InFocus INF4030 User manual

009-1599-03

Contents
Declaraon of Conformity ...................................................................................................................................................................... 3
Safety Consideraons ............................................................................................................................................................................. 4
What’s Included...................................................................................................................................................................................... 7
Setup ...................................................................................................................................................................................................... 8
Mounng ........................................................................................................................................................................................ 8
Aach tray ....................................................................................................................................................................................... 8
Aach stylus .................................................................................................................................................................................... 9
Orienng the monitor in Portrait or Landscape mode .................................................................................................................... 9
Connect to other devices ............................................................................................................................................................... 10
Insert LightCast key (INF4032 only) ............................................................................................................................................... 12
Connect AC power ......................................................................................................................................................................... 12
Turn the Monitor On/O ...................................................................................................................................................................... 12
Use the Keypad..................................................................................................................................................................................... 13
First Time Use ....................................................................................................................................................................................... 14
LightCast Casng .................................................................................................................................................................................. 16
LightCast App ................................................................................................................................................................................. 16
AirPlay ............................................................................................................................................................................................ 17
Miracast ......................................................................................................................................................................................... 18
Whiteboard .......................................................................................................................................................................................... 19
Create a drawing object ................................................................................................................................................................. 19
Import an image ............................................................................................................................................................................ 20
Modify whiteboard canvas objects ................................................................................................................................................ 23
Save the whiteboard canvas .......................................................................................................................................................... 24
Save the whiteboard canvas to a USB thumb drive ....................................................................................................................... 25
Open a new whiteboard canvas .................................................................................................................................................... 25
Open a whiteboard le .................................................................................................................................................................. 26
Open a whiteboard le from a USB thumb drive .......................................................................................................................... 27
Navigaon ...................................................................................................................................................................................... 27
Whiteboard Tools ................................................................................................................................................................................. 28
LightCast Browser ................................................................................................................................................................................. 31
Connect using a WiFi network ....................................................................................................................................................... 33
Change the monitor name ............................................................................................................................................................. 34
Soware version ............................................................................................................................................................................ 35
Update the monitor ....................................................................................................................................................................... 35
Reboot the monitor ....................................................................................................................................................................... 35
Reset the registraon parameters ................................................................................................................................................. 36
Resize the image ............................................................................................................................................................................ 37
Dene the default email address ................................................................................................................................................... 38
Request desktop site ..................................................................................................................................................................... 39
Dene the default browser home page ......................................................................................................................................... 40
Signage Mode ....................................................................................................................................................................................... 41

Acvate Signage mode .................................................................................................................................................................. 41
Exit Signage mode ......................................................................................................................................................................... 41
Update a Monitor without LightCast Key ............................................................................................................................................. 42
OSD (On-Screen Display) Menu System ............................................................................................................................................... 43
Picture menu ................................................................................................................................................................................. 44
Screen menu .................................................................................................................................................................................. 45
Audio menu ................................................................................................................................................................................... 46
PIP menu........................................................................................................................................................................................ 47
Conguraon 1 menu .................................................................................................................................................................... 48
Conguraon 2 menu .................................................................................................................................................................... 49
Advanced Opon menu ................................................................................................................................................................. 50
Troubleshoong ................................................................................................................................................................................... 51
Limited Warranty .................................................................................................................................................................................. 53

Page 3
INF4030/INF4032 DigiEasel User Guide
Declaration of Conformity
Manufacturer: InFocus Corporaon, 13190 SW 68th Parkway, Suite 200, Portland, Oregon 97223-8368 USA
Trademarks
Apple, Mac and Faceme are trademarks or registered trademarks of Apple, Inc. Microso, Windows, PowerPoint, Excel and Word
are trademarks or registered trademarks of Microso Corporaon. Adobe and Acrobat are trademarks or registered trademarks of
Adobe Systems Incorporated. HDMI logo and “High Denion Mulmedia Interface” are registered trademarks of HDMI Licensing
LLC. Manufactured under license from Dolby Laboratories. Dolby and the double-D symbol are trademarks of Dolby Laboratories. SRS
TruSurround HD and SRS TruVolume are trademarks of SRS Labs, Inc. TruSurround HD and TruVolume technologies are incorporated
under license from SRS Labs, Inc. InFocus, In Focus, INFOCUS (stylized), MondoCenter, Mondopad, BigTouch, and JTouch are either
registered trademarks or trademarks of InFocus Corporaon in the United States and other countries. All other trademarks are the
property of their respecve owners. Any other trademarks, service marks, personal names or product names are assumed to be the
property of their respecve owners and are used only for reference. There is no implied sponsorship, aliaon, cercaon, ap-
proval or endorsement if we use one of these terms.
FCC Warning
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC
Rules. These limits are designed to provide reasonable protecon against harmful interference when the equipment is operated in
a commercial environment. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instrucon manual, may cause harmful interference to radio communicaons.
Operaon of the equipment in a residenal area is likely to cause harmful interference in which case the user will be required to cor-
rect the interference at his own expense. Changes or modicaons not expressly approved by InFocus Corporaon may void author-
ity to operate the equipment.
This device complies with part 15 of the FCC Rules. Operaon is subject to the following two condions: (1) This device may not
cause harmful interference and (2) this device must accept any interference received, including interference that may cause unde-
sired operaon.
NOTE:THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR TV INTERFERENCE CAUSED BY UNAUTHORIZED MODIFICA-
TIONS TO THIS EQUIPMENT.SUCH MODIFICATIONS COULD VOID THE USER’S AUTHORITY TO OPERATE THE EQUIPMENT.
FCC Radiaon Exposure Statement
This equipment complies with FCC RF radiaon exposure limits set forth for an uncontrolled environment. This device and its an-
tenna must not be co-located or operang in conjuncon with any other antenna or transmier. To comply with FCC RF exposure
compliance requirements, this grant is applicable to only Mobile Conguraons. The antennas used for this transmier must be
installed to provide a separaon distance of at least 20 cm from all persons and must not be co-located or operang in conjuncon
with any other antenna or transmier.

Page 4
Canada
This Class A digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe A est conforme à la norme NMB-003 du Canada.
This device complies with part 15 of the FCC Rules / RSS-210. Operaon is subject to the following two condions: (1) This device
may not cause harmful interference and (2) this device must accept any interference received, including interference that may cause
undesired operaon.
Cet appareil est conforme à l’arcle 15 des réglementaons de la FCC / CNR-210. Le fonconnement est subordonné aux deux condi-
ons suivantes : (1) ce appareil ne doit pas provoquer d’interférences nuisibles, et (2) ce appareil doit accepter toute interférence
reçue, y compris des interférences qui peuvent provoquer un fonconnemnent non désiré.
이 기기는 업무용으로 전자파적합등록을 한 기기이오니 판매자 또는 사용자는 이 점을 주의하시기 바라며 만약 잘못 판매 또는 구입하였을 때에는 가정용
으로 교환하시기 바랍니다.
申明: 此为A级产品，在生活环境中，该产品可能会造成无线电干扰。在这种情况下，可能需要用户对其干扰采取切实可行的措施。
警告使用者: 這是甲類的通訊產品, 在居住的環境中使用時, 可能會造成射頻干擾, 在這種情況下, 使用者會被要求採取某些適當的對策。
Agency Approvals
See product cercaon label.
This document applies to regulatory model: INF4030
Input rangs: 100-240V 50/60Hz, 1.2A
InFocus reserves the right to alter product oerings and specicaons at any me without noce.
Safety Considerations
Please read and follow all safety instrucons provided below and on the monitor before connecng the monitor to a power source.
Failure to comply with safety instrucons may result in re, electrical shock, or personal injury and may damage or impair protecon
provided by the equipment. Please save all safety instrucons.
• When moving the monitor carton, do not lt or invert the carton. Always keep it in an upright orientaon.
• Disconnect all accessories and cables before moving the monitor.
• Refer to this guide for proper startup and shutdown procedures.
• Follow all warnings and cauons in this manual and on the monitor.
• Locate the monitor at least 4’ (1.2m) away from heang and cooling vents.
• Do not block venlaon openings. Locate the monitor in a well-venlated area without obstrucons to intake or exhaust vents.
• Do not install or use the monitor near any heat sources such as radiators, heat registers, stoves, or other devices (including ampli-
ers) that produce heat.
• Do not place the monitor in direct sunlight, humid, greasy or dusty places or in places where the monitor may come into contact
with rain, smoke or steam.
• The monitor should not be used with the power cord near water, for instance, near a bathtub, washbowl, kitchen sink or swim-
ming pool, etc.

Page 5
INF4030/INF4032 DigiEasel User Guide
• Do not use any components of the monitor, including the speakers, near water. Warning: To reduce the risk of re or electric
shock, do not expose this equipment or any component of this equipment to rain or moisture.
• Do not drop the monitor.
• Do not spill liquid on the monitor. Spilled liquid may damage the monitor.
• The power outlet used to power this monitor should be readliy accessible for fast disconnecon in case of emergency.
• No naked ame source, such as lighted candles, should be placed on the monitor.
• Use the power cord provided. Connect the power cord to a receptacle with a protecve safety (earth) ground terminal. A surge-
protected power strip is recommended. Do not overload wall outlets.
• It is recommended that the monitor be grounded.
• Do not install the monitor in places subject to mechanical vibraon.
• Do not place the monitor on an unstable surface, which could result in serious personal injuries and monitor damage. When
mounng the monitor to a stand, be sure to following the manufacturer’s instrucons. Use only the mounng hardware recom-
mended by the manufacturer.
• When disconnecng the power cord, hold the plug, not the cord.
• Protect the power cord from being walked on or pinched parcularly at plugs, convenience receptacles and the point where they
exit from the monitor.
• Unplug the monitor if you are not going to use it for an extensive period of me.
• Unplug the monitor if you need to clean it with the included microber cleaning cloth. The screen may be wiped with the clean-
ing cloth when the power is o. Never use alcohol, solvents or ammonia-based liquids on this monitor.
• Wash hands aer handling the cables supplied with this monitor.
• Only use properly rated mounng hardware that meets this product’s specicaons and follow the manufacturer installaon
instrucons. The warranty does not cover any damage caused by use of improperly rated mounng hardware or from improper
installaon.
• Refer all service to qualied service personnel. Do not remove the cover or back. Servicing your own monitor can be dangerous
to you and will void the warranty.
• Only use replacement parts specied by InFocus. Unauthorized substuons may result in re, electrical shock or injury and may
void the warranty.
• Follow these instrucons to help ensure image quality over the life of the monitor. Failure to follow these instrucons may aect
the warranty.

Page 6

Page 7
INF4030/INF4032 DigiEasel User Guide
What’s Included
Warranty
Quick Start
Guide
*Not included for all countries. For setup purposes, a keyboard and mouse are recommended. For addional accessory opons, such
as stands, see the InFocus website (www.infocus.com/store) or your local dealer.
VGA cable USB cable
(Type A to B)
Stylus shelf DocumentaonStylusMonitor
Power cord
(varies per country)

Page 8
Setup
Mounting
This product does not ship with mounng accessories, however it can be mounted with any industry standard VESA 200x200 paern.
This could be a stand, wall mount, or cart, etc. the monitor can be used in either portrait and landscape orientaon. Please refer to
InFocus.com for the latest opons.
• Only use properly rated mounng hardware that meet this product’s specicaons and follow the manufacturer installaon
instrucons. The warranty does not cover any damage caused by use of improperly rated mounng hardware or from improper
installaon.
• To prevent damage to the screen surface, carefully place your monitor face-down on a clean, cushioned surface.
• Do not install the monitor in places subject to mechanical vibraon.
• Do not place the monitor on an unstable surface, which could result in serious personal injuries and monitor damage. When
mounng the monitor to a stand, be sure to following the manufacturer’s instrucons. Use only the mounng hardware recom-
mended by the manufacturer.
• Do not install or use the monitor near any heat sources such as radiators, heat registers, stoves, or other devices (including ampli-
ers) that produce heat.
• Do not place the monitor in direct sunlight, humid, greasy or dusty places or in places where the monitor may come into contact
with rain, smoke or steam.
Attach tray
The tray can only be used when the monitor is placed in Portrait mode.
1) Align the tray with the boom edge on the backside of the monitor. Verify the that tray tabs are aligned with the latches on the
back of the monitor.
2) Gently slide the tray up equally on both sides unl an audible click is heard.
3) To release the tray, simply press both latch buons and catch the tray as it falls down.

Page 9
INF4030/INF4032 DigiEasel User Guide
Attach stylus
1) Remove the magnec stylus from the cardboard accessory box.
2) Place the stylus on the back side of the panel in the indentaon on the back side. The stylus can also be placed on the tray if
the tray is installed.
Orienting the monitor in Portrait or Landscape mode
The monitor is automacally senses the posion mode of the embedded computer. Simply follow the mounng guidelines above and
orient the monitor in the desired horizontal or vercal posion.

Page 10
Connect to other devices
A range of digital and analog video inputs and audio source devices can be connected to the connecon panels on the back and side
of the monitor. Available jacks include: HDMI In (4), PC In (1), Composite Video (1), Component RCA (1), RS232 (1), Audio In 3.5mm
(1), Audio In RCA (1-R/L), USB 2.0-A (4), USB B (1) and Audio Out RCA (1-R/L).
A
B
C
A
USB-A
Connect a USB device to one of the USB Type A 2.0 connectors (e.g. USB thumb drive, cam-
era, etc.). Note: These connectors do not have pass through capabiliies. In other words, if
an alternate source, such as a computer, is connected to the monitor, the computer cannot
access the les contained on a USB thumb drive from these connectors.

Page 11
INF4030/INF4032 DigiEasel User Guide
B
POWER ON/OFF Press to turn the monitor on and o.
POWER IN Connect the power cord to this jack.
USB-A Connect a USB device to one of the USB Type A 2.0 connectors (e.g. USB thumb drive).
RJ45 This connector is disabled on this model.
USB-B Connect a USB A to USB B cable from a computer to the monitor in order to acvate touch
capabilies.
VIDEO Connect a composite video cable from the monitor to an external device (such as a VCR or
DVD player).
HDMI 1-4 Connect an HDMI cable from the monitor to an HDMI external device (such as a VCR or
DVD player).
PC IN Connect a VGA computer cable from the monitor to an external computer.
Component Connect a component RCA video cable from the monitor to an external device (such as a
DVD player, HDTV device, or Laser Disc player) (YPbpr) signals.
CRS232 Connect to an RS232 control device for remote control applicaons.
AUDIO IN 1 Connect a 3.5mm audio cable to an external device (e.g., iPod player).
AUDIO IN 2 Connect a RCA L/R audio cable to an external device (e.g., DVD player).
AUDIO OUT Connect an RCA L/R audio cable to external stereo speakers.

Page 12
Insert LightCast key (INF4032 only)
If your monitor did not ship with a LightCast key and you would like to use the LightCast features, you can purchase a LightCast key
(p/n INA-LCKEY1, INA-LCKEY2, or INA-LCKEY3 depending on your region) from InFocus (www.infocusstore.com) or your local dealer.
1) Insert LightCast key into an available USB A port on the side of monitor.
Connect AC power
1) Connect one end of the AC power cord to the POWER IN jack on the back of the monitor.
2) Connect the other end of the AC power cord to an AC outlet.
3) Press the power switch. (The LED on the front of the monitor turns on.)
NOTES:
• Your monitor should only be operated from the power source indicated on the label.
• Always unplug the AC power cord from the power outlet when you are not using your monitor for an extended period of me.
Turn the Monitor On/Off
1) Verify that the power cord is connected to a power outlet. and that the power switch is ON.
2) Press the Power buon on the side of monitor.
3) The soware interface displays. Begin using.
INF4030
(No LightCast key)
INF4032
(With LightCast key)

Page 13
INF4030/INF4032 DigiEasel User Guide
Use the Keypad
The keypad, located on the side of monitor, has the following buons:
Power buon: Switches the power on or puts the monitor into Standby.
OK/Source buon: Toggles the Source menu on and o, allowing the user to switch sources. Saves changes
and selecons when the OSD menu is on. To access the OSD menu (or back out of an OSD submenu), press
the Source buon and Up buon simultaneously.
Up buon: Moves the highlight bar up when the OSD or Source menu is on. To access the OSD menu (or
back out of an OSD submenu), press the Source buon and Up buon simultaneously.
Down buon: Moves the highlight bar down when the OSD or Source menu is on.
Le/Volume decrease buon: Decreases the audio volume when the OSD menu is o. Decreases the value
of the selected OSD item when the OSD menu is on.
Right/Volume increase buon: Incresases the audio volume when the OSD menu is on. Increases the value
of the selected OSD item when the OSD menu is o.

Page 14
First Time Use
Depending on whether you have a LightCast key inserted into your monitor or not, your monitor will either display a LightCast Wel-
come screen, or it will display the whiteboard interface (Go to "Whiteboard" on page 19).
If your monitor did not ship with a LightCast key and you would like to use the LightCast features, you can purchase a LightCast key
(p/n INA-LCKEY1, INA-LCKEY2, or INA-LCKEY3 depending on your region) from InFocus (www.infocusstore.com) or your local dealer.
1) If this is the rst me you have used this monitor, the Welcome screen displays.
2) Using your nger or a mouse, tap the arrow to move to the next screen.

Page 15
INF4030/INF4032 DigiEasel User Guide
3) Enter your registraon informaon and tap the arrow to move to the next screen.
4) Enter the Device Name and WiFi Connecon informaon, and tap the arrow. A conrmaon page displays.
(The LAN informaon populates when a LAN connecon is detected.)
5) Tap the arrow again and the Home page displays.

Page 16
6) Select between the Cast, Whiteboard, and Browser features:
Cast: displays instrucons on how to wirelessly display your computer, tablet, or phone content on the panel using LightCast,
AirPlay, or Miracast.
Whiteboard: provides a whiteboard for capturing meeng notes and annotaon.
Browser: provides access to the internet.
LightCast Casting
If your monitor did not ship with a LightCast key and you would like to use the LightCast features, you can purchase a LightCast key
(p/n INA-LCKEY1, INA-LCKEY2, or INA-LCKEY3 depending on your region) from InFocus (www.infocusstore.com) or your local dealer.
LightCast App
1) Launch the LightCast App on the monitor.
2) Follow the onscreen instrucons.

Page 17
INF4030/INF4032 DigiEasel User Guide
AirPlay
Airplay sends content over either a wired or wireless network. You must have an Apple device with embedded AirPlay in order to use
this AirPlay feature on this monitor. In addion, your network must follow Airplay conguraon guidelines as specied by Apple.
Using iOS on an iPad or iPhone
1) Open the Control Center on your device by swiping up from the boom of your iPad or iPhone screen.
2) Tap the Airplay icon.
3) Select the device name listed in step 3 of the Connect with AirPlay window.
Using an OS X device
1) Select the Airplay icon from the menu bar on OS X device.
2) Select the device name listed in step 2 of the Connect with AirPlay window.

Page 18
Miracast
MiraCast can make an adhoc network connector over Wi, however you must have an Android or Windows device (Windows 8.1 or
above) with embedded MiraCast in order to use the MiraCast feature on this monitor. In addion, your network must follow Miracast
conguraon guidelines as specied by the Wi-Fi Alliance (www.wi-.org).
Using an Android tablet
1) Launch the MiraCast App.
2) Navigate to WiFi Sengs.
3) Search for and select the device name listed in step 3 of the Connect with Miracast window.
4) Mirror your screen.
Using a Windows PC (v8.1 or above)
1) Open the Charms menu on the right side of the Windows PC desktop.
2) Select Devices.
3) Select Project.
4) Select Add a Wireless Device.
5) Select the device name listed in step 5 of the Connect with Miracast window.
