innovair PIN09H1V51 User manual

pÜre
HEAT PUMP SYSTEM
PIN09H1V51
PIN09H2V51
PIN12H1V51
PIN12H2V51
PIN18H2V51
PIN24H2V51
• The information contained in the manual is intended for use by a qualified service technician
familiar with safety procedures and equipped with the proper tools and test instruments
• Installation or repairs made by unqualified persons can resu t in hazards to you and others.
• Failure to carefully read and follow all instructions in thi manual can result in equipment
malfunction, property damage, personal injury and/or death.
• This service is only for service engineer to use
Service & Technical
Manual

Contents
Service Manual

To prevent personal injury, or property or unit damage, adhere to all
precautionary measures and instructions outlined in thismanual.
Before servicing a unit, refer to this service manual and its relevant
sections.
Failure to adhere to all precautionary measures listed in this section
may result in personal injury, damage to the unit or
WARNING indicates a potentially hazardous situation which
if not avoided could result in serious personal injury, or death.
CAUTION indicates a potentially hazardous situation which if
not avoided could result in minor or moderate personal injury,
or unit damage.
1. In case of Accidents or Emergency
WARNING
If the unit comes into contact with liquid, contact an
If liquid from the batteries makes contact with skin or
Do not insert hands or other objects into the air inlet
Do not operate the unit with wet hands.
Do not use a remote controller that has previously
CAUTION
Clean and ventilate the unit at regular intervals whenoperating
it near a stove or near similar devices.
Do not use the unit during severe weather conditions.
2. Pre-Installation and Installation
WARNING
Use this unit only on a dedicated circuit.
Damage to the installation area could cause the unit
emove, or
repair the unit.
work. For
more information, contact your dealer,seller, or an authorized
Innovair service center.
CAUTION
While unpacking be careful of sharp edges around
denser and evaporator.
3. Operation and Maintenance
WARNING
Do not use defective or under-rated circuit breakers.
Ensure the unit is properly grounded and that a
dedicated circuit and breaker are installed.
Do not modify or extend the power cable. Ensure
the power cable is secure and not damaged during
operation.
Do not unplug the power supply plug during
operation.
unit.
Do not open the inlet grill of the unit during
Do not use harsh detergents, solvents, or similar itemsto clean
the unit. Use a soft cloth for cleaning.
Do not touch the metal parts of the unit when
Do not step on or place anything on the unit oroutdoor
units.
Do not drink water drained from the unit
Avoid direct skin contact with water drained from the
manufacturer
procedures when cleaning ormaintaining the unit.
CAUTION
Do not install or operate the unit for an extendedperiod of
time in areas of high humidity or in anenvironment directly
exposing it to sea wind or saltspray.
Do not install the unit on a defective or damaged
installation stand, or in an unsecure location.
Ensure the unit is installed at a level position
Do not install the unit where noise or air discharge
Do not expose skin directly to the air discharged by
the unit for prolonged periods of time.
Ensure the unit operates in areas water or other
Ensure the drain hose is installed correctly to ensure
proper water drainage.
When lifting or transporting the unit, it is
When the unit is not to be used for an extended time,
Do not
Service Manual
w w w . i n n o v a i r . c o m

ºPay attention to such a situation.
Be sure not to do. Grounding is essential.
Warning: Incorrect handling could
cause a serious hazard,
Symbols in this Use and Care Manual are interpreted as shown below.
Service Manual

Service Manual
w w w . i n n o v a i r . c o m
3

Preparation before use
Note
cable away from the copper tube .
Preset
Safeguarding the environment
refrigerant of the appliance is R41 A.Otherwise, chemical composition of refrigerant
(R410A) inside the system may change and thus affect performance of the air
conditioner.
pressure of the tube is very high, so be sure to be careful when you install and repair
the appliance.
service
agent or similarly qualified persons in order to avoid a hazard.
interconnection
Before using the air conditioner, be sure to check and preset the following.
Each tim e after the remote control is replaced with new batteries or is energized, re mote
control auto presetting heat pump.If the air conditioner you purchased is a Cooling Only one,
heat pump remote controller can also be used.
Hold down any button on remote control to activate the back light. It automatically shuts off
10 seconds later.
The air conditioner has an Auto-Restart function.
4
Service Manual

Service Manual
w w w . i n n o v a i r . c o m
5

6
Service Manual

Model PIN09H1V51 PIN12H1V51 PIN09H2V51 PIN12H2V51 PIN18H2V51 PIN24H2V51
Type Heat Pump Inverter Heat Pump Inverter Heat Pump Inverter Heat Pump Inverter Heat Pump Inverter Heat Pump Inverter
Control type Wireless Remote Wireless Remote Wireless Remote Wireless Remote Wireless Remote Wireless Remote
Wifi Yes Yes Yes Yes Yes Yes
Power supply115V~/60Hz/1P 115V~/60Hz/1P 208-230V~/60Hz/1P 208-230V~/60Hz/1P 230V~/60Hz/1P 230V~/60Hz/1P
Rated cooling capacity Btu/h 9,00012,000 9,00012,00018,00024,000
Rated Heating capacity Btu/h 9,50012,00010,00012,50019,00024,500
SEER Btu/W.h20.0 20.019.0 19.0 19.0 18.0
HSPF Rating (Region IV) Btu/W.h10.0 10.0 10.0 9.5 10.0 10.0
EER Btu/W.h10.5 10.0 10.0 9.5 10.0 9.5
COP W/W13.4 3.0 3.0 3.2 3.0 3.0
Minimum Circuit A 17 19 9 10 12 18
Cooling A
Max current8.5 12.1 4.6 6.1 9.7 13.1
Heating A 8.7 12.1 5.5 6.1 9.7 13.1
Cooling W
Max Power input940 1,340 1,010 1,360 2,150 2,890
Heating W 960 1,340 1,210 1,360 2,150 2,890
Cooling A
Rated current6.8 9.7 3.7 4.9 7.8 10.5
Heating A 7.0 9.7 4.4 4.9 7.8 10.5
Cooling W
Rated input7501070810 1,090 1,720 2,310
Heating W 7701070970 1,090 1,720 2,310
Maximum Fuse Size A 20 25 15 15 20 30
Moisture removal Liters/h 1.1 1.6 1.1 1.6 2.45 2.6
High dB(A) 38 40 38 40 44 50
Indoor noise level at
coolingMed. dB(A) 35 37 35 37 39 46
Low dB(A) 32 34 32 34 34 42
Outdoor noise level dB(A) 50 52 50 52 55 58
Gas inches 3/8'' 3/8'' 3/8'' 3/8'' 3/8'' 1/2"
Connecting PipeLiquidinches 1/4'' 1/4'' 1/4'' 1/4'' 1/4'' 1/4"
Connecting WiringSize x Core number4×16AWG 4×16AWG 4×16AWG 4×16AWG 4×16AWG 4×16AWG
Suitable area ft
2
100 ~ 350200 ~ 450100 ~ 350200 ~ 450350 ~ 650550 ~ 1000
mm 811x292x205811x292x205811x292x205811x292x2051010×315×2201186×340×260
Indoor
Net dimensions(W x H x
D)
inch 31.92x11.49x8.07 31.92x11.49x8.07 31.92x11.49x8.07 31.92x11.49x8.07 39.76x12.40x8.66 46.69x13.38x10.23
mm 728x550x285728x550x285715x492x240715x492x240780×605×290845×699×380
Outdoorinch 28.66x21.65x11.22 28.66x21.65x11.22 28.14x19.37x9.44 28.14x19.37x9.44 30.70x23.81x11.41 33.26x27.51x14.96
Indoor kg/Ibs 8/17.6 8/17.6 8/17.6 8/17.6 13/28.7 17/37.5
Net weightOutdoor kg/Ibs 29/63.9 29/63.9 27/59.5 27/59.5 33.5/73.8 45/99.2
mm 885x366x278885x366x278885x366x278885x366x2781094×386×3001265×415×338
Indoor Packing dimensions (W x H x D) inch 34.84x14.40x10.94 34.84x14.40x10.94 34.84x14.40x10.94 34.84x14.40x10.94 43.07x15.19x11.81 49.80x16.33x13.30
Outdoor Packing dimensions (W xH x D)
(with 5m pipe)
mm 835x600x340835x600x340818x520x325818x520x325890×645×385960×750×430
inch 32.87x23.62x13.39 32.87x23.62x13.39 32.25x20.5x12.75 32.25x20.5x12.75 35.03x25.39x15.15 37.79x29.53x16.92
Indoor kg/Ibs 10/22.1 11/24.2 10/22.1 11/24.2 16/35.3 21/46.3
Gross weightOutdoor(without pipe) kg/Ibs 30/66 32/70.5 30/66 31/68.3 37/81.5 50/110.2
*** Indoor Unit ***
Motor BrandWeilling/Broad- Weilling/Broad-Weilling/Broad-Ocean Weilling/Broad-Ocean Weilling/Broad-OceanWeilling/Broad-
Indoor Motor Ocean Ocean Ocean
Motor Model(Factory Code) AC AC AC AC DC DC
Indoor air circulation/Hi CFM 355390325395315885
Evaporator mm 7x2 7x2 7x2 7x2 7x2 7x2
*** Outdoor Unit ***
Compres sor BrandGMCC GMCC GMCC GMCC SANYO SANYO
Motor BrandWeilling/Broad- Weilling/Broad- Weilling/Broad- Weilling/Broad-Weilling/Broad-OceanWeilling/Broad-
Outdoor Motor Ocean/SHIBURA Ocean/SHIBURA Ocean/SHIBURA Ocean/SHIBURA Ocean
Motor Model DC DC DC DC DC DC
Condenser mm 7x2 7x2 7x2 7x2 7x2 7x2
Factory Refrigerant charge(7.5m pipe)g/oz 810g / 28.57oz1002g / 35.34ozs 800g / 28.22oz950g / 33.51oz1150g / 40.56oz1550g / 54.67oz
Factory Precharge Line(m/ft) 7.5 / 25 7.5 / 25 7.5 / 25 7.5 / 25 7.5 / 25 7.5 / 25
Maximum Line Length (m/ft)15 / 50 15 / 50 15 / 50 15 / 50 15 / 50 15 / 50
Maximum Height Difference Indoor and (m/ft) 5 /16.4 5 /16.4 5 /16.4 5 /16.4 5 /16.4 5 /16.4
Operation temperature °F 62 ~ 86 62 ~ 86 62 ~ 86 62 ~ 86 62 ~ 86 62 ~ 86
Outdoor Ambient Cooling °F 5 ~ 122 5 ~ 122 5 ~ 122 5 ~ 122 5 ~ 122 5 ~ 122
Temperature Heating °F -13 ~ 86 -13 ~ 86 -13 ~ 86 -13 ~ 86 -13 ~ 86 -13 ~ 86
Service Manual
w w w . i n n o v a i r . c o m
7

8
Service Manual

Service Manual
w w w . inn o v a i r . c o m
9

10
Service Manual

Service Manual
w w w . i n n o v a i r . c o m
11

12
Service Manual

Service Manual
w w w . i n n o v a i r . c o m
13

14
Service Manual

Service Manual
w w w . i n n o v a i r . c o m
15

16
Service Manual

Service Manual
w w w . i n n o v a i r . c o m
17

18
Service Manual
