Inovonics EN7017 User manual

EN7017 Survey Kit and App Installation
and Site Survey Instructions
Use a mini USB charging cable and any standard USB charger to fully
charge the survey receiver. The LED will light red while charging, and
turn off when fully charged.
3. Download and open the Site Survey App by Inovonics.
Select the Inovonics device that matches the MAC address on the
back of your survey receiver to pair it with the app. Once paired,
the receiver LED will light green.
If located somewhere other than North America, select
your frequency band.
•Survey kit carrying case.
•EN4017SK survey receiver.
•EN1223SK pendant survey
transmitter.
•Mini USB charging cable.
Use a pen or a paper clip to move the switch up to activate the
survey receiver battery. The survey receiver battery can remain
activated indefinitely, and once activated, the survey receiver LED
will blink green until paired.
Install the Survey Kit and App
02.02.17 06818B © Inovonics, 2017 - www.inovonics.com

Press the pendant survey transmitter activation button;
the LED will flash red.
Go to the display screen.
Enter the TXID found on the back of the pendant survey
transmitter to pair it with the app. Once paired,
the signal strength needles will begin to move, indicating
you have successfully completed setup.
02.02.17 06818B © Inovonics, 2017 - www.inovonics.com

Perform a Site Survey
Take the survey receiver and your mobile device to the
first place you plan to install a transmitter.
Place the activated pendant survey transmitter where you plan to
install the Inovonics receiver.
If the average signal strength is green but the current signal
strength dips into the red, you may need a repeater; if the average
and current signal strength are red you will need a repeater.
Look at the app display. If the signal strength is green,
no repeater is needed.
Repeat steps 2 through 5 for each transmitter to be
installed.
If a repeater is needed, walk from the installation point back
towards the pendant survey transmitter. When the average and
current signal strength are consistently green, this is the best
location to place a repeater.
EN1223SK pendant
survey transmitter
Mobile device with
survey app
EN1223SK pendant
survey transmitter
Mobile device with
survey app
EN1223SK pendant
survey transmitter
Mobile device with
survey app
EN1223SK pendant
survey transmitter
Mobile device with
survey app
02.02.17 06818B © Inovonics, 2017 - www.inovonics.com

Close the app and disconnect the receiver when
prompted; the survey receiver will automatically go into
sleep mode.
Press the pendant survey transmitter activation button to turn it
off.
Tips:
• Never store the EN4017SK survey receiver in direct sunlight, such
as on a vehicle dashboard.
• Only charge the EN4017SK survey receiver at room temperature.
• Make sure both Bluetooth®wireless technology and location are
enabled on your mobile device before using the app.
• When surveying a large site, put your mobile device in airplane
mode to conserve battery life.
• Inovonics recommends ensuring your mobile device remains
active, without timing out to the lock screen, while performing site
surveys.
•Depending on the size and complexity of the site, you may find it
useful to refer to a building blueprint or floorplan during your
survey, noting where you plan to install the receiver, transmitters
and any required repeaters.
•You can use the carabiner on the receiver to keep it attached to
your person while performing the survey.
• You can use any Inovonics transmitter with the app however
we recommend the EN1223SK pendant survey transmitter or the
EN1210SK universal survey transmitter, sold separately.
• You can also use the survey app to verify message delivery with
the apps’ status indicator.
- If the status indicator is flashing five times per second or more,
then message receipt is fine. Anything less means you are dropping
messages.
- Repositioning the transmitter to avoid obstacles like metal
barriers and electronic equipment can help improve message
receipt.
- If message receipt remains low, consider adding a repeater.
•For guidance on RF gateway placement see the RF gateway’s
installation instructions and the “EchoStream Device Installation
Recommendation” tech note. Both are available at www.inovonics.
com.
•The signal from a single Inovonics transmitter will generally cover
25,000 square feet in an indoor environment. Addition of a repeater
will generally expand that range to 50,000 square feet.
•If you have any problems, contact Inovonics technical services at
[e-mail] or [phone].
