Contents
Chapter 1 1 Intended Use, Contraindications and General Precautions
Chapter 2 3 Description of the Inogen One® G2 Oxygen Concentrator
3 Important Parts of the Inogen One® G2 Oxygen Concentrator
4 User Controls
4 User Interfaces
5 Input / Output Connections
6 Power Supply Options
11 Inogen One® G2 Accessories
Chapter 3 13 Operating Instructions
13 General Instructions
17 Additional Operating Instructions
20 Battery Operating Instructions
21 Battery Care and Maintenance
Chapter 4 23 Inogen One® G2 Oxygen Concentrator Audible and
Visible Signals (including Alarms)
Chapter 5 31 Troubleshooting
Chapter 6 33 Cleaning, Care and Maintenance
33 Cannula Replacement
33 Case Cleaning
34 Filter Cleaning and Replacement
36 Other Service and Maintenance
36 Disposal of Equipment and Accessories
Chapter 7 37 Symbols Used on Concentrator and Accessories
Chapter 8 39 Inogen One® G2 System Specifications
English

8

1
1Intended Use, Contraindications
and General Precautions
Intended Use, Contraindications and General Precautions Chapter 1
Intended Use
The Inogen One® G2 Oxygen Concentrator is used on a prescriptive basis by patients
requiring supplemental oxygen. It supplies a high concentration of oxygen and is used
with a nasal cannula to channel oxygen from the concentrator to the patient. The Inogen
One® G2 may be used in home, institution, vehicle, on an airplane and various mobile
environments.
The expected life for the Inogen One® G2 Oxygen System is 5 years, with the exception of
the batteries, which have an expected life of 500 full charge/discharge cycles.
CAUTION USA Federal law restricts this device to sale by or on the order of a
physician. May also be applicable in other countries.
CAUTION Use of a cannula other than a high flow cannula (e.g. Salter 1600Q)
may restrict oxygen delivery and/or attachment to nozzle fittings.
WARNING Availability of an alternate source of oxygen is recommended in case of
power outage or mechanical failure. Consult your equipment provider for
type of back-up system recommended.
CAUTION It is the responsibility of the patient to make back-up arrangements for
alternative oxygen supply when traveling; Inogen assumes no liability for
persons choosing not to adhere to manufacturer recommendations.
!
C
English

2
Contraindications
WARNING This device is NOT INTENDED to be life sustaining or life supporting.
CAUTION Under certain circumstances, the use of non-prescribed oxygen
therapy can be hazardous.This device should be used only when
prescribed by a physician.
CAUTION Additional monitoring or attention may be required for patients
using this device who are unable to hear or see alarms or communicate
discomfort. If the patient shows any signs of discomfort, a
physician should be consulted immediately.
CAUTION The Inogen One® G2 is not designed or specified to be used in
conjunction with a humidifier, nebulizer or connected with any other
equipment. Use of this device with a humidifier, nebulizer or connected
with any other equipment may impair performance and/or damage
the equipment. Do not modify the Inogen One® G2 Concentrator. Any
modifications performed on the equipment may impair performance or
damage equipment and will void your warranty.
!
C
!C
!C
General Precautions
WARNING The device produces enriched oxygen gas which accelerates
combustion. Do NOT ALLOW SMOKING OR OPEN FLAMES within
10 feet of this device while in use.
WARNING Do not submerse the Inogen One® G2 or any of the accessories in liquid.
Do not expose to water or precipitation. Do not operate in exposed rain.
This could lead to electrical shock and/or damage.
CAUTION Do not use oil, grease, or petroleum-based products on or near the
Inogen One® G2.
CAUTION Never leave the Inogen One® G2 in an environment which can reach
high temperatures, such as an unoccupied car in high temperature
environments. This could damage the device.

3
Important Parts of the Inogen One® G2 Oxygen Concentrator
Description of the Inogen One®
G2 Oxygen Concentrator
Description of the Inogen One® G2 Oxygen Concentrator Chapter 2
2
On/Off
Button
Alert/Alarm
Light
Flow Control
Display
Display
Backlight
Button
Breath
Detection
Light
Audible
Alarm
Button
English

4
User Controls
ON / OFF Button
Press once to turn “ON”; Press and hold for one second to turn “OFF”.
Audible Alarm Button
Pressing this button will toggle the Inogen One® G2’s breath detection audible
alert on and off:
1. Default Mode. When the Inogen One® G2 is powered up, the breath
detection audible alert is disabled. The display’s mode indication area
will show a bell icon crossed out with an X in default mode.
2.Breath Detection Alert Mode. The Inogen One® G2 will alert with
audible and visual signals for “no breath detected” when this mode is
enabled and no breath has been detected for 60 seconds, the device
will enter into auto pulse mode and once another breath is detected,
the device will exit auto pulse mode and deliver normally on inspiration.
The display’s mode indication area will show a bell icon, flashing
red light and display’s message when the alert is enabled.
3. If power is lost, breath detection alert mode resets to
default mode.
Flow Setting Control Buttons
Use the – or + flow setting control buttons to select the setting as
shown on the display. There are six settings, from 1 to 6.
Display Backlight Button
Push on; automatically turns off after 10 seconds.
User Interfaces
Display
This screen displays information regarding flow setting, power status,
battery life and errors. If you would like to change the language on the
Inogen LCD Screen contact Inogen Client Services.

5
Description of the Inogen One® G2 Oxygen Concentrator Chapter 2
User Interfaces (continued)
Indicator Lights
A red light indicates either a change in operating status or a
condition that may need response (alarm). A flashing light is
higher priority than non-flashing.
Audible Signals
An audible signal (beep) indicates either a change in
operating status or a condition that may need response (alarm).
More frequent beeps indicate higher priority conditions.
Input / Output Connections
Particle Filter
The filter must be in place at the intake end of the concentrator
during operation to keep input air clean.
Cannula Nozzle Fitting
The nasal cannula connects to this nozzle for Inogen One® G2
output of oxygenated air.
DC Power In
Connection for external power from the Universal Power Supply.
USB Port
Used for servicing only.
English

6
Power Supply Options
Single and Double Rechargeable Lithium Ion Batteries
The battery will power the Inogen One® G2 without
connection to an external power source. When fully charged, a
single battery will provide 2 to 5 hours of operation; a double
battery will provide 4 to 10 hours of operation. The battery
recharges when properly installed in the Inogen One® G2 and
the concentrator is connected to AC or DC power. Recharging
time is up to 4 hours for a single battery and up to 8 hours
for a double battery. See information in the “Battery Care and
Maintenance” section.
UNIVERSAL POWER SUPPLY
Overview
The Inogen Universal Power Supply (BA-107/207) is used to power the Inogen One® G2
Concentrator from an AC power source or a DC power source. This allows the user to
power the concentrator in the home, in a vehicle or other places where AC or DC power is
available.
Description
The Inogen One® G2 Universal Power Supply is specifically designed for use with the
Inogen One® G2 Oxygen Concentrator (IO-200). The Universal Power Supply provides the
precise current and voltage required to safely power the Inogen One® G2 and is designed
to operate from specified AC and DC power sources. When used with AC power sources,
the power supply automatically adapts to input voltages from 100V to 240V (50-60HZ)
permitting use with most power sources throughout the world.
The Universal Power Supply will charge the Inogen One® G2 Battery when used with AC
input power or when used with a DC power supply, such as the one found in your car.
Due to aircraft power limitations, the Universal Power Supply cannot be used to charge
the Inogen One® G2 Battery when used on an aircraft.
The Universal Power Supply is used with the following components:
• Power Supply with attached power output cable to connect to the Inogen One® G2
• Automobile DC cigarette lighter Power Input Cable
• AC Power Input Cable

7Description of the Inogen One® G2 Oxygen Concentrator Chapter 2
WARNING Do not use power supplies or power cables other than those specified in this
user manual. The use of non-specified power supplies or power cables may
create a safety hazard and/or impair equipment performance.
Do not wrap cords around Power Supply for storage. Do not drive, drag or
place objects over cord. Keep children and pets away from cord. Doing so may
lead to damaged cords and a failure to provide power to the concentrator.
!
C
* Actual product appearance may vary.
English
Power Output Plug
Universal Power Supply
LED Indicator Light
AC Input
DC cigarette lighter Power Plug for use in Automobile/RV/Boat/Aircraft (RP# 122)*
DC Input
AC Power Plug*
Model# BA-107

8
Power Output Plug
Universal Power Supply
LED Indicator Light
AC Input
DC cigarette lighter Power Plug for use in
Automobile/RV/Boat/Aircraft (RP# 222)*
DC Input
AC Power Plug*
Model# BA-207
* Actual product appearance may vary.
WARNING Do not use power supplies or power cables other than those specified in this
user manual. The use of non-specified power supplies or power cables may
create a safety hazard and/or impair equipment performance.
Do not wrap cords around Power Supply for storage. Do not drive, drag or
place objects over cord. Keep children and pets away from cord. Doing so may
lead to damaged cords and a failure to provide power to the concentrator.
!
C

9
Description of the Inogen One® G2 Oxygen Concentrator Chapter 2
English
LED
Indicator
Light
Power Output Plug*
AC Power Supply
AC Input
AC Power
Plug*
Model # BA-301
WARNING Do not use power supplies or power cables other than those specified in this
user manual. The use of non-specified power supplies or power cables may
create a safety hazard and/or impair equipment performance.
Do not wrap cords around Power Supply for storage. Do not drive, drag or
place objects over cord. Keep children and pets away from cord. Doing so may
lead to damaged cords and a failure to provide power to the concentrator.
!
C
* Actual product appearance may vary.

10
DC cigarette
lighter Power
Plug for use in
Automobile/RV/
Boat/Aircraft*
LED
Indicator
Light
Power Output
Plug*
DC Power Supply
Model# BA-302
WARNING Do not use power supplies or power cables other than those specified in this
user manual. The use of non-specified power supplies or power cables may
create a safety hazard and/or impair equipment performance.
Do not wrap cords around Power Supply for storage. Do not drive, drag or
place objects over cord. Keep children and pets away from cord. Doing so may
lead to damaged cords and a failure to provide power to the concentrator.
!
C
* Actual product appearance may vary.

11
Inogen One® G2 Accessories
WARNING Do not use power supplies/adapters or accessories other than those
specified in this user manual. The use of non-specified accessories
may create a safety hazard and/or impair equipment performance.
Nasal Cannula
A nasal cannula must be used with the Inogen One® G2 to provide
oxygen from the concentrator. A single lumen cannula up to 25 feet
in length is recommended to ensure proper breath detection and
oxygen delivery.
WARNING
Choking and strangulation hazard. Keep tubing away from children
and pets.
NOTE Increasing the cannula length may reduce the perceived noise during
oxygen bolus delivery.
When using a cannula 25ft. in length with the Inogen One® G2,
an increase in flow setting may be required.
Carry Bag
The Carry Bag provides a protective cover with a handle and
shoulder strap to enable you to carry the Inogen One® G2.
The Inogen One® G2 can be operated using battery power
during transport with the Carry Bag.
Cart
The Cart has wheels and a telescoping handle
to provide easy transport of the Inogen One®
G2. The Inogen One® G2 can be operated using
battery power during transport. Place the Carry
Bag over the Cart. Make sure the Cart handle is
inserted between the elastic strap in the back
of the carry bag and the front of the carry bag.
Description of the Inogen One® G2 Oxygen Concentrator Chapter 2
!
C
!
C
English

12
Inogen One® G2 Optional Accessory
External Battery Charger
1. Plug the External Battery Charger AC power supply
cord into an electrical outlet.
2. Plug the External Battery Charger AC power supply into
the battery charger.
3. Slide your charger onto the Inogen One® G2 Battery by
clicking and locking into the charger.
4. When the battery is in the correct position, a solid red light
will indicate that the battery is charging.
5. When the green light illuminates, the battery is
fully charged.
CAUTION Avoid touching the recessed electrical contacts of the External Battery
Charger; damage to contacts may affect charger operation.
NOTE
These contacts are not powered unless a battery is in place and charging.
NOTE To completely remove power from the External Battery Charger, remove
the plug.
Inogen One G2 Backpack
Alternative/optional way of carrying your Inogen One® G2,
hands free, more comfort, out of your way with extra pockets
for additional accessories.
To order please call Inogen Client Services.

13
Operating Instructions
Operating Instructions Chapter 3
3
!
C
Intake
Exhaust
General Instructions
1. Place the Inogen One® G2 in a well ventilated
location.
Air intake and exhaust must have clear access.
Locate the Inogen One® G2 in such a way that any auditory
alarms may be heard.
WARNING Avoid use of the Inogen One® G2 in presence of pollutants, smoke
or fumes. Do not use the Inogen One® G2 in presence of flammable
anesthetics, cleaning agents or other chemical vapors.
CAUTION Do not obstruct air intake or exhaust when operating the device.
Blockage of air circulation or proximity to a heat source may lead to
internal heat buildup and shutdown or damage to the concentrator.
2. Ensure the particle filter is in place.
CAUTION Do not operate the Inogen One® G2 without the
particle filter in place. Particles drawn into the
system may damage the equipment.
3. Install the battery.
Insert the Inogen One® G2 battery by sliding battery into place
and locking at bottom of concentrator.
English

14
CAUTION The Inogen One® G2 battery acts as a secondary power supply in the event of
a planned or unexpected loss of the AC or DC external power supply. When
operating the Inogen One® G2 from an AC or DC external power supply, a
properly inserted Inogen One® G2 battery should be maintained in the unit.
This procedure will ensure uninterrupted operation and will operate all
alarms and alerts in the event of a loss of the external power supply.
NOTE The Inogen One® G2 Battery requires an initial full charge of uninterrupted
charging from an empty state using the Inogen One® G2 on the AC power
source. Do not run the Inogen One® G2 on battery power until this initial
charging has been completed. Once the initial charge is completed, the battery
may be used with any amount of charge level.
4. Connect the Universal Power Supply.
Connect the AC Power plug to the Universal Power Supply. Connect the
AC Power Plug to the power source and connect the Power Output Plug to
the Inogen One® G2.The green LED on the Universal Power Supply will be
illuminated and a beep will sound from the concentrator.
CAUTION Ensure the Universal Power Supply is in a well ventilated location as it relies
on air circulation for heat dissipation. The Universal Power Supply may become
hot during operation. Make sure the Universal Power Supply cools down before
handling.
CAUTION The Universal Power Supply is not water resistant.
CAUTION Do not disassemble the Universal Power Supply. This may lead to
component failure and/or safety risk.
CAUTION Do not place anything in the Universal Power Supply port other than the
supplied wall cord. Avoid the use of electrical extension cords with the Inogen
One® G2. If an extension cord must be used, use an extension cord that has
an Underwriters Laboratory (UL) Mark and a minimum wire thickness of 18
gauge. Do not connect any other devices to the same extension cord.

15
Operating Instructions Chapter 3
NOTE Under certain conditions (see Technical Specifications) the Universal
Power Supply may shut down. The green LED will blink or will no longer
be illuminated. If this occurs, disconnect the Power Supply for at least
10 seconds and reconnect.
NOTE
When the Universal Power Supply is disconnected from the AC outlet, also
disconnect it from the concentrator to avoid unnecessary battery discharge.
5. Connect the nasal cannula tubing to the nozzle fitting.
Nozzle fitting is located next to the handle of the Inogen One® G2.
Use of a single lumen cannula up to 25 feet in length is recommended to
ensure proper breath detection and oxygen delivery . Additional
titration may be needed to ensure proper oxygen
delivery when using a particular cannula.
CAUTION To ensure oxygen flow, ensure that the nasal cannula is properly connected to
the nozzle fitting and that the tubing is not kinked or pinched in any way.
CAUTION
Replace the nasal cannula on a regular basis. Check with your
equipment provider or physician to determine how often the cannula
should be replaced.
6. Turn on your Inogen One® G2 by pressing the ON/OFF Button.
A single short beep will sound after the Inogen logo is displayed.“Please
Wait” will appear while the concentrator starts up. The display will indicate
the selected flow setting and power condition. Following a brief start-up
sequence, a warm up period up to 2 minutes will initiate. During this time
period the oxygen concentration is building to but may not have reached
specification. Additional warm up time may be needed if your Inogen One®
G2 has been stored in extremely cold temperatures.
English

16
!
C
7. Set the Inogen One® G2 Concentrator to the flow rate prescribed by your
physician or clinician.
Use the + or – setting buttons to adjust the Inogen One® G2 to the desired setting.
The current setting can be viewed on the display.
8. Position the nasal cannula on your face and breathe through your nose.
The Inogen One® G2 will sense the onset of inhalation and deliver
a burst of oxygen at a precise time when you inhale. The Inogen
One® G2 will sense each breath and continue to deliver oxygen
in this manner. As your breathing rate changes, the Inogen One®
G2 will sense these changes and deliver oxygen only as you need
it. At times, if you inhale very quickly between breaths the Inogen
One® G2 may ignore one of the breaths, giving the appearance of a
missed breath. This may be normal as the Inogen One® G2 senses
and monitors the changes in your breathing pattern. The Inogen
One® G2 will normally sense the next breath and deliver oxygen
accordingly.
A green light will flash each time a breath is detected. Make certain that the nasal cannula
is properly aligned on your face and you are breathing through your nose.
WARNING If you begin to feel ill or are experiencing discomfort while using this
device, consult your physician immediately.
CAUTION The Inogen One® G2 is designed to provide a flow of high purity oxygen.
An advisory alarm,“Oxygen Low”, will inform you if oxygen concentration
drops. If alarm persists, contact your equipment provider.
General
To remove power, unplug the input cord from its source (i.e., AC wall outlet, DC car
cigarette lighter adapter).
CAUTION Ensure the Universal Power Supply is powered from only one power source
(AC or DC) at any given time.The Universal Power Supply may not operate
properly if simultaneously powered using both AC and DC sources.
