Overhead Radiant Plaque Heaters
INSTALLATION, SERVICING AND OPERATING INSTRUCTIONS
OWNER / INSTALLER: For your safety this manual must be carefully and thoroughly read and understood
before installing, operating or servicing this heater. This heater is intended for use with either Natural Gas or
Propane Gas. It must be installed by a qualified service person or a licensed contractor in accordance with
state and local codes.
700 (PILOT) SERIES
MODELS: 708AN, 716AN, 722AN, 731AN, 731ANHILO
716AP, 731AP, 731APHILO
INSTALLER: This manual is the property of the owner. Please present this manual to the owner when
you leave the job site.
WARNING:Improper installation, adjustment, alteration, service, or maintenance
can cause property damage, injury or death. Read the installation,
operation and maintenance instructions thoroughly before installing or
servicing this equipment.
Before installation, check that the local distribution conditions, nature
of gas and pressure and adjustment of the appliance are compatible.
In locations used for the storage of combustible materials, signs must
be posted to specify the maximum permissible stacking height to
maintain the required clearances from the heater to the combustibles.
Signs must either be posted adjacent to the heater thermostats or in
the absence of such thermostats, in a conspicuous location.
Infraglo Limited
Dannemora Drive
Greenland Road Industrial Park
Sheffield S9 5D UK Tel: [phone]
Email: [e-mail]
Country : GB, I 655
NOT FOR RESIDENTIAL USE.
This heater is not approved in any residential application. This includes (but is not limited
to) the home, living quarters, attached garages, etc. Installation in residential indoor
spaces may result in property damage, asphyxiation, and serious injury or death.

Our Address
Puravent, Adremit Limited, Unit 5a, Commercial Yard,
Settle, North Yorkshire, BD24 9RH
Get In Touch
Call: 0845 6880112
Email: [email protected]
1 Form 44201490
May 2020
TABLE OF CONTENTS
Section Title Starting Page
1. Safety 2
2. Installer Responsibility 2
3. General Information 3
4. Minimum Clearances to Combustion 5
5. Technical Data 7
6. Dimensions –Models 708A, 716A, 722A 10
6.1 Dimensions –Models 731A 10
7. Un-Packing 11
8. Installation 11
8a. Suspension 11
9. Gas Supply 12
10. Electrical Supply 14
11. Ventilation 16
11a. Ventilation by Thermal Evacuation 17
11b. Ventilation by Mechanical Evacuation 17
11c. Ventilation by Natural Air Change 17
11d. Air Supply 17
12. Assembly 18
12a. 708A, 716A, 722A, 731A (Direct Burner Spark Ignition) 18
12b. 731A Hi/Lo (Direct Burner Spark Ignition) 18
12c. 708A, 716A, 722A (Standing Pilot Ignition 19
13 Commissioning 19
(Direct Burner Spark Ignition Models)
13a. Ignition 19
13b. Shut Down 20
13c. Checking Gas Pressure 20
13d. Flame Supervision 21
(Standing Pilot Ignition Models)
13e Ignition 21
13f. Shut Down 22
13g. Checking Gas Pressure 22
13h. Flame Supervision 23
14. Servicing 23
14a. Ignition Electrode 23
14b. Flame Sensor Probe 24
14c. Venturi Fabrication 24
14d. Injector 24
14e. Electrical Wiring 24
14f. Reflector 24
14g. Emitter Assembly (ceramic plaque) 24
14h. Pilot Burner Frame (Standing Pilot Ignition) 25
14i. Pilot Injector (Standing Pilot Injector) 25
14j. Re-assemble and Commission 25
14k. Auxiliary Controls 25
15. Replacing Components 26
15a. Ignition Electrode 26
15b. Flame Sensor 26
15c. Ignition Control (SIT #0.579.019) 26
15d. Injector 27
15e. Venturi Fabrication 27
15f. Twin Solenoid Control Valve (direct burner spark ignition) 27
15g. Millivolt Control Valve (Standing Pilot Ignition) 27
15h. Thermocouple (Standing Pilot Ignition) 28
15i. Thermopile (Standing Pilot Ignition) 27
15j. Pilot Injector (Standing Pilot Ignition) 28
15k. Pilot Burner Frame (Standing Pilot Ignition) 28
15l. Reverberatory Screen 28
15m. Emitter Assembly 28
16a. Operating Instructions (direct burner spark ignition models) 29
16b. Operating Instructions (standing pilot ignition models) 29
17. Replacement Parts Guide (Models 708A, 716A, 722A) 30
17.1 Replacement Parts Guide (Models 731A) 32
