infobit WP70-T User manual

HDBaseT Wall-plate Transmitter
(1-Gang US Decora)
VER 2.1
Model: WP70-T

Thank you for purchasing this product
For optimum performance and safety, please read these instructions
carefully before connecting, operating or adjusting this product. Please
keep this manual for future reference.
Surge protection device recommended
This product contains sensitive electrical components that may be
damaged by electrical spikes, surges, electric shock, lighting strikes,
etc. Use of surge protection systems is highly recommended in order
to protect and extend the life of your equipment.
Table of Contents
1. Introduction...................................................................................
2. Features.........................................................................................
3. Package Contents........................................................................
4. Specifications................................................................................
5. Operation Controls and Functions..............................................
5.1. Front Panel............................................................................
5.2. Rear Panel.............................................................................
6. Application Example....................................................................
2
2
2
3
4
4
4
6
1/61/6

1. Introduction
The HDBaseT Wall-plate Transmitter can transmit up to 4K2K@60 (4:4
:4) video over a single CAT6/6a/7 cable up to 130ft/40m or 1080p up to
230ft/70m. It supports Power over Cable(PoC) functionality that allows
for greater flexibility in installations. It also supports two-way IR and
RS-232.
2. Features
HDMI 2.0b 18Gbps, HDCP 2.2 compliant
up to 4K2K@60Hz(4:4:4), 4K2K@30Hz, 1080p@120Hz
up to 7.1 channels HD audio
HDBaseT™ over a single CAT 6/6a/7 cable up to 230ft/70m distance
One HDMI input, 1 Gang US Decora Wall Plate
Two-way IR and RS-232
POC (Power Over Cable) function is supported, either TX or RX is
powered by 24V1A power supply, the another does not need power
supply from the DC jack. POC Power consumption is less than 10W.
ȤSee the description 1
Transfer Bidirectional Infrared control signal together with the HDMI
signal.
ȤSee the description 2.
Transfer Bidirectional RS-232 control signal together with the HDMI
signal.
ȤSee the description 3.
3. Package Contents
ʒ1× 18G HDMI Wall Plate Transmitter
ʓ2× Phoenix connectors (3 pins)
ʔ2× Phoenix connectors (2 pins)
ʕ1× User Manual
2/6

4. Specifications
Human body model—±8kV (Air-gap discharge) &
±4kV(Contact discharge)
Power Supply
Dimensions
White-Front Panel, Black-Rear CaseColor
103.5mm [W] x 46mm [D] x 30mm [H]
Input: AC100 - 240V 50/60Hz, Output: DC 24V/1A
(US/EU standards, CE/FCC/UL certified)
Operating Temperature
9W (Max)
Storage Temperature
32 - 104°F / 0 - 40°C
Relative Humidity
-4 - 140°F / -20 - 60°C
Power Consumption
20 - 90% RH (no condensation)
ESD Protection
Technical
HDMI Compliance HDMI 2.0b
HDCP Compliance HDCP 1.4 and HDCP 2.2
Video Bandwidth 18 Gbps
Video Resolution up to 4K2K@50/60Hz(YUV4:4:4),4K2K@30Hz,
1080P@120Hz, and 1080P 3D@60Hz
Color Space RGB/YCbCr 4:4:4, YCbCr 4:2:2
Color Depth 10-bit, 12-bit
HDMI Audio Formats
LPCM 2/5.1/7.1CH, Dolby Digital, DTS 5.1, Dolby
Digital+, Dolby TrueHD, DTS-HD Master Audio,
Dolby Atmos, DTS:X
Connections
Mechanical
Plastic-Front Panel, Metal-Rear Case
Optical Audio Formats LPCM 2CH, LPCM 5.1, Dolby Digital 2/5.1CH, DTS
2/5.1CH
Housing
Weight
Transmitter
Inputs: 1x HDMI Type A [19-pin female]
1x IR INPUT [Phoenix jack]
1x RS-232 [Phoenix jack]
Outputs:1x HDBaseT Out [RJ45]
1x IR OUTPUT [Phoenix jack]
1x RS-232 [Phoenix jack]
163g
3/6

5. Operation Controls and Functions
5.1 Front Panel
3
Number Name Function description
1 HDMI IN Connect to HDMI source devices such as Blu-ray or
PS4 player.
2 ACTIVE Green LED input signal indicator.
5.2 Rear Panel
34
1
3
Number Name Function description
HDBaseT OUT
IR IN/OUT
RS-232
4
DC 24V
Use the phoenix jack for connect PC or control
system to transmit RS-232 commands.
Use the phoenix jack for connect power supply.
Use the phoenix jack for connect IR input or output.
HDBaseT output port. Connect HDBaseT receiver
with an UTP cable.
4/6
2
1
1
345 2
2
5
5V OUT Supply 5V power for external IR receiver.

※Description 1
POC (Power over Cable) Application Example
CAT5e/6 /7
CAT5e/6 /7
※Description 2
Bidirectional Infrared control Application Example
TX RX
TV
HDMI C abl e HDMI C abl e
TX 2
Rx1
DVD R emote
UTP Ca ble
※Description 3
Bidirectional RS-232 control Application Example
5/6

6. Application Example
6/6
