Amtrol Extrol 100 lbc User manual

West Warwick, Rhode Island 02893

INSTALLATION, OPERATION &

SERVICE INSTRUCTIONS

EXTROL® LBC SERIES

Part #9017-095 (04/07)

Telephone 401-884-6300

LBC Series Bottom Connection Bladder Series

Pressurized Expansion Tanks (ASME)

35 LBC

50 LBC

85 LBC

100 LBC

130 LBC

165 LBC

200 LBC

300 LBC

400 LBC

500 LBC

600 LBC

For Models:

READ CAREFULLY THE PRODUCT INSTALLATION, OPERATING AND MAINTENANCE MANUAL. FAILURE TO FOLLOW THE

INSTRUCTIONS AND WARNINGS IN THE MANUAL MAY RESULT IN SERIOUS OR FATAL INJURY AND/OR PROPERTY DAMAGE, AND

WILL VOID THE PRODUCT WARRANTY. THIS PRODUCT MUST BE INSTALLED BY A QUALIFIED PROFESSIONAL. FOLLOW ALL APPLICABLE LOCAL AND

STATE CODES AND REGULATIONS, IN THE ABSENCE OF SUCH CODES, FOLLOW THE CURRENT EDITIONS OF THE NATIONAL PLUMBING CODE AND

NATIONAL ELECTRIC CODE, AS APPLICABLE.

EXPLOSION OR RUPTURE HAZARD A relief valve must be installed to prevent pressure in excess of local code requirement or

maximum working pressure designated in the Product Manual, whichever is less. Do not expose Product to freezing temperatures

or temperatures in excess of 240° F. Do not adjust the pre-charge or re-pressure this Product except for any adjustments required at the time of initial

installation, especially if Product corroded, damaged or with diminished integrity. Adjustments to pre-charge must be done at ambient temperature only.

Failure to properly size the Product or follow these instructions may result in excessive strain on the system lead to Product failure, serious or fatal personal

injury, leakage and/or property damage.

THIS IS THE SAFETY ALERT SYMBOL. IT IS USED TO ALERT YOU TO POTENTIAL PERSONAL INJURY AND OTHER HAZARDS. OBEY ALL SAFETY

MESSAGES THAT FOLLOW THIS SYMBOL TO REDUCE THE RISK OF PERSONAL INJURY AS WELL AS PROPERTY DAMAGE.

POTABLE WATER AND RADIANT HEATING WARNING.

THIS PRODUCT MUST NOT BE USED IN RADIANT

HEATING, POTABLE WATER OR OPEN SYSTEMS OF

ANY KIND. THESE SYSTEMS CONTAIN OXYGENATED WATER WHICH WILL

CAUSE INTERNAL CORROSION AND PREMATURE PRODUCT FAILURE. USE

A THERM-X-TROL®FOR POTABLE WATER SYSTEMS AND A RADIANT

EXTROL™ FOR RADIANT HEATING SYSTEMS. MOUNT VERTICALLY ONLY.

DO NOT INSTALL ON DEAD-END PIPE.

NOTE: INSPECT FOR SHIPPING DAMAGE AND NOTIFY FREIGHT CARRIER

OR STORE WHERE PURCHASED IMMEDIATELY IF DAMAGE IS PRESENT. TO

AVOID RISK OF PERSONAL INJURY AND PROPERTY DAMAGE, IF THE

PRODUCT APPEARS TO BE MALFUNCTIONING OR SHOWS SIGNS OF

CORROSION, CALL A QUALIFIED PROFESSIONAL IMMEDIATELY. CURRENT

COPIES OF THE PRODUCT MANUAL CAN BE VIEWED AT

WWW.AMTROL.COM. USE PROPER SAFETY EQUIPMENT WHEN INSTALLING.

FAILURE TO PROPERLY SEAL WILL RESULT IN LOSS

OF PRECHARGE CAUSING PRODUCT TO FAIL.

GENERAL SAFETY INFORMATION - ADDITIONAL

SPECIFIC SAFETY ALERTS APPEAR IN THE

FOLLOWING INSTRUCTIONS.

CALIFORNIA PROPOSITION 65 WARNING: THIS PRODUCT CONTAINS A

CHEMICAL KNOWN BY THE STATE OF CALIFORNIA TO CAUSE CANCER AND

TO CAUSE BIRTH DEFECTS OR OTHER REPRODUCTIVE HARM. (CALIFORNIA

INSTALLER/CONTRACTOR - CALIFORNIA LAW REQUIRES THAT THIS NOTICE

BE GIVEN TO CONSUMER/END USER OF THIS PRODUCT.) FOR MORE

INFORMATION: WWW.AMTROL.COM/PROP65/HTM.

Location of EXTROL®Expansion

Tanks

DO NOT LOCATE THIS PRODUCT WHERE LEAKING

OR FLOODING COULD CAUSE DAMAGE TO THE

SURROUNDING PROPERTY.

The AMTROL®expansion tank may be placed in any convenient position

within the mechanical room (or building). If multiple tanks are installed,

they should all be on the same level.

Point of Connection

Unlike a conventional tank, the EXTROL®sealed air cushion does not

require replenishment so DO NOT connect to an air separator or other air

collection device.

As with any expansion tank, it is recommended that the EXTROL®be

connected to the suction side of the pump. This will prevent the pump

head from becoming subtractive which may result in entry of air and vapor

formation at high points in the system.

By connecting the EXTROL®on the boiler return, displacement of coolest

system water into tank is ensured reducing energy waste.

Low pressure drop components such as air separators and boilers may be

placed between point of connection and pump suction if desired. System

design will dictate the feasibility of this.

Natural convection losses and the entry of air into tanks are eliminated by

connection to the side or underside of main pipe. The piping should be

pitched up and away from the EXTROL®to eliminate any potential air

traps.

Installation

THIS PRODUCT MUST BE INSTALLED BY A QUALIFIED

PROFESSIONAL.

1. Note location of system connection, air charge valve and drain

connection on tank.

2. Remove the plug or pipe cap from the system connection.

3. Remove the 1 1/2” NPT plug covering the air charge valve.

4. Before making any connection to the tank, check the tank and air

charge (use an accurate pressure gauge). The air pressure must be

equal to the minimum system pressure at the tank location.

PLEASE READ THE FOLLOWING INSTRUCTIONS CAREFULLY

5. After making sure the air charge is correct, replace the 1 1/2” plug

over the air valve.

6. The EXTROL®may now be piped to the system (use the suggested

EXTROL®piping diagrams on the next page).

7. Using the table below, select appropriate pipe size. Connection to

each EXTROL®must have a lock shield gate valve and union to allow

isolation and removal if required. Make up and fill valves, whether

manual or automatic, should be tied into the connecting line. This will

ensure that pump operation will not affect valve operation.

Operational Limits

Maximum Operating Pressure: As stamped on nameplate

Maximum Operating Temperature: 240 °F

Minimum Operating Temperature: 35°F (non-glycol application)

If unit is being installed in a glycol system where minimum temperatures

fall below 35°F, contact the AMTROL technical service department at

(401) 535-1216.

Operating Instructions

1. Check the expansion tank pre-charge before the system is filled with

water. The charge is 12 psig unless noted otherwise on the tank label.

Check to make sure this is the correct pre-charge pressure specified

for the system.

2. If the tank pre-charge pressure needs to be changed on a dry system

follow the following procedure:

a. Check the expansion tank air pressures at the pre-charge

connection with an accurate tire type pressure gauge. The

pre-charge connection is the same kind of connection

found on automobile tires.

b. If the pressure is low, charge the tank with nitrogen gas or

with oil free compressed air. Check the pressure frequently

during this process as you would when filling a tire with air.

3. If, after the system has been filled with water and operating, it is found

that the expansion tank pre-charge must be changed use the

following procedure:

a. Turn off the heat source and allow the system water to cool

to ambient temperature.

b. Close the lock-shield valve in the tank-to-system piping.

c. Open the drain valve to empty the water from the tank.

d. Check the tank air pressure at the pre-charge connection

with an accurate tire type air gauge.

e. Refer to 2b above.

f. Close the drain valve, open the lock-shield valve and turn on

the heat source.

g. Relock the lock-shield valve.

IMPORTANT: Expansion tank cannot be properly air

charged other than at ambient temperature.

Firing Rate Length of Pipe Connecting

of Boiler Tank to System:

MBTU/H Below 11’ 11’ – 30’ 31’ – 100’

2,000 1/2” 3/4” 1”

4,000 3/4” 1” 1 1/4”

8,000 1” 1 1/4” 1 1/2”

12,000 1 1/4” 1 1/2” 2”

16,000 1 1/4” 2” 2 1/2”

20,000 1 1/2” 2” 2 1/2”

DANGER: Excessive pressure can cause tank to

explode. Exercise care when filling a tank with air so the

pressure does not exceed that required or does not exceed the

working pressure of the tank as stamped on the nameplate.

Failure to follow these instructions will result in serious

personal injury or death and property damage.

SUGGESTED PIPING DIAGRAMS

ALTERNATE PIPING DIAGRAMS

AMTROL®INC. LIMITED PRODUCT WARRANTY

Products covered: all Products manufactured by AMTROL Inc. (“AMTROL”).

This warranty cannot be transferred – it is extended only to the original Purchaser or First User of the Product. By accepting and keeping this

Product you agree to all of the warranty terms and limitations of liability described below.

IMPORTANT WARNING – READ CAREFULLY THE INSTALLATION, OPERATING AND MAINTENANCE INSTRUCTIONS MANUAL (“MANUAL”) to

avoid serious personal injury and/or property damage and to ensure safe use and proper care of this product.

Who Receives AMTROL’s Product Warranty

All purchasers or first users of the new Product. The Warranty is non-transferable.

What is covered by this Warranty

AMTROL warrants to the purchaser or first user of the new Product that at the time of manufacture, the Product is free from defects in material and

workmanship. Any warranty claim must be made within one (1) year unless another time period is set forth in the Manual, measured from the

time the Product was purchased.

What AMTROL Will Do If You Have a Covered Warranty Claim

In the event of a breach of the foregoing warranty, AMTROL will at its option either make repairs to correct any defect in material or workmanship or

supply and ship either new or used replacement parts or products. AMTROL will not accept any claims for labor or other costs.

What This Warranty Does Not Cover — Exclusions and Limitations

This Warranty does not cover any failure or problem unless it was caused by a defect in material or workmanship. In addition, this Warranty shall not

apply:

• if the Product is not correctly installed, operated, repaired or maintained as described in the Manual provided with the Product;

• to any failure or malfunction resulting from abuse (including freezing); improper or negligent: handling, shipping (by anyone other than AMTROL),

storage, use, operation, accident; or alteration, lightning, flood or any other environmental condition;

• to any failure or problem resulting from the use of the Product for any purpose other than those specified in the accompanying Manual or alteration

of any part of the product;

• if the Product is used anywhere except the United States, its territories or possessions, or Canada;

• this Warranty does not cover labor costs, shipping charges, service charges, delivery expenses, administrative fees or any costs incurred in

removing or reinstalling the Product;

• this Warranty does not cover any claims submitted to AMTROL or an AMTROL-authorized distributor or retailer more than 30 days after expiration

of the applicable warranty time period described in this Warranty;

• this Warranty also does not cover repair or replacement costs not authorized in advance by AMTROL.

Additional Warranty Limitations

ALL IMPLIED WARRANTIES, INCLUDING THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE

ARE SPECIFICALLY DISCLAIMED. Some states do not allow limitations on how long an implied Warranty lasts, so the above limitation may

not apply to you.

Limitations of Remedies

THE REMEDIES CONTAINED IN THIS WARRANTY ARE THE PURCHASER’S OR FIRST USER’S EXCLUSIVE REMEDIES. IN NO

CIRCUMSTANCES WILL AMTROL BE LIABLE FOR MORE THAN, AND PURCHASER-FIRST USER’S REMEDIES SHALL NOT EXCEED, THE

PRICE PAID FOR THE PRODUCT. IN NO CASE SHALL AMTROL BE LIABLE FOR ANY SPECIAL, INDIRECT, INCIDENTAL OR CONSEQUENTIAL

DAMAGES, WHETHER RESULTING FROM NONDELIVERY OR FROM THE USE, MISUSE, OR INABILITY TO USE THE PRODUCT OR FROM

DEFECTS IN THE PRODUCT OR FROM AMTROL’S OWN NEGLIGENCE OR OTHER TORT. This exclusion applies regardless of whether such

damages are sought for breach of warranty, breach of contract, negligence, strict liability, in tort or under any other legal theory. Such damages include,

but are not limited to, inconvenience, loss or damage to property, mold, loss of profits, loss of savings or revenue, loss of use of the Products or any

associated equipment, facilities, buildings or services, downtime, and the claims of third parties including customers. Some states do not allow the

exclusion or the limitation of incidental or consequential damages, so the above limitation or exclusion may not apply to you.

What To Do If You Have a Problem Covered By This Warranty

Any covered Warranty service must be authorized by AMTROL. Contact the person from whom you purchased the Product, who must receive

authorization from an AMTROL distributor or AMTROL. If you do not receive a prompt response, call AMTROL directly at 877-517-9673. Notice of a

Warranty claim should be submitted by the authorized distributor to AMTROL at the following address:

AMTROL Inc.

Warranty Claim Dept.

1400 Division Rd.

West Warwick, RI 02893

Before AMTROL determines to provide any replacement part or Product, it may as a pre-condition to making such a determination require that

the warranty claimant ship the Product, postage prepaid to an authorized AMTROL distributor, or to AMTROL and provide proof of purchase

evidenced by the original sales receipt or Product registration.

Replacement Product Warranty

In case of replacement of a Product or any component part, AMTROL reserves the right to make changes in the design, construction, or material of

the substitute components or products, which shall be subject to all of the terms and limitations of this Warranty, except that the applicable warranty
