innovair ICS0848C21 User manual

Four-way Inverter CassetteType
OWNER'SMANUAL
Thankyou verymuchforpurchasing our airconditioner,
Before using yourairconditioner,pleasereadthis manualcarefullyandkeepitfor future reference.
ICS0629C21
ICS0736C21
ICS0848C21

INDOORUNIT
OUTDOORUNIT
1
2
3
4
5
6
7
8
9
10
11
12
Air flowlouver(atairoutlet) Air-ingrill
Drainpump(drainwaterfromindoorunit) Display panel
Drainpipe Remotecontroller
Air outlet Refrigerantpipe
Air filter(inside air-ingrill) Air inlet
Air inletAir inlet Air outlet
3
9
10
10
11
11
11
11
11
11
12
12
12
All the picturesinthis manualare for explanation purposeonly.Theymaybe slightlydifferentfromthe air
conditioner you purchased(depend on model).The actualshapeshallprevail.
NOTE
OR
10
11
1
5 7 8
2
4
6
Fig.1

1
owner s manual
1.IMPORTANTSAFETY INFORMATION
Topreventinjurytotheuserorotherpeopleand property
damage,thefollowinginstructionsmustbefollowed.Incorrect
operation duetoignoringofinstructionsmay cause harmor
damage.
WARNING
Ask yourdealerfor installationoftheairconditioner.
Incompleteinstallation performed byyourselfmayresultina
water leakage,electricshock, and fire.
Askyourdealerforimprovement,repair,and
maintenance.
Incompleteimprovement, repair,and maintenancemayresult
inawater leakage,electricshock, and fire.
Inordertoavoidelectricshock,fireor injury,orifyou
detect anyabnormalitysuchas smelloffire,turn off the
powersupplyand callyourdealerfor instructions.
Neverlettheindoor unitor theremote controllergetwet.
Itmaycauseanelectricshock orafire.
Neverpress thebuttonoftheremote controllerwitha
hard, pointedobject.
The remotecontrollermaybe damaged.
Neverreplace afusewiththat ofwrong ratedcurrentor
otherwires whenafuse blowsout.
Useofwireor copper wire maycausethe unittobreakdown
or causeafire.
Itisnotgoodforyourhealthtoexpose yourbodytothe
airflowfor along time.
Donotinsertfingers,rodsorotherobjects intotheair
inlet oroutlet.
When the fanisrotating athigh speed,itwillcauseinjury.
Neveruse aflammablespray suchas hairspray,lacquer
or paintneartheunit.
Itmaycauseafire.
Nevertouchtheairoutlet or thehorizontalblades while
theswingflapisinoperation.
Fingersmaybecomecaughtor the unitmaybreak down.
Neverputanyobjects intotheairinletor outlet.
Objectstouchingthe fan athigh speed can bedangerous.
Neverinspect orservice theunitbyyourself.
Askaqualifiedservicepersontoperformthiswork.
Donotdisposethisproductasunsortedmunicipal
waste.Collection ofsuchwaste separatelyfor special
treatmentisnecessary.
Donotdisposeofelectricalappliances asunsorted
municipalwaste,use separatecollectionfacilities.
Contactyou localgovernmentfor information regarding the
connection systemsavailable.
Ifelectricalappliancesaredisposedofinlandfillsor
dumps,hazardoussubstancescanleakintothe
groundeaterandget intothefoodchain,damagingyour
healthandwell-being.
Topreventrefrigerantleak,contact yourdealer.
When the systemisinstalled and runsinasmall room,itis
requiredtokeep the concentration ofthe refrigerant,ifbyany
chancecoming out,below the limit.Otherwise,oxygen inthe
roommaybe affected,resultinginaseriousaccident.
Therefrigerantintheairconditionerissafeandnormally
doesnotleak.
Ifthe refrigerantleaks inthe room,contact withafire ofa
burner,aheateroracookermayresultinaharmfulgas.
Turn offanycombustibleheatingdevices,ventilate the
room,and contactthedealerwhereyou purchasedthe
unit.
Do notusethe airconditioner untilaserviceperson confirms
thatthe portion where the refrigerantleaksisrepaired.
Donotuse theairconditionerfor otherpurposes.
Inorder toavoidanyqualitydeterioration,donotusethe unit
for cooling precision instruments,food,plants,animalsor
worksofart.
Beforecleaning,besuretostop theoperation,turn the
breakeroffor pulloutthesupplycord.
Otherwise,an electricshockand injurymayresult.
Inordertoavoidelectricshock or fire,makesurethat an
earthleak detector isinstalled.
Be suretheairconditionerisgrounded.
Inordertoavoidelectricshock,makesure thatthe unitis
grounded and thatthe earthwire isnotconnected togasor
water pipe,lightning conductor or telephone earthwire.
Inordertoavoidinjury,donotremove thefanguard of
theoutdoorunit.
WARNING
The safetyprecautionslistedare divided intotwocategories.Ineither
case,importantsafetyinformationislisted whichmust be read
carefully.
CAUTION
Failuretoobserveacaution mayresultininjuryordamage
to the equipment.
Failure toobserveawarning mayresultindeath.The
applianceshall be installed inaccordancewithnational
wiring regulations.
CONTENTS PAGE
IMPORTANTSAFETY INFORMATION..................... ...................................... 1
PARTSNAMES.........................................................................................2
AIRCONDITIONEROPENRATIONS ANDPERFORMANCE...........................3
HINTSFORECONOMICAL OPERATION......................................................3
ADJUSTING AIRFLOWDIRECTION...........................................................3
MAINTENANCE........................................................................................4
FOLLOWINGSYMPTOMSARE NOTAIRCONDITIONERTROUBLES...........5
TROUBLESHOOTING................................................................................5
CAUTION

2
owner s manual
Donotoperate theairconditionerwithawethand.
Anelectricshock mayhappen.
Donottouchtheheat exchangerfins.
Thesefinsare sharpand couldresultincutting injuries.
Donotplace itemswhichmightbedamagedbymoisture
undertheindoor unit.
Condensation mayformifthe humidity isabove80%,the drain
outletisblocked or the filterispolluted.
Afteralonguse,check theunitstandandfittingfordamage.
Ifdamaged,the unitmayfalland resultininjury.
Toavoidoxygendeficiency,ventilatetheroomsufficientlyif
equipmentwithburnerisusedtogetherwiththeair
conditioner.
Arrangethedrainhose toensuresmoothdrainage.
Incompletedrainage maycausewetting ofthebuilding,furniture
etc.
Nevertouchtheinternalpartsofthecontroller.
Do notremovethe frontpanel.Somepartsinside are dangerous
totouch,and amachinetroublemayhappen.
Neverexposelittlechildren,plants or animalsdirectlyto
theairflow.
Adverseinfluencetolittlechildren,animals andplantsmayresult.
Donotallow achildtomountontheoutdoor unitoravoid
placinganyobjecton it.
Falling or tumbling mayresultininjury.
Donotoperatetheairconditionerwhenusingaroom
fumigation -typeinsecticide.
Failuretoobservecouldcausethechemicalstobecome
deposited inthe unit,whichcouldendanger the healthofthose
who are hypersensitivetochemicals.
Donotplace appliances whichproduce openfireinplaces
exposedtotheairflowfromtheunitorundertheindoor unit.
Itmaycauseincompletecombustion or deformation ofthe unit
due totheheat.
Donotinstalltheairconditionerat anyplacewhere
flammablegas may leak out.
Ifthe gasleaksoutandstaysaround the airconditioner,afire
may breakout.
Thisappliance canbeusedbychildrenagedfrom8years
and above andpersonswithreducedphysical,sensoryor
mentalcapabilities or lack ofexperienceandknowledgeif
they have beengivensupervisionor instructionconcerning
useoftheapplianceinasafewayandunderstandthe
hazardsinvolved.Childrenshallnotplay withtheappliance.
Cleaning andusermaintenance shallnotbemadeby
childrenwithoutsupervision.
Thisappliance isnotintendedfor use bypersons(including
children)withreducedphysical, sensoryormental
capabilities,orlack ofexperienceandknowledge,unless
they have beengivensupervisionor instructionconcerning
useoftheappliancebyaperson responsiblefortheir
safety.
Childrenshouldbesupervisedtoensurethat they do not
play withtheappliance.
Ifthesupplycordisdamaged,itmust bereplacedbythe
manufacturer,its service agentorsimilarlyqualifiedpersons
inordertoavoidahazard.
Donotoperate your airconditionerinawet roomsuchas a
bathroomor laundryroom.
Displaypanel Fig.2-2
PRE-DEFindicator(cooling andheatingtype)
orfanonlyindicator(coolingonly type)
Infrared signal receiver
Operationlamp Timerindicator Alarm indicator
Temporarybutton
ThismanualdoesnotincludeRemoteController
Operations,seethe<<RemoteControllerOwner's
manual>> packed withthe unitfordetails.
NOTE
2.PARTSNAMES
Theairconditionerconsists oftheindoorunit,theoutdoor unit,
theconnectingpipeand theremote controller. (See Fig.2)
Functionindicatorsonindoorunitdisplay panel
FORCEDAUTO
The OPERATIONlampislit,and the airconditioner willrun
underFORCEDAUTOmode.The remotecontroller operationis
enabled tooperateaccordingtothe received signal.
1
FORCED COOL
The OPERATIONlampflashes,the airconditioner willturn to
FORCEDAUTOafteritisenforced tocoolwithawind speedof
HIGHfor30minutes.Theremotecontrolleroperationis
disabled.
OFF
The OPERATIONlampgoesoff.The airconditionerisOFF
whilethe remotecontroller operation isenabled.
2
3
Forinvertertype,thisswitchisusedforafter-salesservice
purposeonly,the user shouldnotpushit.
For fixed-frequency type,thisfunctionisusedtooperatethe unit
temporarilyincaseyou misplacetheremotecontrollerorits
batteriesare exhausted.Two modesincluding FORCED
AUTOandFORCEDCOOLcanbeselected throughthe
TEMPORARYBUTTONon the air-ingrillcontrolboxofthe
indoor unit.Onceyou pushthisbutton,theairconditionerwill
runinsuchorder: FORCED AUTO,FORCEDCOOL,OFF,
and back to FORCED AUTO.
Displaypanel Fig.2-1
PRE-DEFindicator(cooling andheatingtype)
orfanonlyindicator(coolingonly type)
Infrared signal receiver
Operationlamp Timerindicator Alarm indicator
Temporarybutton

3
owner s manual
3.AIR CONDITIONEROPENRATIONSAND
PERFORMANCE
Use the systeminthefollowing temperatureforsafeand
effectiveoperation.TheMax operationtemperaturefor
theairconditioner(Cooling/Heating).
1 Ifairconditioner isused outside the aboveconditions, it
may causetheunittofunction abnormally.
NOTE
Table3-1
Table3-2(for inverter typeairconditioner)
Coolingoperation
Drying operation
Heatingoperation
(cooling onlytype without)
Mode
Temperature Outdoor
temperature
(formodelswithlow
temperaturecooling system)
(forspecial tropicalmodels)
(forspecial tropicalmodels)
temperature
18°C~43°C/ 64 °F~109°F
18°C~52°C/ 64 °F~126°F
-7°C~43°C/ 20 °F~109°F
-7°C~24°C/ 20 °F ~76°F
18°C~43°C/ 64 °F~109°F
18°C~52°C/ 64 °F~126°F
0°C~30°C/32 °F~86°F
17°C~32°C
(62 °F~90°F)
17°C~32°C
(62 °F~90°F)
0°C~30°C/32 °F~86°F
17°C~32°C
(62 °F~90°F)
17°C~32°C
(62 °F~90°F)
Coolingoperation
Drying operation
Heatingoperation
(cooling onlytype without)
Mode
Temperature Outdoor
temperature
(formodelswithlow
temperaturecooling system)
temperature
0°C~50°C/32 °F~122°F
0°C~50°C/32 °F~122°F
-15°C~50°C/ 5 °F~122°F
-15°C~24°C/ 5 °F~76°F
Thephenomenon isnormalthatthesurfaceofair
conditioningmaycondensewater whenthe relative
largerhumidity inroom,pleaseclosethedoorand
window.
Optimumperformancewillbeachievedwithinthese
operating temperature range.
2
3
4.HINTSFORECONOMICALOPERATION
Thefollowingshouldbenoticedtoensureaneconomical
operation.
Adjustthe airflow louver properlyand avoiddirectairflow to
roominhabitants.
Adjust theroomtemperatureproperlyforacomfortable
environment.Avoidexcessiveheating or cooling.
Preventdirectsunlightduringcoolingoperationbyusing
curtainsor blinds.
Ventilateoften.Extendeduserequiresspecialattentionto
ventilation.
Keep doorsand windowsclosed.Ifthe doorsand windows
remainopen,airwill flow outofyour roomcausingadecrease
inthe cooling orheating effect.
Never placeobjects nearthe airinletor the airoutlet of the unit.
Itmaycausedeterioration inthe effector stop theoperation.
Setthe timer .
Ifyou don'tplan tousethe unitfor along time,pleasetakethe
batteriesfromthe remotecontroller.When the power ison,
someenergy willbe consumed,even ifthe airconditioner isn't in
operation.Sopleasedisconnectthe power tosaveenergy.
Keep the indoorunitand remotecontrolleratleast1maway
fromtelevisions,radios, stereos,and other similar equipment.
Failing todo somaycausestaticor distorted pictures.
Adirtyairfilter willreducecooling or heating efficiency,please
clean itoncetwoweeks.
5.ADJUSTINGAIRFLOWDIRECTION
Whiletheunitisinoperation,you canadjust theairflowlouver
tochangetheflowdirectionandnaturalizetheroom
temperatureevenly.Thusyou canenjoyitmorecomfortably.
Settheairflowdirection.
Press the SWINGbutton toadjustthe louver tothe desired
position and press thisbutton againtomaintainthe louverat
thisposition.
Adjust theairflow direction automatically.
Press theSWINGbutton,thelouverwill swing automatically.
Whilethisfunction isset,theswing fan ofindoor unitruns;
otherwise,the swingfan doesn'trun.The swingscaleofevery
side is30°.When the airconditioner isn'tinoperation (including
when TIMERONisset),the SWINGbutton will be invalid.
Adjust it upanddown Fig5-1
Three-minuteprotection feature
Aprotection feature preventsthe airconditioner frombeing
activated for approximately3minutes
when itrestartsimmediatelyafter operation.
Powerfailure
Power failure during operation will stop the unitcompletely.
Disconnectthe unitwiththe power and then connectthe unit
withthe power again.Pushthe ON/OFFbutton on the remote
controller torestartoperation.
The OPERATIONlampon the indoor unitwill start
flashing when power isrestored.
Torestartoperation,pushthe ON/OFF button on the
remotecontroller.
Lightning oracar wirelesstelephone operatingnearby
maycausethe unittomalfunction.

4
owner s manual
6.MAINTENANCE
CAUTION
Beforeyoucleantheairconditioner,besurethepower
supplyisoff.
Check ifthewiring isnotbrokenoff or disconnected.
Useadryclothtowipetheindoorunitandremote
controller.
Awetclothmay beusedtocleantheindoor unitifitis
verydirty.
Neveruse adampclothontheremotecontroller.
Donotuse achemically-treteddusterfor wipingor leave
suchmaterialon theunitforlong.
itmaydamage or fade thesurfaceofthe unit.
Donotuse benzine,thinner,polishing powder,orsimilar
solvents for cleaning.
Thesemaycausethe plastic surfacetocrack ordeform.
Cleaning theairfilter
The airfilter canpreventthe dustor other particulatefrom
going inside. Incaseofblockage ofthefilter,theworking
efficiencyofthe airconditioner maygreatlydecrease.
Therefore,the filter must becleaned oncetwo weeksduring
long timeusage.
Iftheairconditionerisinstalled inadustplace,clean the air
filter frequent.
Ifthe accumulated dust istoo heavytobe cleaned,please
replacethe filter withanewone(replaceableairfilter isan
optionalfitting).
Opentheair-ingrill
Pushthe grillswitchestowardsthe middlesimultaneouslyas
indicated in Fig.6-1.Then pull down the air-ingrill.
The controlboxcables,whichare originallyconnected with
the mainbodyelectricalterminatorsmust bepulled off before
doing asindicated above.
1
2
3
4
Takeouttheair-ingrill (togetherwith theairfiltershown in
Fig.6-1 ).
Pulltheair-ingrilldownat45andlift itup totakeout the
grill.
Dismantle theairfilter.
Cleanthe airfilter
Vacuumcleaner orpure watermaybe usedtocleantheair
filter.If thedust accumulationistooheavy , pleaseusesoft
brushand milddetergenttocleanit anddry outincoolplace.
The air-inside shouldfaceup when using vacuumcleaner.
(SeeFig.6-3)
The air-inside shouldfacedownwhen using water.
(SeeFig.6-4)
Re-installtheairfilter.
Install andclose theair-ingrillinthereverse orderofstep1
and2andconnect thecontrolboxcablestothe
corresponding terminatorsofthemainbody.
5
6
Fig.6-1
Fig.6-2
Fig.6-3
Fig.6-4
Donotdryouttheairfilterunderdirect sunshineorwith
fire.
CAUTION
Maintenance afteralong stop period
(eg.at the beginning of the season)
Maintenance beforealong stop period
(eg.at the end ofthe season)
Checkand removeeverything thatmightbe blocking inlet
and outletventsofindoorunitsand outdoor units.
Clean airfiltersand casings ofindoor units.
Refer to"Cleaning the airfilter" for detailson how toproceed
and makesure toinstall cleaned airfiltersbackinthesame
position.
Turnonthe power atleast 12 hoursbeforeoperatingthe unit
inorder toensure smoother operation.Assoon ashepower
isturned on,the remotecontroller displaysappear.
Letthe indoor unitsrun infanonlyoperationfor abouthalfa
dayinorder todrytheinterior ofthe units.
Cleanairfiltersand casingsofindoorunits. Referto"
Cleaning the airfilter"for detailson how toproceed and
makesuretoinstall cleanedairfiltersbackinthe same
position.

5
owner s manual
Symptom 4: Noiseof airconditionerscooling
Symptom4.1: Indoor unit
When humidityishigh during cooling operationIfthe interior of
anindoorunitisextremelycontaminated,thetemperature
distribution inside aroombecomesuneven.Itisnecessaryto
clean theinterior ofthe indoor unit.Askyour dealer for details
on cleaning the unit.Thisoperation requiresaqualifiedservice
person.
When thesystemischanged overtoheatingoperation after
defrost operationMoisturegeneratedbydefrostbecomes
steamand is exhausted.
Acontinuouslow "shah"sound isheard when the systemisin
cooling operation oratastop.
When the drainpump(optionalaccessories)isinoperation,this
noiseisheard.
A"pishi-pishi"squeaking soundisheardwhen the systemstops
after heatingoperation.
Expansion and contractionofplasticpartscausedby
temperature change makethisnoise.
Symptom4.2: Indoor unit,outdoor unit
Acontinuouslow hissing sound isheard when the systemisin
operation.
Thisisthe sound ofrefrigerantgasflowing through bothindoor
and outdoor units.
Acontinuouslow hissing sound isheard when the systemisin
operation.
Thisisthe sound ofrefrigerantgasflowing through bothindoor
and outdoor units.
Ahissing sound whichisheard atthe startorimmediatelyafter
stopping operationor defrostoperation.
Thisisthe noiseofrefrigerantcaused byflow stop or flow
change.
Symptom4.3: Outdoor unit
When the toneofoperating noisechanges.
This noiseiscaused by the change offrequency.
The operation lampisflashing rapidly(5Hz).
Thislampisstillflashing rapidlyafter turn off the powerand turn
on again.(See inTable8-1and Table8-2)
Remotecontrollerreceivesmalfunction orthe button doesnot
workwell.
Asafetydevicesuchasafuse,abreaker frequentlyactuates.
Obstaclesand waterenter the unit.
Water leaks fromindoor unit.
Othermalfunctions.
8.TROUBLESHOOTING
Ifoneofthefollowingmalfunctionsoccur,stopoperation,shut
off thepower,andcontact withyour dealer.
Ifthesystemdoesnotproperlyoperateexcepttheabove
mentionedcasesor theabovementionedmalfunctionsis
evident,investigate thesystemaccording tothefollowing
procedures. (See inTable8-3)
8.1Troubles and causes ofairconditioner
Symptom 5: Dust comesoutof the unit
Symptom 6: Theunitscangiveoff odours
When the unitisused for thefirsttimeinalongtime.
This isbecausedusthasgottenintothe unit.
The unitcan absorb the smell ofrooms, furniture,cigarettes,
etc.,and then emititagain.
Symptom 7: Theoutdoorunit fandoesnot spin.
During operation.The speed ofthe fan iscontrolledinorder to
optimizeproductoperation.
8.2Troubles and causes ofremotecontroller
Beforeasking forserving or repairing,check thefollowing points.
(See inTable8-4)
7.FOLLOWINGSYMPTOMSARENOT AIR
CONDITIONERTROUBLES
Symptom 1: Thesystem does not operate
Symptom 2: Changeintothe fanmode during cooling
mode
Symptom 3: Whitemist comes out of aunit
The airconditionerdoesnotstartimmediatelyafterthe ON/OFF
button on the romotecontroller ispressed.
Iftheoperation lamplights,the systemisinnormalcondition.To
preventoverloadingofthecompressormotor,theair
conditioner starts3minutesafterit isturned ON.
Ifthe operation lampand the "PRE-DEFindicator(coolingand
heating type) or fan onlyindicator(coolingonlytype)"light,it
meansyou choosethe heating model,When juststarting,ifthe
compressor hasnotstarted,theindoorunitappears"anticold
wind"protection becauseofits overlow outlettemperature.
Inorder topreventthe indoorevaporator frosting,the system
will change intofan mode automatically,restoretothecooling
mode aftersoon.
When the roomtemperaturedropstothe settemperature,the
compressor goesoffand the indoor unitchangestofan mode;
when thetemperaturerisesup,the compressor startsagain.It
issameinthe heatingmode.
Symptom3.1: Indoor unit
Symptom3.2: Indoor unit,outdoor unit
When humidityishigh during cooling operationIfthe interior of
anindoorunitisextremelycontaminated,thetemperature
distribution inside aroombecomesuneven.Itisnecessaryto
clean theinterior ofthe indoor unit.Askyour dealer for details
on cleaning the unit.Thisoperation requiresaqualifiedservice
person

6
owner s manual
Table8-1 (Applicabletoinverter airconditioner only)
NO. Malfunction running lamptimer lamp defrosting lamp alarmlamp
1
2
3
4
5
6
7
8
display(nixietube)
EEPROMmalfunction
Quick-flash E7
Indoorfan unitstall malfunction Quick-flash E8
Quick-flash
E2
Roomtemperature sensor
checking channelis abnormal
Quick-flash
E3
Pipe temperature sensor (T2)
checking channelis abnormall
Quick-flash
E4
Pipe temperature sensor (T2B)
checking channelis abnormal
Quick-flash
EE
Water-levelalarmmalfunction
Quick-flash
9
In-outdoor unitcommunication
checking channelis abnormal
Quick-flash E1
10
11
Indoor master/slaveunit
communication checking channel
isabnormal F3
Quick-flash Quick-flash
Othermalfunctionsofmaster/
slaveunit
F4 Quick-flash
Quick-flash
Outdoor unitmalfunction Ed
Slow-flash
Collision modelmalfunction E0 Quick-flash
Table8-2 (Applicabletofixed-frequencyairconditioner only)
NO. Malfunction running lamptimer lamp defrosting lamp alarmlamp
1
2
3
4
5
Roomtemperature sensor
checking channelis abnormal
Water pumptemperature
sensor
Evaporator sensormalfunction
Condenser sensormalfunction
Water-levelalarmmalfunction
EEPROMmalfunction
Outdoor malfunction
6
7
display
(nixietube)
Quick-flash
Quick-flash
Quick-flash
Quick-flash
Quick-flash
Quick-flash
Quick-flash
Quick-flash
Quick-flash
Quick-flash
Quick-flash
E2
E8
E4
E3
E6
E5
E7

7
owner s manual
Solution
Clean the heatexchanger.
Clean the airfilter.
Eliminatealldirtiesandmakeair
smooth.
Closedoorsand windows.
Makecurtainsinorder toshelter from
sunshine.
Reduceheatsource.
ACcooling capacity reduces(normal).
Checkleakageandrightlyrecharge
refrigerant.
Symptoms Causes
Unit does not start
Airflowingnormallybut
completelycan't cooling
Unitsstart orstop frequently
Lowcoolingeffect
Lowheatingeffect
Power failure.
Power switchisoff.
Fuseofpower switchmayhaveburned.
Batteriesofremotecontroller exhausted
or otherproblemofcontroller.
Temperature is notsetcorrectly.
Bein3minutesprotectionof
compressor.
Refrigerantistoolittleortoo much.
Airornoconcretinggasinthe
refrigerating circuit.
Compressor ismalfunction.
Voltage istoo high ortoo low.
Systemcircuitisblocked.
Outdoorunitandindoorunitheat
exchanger isdirty.
The airfilter isdirty.
Inlet/outletofindoor/outdoorunitsis
blocked.
Doorsandwindowsareopen
Sunlightdirectlyshine.
Too muchheatresource.
Outdoor temp.istoo high.
Leakageofrefrigerantorlackof
refrigerant.
Waitfor the comebackofpower.
Switchon the power.
Replacethe fuse.
Replacethebatteriesor checkthe
controller.
Setthe temperature properly.
Wait.
Checkleakage,andrightlyrecharge
refrigerant.
Vacuumand recharge refrigerant.
Maintenanceorchange compressor.
Installmanostat.
Find reasonsand solution.
Useheating device.
Closedoorsand windows.
Checkleakageandrightlyrecharge
refrigerant.
Outdoor temperature islower than7C.
Doorsand windowsnotcompletely
closed.
Leakageofrefrigerantorlackof
refrigerant.
Table8-3

8
owner s manual
Symptoms Causes
Thefan speed can not be
changed.
Check whether theMODE
indicated on the displayis
"AUTO"
Check whether theMODE
indicated on the displayis
"DRY"
When the automaticmode is
selected,the airconditioner will
automatically change the fan
speed.
When dryoperation isselected,
the airconditionerautomatically
changethe fan speed.The fan
speedcanbe selected during
"COOL","FANONLY",and "HEAT".
Theremotecontrollersignal is
nottransmittedevenwhen
theON/OFFbuttonispushed.
Check whether thebatteries
inthe remotecontroller are
exhausted. The power supply isoff.
Noreceiving tone sounds
from the indoorunit even
when the ON/OFF button is
pressed.
Check whether thesignal
transmitterofthe remote
controller isproperly directed
tothe infrared signalreceiver
ofthe indoor unitwhen the
ON/OFF button ispressed.
Directlytransmitthe signaltransmitter
ofthe remotecontroller tothe infrared
signalreceiverofthe indoor unit,and
then repeatlypushthe ON/OFFbutton
twice.
Theindication onthe display
disappearsafteralapseof
time.
Check whether thetimer
operation hascometoan
end when the TIMEROFF
isindicated on the display.
The airconditioner operation will
stop uptothe settime.
TheTIMER ONindicator
goesoffafteralapse of
certaintime.
Check whether thetimer
operation isstarted when
the TIMERON isindicated
on the display.
Up tothe settime,the airconditioner
will automatically startand the
appropriateindicator willgo off.
TheTEMP. indicatordoes
notcomeon.
Check whether theMODE
indicated on the displayis
FANONLY
The temperaturecannotbe setduring
FANmode.
Solution
Table8-4

QS01U-007AW
202000171405
20130618
The designand specificationsaresubjecttochangewithoutpriornoticeforproduct
improvement.Consultwiththe salesagency ormanufacturerfordetails.
