Ingram Products RB1215D User manual

Hole Pattern for Mounting
Ø 1/4"
Ø 7/8"
1/2" Knock
Out or
2 1/8"
1 1/2" 1 1/2"
3/8"
6 1/4"
4 3/4"
Gasket
Website:www.ingramproducts.com e-mail: [email protected]888-875-2221 ph [phone] fax8725 Youngerman Court Ste. 206 Jacksonville, FL 32257
DC Rotating Beacon
Technical Specifications
Voltage: 12VDC
Current Draw: 1.26A max
Bulb: 15 Watts Max
NEMA Type 3, 3R, 12,and 13
Variable speed motor for rotation
Gasketed
Stainless steel ring
Globe molded from shatter
resistant polycarbonate
Available in 3 colors (red,
amber, and green)
Features
The Ingram RB1215 is a NEMA
Type 3, 3R, 12 and 13 low cost
rotating beacon suitable for heavy
duty applications inside and
outdoors. Applications include, but
are not limited to, use on vehicles,
machines, and control panels. This
rotating beacon is particularly useful
in areas with high ambient noise
levels where an audible signal may
not be heard.
Part No.: RB1215D

RB1215D Assembly
Wire Leads
10-32 Studs
Gasket
Enclosure Wall
10-32 Washer
10-32 Hex Nut

Template for Mounting RB1215
1 15/32" 1 15/32"
3/8"
1 15/32"
2 1/8"
Ø 1/4"
Ø 7/8"
Description: Template for RB1215
Drawing No. RBT001 Rev. No. 0
Date: 02/08/05 Drawn by: ADI
Sheet: 1 of 1Part No. NA
P R O D U C T S I N C .
INGRAM
Drawn Full Size

RB1215D
Thank you for purchasingGGproduct.
Please read this manual carefully before installing this system
for safe and long use of the product.
▪ Ensuring high revolving durability by applying a small bearing to
the revolving axis.
▪ High effency in diffusioning light by employing
vacuum-metalized reflector.
▪ Volume(Buzzer Built-in Type) : 90dB(1m)
▪ RPM : 120-140/Min.(Controllable)
▪ Material : Lens-PC, Body-PC, Reflector-PC
▪ Protection Class : IP23
▪ Certification : UL Class 2
Model Rated
Voltage Current Bulb Weight Color
RB1215D
DC12V 1.170A 12V15W G23 15S 17 0.41Kg
Red-R
Amber-A
Green-G
Blue-B
▪ Power line UL1015-NO.16 (1.25sq) x 2C 400mm comes out from
the product.
▪ Black line is negative(-) *This product is for DC12V only.
Indoor Outdoor
▪ This product was manufactured with the structure for indoor use.
Installing in any direction is okay for indoor use.
▪ Outdoor use is limited at a place where no water or very little
water percolates. Mounting also should be done only with
vertical standing shape.
▪ Mount at the place where exists low vibration, low impact, low
moisture and low dust as long as possible.
▪ Refer to below information and drill necessary mounting holes on
profitable part of the product.
(Make sure PCD from external view drawing.)
▪ Fix the product by using nuts(M5-3EA) originally equipped on
mounting bolt on bottom of the product.
1) Lens Removal
Separate Lens② and joining ring③ by loosening bolts and
nuts(M5-3EA)① and make sure revolving spped control volume
and bulb on assembling board.
2) Revolving Speed Control
▪ The volume(1) for revolving speed control is built-in this
product. Turn it closckwise for increasing revolving speed and
turn it counterclockwise for decreasing revolving speed.
▪ Treating with strong power can break the volume.
Please be careful.
OPERATING MANUAL
Bulb Revolving Warning Light

3) Bulb Change
※ Warning ! Turn off Power
Must turn off power supply and change the bulb after at least
1 minute.
▪ Make sure the rated voltage and wattage of new bulb. If the
voltage of new bulb is higher than that of original bulb, the
self-life of product can be reduced and can cause damage on
lens and reflector. Therefore, please use same bulb as original
one which has same rated voltage and wattage or lower one.
▪ Bulb Removal : Press slightly the bulb downward and turn it
counterclockwise for removing.
▪ Bulb Fitting : Fit new bulb into the socket by pressing it
clockwise.
Bulb Removing Bulb Fitting
4) Lens Assembling
Assemble the lens in reverse order of separating.
▪ If using voltage is seriously higher or lower than rated voltage, it
can reduce the self-life of the product or can cause a problem
on product operating. Make sure the using voltage does not
exceed +/- 5% of the rated voltage.
▪ If lens or body of the product is contaminated by chemicals such
as thinner, benzene, the product can be damaged, discolored
or deformed. Please be careful.
▪ Do not give strong impact to the product. It can be a reason of
wire disconnection or short circuit.
▪ Do not strongly pull the wire out from the product. It can cause a
disorder.
Situation Main Cause Solution
Non-Lighting Wire Disconnection
with Bulb
Wire Re-connection or
Bulb Change
Feeble Lighting
Low Revolving Speed
Supplying Voltage
Lower than Rated
Voltage
Making Sure Using
Voltage
Short Self-Life of Bulb
Supplying Voltage
Higher than Rated
Voltage
Making Sure Using
Voltage
Lens Deformation Caused by
Bulb Overheating (AC Type)
The Voltage of Bulb is
Higher than Rated
Voltage
Changing Bulb with Rated
Voltage
Non Revolving Problem with Motor Contact Q.Light or Their
Agent
Wrong Wiring Making Sure Wiring
Neither Lighting Nor
Revolving No Power Supply Making Sure Power
Supply
