infobit iMatrix M Series User manual

iMatrix M
4K Modular Seamless Switching Matrix w/ Videowall
VER 2.0
www.infobitav.com [e-mail]

Thank you for purchasing this product
For optimum performance and safety, please read these instructions carefully before
connecting, operating or adjusting this product. Please keep this manual for future
reference.
Surge protection device recommended
This product contains sensitive electrical components that may be damaged by
electrical spikes, surges, electric shock, lighting strikes, etc. Use of surge protection
systemsishighlyrecommendedin order to protect and extend the life of your equipment.
Table of Contents
1. Introduction. ........................................................................................................
1
2. Features. ..............................................................................................................
2
3. Package Contents. .............................................................................................
3
4. Specifications......................................................................................................
3
4.1 Specifications-Matrix. ...................................................................................
3
4.2 Specifications-2K Input/Output Card. .........................................................
5
5. Operation Controls and Functions.....................................................................
6
6. IR Remote ............................................................................................................
10
7. Card Introduction................................................................................................
11
7.1 2K Input Card................................................................................................
11
7.2 2K Output Card.............................................................................................
18
7.3 4K Input Card................................................................................................
22
7.4 4K Output Card.............................................................................................
26
8. Host Computer Control Operation Guide. ........................................................
28
8.1 Login & Connection. .....................................................................................
28
8.2 Host Computer Main Interface.....................................................................
30
9. API Control Command. ......................................................................................
37
10. Application Example. .......................................................................................
45

1/45
1. Introduction
This Modular Seamless Switching Matrix is a professional all-in-one machine that supports
various audio and video signal switching and distribution, integrated video wall function and
control system.
It supports up to 8~36 signal inputs and 8~36 signal outputs. Audio and video matrix adopts
pure hardware high-speed matrix switching chip, which has high integration, stable system,
no compression/loss/delay of signal.
Advanced full digital signal processing technology can ensure signal distortion-free processing,
and the best image quality to the display devices.
This series of Modular Seamless Switching Matrix, supported by the high bandwidth
backplane, provides up to 4Kx2K@60Hz YCbCr 4:4:4 24bit input/output and arbitrary
routing of various signals. It supports HDMI 2.0b, 18Gbps video bandwidth, color depth
up to 12 bits. The matrix adopts pluggable card structure, which is flexible and convenient
for installation. It provides HDMI, DVI-U (DVI/VGA/YPbPr/CVBS), VGA, 3G/HD/SDI, HDBaseT
and optical fiber input/output cards. One card with four channels, both 2K series and 4K
series cards are supported. Input cards support audio embedding, and output cards support
audio de-embedding, providing maximum support for the audio system in the whole system.
It offers multiple control methods such as front panel buttons (with LCD screen), IR remote,
RS-232 signals, LAN, PC tool or Web GUI control.
The built-in video wall function can realize any splicing mode within the range of 8/16/36 total
output channels, providing a turnkey solution for the distribution and processing of video
signals with various formats in various industries.
The built-in control system integrates multiple control interfaces and intelligent control GUI
modules that can be directly recalled by users.
This Matrix is applicable to video conference, energy and power, judicial prison, smart city,
government service, water conservancy and hydrology, meteorology and earthquake,
enterprise management, metallurgy and steel, banking and finance, public security and
transportation, exhibition, production scheduling, radio and television, education and
scientific research and other fields.

2/45
2. Features
☆HDMI 2.0b and HDCP 2.2 compliant
☆HDMI 18Gbps video bandwidth, up to 4K60 YCbCr 4:4:4 24bit
☆Pluggable card structure (One card with four channels)
☆Support 8/16/36 channel video signal inputs and outputs
☆Multiple input/output cards with HDMI, DVI-U (DVI/VGA/YPbPr/CVBS), VGA, 3G/HD/
SD-SDI, HDBaseT and optical fiber
☆ Video resolution up to 1920×1200p60hz (2K series card), 3840x2160p60hz (4K series
card)
☆Seamless switching without image tear, black screen or flicker in the switching process
☆Based on Gen-Lock video wall splicing technology, the latency between any output
channel is less than 0.1ms
☆Any videowall layout modes in the allowed range of 8x8~36x36, especially suitable for
LCD/LEDvideo wall
☆Multiple output resolutions to meet the needs of different types of display devices
☆Adopt pure-hardware high-speed matrix switching chip
☆Built-in signal equalization, signal recovery and signal re-driver
☆Built-in video quality enhancement, output video quality can be adjusted
☆Built-in HDCP processing logic to avoid HDCP compatibility issues
☆Input cards support audio embedding, output cards support audio de-embedding
☆Analog audio embedding supports LPCM 2.0CH, analog audio and video signals
are input synchronously.
☆Analog audio de-embedding supports LPCM 2.0CH, analog audio and video signals
are output synchronously
☆Up to 64x of scene-presets can be recalled
☆Advanced EDID management (Internal EDID or copy from any output devices)
☆Control via front panel buttons, IR, RS-232, TCP/IP, Web GUI or PC program
☆Built-in intelligent control system with user-friendly GUI
☆Silent fan design, noiseless, stable performance
☆AC power port with built-in power module
☆Standard rack size design, convenient for installation

3/45
3. Package Contents
①1 x Modular Seamless Switching Matrix
②1 x IR Remote
③1 x RS-232 Serial Cable (DP9 female connector to 3pin H2.0 Phoenix Connector,
1.5 meters)
④ 1 × USB to RS-232 Serial Cable (USB A to RS-232 serial DB9 male connector)
⑤4 × Rubber Foot
⑥ 4 × Machine Screw (M3*4)
⑦1 x 100~240V AC 50/60Hz Power Cord
(Note: The dual power card is equipped with two AC power cords.)
⑧1 x User Manual
4. Specifications
4.1 Specifications-Matrix
Technical
HDMI Compliance
HDMI 1.4 (2K series card), HDMI 2.0b (4K series card)
HDCP Compliance
HDCP 1.4 (2K series card), HDCP2.2 (4K series card)
Video Bandwidth
600MHz/18Gbps
Video Resolution
1920x1200p60Hz (2K series card)
3840x2160p60Hz 4:4:4 (4K series card)
Color Depth
2K series card: 8/10/12-bit (1080P60Hz)
4K series card: 8/10/12-bit (4K30Hz); 8-bit (4K60Hz 4:4:4)
Color Space
RGB, YCbCr 4:4:4 / 4:2:2 / 4:2:0
Audio Formats
HDMI audio: LPCM 2.0 / 5.1 / 7.1CH
Analog audio:LPCM 2.0CH
Transmission
Distance
HDMI: 1080P/15 meters, 4K30/10 meters, 4K60/5 meters
HDBT: 1080P/70meters/100 meters/150 meters;
4K/40 meters/70 meters/120 meters
ESD Protection
Human body model —
± 8KV (Air-gap discharge) & ± 4KV (Contact discharge)

4/45
Connections
Input Ports
2 x Input card (8x8 Matrix); 4 x Input card (16x16 Matrix);
9 x Input card (36x36 Matrix)
Output Ports
2 x Output card (8x8 Matrix); 4 x Output card (16x16 Matrix);
9 x Output card (36x36 Matrix)
Control Ports
1 x Master control card, including the following ports：
1 x RS-232 [3-pin Phoenix Connector]
4 x COM [3-pin Phoenix Connector]
1 x IR-SERIAL [4-pin Phoenix Connector]
1 x RELAY [4-pin Phoenix Connector]
1 x I/O [3-pin Phoenix Connector]
1 x RESET [Reset button for the central control system]
3 x LAN [RJ45]
Mechanical
Housing
Metal Enclosure
Color
Black
Dimensions
8x8 Matrix: 483mm (W) × 377mm (D) × 89mm (H)
16x16 Matrix: 483mm (W) × 379mm (D) × 133mm (H)
36x36 Matrix: 483mm (W) × 378mm (D) × 266mm (H)
Weight
8x8 Matrix: 5.95kg (No input/output cards are included)
16x16 Matrix: 8.62kg (No input/output cards are included)
36x36 Matrix: 15.4kg (No input/output cards are included)
Power Supply
AC 100-240V, 50/60Hz
Power
Consumption
8x8 Matrix: 40W~190W (Match with different input/output cards)
16x16 Matrix: 80W~320W (Match with different input/output cards)
36x36 Matrix: 200W~840W (Match with different input/output cards)
Operating
Temperature
0°C ~ 40°C / 32°F ~ 104°F
Storage
Temperature
-20°C ~ 60°C / -4°F ~ 140°F
Relative
Humidity
20~90% RH (no condensation)

5/45
4.2 Specifications-2K Input/Output Card
Input
Interface
Type
Signal
Format
DVI-U
HDMI
DVI
VGA
YPbPr
CVBS
HDMI / DVI: 640x480p60, 800x600p60, 1024x768p60,
1280x768p60, 1280x800p60, 1280x1024p60,
1360x768p60, 1400x1050p60, 1600x1200p60,
1920x1080p60, 1920x1200p60, 480i60, 576i50,
1080i50/60,720p50/60,1080p23/24/25/29/30/50/60
VGA: 640x480p60, 800x600p60, 1024x768p60,
1280x768p60, 1280x800p60, 1280x1024p60,
1360x768p60, 1440x900p60, 1400x1050p60,
1600x1200p60, 1920x1080p60, 1920x1200p60
YPbPr: 480i60, 576i50, 720p50, 720p60, 1080i50,
1080i60, 1080p50, 1080p60
CVBS: PAL, NTSC
HDMI
HDMI
Same as HDMI input of DVI-U universal card
VGA
VGA
Same as VGA input of DVI-U universal card
BNC
SDI
480i60, 576i50, 1080i50/60, 720p23/24/25/29/30/50/60,
1080p23/24/25/29/30/50/60
RJ45
HDBaseT
Same as HDMI input of DVI-U universal card
LC
Fiber
Same as HDMI input of DVI-U universal card
Single-mode with single fiber,
transmission distance: 10 km
Output
Interface
Type
Signal
Format
DVI-U
HDMI
DVI
VGA
HDMI / DVI / VGA: 1024x768p60, 1280x720p60,
1280x1024p60, 1360x768p60, 1680x1050p60,
1600x1200p60, 1920x1080p30, 1920x1080p60,
1920x1200p60
HDMI
HDMI
Same as HDMI output of DVI-U universal card
VGA
VGA
Same as VGA output of DVI-U universal card
BNC
SDI
480i60, 576i50, 720p25, 720p30, 720p50, 720p60,
1080i50, 1080i60, 1080p24/25/30/50/60
RJ45
HDBaseT
Same as HDMI output of DVI-U universal card
LC
Fiber
Same as HDMI output of DVI-U universal card
Single-mode with single fiber,
transmission distance: 10 km

6/45
1
2
3
4
5
5. Operation Controls and Functions
(Take the 16x16 Matrix as an example)
Front Panel
No.
Name
Function Description
1
LED screen
Display the current status information (Matrix switching channel, EDID
information, baud rate and so on).
2
PWR LED
The power LED lights in green when the system is powered on, and
red when the system is in standby.
3
INPUT &
OUTPUT
buttons (0~9)
Used to select the corresponding input and output channels. You need
to press the input button (0~9) firstly, then press the output button (0~
9) , finally press “ENTER” button to complete switching.
Note: If the selected input/output channel number exceeds 16, it will
prompt that the number is out of range and need to be reselected.
4
Control
buttons
SAVE: Used to save the current display scene (up to 64 scenes can
be saved). For example, press SAVE button firstly, the LED screen will
show “Save Config to: Preset n”（n=1,2,...64). Then press UP/DOWN
button to select “Preset 1”, finally press ENTER button to save the
current display scene as Scene 1.
MENU: Short press MENU to enter various menu function setting
options in turn. When entering a certain function menu, select the
setting parameters or input/output channel values through the UP/
DOWN button circularly, and finally press ENTER to confirm.
UP: Press this button to select upwards on the display screen.
DOWN: Press this button to select downwards on the display screen.
POWER: Press and hold this button for 3s to enter the standby mode,
the power LED will light in red; press the button again to resume
starting, the power LED will light in green.
RECALL: Used to recall the saved scene as the current display scene.
e.g. Press “RECALL→UP/DOWN (to select number 1 ~ n)→ENTER”
to recall the saved Scene n as the current display scene.
ENTER: Used to confirm the operation and save the setting.
LOCK: Short press this button to to lock the current setting status,
other panel buttons will be locked. Press this button again to unlock,
all panel buttons can be used normally.
5
IR window
IR receiver window. It only receives the IR remote signal from this
product.

7/45
1
2
3
4
1
2
3 4
5
6
7
Rear Panel
No.
Name
Function Description
1
Input cards
Video input card, connected to source devices directly or via an
Extender.
2
Output
cards
Video output card, connected to display devices directly or via an
Extender.
3
Main
Control card
Main control card, equipped with various control ports.
4
Power card
Power cord, equipped with a power port, a power switch and a ground
port.
Main Control Card (optional 1)
No.
Name
Function Description
1
RS-232
port
Connect to the PC or the third party control processor to transmit
RS-232 command and control the Matrix.
2
COM1-4
Four sets of programmable two-way multi-mode serial port, which is a
3-pin phoenix connector (male), compliant with RS-232 communication
protocol, and capable of configuring 8 baud rates in the range of 2400-
115200bps.
The pin-outs of the RS-232 ports are PIN1 for TXD, PIN2 for GND, and
PIN3 for RXD.

8/45
No.
Name
Function Description
3
IR-SERIAL
2 sets of multi-mode 2-PIN phoenix connectors for IR transmitting or
one-way serial signal outputting. The ports can connect to devices
with signal level 0-5V in RS-232 mode. The left pin is for IR/serial
data, the right for signal GND.
The IR-Serial working mode is programmable:
In IR transmitting mode, the outputting IR wave length ranges within
20K-60KHZ.
In one-way serial data outputting mode, the left pin is for TXD, the
right for GND, and both are configurable in the program.
4
RELAY
2 sets of relay output ports (2-PIN phoenix connectors); each relay is
isolated and normally open, and can switch up to 2A 30VDC / 1A
125VAC peak. The connector does not support voltage output.
5
I/O
2-CH GPIO dry contact input interface, with a voltage range of 0~
24V, for collecting digital level signals, capable of low level signal
sensing.
6
LAN1-3
Standard 10M/100M Ethernet RJ45 port, allowing device access,
connected to the PC or the third party control processor to control
the Matrix.
The control host boots up with DHCP enabled by default. After
powering on, when the control host connects to a network where
there is no router present to assign IP addresses, the control host
will take the pre-set IP address: 192.168.0.101. If there is a router
present on the same network, the router will assign an IP address
to the control host in three minutes and the pre-set IP address will
be invalid.
Note: When the control host is DHCP enabled after power on, the
router (if connected to the same network) will assign an IP address
to the control host. If network is disconnected at this time, the control
host won’t be able to pre-set an IP address and its IP address would
be 0.0.0.0. If a pre-set IP address is needed, you need to power off
the control host and then power it on again. If it is in static IP mode
after power on, the control host won’t preset an IP address either.
If there is no router present, you can connect your PC to the LAN
port of the host and modify the PC’s IP address in the network
segment of 192.168.0.X, then the PC will preset an IP address to
the control host in three minutes for data communication.
7
RESET
button
#1 Short press the RESET button for less than 1s, there isno reaction.
#2 Long press the RESET button for more than 1s but less than 5s,
the control device will reboot. It won’t upload the user projects
after rebooting.
#3 Long press the RESET button for more than 5s, the control host
will reset the user configuration information, the IP will be restored
to DHCP state, the login password of the management page will
be initialized to “admin”, the time will be initialized to automatic
acquisition mode, but user projects won’t be deleted by factory
initialization.

9/45
1
2
3
4
1
2
3
1
2
3
4
5
Main Control Card (optional 2, by default)
No.
Name
Function Description
1
RS-232 IN
port
RS-232 serial signal input port, connected to the PC or the third party
control processor to transmit RS-232 command and control the Matrix.
2
RS-232
OUT port
RS-232 serial signal output port.
(1) Connect to external device and control it through RS-232 command.
(2) Connect to other Matrix for cascading.
3
LAN
Standard 10M/100M Ethernet RJ45 port, allowing device access,
connected to the PC or the third party control processor to control
the Matrix.
4
RESET
button
After the device boots up, long press the RESET button for more than
10s, then release it, the system will reset the MCU configuration and
the MCU will restore factory settings.
Single Power Card (optional 1)
No.
Name
Function Description
1
Power port
Connect the power input port to the AC power supply using the
included power cord.
2
Power switch
Press the power switch to turn on/off the system.
3
GND
Used for connecting the ground or the earthing conductor of the rack.
Dual Power Card (optional 2, by default)

10/45
methods：
No.
Name
Function Description
1
Power port
Connect the power input port to the AC power supply using the
included power cord.
2
Power switch
Press the power switch to turn on/off the system.
3
Redundant
power port
When the external AC power supply fails, the DC power supply
continues to be provided to ensure the normal operation of the device.
4
Redundant
power switch
When using the redundant power supply, press the power switch to
turn on/off the system.
5
GND
Used for connecting the ground or the earthing conductor of the rack.
6. IR Remote
①Power button: Power on the Matrix or set it to
standby mode.
②Input 1/2/3/4/5/6/7/8/9/0: Used to select the input
channel.
③Output 1/2/3/4/5/6/7/8/9/0: Used to select the
output channel.
The IR Remote has the following three operation
Method 1: First press the input button, then press the
output button to switch the input signal to the display
device.
For example:
Press Input-Y
(Y represents the input button from 01 to 16)
Then press Output-X
(X represents the output button from 01 to 16)
Note：In order to support the multi-channel switching
of output channels, the input and output channels
must be selected with double digit (the maximum
value cannot exceed 16), that is, for input and output
channels less than 10, press 0 first, and then press
the corresponding number button. For example, when
switching from input 1 to output 1, press the input
buttons 0 and 1 first, and then press the output buttons
0 and 1.
Method 2: Press the PTP button, then all input channels and output channels are switched
in one-to-one correspondence.
Method 3: First press the input button (select the input channel), then press All button (select
all output channels), the signals of the selected input channel will be output to all display
devices.
1
2
3

11/45
7. Card Introduction
7.1 2K Input Card
(1) 2K HDMI Input Card
Signal Channel
4-channel HDMI input signals
Resolution
640x480p60Hz, 800x600p60Hz, 1024x768p60Hz,
1280x768p60Hz, 1280x800p60Hz, 1280x1024p60Hz,
1360x768p60Hz, 1400x1050p60Hz, 1600x1200p60Hz,
1920x1080p60Hz, 1920x1200p60Hz；
720x480i59.94Hz (480i59), 720x480p59.94Hz (480p59),
720x576i50Hz (576i50), 720x576p50Hz (576p50),
1280x720p50Hz (720p50), 1280x720p59.94Hz (720p59),
1280x720p60Hz (720p60), 1920x1080i50Hz (1080i50),
1920x1080i59.94Hz (1080i59), 1920x1080i60Hz(1080i60),
1920x1080p23.98Hz (1080p23), 1920x1080p24Hz (1080p24),
1920x1080p25Hz (1080p25), 1920x1080p29.97Hz (1080p29),
1920x1080p30Hz (1080p30), 1920x1080p50Hz (1080p50),
1920x1080p59.94Hz (1080p59), 1920x1080p60Hz (1080p60),
1920x1200p60Hz (1200p60)
HDMI Compliance
HDMI 1.4
HDCP Compliance
HDCP 1.4
Video Bandwidth
6.75Gbps
Color Depth
8/10/12-bit (1080p60Hz)
Audio
Support external audio source input (LPCM 2.0CH)
Audio Port
3.81mm Phoenix Connector
HDMI Port
HDMI Type A

12/45
(2) 2K HDBT 70M Input Card
Signal Channel
4-channel HDBT input signals
Resolution
640x480p60Hz, 800x600p60Hz, 1024x768p60Hz,
1280x768p60Hz, 1280x800p60Hz, 1280x1024p60Hz,
1360x768p60Hz, 1400x1050p60Hz, 1600x1200p60Hz,
1920x1080p60Hz, 1920x1200p60Hz；
720x480i59.94Hz (480i59), 720x480p59.94Hz (480p59),
720x576i50Hz (576i50), 720x576p50Hz (576p50),
1280x720p50Hz (720p50), 1280x720p59.94Hz (720p59),
1280x720p60Hz (720p60), 1920x1080i50Hz (1080i50),
1920x1080i59.94Hz (1080i59), 1920x1080i60Hz(1080i60),
1920x1080p23.98Hz (1080p23), 1920x1080p24Hz (1080p24),
1920x1080p25Hz (1080p25), 1920x1080p29.97Hz (1080p29),
1920x1080p30Hz (1080p30), 1920x1080p50Hz (1080p50),
1920x1080p59.94Hz (1080p59), 1920x1080p60Hz (1080p60),
1920x1200p60Hz (1200p60)
HDMI Compliance
HDMI 1.4
HDCP Compliance
HDCP 1.4
Video Bandwidth
6.75Gbps
Color Depth
8/10/12-bit (1080p60Hz)
Audio
Support external audio source input (LPCM 2.0CH)
Audio Port
3.81mm Phoenix Connector
HDBT Port
RJ45
Max Transmission
Distance
HDBT 1080p60Hz=70 meters

13/45
(3) 2K HDBT 100M Input Card
Signal Channel
4-channel HDBT input signals
Resolution
640x480p60Hz, 800x600p60Hz, 1024x768p60Hz,
1280x768p60Hz, 1280x800p60Hz, 1280x1024p60Hz,
1360x768p60Hz, 1400x1050p60Hz, 1600x1200p60Hz,
1920x1080p60Hz, 1920x1200p60Hz；
720x480i59.94Hz (480i59), 720x480p59.94Hz (480p59),
720x576i50Hz (576i50), 720x576p50Hz (576p50),
1280x720p50Hz (720p50), 1280x720p59.94Hz (720p59),
1280x720p60Hz (720p60), 1920x1080i50Hz (1080i50),
1920x1080i59.94Hz (1080i59), 1920x1080i60Hz(1080i60),
1920x1080p23.98Hz (1080p23), 1920x1080p24Hz (1080p24),
1920x1080p25Hz (1080p25), 1920x1080p29.97Hz (1080p29),
1920x1080p30Hz (1080p30), 1920x1080p50Hz (1080p50),
1920x1080p59.94Hz (1080p59), 1920x1080p60Hz (1080p60),
1920x1200p60Hz (1200p60)
HDMI Compliance
HDMI 1.4
HDCP Compliance
HDCP 1.4
Video Bandwidth
6.75Gbps
Color Depth
8/10/12-bit (1080p60Hz)
Audio
Support external audio source input (LPCM 2.0CH)
Audio Port
3.81mm Phoenix Connector
HDBT Port
RJ45
Max Transmission
Distance
HDBT 1080p60Hz=100 meters

14/45
(4) 2K HDBT 150M Input Card
Signal Channel
4-channel HDBT input signals
Resolution
640x480p60Hz, 800x600p60Hz, 1024x768p60Hz,
1280x768p60Hz, 1280x800p60Hz, 1280x1024p60Hz,
1360x768p60Hz, 1400x1050p60Hz, 1600x1200p60Hz,
1920x1080p60Hz, 1920x1200p60Hz；
720x480i59.94Hz (480i59), 720x480p59.94Hz (480p59),
720x576i50Hz (576i50), 720x576p50Hz (576p50),
1280x720p50Hz (720p50), 1280x720p59.94Hz (720p59),
1280x720p60Hz (720p60), 1920x1080i50Hz (1080i50),
1920x1080i59.94Hz (1080i59), 1920x1080i60Hz(1080i60),
1920x1080p23.98Hz (1080p23), 1920x1080p24Hz (1080p24),
1920x1080p25Hz (1080p25), 1920x1080p29.97Hz (1080p29),
1920x1080p30Hz (1080p30), 1920x1080p50Hz (1080p50),
1920x1080p59.94Hz (1080p59), 1920x1080p60Hz (1080p60),
1920x1200p60Hz (1200p60)
HDMI Compliance
HDMI 1.4
HDCP Compliance
HDCP 1.4
Video Bandwidth
6.75Gbps
Color Depth
8/10/12-bit (1080p60Hz)
Audio
Support external audio source input (LPCM 2.0CH)
Audio Port
3.81mm Phoenix Connector
HDBT Port
RJ45
Max Transmission
Distance
HDBT 1080p60Hz=150 meters

15/45
(5) 2K SDI Input Card
Signal Channel
4-channel SDI input signals
Signal Format
HD-SDI (SMPTE 292M)/3G-SDI
Resolution
720x480i59.94Hz (480i59), 720x576i50Hz (576i50),
1280x720p50Hz (720p50), 1280x720p59.94Hz (720p59),
1280x720p60Hz (720p60), 1920x1080i50Hz (1080i50),
1920x1080i59.94Hz (1080i59), 1920x1080i60Hz(1080i60),
1920x1080p23.98Hz (1080p23), 1920x1080p24Hz (1080p24),
1920x1080p25Hz (1080p25), 1920x1080p29.97Hz (1080p29),
1920x1080p30Hz (1080p30), 1920x1080p50Hz (1080p50),
1920x1080p59.94Hz (1080p59), 1920x1080p60Hz (1080p60)
Color Depth
8-bit (1080p60Hz)
Video Bandwidth
2.97Gbps
Impedance
75Ω
Audio
Support external audio source input (LPCM 2.0CH)
Audio Port
3.81mm Phoenix Connector
SDI Port
BNC/female

16/45
(6) 2K VGA Input Card
Signal Channel
4-channel VGA input signals
Signal Format
RGB (Analog)
Resolution
640x480p60Hz, 800x600p60Hz, 1024x768p60Hz, 1280x720p
60Hz, 1280x800p60Hz, 1280x1024p60Hz,1360x768p60Hz,
1440x900p60Hz, 1440x1050p60Hz, 1600x1200p60Hz,
1920x1080p60Hz, 1920x1200p60Hz
Color Depth
8-bit (1080p60Hz)
Horizontal Scan
Frequency
15KHz ~ 90KHz
Synchronization
Type
RGBHV
Impedance
75Ω
Nominal level
0.7Vp-p
Audio
Support external audio source input (LPCM 2.0CH)
Audio Port
3.81mm Phoenix Connector
VGA Port
DB15, 15-pin female
(7) 2K DVI Input Card
Signal Channel
4-channel DVI input signals
Signal Format
DVI-I full digital TMDS signal, which is compliant with DVI1.0
Resolution
640x480p60Hz, 800x600p60Hz, 1024x768p60Hz,1280x800p
60Hz, 1280x1024p60Hz,1360x768p60Hz, 1440x900p60Hz,
1440x1050p60Hz, 1600x1200p60Hz, 1920x1200p60Hz

17/45
Color Depth
8-bit (1080p60Hz)
Signal Level
TMDS 400 ~ 600mVp-p
Impedance
100Ω
Video Bandwidth
4.95Gbps
Audio
Support external audio source input (LPCM 2.0CH)
Audio Port
3.81mm Phoenix Connector
DVI Port
DVI-I, 28-pin female
(8) 2K FIBER Input Card
Signal Channel
4-channel FIBER input signals
Resolution
640x480p60Hz, 800x600p60Hz, 1024x768p60Hz,
1280x768p60Hz, 1280x800p60Hz, 1280x1024p60Hz,
1360x768p60Hz, 1400x1050p60Hz, 1600x1200p60Hz,
1920x1080p60Hz, 1920x1200p60Hz；
720x480i59.94Hz (480i59), 720x480p59.94Hz (480p59),
720x576i50Hz (576i50), 720x576p50Hz (576p50),
1280x720p50Hz (720p50), 1280x720p59.94Hz (720p59),
1280x720p60Hz (720p60), 1920x1080i50Hz (1080i50),
1920x1080i59.94Hz (1080i59), 1920x1080i60Hz(1080i60),
1920x1080p23.98Hz (1080p23), 1920x1080p24Hz (1080p24),
1920x1080p25Hz (1080p25), 1920x1080p29.97Hz (1080p29),
1920x1080p30Hz (1080p30), 1920x1080p50Hz (1080p50),
1920x1080p59.94Hz (1080p59), 1920x1080p60Hz (1080p60),
1920x1200p60Hz (1200p60)
Color Depth
8/10/12-bit (1080p60Hz)
Impedance
100Ω
Video Bandwidth
6.75Gbps
Audio
Support external audio source input (LPCM 2.0CH)
Audio Port
3.81mm Phoenix Connector
SFP Port
SFP_HOST, 20-pin female

18/45
7.2 2K Output Card
(1) 2K HDMI Output Card
Signal Channel
4-channel HDMI output signals
Resolution
1024x768p60, 1280x720p60, 1280x1024p60, 1360x768p60,
1680x1050p60, 1600x1200p60, 1920x1080p30, 1920x1080p
60, 1920x1200p60 (The user can select the resolution through
the control software)
HDMI Compliance
HDMI 1.4
HDCP Compliance
HDCP 1.4
Video Bandwidth
4.95Gbps
Color Depth
8-bit (1080p60Hz)
Audio
Support stereo analog audio output (LPCM 2.0CH)
Audio Port
3.81mm Phoenix Connector
HDMI Port
HDMI Type A
(2) 2K HDBT 70M Output Card
Signal Channel
4-channel HDBT output signals
Resolution
1024x768p60, 1280x720p60, 1280x1024p60, 1360x768p60,
1680x1050p60, 1600x1200p60, 1920x1080p30, 1920x1080p
60, 1920x1200p60 (The user can select the resolution through
the control software)
HDMI Compliance
HDMI 1.4
HDCP Compliance
HDCP 1.4
Video Bandwidth
4.95Gbps
Color Depth
8-bit (1080p60Hz)
Audio
Support stereo analog audio output (LPCM 2.0CH)
Audio Port
3.81mm Phoenix Connector
HDBT Port
RJ45
Max Transmission
Distance
HDBT 1080p60Hz=70 meters
