INFODRAW TMRS-102 User manual

TMRS-102
Date: April, 2013
Manual version 5.3
Firmware 4.5.0.0

April 10, 2013 INFODRAW TMRS User Manual v5.3
2
AboutThisManual
Thank you for purchasing the Personal Media Relay System (TMRS) device. This User Manual
has been specifically designed to guide you through the setup configurations, the features
and operational functions of the TMRS Unit.
Read Me First
•Please read this user manual carefully before using your TMRS device to ensure safe
and proper use.
•The descriptions in this manual are based on the default settings of your device.
•Content and images used in this manual may differ from the actual product.
•Software images and screenshots used in this manual may differ in appearance from
the actual software, depending on the software version in use.
•The stability and performance of the TMRS unit’s wireless data streaming may vary
in different countries, due to bandwidth and reception capabilities of the available
carrier wireless networks and service providers in each country.
•Every effort has been made to ensure that the information in this user manual is
accurate. Infodraw is not responsible for printing or spelling errors.
•Please keep this manual for future reference.
•For support please refer to your local distributor with a detailed account of the
problem you have encountered.
Version Author(s) Applies to Firmware
Version
Date
Completed
Release Notes
5.3 Gidon Teff/
Jonathan Kein
4.5.0.0 04/2013 First TMRS manual

April 10, 2013 INFODRAW TMRS User Manual v5.3
3
Safety Precautions
To prevent damage to your TMRS device or injury to yourself and others, please read the
following safety information prior to using your device.
WARNING
To prevent damage, electric shocks, fires and/or explosions:
•Do not use damaged power charger cords or plugs, or loose electrical sockets.
•Do not touch the TMRS device or the power charger cords with wet hands.
•Do not place or use this product near water or wet locations.
•Do not twist, bend, cut or damage the power charger cords.
•Do not drop or cause an impact to the TMRS device or the power chargers.
•Do not place your device on an object where it is likely to fall. If your device falls, it
may get damaged.
•Do not charge the TMRS device with chargers that are not approved by the
manufacturer.
•Do not use the TMRS device if the built-in lithium battery is damaged or leaking.
•Avoid exposing the TMRS device to very hot or very cold temperatures. Extreme
temperatures may cause deformation of the device and reduce the charging capacity
and/or life of your device/ battery.
•Do not use or store your device in dusty or dirty areas.
•Do not allow children to use your TMRS device.
When turning the unit on:
•To turn the TMRS unit on, locate the ON/OFF switch on the side of the unit. Carefully
move the switch to the ON position until it clicks and the LED lights turn on. Repeat
the process to turn it off.
•Before turning the unit ON, please make sure that the GSM Antenna is connected to
its appropriate antenna connector on the unit. If the SIM card is inserted into the
unit and the unit is turned ON without the GSM antenna being connected, this may
cause harm to the internal cellular modem. Therefore it is recommended to keep
the GSM Antenna connected all the time.
•After turning the unit OFF, please wait until the LED’s on the top of the unit shut off
completely before turning the unit back ON.

April 10, 2013 INFODRAW TMRS User Manual v5.3
4
When charging the unit:
•The TMRS unit’s maximum power input is 5V. The chargers supplied by Infodraw
provide the correct (5V) power output to the unit. WHEN CHARGING THE UNIT,
ONLY USE THE CHARGERS PROVIDED BY INFODRAW. DO NOT CHARGE THIS UNIT
WITH ANY HIGHER VOLTAGE THAN 5V. THIS MAY CAUSE IRREVERSIBLE INTERNAL
DAMAGE TO THE UNIT’S HARDWARE COMPONENTS.
•Never use a damaged charger to charge the device.
When configuring the unit:
•The TMRS unit has to be configured prior to operation and later on as well. The
configurations are done using the Device Configurator Application on any PC,
through the USB Cable provided. MAKE SURE THAT ANY SIM CARD IN THE UNIT IS
REMOVED BEFORE CONFIGURING THE UNIT THROUGH THE USB CABLE.
Using the unit’s Dip Switches:
•The TMRS Unit has 4 Dip Switches used for setup and operation, located on the side
of the unit. The functions of each dip switch can be found in the Dip Switch section
of the Unit Hardware Interfaces chapter in this manual. Make sure you understand
the functions of each dip switch, prior to using the unit.
When installing the unit in a vehicle:
•Only use Infodraw Chargers to charge the TMRS Unit. Non-Infodraw chargers are not
covered by the 1 Year Limited Warranty.
•When installing custom 12V Power Outlets directly into vehicle batteries, please
ensure that this is done by a qualified, experienced Auto Electrician.
Disposal and Recycling:
Please ensure this product is recycled in an environmentally friendly way. You must dispose
of the TMRS device properly according to local laws and regulations. As the TMRS device
contains electronic components and a lithium battery, it must be disposed of separately
from household waste. When the TMRS device reaches the end of its life, contact local
authorities to learn about disposal and recycling options.
Copyright
© 2012 Infodraw R&D LTD. All rights Reserved.
Information in this manual is protected by copyright laws and is the property of INFODRAW.
No part of this manual may be reproduced, copied, translated, or published in any form or
by any means without INFODRAW’s prior permission. Information is this manual is subject
to change by INFODRAW without prior notice.

April 10, 2013 INFODRAW TMRS User Manual v5.3
5
