
BULB, YOU MUST ENSURE THAT YOU HAVE DISCONNECTED
THE COOKER HOOD FROM YOUR MAINS SUPPLY.
⚫Remove the grease filters；
⚫Prior to touching the light bulbs ensure they are cooled down；

9
⚫Find the light fixture which is inside the exposed section of the canopy.
⚫Unscrew the light bulb that needs to be replaced and separate the power
supply quick joint terminal of the light bulb.
⚫Check the model and parameter of new light bulb newly installed. Connect
the power supply quick joint terminal. And replace the old light bulb.
⚫IMPORTANT: Defective bulbs should be replaced immediately.
⚫If the lights still do not work, make sure that the lamps are fitted properly
into their housing before you call for technical assistance.
⚫Refit the grease filters.
FITTING THE CARBON FILTER
If the appliance is being used in recirculation mode then it is necessary to fit carbon
filters. This will help to absorb unpleasant odors caused by cooking.
IMPORTANT: BEFORE ATTEMPTING TO FIT OR
REMOVE THE CARBON FILTERS, YOU MUST ENSURE
THAT YOU HAVE DISCONNECTED THE COOKER HOOD
FROM YOUR MAINS SUPPLY.
1.Remove the grease filters.
2. Hook the carbon filter over the pins that are located
at the end of the motor.
3.Turn the carbon filter anticlockwise, until you feel
it click into place.
⚫Repeat this process for the second carbon filter. You
need to place a carbon filter at either end of the motor.
⚫Refit the grease filters.
⚫The carbon filters should be replaced every three
months of if they show signs of damage.

10
5. INSTALLATION
IMPORTANT: Before installation and usage, read all the
instructions and make sure that the voltage (V) and the
frequency (Hz) indicated on the rating plate are exactly the
same as the voltage and frequency in your home. The rating
plate can be found behind the grease filters.
The manufacturer declines all responsibility in the event of the installer failing to
observe all the accident prevention regulations in force, which are necessary for
normal use and the regular operation of the electric system.
5.1. ELECTRICAL CONNECTION
YOUR COOKER HOOD IS INTENDED FOR FITTEDAND
PERMANENT INSTALLATION.
⚫The power cable must be connected to the terminals marked L (live) and N
(neutral) in the hood and fixed with a cable clamp.
⚫The cooker hood’s power cable must be fitted upstream from the electrical
connection, using an omni-polar switch with a contact distance of at least 3mm.
5.2. BEFORE BEGINNING INSTALLATION
⚫Check that the product purchased is of suitable size for the chosen
installation area.
⚫Carry out all necessary masonry work prior to the fitting of the cooker hood.
⚫Ensure that all electrical connections are carried out by a suitably qualified
person.
⚫Before commencing installation of the cooker hood the grease filter should
be removed.

11
⚫Check inside the product and ensure that there is no transit packaging or any
other materials, such as packets of screws, guarantee etc. These should be
removed and kept for future use.
⚫If possible, disconnect and move freestanding or slot-in cookers from their
position, to provide easier access to the rear wall and ceiling. If this is not
possible, then a thick, protective covering should be placed over the worktop,
hob top or cooker. This will help to protect these surfaces from damage and
debris.
⚫Select a flat surface for assembling the cooker hood. Cover that surface with
a protective covering and place all cooker hood parts and fittings on it.
⚫In addition check whether there is an electrical socket available, which will
be accessible after the hood is mounted. If you are going to use the appliance
in extractor mode, you should also ensure that there is space to connect a
fumes discharge device to the outside.
⚫Raw plugs are provided to secure the hood to most types of walls and
ceilings. However a qualified technician must verify the suitability of the
materials, in accordance with the type of wall and ceiling. The wall and
ceiling must strong enough to take the weight of the hood.
Do not tile, grout or silicone this appliance to the wall. This appliance is designed
to be surface mounted only.
5.3. INSTALLINGYOUR COOKER HOOD
IMPORTANT: YOU WILLHAVE TO DECIDE BEFORE INSTALLATION
YOUR COOKER HOOD WHETHER TO USE IT IN EXTRACTION
MODE OR RECIRCULATION MODE. PLEASE TURN TO PAGE 17
NOW TO UNDERSTAND THE DIFFERENCES BETWEEN THERES TWO MODES.
⚫The cooker hood should not be exposed to a direct heat source from the cooking
device underneath it, i.e. naked flame from a gas burner or heat from electric hob
zones without a pan on them.

12
⚫We recommend that at least two people install this hood.
⚫The lights on this appliance should only be used during operation of the cooker
hood. They should not be left on permanently and used as a lighting source.
IMPORTANT: YOUR COOKER HOOD SHOULD BE CONNECTED TO
YOUR MAINS SUPPLY AFTER THE REST OF THE INSTALLATION
PROCESS HAS BEEN COMPLETED.
1）Remove the metal grease filters.
2） Position the hood against the wall that you are
intending to install it and mark the position of
the support holes that are to be drilled .
3） Using a drill bit with an 8 mm diameter, make holes
in the wall on the positions that you have marked in
step 2, and insert raw plug into the holes that you
have drilled.
4）Screw the hook into the wall at Hole B.
③

13
5）Hang the cooker hood onto the hook. And fix the machine into the wall at Hole A
6） Connect the check valve onto the top of the chimney section. And then connect
the ducting hose to the check valve.
⚫The other end of the ducting hose should be connected to your discharge
outlet that is suitable for cooking vapors. It should have a cross section of at
least 150 ㎡.
⚫The maximum distance between the check valve and your discharge outlet
should be 3 meters, with one 90 degree bend.
7） Install the Chimney Section C and Fixing Bracket E
⚫Connect the Chimney Section C and
Fixing Bracket E. Put the bottom part
of this coupling on the cooker hood.
Mark the fixing holes between the
bracket and wall with a pencil. And
remove the Chimney Section and
Fixing Bracket E.
⚫Using a drill bit with an 8 mm
diameter make holes in the wall on
the positions that you have marked,
and insert raw plugs. Screw the
chimney section and bracket fixing into the wall tightly.

14
5.4. EXTRACTION MODE OR RECIRCULATION MODE
What is the difference between extraction and recirculation modes?
To get optimum performance form your cooker, the air will be taken out of the room
via external ducting.
Unfortunately if you live in a flat or the hood is too far from an outside wall, this may
not be possible. The only alternative is to recirculate the air.
In recirculation mode stale air is taken via the grease filter, and passed through a
charcoal filter for purification. The air then re-enters the kitchen via an opening in the
hood.
What is a charcoal filter and do I need one?
All cooker hoods have a grease filter but if you are using your cooker hood in
recirculation mode, then a charcoal filter must be fitted in addition to the grease filter.
8) Installing the fixing bracket F
* Screw the chimney section D and fixing
bracket F. Insert chimney section C and
lift it upwards until it reaches the ceiling.
You must ensure that it is perpendicular
to the hood. Use a pencil to mark the
holes for positioning the sides of the
chimney D and fixing bracket F. Remove
the himney section adn fixing bracket F.
- Use an 8mm bit, drill out holes marked
on the wall, and insert raw plugs. Screw
the chimney bracket F onto the wall.
9) Insert Chimney D into Chimney C and
lift it upwards until it reaches the ceiling.
Screw the chimney bracket F tightly.

15
6.TROUBLESHOOTING
IMPORTANT: If your cooker hood appears not to be operating properly, before
contacting the Service Department, please refer to the checklist below.
My cooker hood will not start
⚫Check that the hood is connected to the electricity supply.
⚫Check that the fan speed control is set correctly.
My cooker hood is not working effectively.
⚫The fan speed is not set high enough.
⚫The grease filter is dirty and requires cleaning.
⚫The kitchen is not well ventilated enough.
⚫If the hood is set up for recirculation mode, check that the carbon
filters do not need replacing.
⚫If the hood is set up for extraction mode, check that the ducting hose
and discharge outlet are not blocked.
My cooker hood has switched off during operation.
⚫The safety cut-out device has been tripped；
⚫Turn off the hob and then wait for the safety cut-out device to reset.
⚫IMPORTANT: If you have installed your cooker hood too low, the
safety cut-out device will frequently trip. Your cooker hood may
become damaged if the safety cut-out device is tripped frequently.

16
7.ELECTRICAL CONNECTION
8.AFTER-SALES SERVICES
Contact local distributor

Manual de usuario para su
Campana extractora
CMP-HT90C1
NOTA: Este manual de instrucciones para el usuario contiene información importante,
incluidos los puntos de seguridad e instalación, que le permitirán aprovechar al
máximo su dispositivo. Manténgalo en un lugar seguro para que esté fácilmente
disponible para futuras consultas; para usted o cualquier persona que no esté
familiarizada con el funcionamiento del aparato.

CONTENIDO
1. Especificación de su campana extractora…..……………………1
2. Informacion de Seguridad Importante ……………...…………2-4
3.Usando su campana extractora………..………….………………6
4.Limpieza y mantenimiento…………………..……………...….7-9
5.Instalación…………………………………………………10-15
5.1. Conexión eléctrica………………………………….…10
5.2. Antes de comenzar la instalación...………….…......10-11
5.3. Instalación de la campana extractora…..…..………11-14
5.4. Modo de extracción y modo de recirculación…...……15
6.Solución de problemas...………………………….…………….16
7.Conexión eléctrica….…………….………………….…….……17
8.Servicio posventa....………………………………….…………17
