Installation and Operation Manual
IW-25-1 Dehumidifier
Please Read and Save These Instructions
Innovative Dehumidifier Systems, LLC
6260 Ocean Highway 17 West
Ocean Isle Beach, NC 28469
910-579-DEHU
910-579-3348
www.innovativedehu.com
1
Installation and Operation Manual
IW-25-1 Dehumidifier
Please Read and Save These Instructions
Innovative Dehumidifier Systems, LLC
6260 Ocean Highway 17 West
Ocean Isle Beach, NC 28469
910-579-DEHU
910-579-3348
www.innovativedehu.com
Please Read and Save These Instructions

Table of Contents
1
Safety Notes
2
Identification
3
Electrical Supply
3
Principle of Operation
3
Installation
4
Operating Instructions
4
Diagram
5
Maintenance
6
Troubleshooting
8
Warranty Information
9

•The IW-25-2 Dehumidifier must always be connected using a grounded electrical connec-
tion (as required for all electrical appliances). If non-grounded wiring is used, all liability re-
verts to owner and the warranty is voided.
•The IW-25-2 Dehumidifier should only be installed and serviced by a qualified technician.
•If there is a chance that water flooded the dehumidifier, it should be opened and allowed
to dry thoroughly before reconnecting to electrical power and restarting.
•To ensure proper operation, no obstruction should be located within 36” of the discharge
of the unit.
•Do not insert any objects or fingers into the inlet or discharge. If service is required, call a
qualified technician.
•All work on the dehumidifier should be done with the unit “off” and unplugged or the
breaker turned off.
•Do not use water to clean the exterior. To clean unit, unplug from power, then use a damp
cloth to wipe exterior.
•Drain hose must be installed to ensure proper gravity flow of condensate water to a drain
source
2
Safety Notes

Identification!
For future reference, write down the model, serial number, and date of purchase for your dehumidifier.
This is extremely helpful if you need to seek assistance in the future. The data label on the side of your
unit has key characteristics of your specific unit.
Model Number: IW-25-2
Serial Number: Date of Purchase:
For additional questions concerning your dehumidifier, the following options are available:
•Contact your installing contractor
•Call Innovative Dehumidifier Systems @ [phone]
Electrical Supply
Power Supply: 115 V, 60 Hz AC, Single Phase
Outlet Requirement: 3-Prong, GFI
Circuit Protector: 15 Amp Time Delay Fuse or Circuit Breaker
WARNING: 115 Volts AC may cause serious injury from electric shock.
To ensure safety:
1. 1. Disconnect electrical power before servicing
2. 2. Only plug unit into grounded electrical circuit
3. 3. Do not use extension cord
4. 4. Do not use a plug adapter.
Principle of Operation
#The IW-25-2 Dehumidifier utilizes its integral humidistat to monitor the conditioned space. When
the relative humidity goes above the selected set point, the dehumidifier will energize. Air is drawn
across an evaporator coil, which is cooler than the dew point of air. This means moisture will condense
out of the air. The air is then reheated through the condenser coil and distributed back into the room.
Control Board
3
5
Control Board
Installation
Mounting:
The IW-25-1 Dehumidifier is designed to mount into the wall cavity between two studs mounted
on standard 16” centers. The chassis of the unit slips into the wall from the front and is secured by
the four mounting tabs with screws provided by others. Blocking is REQUIRED under the
bottom of the cabinet before screwing to the wall.
Plumbing:
The 10’ drain line (included) is to be attached to the barbed drain hose connection on the rear of
the unit. The entire length of drain line to the gravity drain must be downhill. No low spots or
dips are permitted as they may cause leaks. It is possible to use a short piece of included tube
to deposit condensate directly into a PVC gravity drain system. All state and local plumbing
codes must be adhered to for proper operation of the unit and maintain warranty
compliance.
Humidity Display
On/Off Button
Humidity Setpoint Button

Installation
#WARNING: Do not install your dehumidifier in a corrosive environment.
Mounting:
The IW-25-2 Dehumidifier is designed to mount into the wall cavity between two studs
mounted on standard 16” centers. The chasis of the unit slips into the wall from the front
and is secured by the four mounting tabs with screws (not provided). Ensure the bottom
of the unit is properly supported before screwing into drywall.
Plumbing:
The 10’ drain line (included) is to be attached to the barbed drain hose connection on the
rear of the unit. Secure hose with a hose clamp (included). The entire length of drain line to
the gravity drain must be downhill. No low spots or dip are permitted as they may
cause leaks. It is possible to use a short piece of the included tube to deposit condensate
directly into a PVC gravity drain system. All state and local plumbing codes must be ad-
hered to for proper operation of the unit and to maintain warranty compliance.
Optional Condensate Pump:
If desired, condensate from the unit can be drained into a remote condensate pump (provided in end-
use). If the condensate pump has a normally open safety switch, the safety switch can be connected to
the dehumidifier. This will allow the safety switch to shut offthe dehumidifier if it detects a problem. The
wiring connections for the remote condensate pump are located on the left hand side of the electrical
compartment on the back of the dehumidifier. Connect the red and black wires on the dehumidifier to
the Normally Open Pump Safety switch.
Electrical:
A 10’ power cord is provided for use with a standard grounded outlet. It is also possible to
hard wire the unit, if necessary. Simply remove the electrical cover plate from the back of
the unit, remove the cord, and connect the hard wiring. All state and national electrical
codes must be adhered to for proper unit operation and warranty compliance.
4
Optional NO contacts for
safety switch on conden-
sate pump (NIC)
Hose Clamp to Secure
Hose

Operating Instructions
1.ON/OFF Control
6
Electrical:
A 10’ power cord is provided for use with a standard grounded outlet. It is also possible to hard
wire the unit. Remove the electrical cover plate from back of unit and the cord can be removed
and hardwiring connected. All state and national electrical codes must be adhered to for
proper unit operation and warranty compliance.
Unit Operation
1. ON/OFF Control
Plug the unit in and the display will show the current room relative humidity. Press the
on/off button, the machine will beep twice indicating it is ready for automatic service. If
the humidity is below setpoint, it will remain in standby condition. If the humidity is
above setpoint, unit will turn on and begin to remove moisture from the room.
Press the on/off button again, and a single beep will be your indication that you’ve taken
the unit offline. No room conditioning will occur until you turn the unit on.
2. Setting the Humidity Level
Press the button to set indoor humidity. The humidity display will shift from
displaying the actual room humidity level to the current setpoint. The humidity can be set in 5%
increments from 30-90%. Pressing the SET button increases the setpoint by 5% unit you reach 90%
and then it sequence back to 30% and increases from there.
--
Plug the unit in and the display will show the current room relative humidity. Press the on/
offbutton, and the machine will beep twice indicating it is ready for automatic service. If
the humidity is below setpoint, it will remain in standby condition. If the humidity is above
setpoint, the unit will turn on and begin to remove moisture from the room.
Press the on/offbutton again, and a single beep will indicate that the unit is turning off. No
room conditioning will occur until the unit is turned on again.
2. Setting the Humidity Level
6
Electrical:
A 10’ power cord is provided for use with a standard grounded outlet. It is also possible to hard
wire the unit. Remove the electrical cover plate from back of unit and the cord can be removed
and hardwiring connected. All state and national electrical codes must be adhered to for
proper unit operation and warranty compliance.
Unit Operation
1. ON/OFF Control
Plug the unit in and the display will show the current room relative humidity. Press the
on/off button, the machine will beep twice indicating it is ready for automatic service. If
the humidity is below setpoint, it will remain in standby condition. If the humidity is
above setpoint, unit will turn on and begin to remove moisture from the room.
Press the on/off button again, and a single beep will be your indication that you’ve taken
the unit offline. No room conditioning will occur until you turn the unit on.
2. Setting the Humidity Level
Press the button to set indoor humidity. The humidity display will shift from
displaying the actual room humidity level to the current setpoint. The humidity can be set in 5%
increments from 30-90%. Pressing the SET button increases the setpoint by 5% unit you reach 90%
and then it sequence back to 30% and increases from there.
--
Press the
6
Electrical:
A 10’ power cord is provided for use with a standard grounded outlet. It is also possible to hard
wire the unit. Remove the electrical cover plate from back of unit and the cord can be removed
and hardwiring connected. All state and national electrical codes must be adhered to for
proper unit operation and warranty compliance.
Unit Operation
1. ON/OFF Control
Plug the unit in and the display will show the current room relative humidity. Press the
on/off button, the machine will beep twice indicating it is ready for automatic service. If
the humidity is below setpoint, it will remain in standby condition. If the humidity is
above setpoint, unit will turn on and begin to remove moisture from the room.
Press the on/off button again, and a single beep will be your indication that you’ve taken
the unit offline. No room conditioning will occur until you turn the unit on.
2. Setting the Humidity Level
Press the button to set indoor humidity. The humidity display will shift from
displaying the actual room humidity level to the current setpoint. The humidity can be set in 5%
increments from 30-90%. Pressing the SET button increases the setpoint by 5% unit you reach 90%
and then it sequence back to 30% and increases from there.
--
button to set the indoor humidity. The humidity display
6
Electrical:
A 10’ power cord is provided for use with a standard grounded outlet. It is also possible to hard
wire the unit. Remove the electrical cover plate from back of unit and the cord can be removed
and hardwiring connected. All state and national electrical codes must be adhered to for
proper unit operation and warranty compliance.
Unit Operation
1. ON/OFF Control
Plug the unit in and the display will show the current room relative humidity. Press the
on/off button, the machine will beep twice indicating it is ready for automatic service. If
the humidity is below setpoint, it will remain in standby condition. If the humidity is
above setpoint, unit will turn on and begin to remove moisture from the room.
Press the on/off button again, and a single beep will be your indication that you’ve taken
the unit offline. No room conditioning will occur until you turn the unit on.
2. Setting the Humidity Level
Press the button to set indoor humidity. The humidity display will shift from
displaying the actual room humidity level to the current setpoint. The humidity can be set in 5%
increments from 30-90%. Pressing the SET button increases the setpoint by 5% unit you reach 90%
and then it sequence back to 30% and increases from there.
--
will shift from
displaying the actual room humidity level to the current setpoint. The humidity can be in
5% increments from 30%-90%. Pressing the
6
Electrical:
A 10’ power cord is provided for use with a standard grounded outlet. It is also possible to hard
wire the unit. Remove the electrical cover plate from back of unit and the cord can be removed
and hardwiring connected. All state and national electrical codes must be adhered to for
proper unit operation and warranty compliance.
Unit Operation
1. ON/OFF Control
Plug the unit in and the display will show the current room relative humidity. Press the
on/off button, the machine will beep twice indicating it is ready for automatic service. If
the humidity is below setpoint, it will remain in standby condition. If the humidity is
above setpoint, unit will turn on and begin to remove moisture from the room.
Press the on/off button again, and a single beep will be your indication that you’ve taken
the unit offline. No room conditioning will occur until you turn the unit on.
2. Setting the Humidity Level
Press the button to set indoor humidity. The humidity display will shift from
displaying the actual room humidity level to the current setpoint. The humidity can be set in 5%
increments from 30-90%. Pressing the SET button increases the setpoint by 5% unit you reach 90%
and then it sequence back to 30% and increases from there.
--
button increases setpoint by %5 until
you reach 90%, then rolls over to 30% and increases from there.
IW-25-2 Dehumidifier Diagram
•
•Front View
Back View
5
4
Unit Overview
Front View
Rear View
Front Cover
Electrical Cover Plate
Air Discharge
Chassis
Air Inlet
Front Cover Screws and Caps
Power Cord
Drain Hose Connection
Chassis
Mounting Flanges – Typ 4

Back View
Maintenance
WARNING: 115 Volts AC may cause seri-
ous injury from electric shock. Be sure
the unit is powered offand unplugged or
circuit breaker is turned offbefore remov-
ing front cover to service unit.
Cleaning Front Cover
Use a soft damp cloth to clean the front cover
as required. Do not use any soap or solvents.
Filter Maintenance
••Check the filter on a regular basis
(will vary based on application). Clean
or replace, as necessary
••To Remove Filter:
1. 1. Remove screws in the front
cover.
2. 2. Push the front cover up gently to
free the cover hooks from the chas-
sis.
3. 3. The filter is located on the back
side of the front cover.
4.
5.
6
7
5．Maintenance
WARNING: 120 Volts AC may cause serious injury from electric shock. Be
sure the unit is powered off and unplugged or circuit breaker turned “off”
before removing the front cover to service unit.
5．1. Clean the front cover using a moist cloth as required.
5．2. Filter Maintenance – Check filter on a bi-monthly basis. Clean or replace as necessary.
5．2.1.Removing the Filter
5．2.2 Filter Cleaning
Filter can be vacuumed with a wet/dry vac or washed with warm water.
Remove the screws in the front
cover and then push the front
cover up gently to free the cover
hooks from chassis. Filter is
located on the back side of Front
cover.
NOTE: Machine is intended to
operate with all components shown.
Do not remove any parts including
Styrofoam fan shroud.
8
5.2.3 Filter Installation
6. Troubleshooting
Symptom Cause Solution
Machine Doesn’t Work
Power not getting to unit
Check Cord connection.
Check Breaker or Fuse
Room outside machine
operating temp range
(50-90˚F)
Return room to operating
temperature range
No Airflow
Filter Dirty Clean the filter according
to manual
Air inlet or outlet jammed? Clear the blockage from
air inlet or air outlet
Machine is Noisy
Machine Not Level Reposition
Filter mesh jammed? Clean the filter mesh
Unit not installed with 4
screws or poor quality screws
Unit MUST be installed
with 4 screws provided or
good quality screws.
Machine not supported by
blocking Blocking is required
When installing the filter to the
back of the cover, insert in tabs on
top of mount and then flex filter to
insert under bottom taps.
Reinstall cover by lining up tabs,
sliding down into place, securing
with tamperproof screws and
covering screws with caps.
4
Unit Overview
Front View
Rear View
Front Cover
Electrical Cover Plate
Air Discharge
Chassis
Air Inlet
Front Cover Screws and Caps
Mounting Flanges – Typ 4
Power Cord
Drain Hose Connection
Chassis

6.
7.•To Clean Filter:
8. Filter can be vacuumed with a wet/dry vac or washed with warm water.
9.
10.
11.
12.
13.
••To Install Filter:
1. 1. Insert filter in tabs on top of mount
2. 2. Flex filter to insert under bottom taps
3. 3. Once filter is in place, reinstall front cover:
1. a. Line up cover with tabs
2. b. Slide down into place
3. c. Secure with tamperproof screws
Coil Maintenance
•Once per year, clean the coils with an approved coil cleaner
•Coil cleaner should be a self rinsing, foaming cleaner such as WEB® Coil Cleaner.
7
7
5．Maintenance
WARNING: 120 Volts AC may cause serious injury from electric shock. Be
sure the unit is powered off and unplugged or circuit breaker turned “off”
before removing the front cover to service unit.
5．1. Clean the front cover using a moist cloth as required.
5．2. Filter Maintenance – Check filter on a bi-monthly basis. Clean or replace as necessary.
5．2.1.Removing the Filter
5．2.2 Filter Cleaning
Filter can be vacuumed with a wet/dry vac or washed with warm water.
Remove the screws in the front
cover and then push the front
cover up gently to free the cover
hooks from chassis. Filter is
located on the back side of Front
cover.
NOTE: Machine is intended to
operate with all components shown.
Do not remove any parts including
Styrofoam fan shroud.

Troubleshooting
8
Symptom
Cause
Solution
Machine Won’t Run
Power Supply
Verify that there is power to the outlet and
that the plug is properly installed in outlet
Machine Won’t Run
Room Temperature Over 90°F or
Below 50°F
The unit is outside the operating
temperature range. Modify the room
conditions so the temperature is between
50°-90°F and operation will commence.
Cannot Start Dehumidifier
Air Filter is Clogged
Clean the filter mesh according to
instructions listed in manual.
Cannot Start Dehumidifier
Air Inlet or Outlet is Jammed
Clear the blockage from inlet or outlet.
Loud Noise
Machine Is Not Level
Reposition unit so it is level
Loud Noise
Filter Mesh is Jammed
Clean the filter mesh according to
instructions listed in manual.
Loud Noise
Unit not installed with 4 screws or
poor quality screws
Unit MUST be installed with 4 screws
provided.
Loud Noise
Machine not supported by blocking
Blocking is required
Loud Noise
Machine is touching or rubbing an
unrelated item
Isolate items to eliminate noise/vibration
Water is Leaking
Low spots, dips, or kinks are
present inside or outside machine.
•Ensure end of drain hose is not
submerged in water from property’s drain
source
• Re-route tubing to eliminate all low
spots, kinks, valleys, and dips
E1 Warning Light
Sensor or Sensor Communication
Issue
•Check sensor cable connection is secure
at both ends
• Replace Sensor
E2 Warning Light
Remote Alarm
•Alarm is designed to indicate that the
remote condensate pump has an issue.
•If pump is installed, clean or replace as
necessary.
•If no pump is installed, ensure the safety
wires (shown on page 4) are not
connected to each other
LO Warning Light
Sensor believes temperature is
below 50°F
•If room temperature is low, raise the
temperature and unit will function
normally. If not, replace the sensor.
HI Warning Light
Sensor believes temperature is
above 90°F
•If room temperature is high, lower the
temperature and the unit will function
properly. If not, replace the sensor

Warranty
Innovative Dehumidifier Systems, LLC (IDS) warrants the equipment to be free from defects in workman-
ship and materials for a period of 24 months after shipment. This warranty is limited, however, to the re-
pair or replacement of defective equipment. If it is necessary to return unit for service, customer is
solely responsible for proper packaging, transportation costs. Customer must initiate warranty process
by contacting IDS. Do not send any component or product back to IDS without Return Material Authori-
zation.
This limited warranty does not apply to any part or component that is damaged in transit or when han-
dling, has been subject to misuse, corrosion, chemicals, acts of God, has not been installed, operated
or serviced according to the Seller’s instructions, or has been operated beyond the factory-rated capac-
ity or has been altered in any way. Routine maintenance is not covered by this warranty.
Seller’s liability is limited to replacement of defective parts or components and does not include any
cost of labor (including, but not limited to, labor to remove and/or reinstall any defective part), refriger-
ant or piping. Customer may elect to have unit fixed locally in which case required replacement parts
will be sent to customer at customer’s expense.
IDS shall not be responsible for loss of use of any product, loss of time, inconvenience, or damage to
other equipment, or any other indirect or consequential damage with respect to property whether as a
result of breach of warranty, neglect, or otherwise.
THE WARRANTIES AND LIABILITIES SET FORTH ARE IN LIEU OF ALL OTHER WARRANTIES EX-
PRESSED OR IMPLIED, IN LAW OR IN FACT, INCLUDING IMPLIED WARRANTIES OF MERCHANT-
ABILITY AND FITNESS FOR PARTICULAR PURPOSE. IDS total liability, regardless of nature of claim
shall not exceed original purchase price of the product. If a product or component is replaced while un-
der warranty, the applicable warranty period shall not be extended beyond the original warranty time
period.
The foregoing shall constitute the total liability of seller in the case of defective performance of all or any
of the equipment or services provided to Buyer. Buyer agrees to accept and hereby accepts the forego-
ing as the sole and exclusive remedy for any breach or alleged breach of warranty by Seller.
10
7. Warranty
Innovative Dehumidifier Systems, LLC (IDS) warrants the equipment to be free from defects in workmanship and
materials for a period of 24 months after shipment. This warranty is limited, however, to the repair or replacement of
defective equipment. If it is necessary to return unit for service, customer is solely responsible for proper packaging,
transportation costs. Customer must initiate warranty process by contacting IDS. Do not send any component or
product back to IDS without Return Material Authorization.
This limited warranty does not apply to any part or component that is damaged in transit or when handling, has
been subject to misuse, has not been installed, operated or serviced according to the Seller’s instructions, or
has been operated beyond the seller’s – rated capacity or has been altered in any way. Routine maintenance
is not covered by this warranty.
Seller’s liability is limited to replacement of defective parts or components and does not include any cost of
labor (including, but not limited to, labor to remove and/or reinstall any defective part), refrigerant or
piping. Customer may elect to have unit fixed locally in which case required replacement parts will be sent to
customer at customer’s expense.
IDS shall not be responsible for loss of use of any product, loss of time, inconvenience, or damage to other
equipment, or any other indirect or consequential damage with respect to property whether as a result of
breach of warranty, neglect, or otherwise.
THE WARRANTIES AND LIABILITIES SET FORTH ARE IN LIEU OF ALL OTHER WARRANTIES
EXPRESSED OR IMPLIED, IN LAW OR IN FACT, INCLUDING IMPLIED WARRANTIES OF
MERCHANTABILITY AND FITNESS FOR PARTICULAR PURPOSE. IDS total liability, regardless of nature of
claim shall not exceed original purchase price of the product. If a product or component is replaced while
under warranty, the applicable warranty period shall not be extended beyond the original warranty time period.
The foregoing shall constitute the total liability of seller in the case of defective performance of all or any of the
equipment or services provided to Buyer. Buyer agrees to accept and hereby accepts the foregoing as the
sole and exclusive remedy for any breach or alleged breach of warranty by Seller.
9

10
