infobit iTrans DB-TR-22 User manual

iTrans DB-TR-22
Dante Bluetooth
Transceiver
All Rights Reserved
Version: V1.1
Product Introduction
Thanks for choosing the iTrans DB-
TR-22. It connects to your Dante
network and supports 2X1 channels
of wireless audio, allowing PC and
mobile device to playout and receive
audio with your Dante devices using
a Bluetooth connection.
Features
⚫Plug and Play
⚫24-bit audio support
⚫2X1 audio channels
⚫Supports 802.3af PoE
⚫Bluetooth 5.0
⚫Maximum transmission
distance 20m
Packing List
⚫1 x iTrans DB-TR-22
⚫1 x User Manual
Note: Please contact your distributor
immediately if any damage or defect in the
components is found.
Panel Description
①RJ45: Dante network
communication port. Green
steady light indicates system
ready; yellow flashing light
indicates link/data traffic. The
green light will flash to identify
the device when clicking the
Dante Controller “Identify” button
(an eye-shaped symbol) on the
host computer.
②Bluetooth: 1 x backlit key, blue
backlight, for Bluetooth pairing.

Bluetooth pairing process
After the device is powered on, press
the pairing button, the blue backlight
of the button flashes quickly,
indicating that the device is in the
state of being connected.
After the Bluetooth device is
successfully paired with it, the blue
backlight of the button is always on.
If the Bluetooth is not connected to
any device within one minute, the
blue backlight is off, the Bluetooth is
turned off, and the pairing button
needs to be pressed again.
In the power-on state, press and hold
the button for more than 5 seconds,
the backlight will turn off. At this time,
the pairing will be reset, and the
Bluetooth will return to the initial
state.
Technical Specification
Dante
Power
802.3af PoE
Sample Rate
48 kHz
Dante Device
Latency
1,2 or 5ms
(configurable
using Dante
Controller)
Bit Depth
24
Channels
Bluetooth
2X1
Control
Control Part
(1) Bluetooth
General
Power
802.3af PoE
Operation
Temperature
-5 to +55℃
Storage
Temperature
-25 to +70℃
Power
Consumption
1.9W(Max)
Dimension
(W*H*D)
115x 34 x 28
mm
Net Weight
70g
