Gorenje D722CM Operating instructions

EN
DETAILED
INSTRUCTIONS
HOW TO USE YOUR
DRYER
www.gorenje.com

We thank you for the
confidence you have shown us by
purchasing this dryer. Your new
dryer complies with the requirements
of modern laundry care; it will
dry your laundry quickly, leaving
it soft and smooth, while use of
special programs will not deform
it. SenzoCare technology will allow
simple operation of the dryer with
very low power consumption.
This appliance is designed exclusively
for household use for clothes which
may be drying in a dryer.

3
TABLE OF CONTENTS
350077
DRYING
STEPS
CLEANING
AND
MAINTANCE
OF THE
APPLIANCE
INTRODUCTION
TROUBLE-
SHOOTING
GETTING
STARTED
OTHER
4 APPLIANCE
5 Technical information
6 Control panel description
8 SAFETY PRECAUTIONS
10 INSTALLATION AND CONNECTION
10 Selecting the room
13 Installation
14 Moist air evacuation
15 Condensate discharge
16 Electrical connections
17 Moving and transport
17 Subsequent transport
18 BEFORE THE FIRST USE
19 DRYING STEPS (1 - 6)
19 1. Step: Check the tags on your laundry
20 2. Step: Preparing the laundry
23 3. Step: Selecting a program
25 4. Step: Additional functions (extra)
27 5. Step: Program start-up
27 6. Step: End of drying cycle
28 CLEANING AND MAINTENANCE
29 Cleaning the filter on the lower side of the door opening
30 Cleaning the net filter in the door
31 Cleaning of water condenser
33 Emptying the condensate tank
34 Cleaning of evacuation duct
34 Cleaning the dryer
35 INTERRUPTING AND CHANGING THE PROGRAM
36 What to do...?
38 TIPS AND RECOMMENDATIONS FOR DRYING AND ECONOMIC USE
OF YOUR DRYER
39 DISPOSAL
40 TYPICAL CONSUMPTION TABLE

4
APPLIANCE
(DRYER DESCRIPTION)
350077
FRONT
1 Program selector dial
2 Control panel
3 Condensate tank
(depending on the model)
4 Door
5 Net filter
6 Filter on the lower side
of the door opening
(depending on the model)
7 Condenser
(depending on the model)
8 Evacuation opening
(depending on the model)
9 Rating plate
BACK
1 Condensate discharge pipe
(depending on the model)
2 Evacuation opening
(depending on the model)
3 Power cord
4 Adjustable feet
1
2
5
6
7
9
4
8
3
2
2
3
4
4
4
4
1
8

5
TECHNICAL INFORMATION
(DEPENDING ON THE MODEL)
TYPE: SP10/XXX
Art.No.: XXXXXX
AC 220-240V 50 Hz
Pmax.: XXXXW
10A
MADE IN SLOVENIA
MODEL: XXXXXX
Ser.No.: XXXXXX
X
kg
IPX4
350077
The rating plate with the basic information on the dryer is located under the door frame.
Width 600mm
Height 850mm
Depth 600mm
Depth with door
open
1100mm
Weight XX/YY kg
(depending on the
model)
Rated voltage See rating plate
Fuse See rating plate
Nominal power See rating plate
Maximum load See rating plate
The rating plate

66
CONTROL PANEL DESCRIPTION
FOR MODELS A) CONDENSATION AND
B) AIR VENTED
START|PAUSE
12h
4h
2h
OFF
30
9060
1
4c
5
2c
2a
3c
3b
3a
4b
4a
START|PAUSE
12h
4h
2h
OFF
30
9060
1
4c
5
2c
2b
2a
3c
3b
3a
4b
4a
350077
1START/ PAUSE key, use this key to start or
stop the program. When
selected, the signal light on
the key will flash. When the
program has started it will
be lit continuously.
2a, b, c: SIGNAL LIGHTS are on: when
it is necessary to clean the
filter, empty the condensate
tank (depending on the
model) or when the child
lock is on.
3LAMPS indicating delayed start of the
operation, or display of
drying, cooling, and end of
drying stages.
B) AIR VENTED
A) CONDENSATION

77
START|PAUSE
12h
4h
2h
OFF
30
9060
1
4c
5
2c
2b
2a
3c
3b
3a
4b
4a
350077
4a, b, c: ADDITIONAL FUNCTION keys, to
extend or adjust the basic
programs.
5ON/OFF and PROGRAM SELECTOR dial
MOST USED PROGRAMS

8
SAFETY PRECAUTIONS
350077
Please don´t use the appliance unless you
have studied and understood the instruction
manual.
Your dryer is intended solely for household
use.
If the dryer is used for professional, for-profit
purpose or purpose exceeding normal use
in a household, or if the dryer is used by a
person who is not a consumer, the warranty
period shall be equal to the shortest warranty
period required by relevant legislation.
Before connecting the dryer to the power
mains, please read carefully the instructions
for use which describe the dryer and its
correct and safe use. The instructions apply
for several appliance types/models; thus,
settings or equipment may be described
herein which is not available in your dryer.
Failure to observe instructions or incorrect
use of the dryer, can lead to damage of
laundry, dryer or the user.
Store the instruction manual nearby the
dryer.
Do not allow the children to play with the
appliance.
Prevent your children and pets to enter the
dryer drum.
Air in the dryer environment should not
contain dust particles.
The air where the dryer is installed, should
be well ventilated to prevent feedback of
gases released from the gas appliances with
open fire (e.g. fireplace).
Clean the filters after each drying cycle. If
you have removed the filters, replace them
before the next drying cycle.
After each cleaning insert the condenser
back into the air duct (depending on
model). Operation of the appliance without
condenser, or with damaged condenser is
extremely dangerous and may cause fire.
Always switch off the dryer after use (the
program selector switch should be in the
"OFF" position) and unplug the power cord
from the wall outlet (to prevent the hazard of
lightning or voltage overload).
Leave any repairs and similar tasks on the
dryer to an expert.
Unprofessional repair may result in an
accident or major malfunction. Call the
authorized service department (see list of
service departments attached).
The warranty does not cover (consumables
(light bulbs), minor deviations in colour,
increased noise which is a consequence of
the appliance age and does not affect the
functionality of the appliance, and aesthetic
defects on components that do not affect
the functionality and safety of the appliance.
The appliance is manufactured in
compliance with all effective safety
standards.
Nevertheless, we recommend it is not used
by persons with impaired physical or mental
abilities and motor skills, or persons with
deficient experience or knowledge, without
due supervision. The same recommendation
applies to the use of appliance by minors.

9
350077
TO REDUCE FIRE HAZARD, PLEASE READ THE
FOLLOWING INSTRUCTIONS:
Do not dry in the dryer any laundry, that has not been
washed earlier.
Use the dryer only to dry laundry that was washed with
water. Do not dry any laundry that was washed of cleaned
with inflammable cleaners or substances (such as gasoline,
trichloroethylene etc.) as this may result in an explosion.
Laundry stained with oil, acetone, alcohol, oil derivatives,
stain removers, turpentine, wax, and wax removers should
be washed in a washing machine with hot water and
detergent before it is dried in the dryer.
Clothing that includes foam rubber, latex, rubber parts,
shower and bathing caps, water proof textiles, and rubber
backed articles and clothes or pillows fitted with foam rubber
pads should not be dired in the tumble dryer
Laundry conditioners or similar products have to be used in
compliance with manufacturer's instructions.
The dryer back wall can be hot danger of
burns.
Never stop the drying cycle before it is
completed; if you do interrupt the cycle
for any reason, be careful when removing
the laundry from the drum as it is very hot.
Quickly remove the laundry from the drum
and spread it to allow it to cool down as
quickly as possible.
Final drying cycle includes cooling; be
careful not to extract excessively hot
laundry from the drum.

10
INSTALLATION AND
CONNECTION
SELECTING THE ROOM
10 cm
10 cm
5 cm
350077
Ventilation slots and the opening on the front and rear side should always be
kept free.
When installing the dryer in a room, note the required clearance as indicated
in the image. In case of failure to heed the required minimum clearance, the
dryer may overheat.
For condensation dryer
Do not install the appliance in a room where there is danger of frost.
The room in which the appliance is installed should be adequately ventilated,
with temperature between 10°C and 25°C. When the dryer is operated at a
lower ambient temperature, condensate can accumulate in the appliance
interior.Frozen water in the condensate tank or pump may damage the dryer.
For vented dryer
Place the appliance in well aerated room with a window or fitted with a fan.
Put the evacuation tube into the appropriate opening. Evacuation duct may
not be placed into the chimney or other type of air duct used for evacuation
of exhaust fumes and smoke of appliances using other combustible
substances. Exhaust air must not be discharged into a flue which is used for
exhausting fumes from appliances burning gas or other fuels

11
POSITIONING THE APPLIANCE
4X
350077
Positioning the appliance on top of the washing machine by using the vacuum feets or
side by side.
Dryer can be stand freely on the floor or on a washing machine of the same dimensions
– minimum width 517 mm, minimum depth 476 mm. The surface on which the dryer is
placed should be clean and level.
Use the vacuum feet attached; they are designed to prevent the dryer from sliding.
(Vacuum feet are attached or can be purchased (depending on model))
Washing machine on which you wish to install the dryer must be able to bear the weight
of the dryer (see washing machine's rating plate or technical information).

12
350077
Do not place the dryer behind lockable or sliding door or door
with a hinge opposite the dryer. Install the dryer in such way
that the door can always be freely opened.
Air ventilation duct must be kept unobstructed (see
"Description of the appliance").
Drying machine on top should be placed by at least two
persons.
Do not place the dryer on a carpet with long fibres as this may
impede air circulation.
The appliance may not be in contact with a wall or adjacent
furniture.

13
INSTALLATION
350077
Level the dryer in
longitudinal and
traverse direction
by rotating the
adjustable feet
which allow levelling
by +/- 1 cm. Use
key nr. 22 and spirit
level.
Floor on which the machine is placed must have a concrete
base. They must be clean and dry; otherwise, the machine may
slide. Also clean the adjustable feet.
The appliance must stand level and stable on a solid base.
Vibrations, moving of the appliance across the room, or loud
operation due to improperly adjusted feet are not covered by
the warranty.
Sometimes, unusual or loud noise may appear during
appliance operation; these are mostly the result of improper
installation.

14
MOIST AIR EVACUATION
(For vented dryer)
Distance between the drying machine and the evacuation
opening (vent duct, window) may not be more than 2 m,
otherwise you may expect concentration of moisture within
the exhaust tube.
The appliance is fitted with two openings for moist air evacuation
(option a/b), of which one must be covered with the lid, and other
used to fix the exhaust tube.
a b
max 2 m
max 2 m
350077
Lint must not be allowed to accumulate around the tumble dryer

15
CONDENSATE DISCHARGE
(For condensation dryer)
max 80 cm
350077
The moisture from the laundry is extracted in the condenser unit
and accumulated in the condensate tank.
During the drying process, a control light will warm you of a full
condensate tank which has to be emptied.
Interruption of the drying cycle due to full condensate tank can be
avoided by running the condensate discharge tube found at the
back of the appliance directly into a drain.
If the condensate discharge tube is run into a drain, make sure
the tube is firmly secured. This will prevent any water spillage
which could result in unexpected damage.
In this case, the steam generator tank will not be filled
automatically. It will always require manual filling (see section
Filling and replenishing the steam generator tank).
1Pull the tube to remove it with
flat screw-driver,
from the holder on
the appliance back
wall.(on the left
hand side under the
cover).
2Install tube into the drain, at
a height of 80 cm
from the ground.

16
ELECTRICAL CONNECTIONS
2h
350077
The dryer should be left to stand still for at least two hours
before it is connected to the power mains to allow the system to
stabilize.
Use the power cord to connect the dryer to the power mains
through a power outlet. The dryer may not be connected to the
power mains through an extension cable (danger of overheating
and fire). Nominal voltage and other information is given on the
rating plate located under the door frame.
To prevent from damage by excess voltage on the mains due
to lightning strike we recommend to use a class I over-voltage
protector between the machine and the mains.
After installation, the wall outlet should be freely accessible.
The outlet should be fitted with an earth contact (in
compliance with the relevant regulations).
A damaged power cord may only be replaced by a person
authorized by the manufacturer.

17
SUBSEQUENT TRANSPORT
MOVING AND TRANSPORT
350077
After each drying certain amount of condensed water is retained
in the appliance. Switch on the appliance and choose one of the
programs, then let the appliance operate for approximately half
a minute. This will pump out the remaining water and prevent
damage to the dryer during transport.
After transport, the dryer should be left to stand still for at
least two hours before it is connected to the power mains to
allow the system to stabilize. We recommend that installation
and connection should be done by a qualified person.
If the appliance was not transported in compliance with the
instructions, the dryer should be left to stand still at least two
hours before it is reconnected to the power mains.
Before connecting the appliance, read the instructions for
use. Repair or any warranty claim resulting from incorrect
connection or use of the appliance shall not be covered by the
warranty.
The belt can be replaced by a servising engineer only, who
incorporates an original spare part with the marking OPTIBELT
EPH 1906, code 104265, OPTIBELT 8 EPH 1941, code 160165
(depending on model).

18
BEFORE THE FIRST USE
1 2
350077
Clean the dryer
drum before using
the dryer for the first
time. Use a damp
cloth and a mild
cleaning agent.
Open the disconnected dryer by pressing the door on the left side.

19
DRYING STEPS (1 - 6)
350077
1. STEP: CHECK THE TAGS ON YOUR LAUNDRY
Normal wash
Delicate wash
Max.
washing
95°C
95
95
Max.
washing
60°C
60
60
Max.
washing
40°C
40
40
Max.
washing
30°C
30
30
Manual
washing
Washing
not
allowed
Whitening Whitening in cold water
c1
Whitening not allowed
Dry cleaning Dry cleaning in
all solvents
A
Perchloret-
yhlene R11, R113,
Petrolej
P
Dry cleaning in
kerosene, in pure
alcohol and in
R 113
F
Dry cleaning
not allowed
Ironing Hot iron max.
200°C
Hot iron max.
150°C
Hot iron max.
110°C
Ironing not
allowed
Drying Place on flat
surface
Hang wet
Hang
High temp.
Low temp.
Tumble drying
not allowed

20
2. STEP: PREPARING THE LAUNDRY
350077
1. Sort the laundry by type and thickness of the fabric (see Program Table).
2. Close the buttons and zips, tie any ribbons, and turn the pockets inside out.
3. Place very sensitive clothes in a special-purpose laundry washing bag.
The following types of laundry may not be dried in the dryer
as this may cause your garments to deform:
•leather garments and other leather products;
•garments that are waxed or treated in any other way;
•garments with major wooden, plastic, or metal parts;
•garments with spangles;
•garments with metal parts subject to rusting.
The final part of a tumble dryer cycle occurs without heat
(cool down cycle) to ensure that the items are left at a
temperature that ensures that the items will not be damaged.
Remove all objects from pockets such as lighters and matches.
Oil-affected items can ignite spontaneously, especially when
exposed to heat sources such as in a tumble dryer. The
items become warm, causing an oxidation reaction in the oil.
Oxidation creates heat. If the heat cannot escape, the items
can become hot enough to catch fire. Piling, stacking or
storing oil-affected items can prevent heat from escaping and
so create a fire hazard.
If it is unavoidable that fabrics that contain vegetable or
cooking oil or have been contaminated by hair care products
be placed in a tumble dryer they should first be washed in hot
water with extra detergent - this will reduce, but not eliminate,
the hazard
