Inscape Data Link Power LPS3800-T2 Series User manual

Page | 1
Link Power LPS3800-T2 Series
Outdoor Industrial 8-Port PoE
2-RJ45 & 4-Port SFP Network
Switch
USER MANUAL
Inscape Data Corporation
1620 Oakland Road, STE D101
San Jose, CA 95131
U.S.A.
© Copyright 2015, Inscape Data Corporation, All Rights Reserved. LinkPower, AirEther, AirGoogle,
and Inscape Data are trademarks of Inscape Data Corporation
Disclaimer: While every effort is made to ensure the information given is accurate, Inscape Data
Corporation does not accept liability for any errors or mistakes which may arise. All information and
specifications are subject to change without notice.

Page | 2
Certification
Inscape Data Corporation certifies that this product met its published specifications at time of
shipment from the factory.
FCC Statement
This equipment has been tested and found to comply with the limits for a Class A digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio frequency energy and, if
not installed and used in accordance with the instruction manual, may cause harmful
interference to radio communications. Operation of this equipment in a residential area is likely
to cause harmful interference in which case the user will be required to correct the interference
at his own expense.
The user is cautioned that changes and modifications made to the equipment without approval
of the manufacturer could void the user's authority to operate this equipment.
The manufacturer is not responsible for any radio or TV interference caused by unauthorized
modifications to this equipment. Such modifications could void the user’s authority to operate
the equipment.
Industry Canada Statement
This Class A digital apparatus complies with Canadian ICES-003.
CE Statement
This product complies with the European Low Voltage Directive 73/23/EEC and EMC Directive
89/336/EEC as amended by European Directive 93/68/EEC.
Warning: This is a class A product. In a domestic environment this product may cause radio
interference in which case the user may be required to take adequate measures.

Page | 3
Safety Summary
The following general safety precautions must be observed during all phases of operation of this
instrument. Failure to comply with these precautions or with specific warnings elsewhere in this
manual violates safety standards of design, manufacture, and intended use of the instrument.
Inscape Data Corporation assumes no liability for the customer’s failure to
comply with these requirements.
Before Applying Power
Verify that the product is set to match the available line voltage and all safety precautions are
taken.
Over Temperature Warning
To prevent the switch from overheating, do not operate it in an area that exceeds the maximum
recommended ambient temperature of (75°C). To prevent product cooling restriction, allow at
least 3 inches (7.6 cm) of clearance around the product after installation.
Ground the Instrument
To minimize shock hazard, the instrument chassis and cabinet must be connected to an
electrical ground. The instrument must be connected to the ac power supply mains through a
three-conductor power cable, with the third wire firmly connected to an electrical ground (safety
ground) at the power outlet. For instruments designed to be hard-wired to the ac power lines
(supply mains), connect the protective earth terminal to a protective conductor before any other
connection is made. Any interruption of the protective (grounding) conductor or disconnection of
the protective earth terminal will cause a potential shock hazard that could result in personal
injury.
When installing the unit, always make the ground connection first and disconnect it last.
Jewelry Removal Warning
Before working on equipment that is connected to power lines, remove jewelry (including rings,
necklaces, and watches). Metal objects will heat up when connected to power and ground and
can cause serious burns or weld the metal object to the terminals.
Do not Operate in Explosive Atmosphere
Do not operate the product in the presence of flammable gases or fumes.

Page | 4
Chassis Power Connection
Before connecting or disconnecting ground or power wires to the chassis, ensure that power is
removed from the device. To ensure that all power is OFF, locate the circuit breaker on the
panel board that services the device, switch the circuit breaker to the OFF position, and tape the
switch handle of the circuit breaker in the OFF position.
Work During Lightning Activity
Do not work on the system or connect or disconnect cables during periods of lightning activity.
Comply with Local and National Electrical Codes
Installation of the equipment must comply with local and national electrical codes
Do Not Exceed Input and Output Ratings
Do not operate the product to exceed the power input and output ratings.
This product Conforms to the following safety standards
Specification
Description
Regulatory Compliance
Products with the CE Marking are compliant with the 89/336/EEC
and 73/23/EEC directives, which include the safety and EMC
standards listed.
Safety
UL/CSA 60950
UL 60601-1
IEC 60950 with all country deviations
EN60950
EMC
FCC Part 15 Class A
CE Marking

Page | 5
Packing List:
Each package includes the following items:
1. LPS3800AF-T2 or LPS3800AT-T2 (1)
2. WM0001 Wall Mounting Kit (1)
3. WECK0001 Waterproof Ethernet Connector Kit (10)
Eight (8) WECK0001 for Gigabit PoE Ports
Two (2) WECK0001 for Gigabit RJ45 Uplink Ports
4. WPCK0001 Waterproof Power Cable Kit (1)
5. FOWC0001 Fiber Optic Waterproof Connector - OPTIONAL
6. User Manual (1)
7. Warranty Sheet (1)

Page | 6
Product Description
LPS3800-T2 Series Outdoor Industrial PoE Switch features with four PoE Ethernet ports and comply to
10/100/1000BaseT(X), IEEE802.3af/at PoE and two RJ45 and four Gigabit SFP fiber optics uplink
interfaces. Each of the PoE ports supplies DC power up to 15.4W for 802.3af and 25.5W for 802.3at. The
transfer data is up to 120Km from SFP fiber port to a control center. Additionally, the product also
features with an anti-electromagnetic interference designed for harsh outdoor applications, and the
3KV network port surge protection adapts to harsh outdoor environment and ensures the reliability of
the uninterrupted PoE operations. The system is rated at IP67, and the system is able to operate under 40˚
C ~ +75˚ C temperature range.
Product Features
1. Comply to IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.3ab, IEEE 802.3x, IEEE 802.1D, IEEE
802.3at, IEEE 802.3af, IEEE 802 . 1Q IEEE 802.1p, IEEE 802.1x, IEEE 802.1W, SNMP, IGMP
s t andards
2. 10/ 100/ 1000M self-sensing RJ45 port, support PoE power supply f unc t ion ; All ports support
auto-flip (Auto MD I/ MD I X) ;
3. Each PoE port can provide power up to 15.4W per IEEE 802.3af standard and 30W per
IEEE802.3at standard ; Supply power for powered devices compatible with I EEE802 . 3a f/at;
4. Support IEEE802.3x full duplex flow control and duplex backpressure flow con t rol ;
5. 8.8G backplane bandwid t h ;
6. 1K MAC address t able ;
7. Its 3KV network port surge protection can adapt to harsh outdoor environmen t; Under the
temperature of -40˚~ +75˚ C, working at a full load 150W for IEEE802.3af and 225W for
IEEE802.3at;
8. The four gigabit SFP fiber ports are capable of high bandwidth and for up to 120KM long
distance t ransmission.
System Overview:
Figure 1 shows the detailed view of all the connectors of the system:
i. AC & DC Power: 5-PIN Power Input Connector
ii. LAN 1 ~ LAN8: Gigabit PoE Ports
iii. SFP 1 ~ SFP 4: Gigabit Fiber Optic Uplink Ports
iv. RJ45 1 & RJ45 2: Gigabit RJ45 Uplink Ports
v. RESET: System Reset Switch
vi. SYS: System LED
vii. Vent: Ventilation Port for moisture and condensation
Figure 1: Direct Front View with Detailed Connector Layout

Page | 7
Power Input Installation:
The system supports DUAL POWER INPUT REDUNDANCY:
The WPCK0001 Waterproof Power Cable has five colored wires, i.e., Red, Black, Yellow, Blue,
and Green Wire
Wire polarity and AC/DC assignment are based on the following wire color scheme:
110 ~ 240V AC: Yellow (AC/N ), Green (AC/L ), Blue Unused
48V DC: Red (+), Black ( –)
AC Power can be used as the main power input, or you can use the DC power as either a
backup power or main power input when the AC power is not available
After the AC power or DC power connected, the switch will automatically initialize, and SYS LED
lights status will turn ON
PoE Installation:
1. Before the PoE installation, please ensure the following:
I. All PD devices, i.e., PoE Clients, meet the power requirement of the connecting devices.
II. All PD devices, i.e., PoE Clients, match with the power receiving device power pinout
specification (1/2+ & 3/6–)
2. Connect the network devices with network cables to the POE switch port though WECK0001
Waterproof Ethernet Connector, Figure 2, an outdoor grade Ethernet cable with UV resistant is
highly recommended,
Figure 2: WECK0001 Waterproof Ethernet Connector
Route the outdoor Ethernet cable through the WECK0001 and refer to the following assembly
structure, Figure 3:
Figure 3: WECK0001 Waterproof Ethernet Cable Assembly

Page | 8
Uplink Fiber Optical and RJ45 Cable Installation:
1. RJ45 Uplink Cable: Two WECK0001 kits are included as the standard package. Simply follow
Figure 2 to assemble the connector with an Ethernet cable and connect to RJ45 1 and RJ45 2
Uplink Ports to a backbone Gigabit Network Switch
2. SFP Uplink Cable: SFP 1 ~ SFP 4 Uplink Ports are used to connect the system with a fiber optic
infrastructure or a Backbone Gigabit Fiber Optical Network Switch with the following steps:
a. FOWC0001 Fiber Optic Waterproof Connector is an optional accessory. When purchase,
please follow Figure 4 for fiber cable and connector assembly.
b. Attach the duplex LC connector, FOWC0001, with the fiber optic cable into one of the
active SFP Ports
c. Connect the other end of the cable to a device - a Fiber Optical Network Switch or a
Media Converter.
Figure 4: WECK0001 Waterproof Ethernet Cable Assembly

Page | 9
RESET Switch:
To reset the system, please hold and press the RESET Switch for 9 seconds. The system will reset
automatically.
Uplink Fiber Optical Application Reference:
Figure 5 shows one of the applications using LPS3800AF-T2 in a self-healing Gigabit fiber optic backbone system.
FIGURE 5 Self-Healing Gigabit Fiber Optic Backbone System
Optional Accessories:
The following optional accessories can be order if required:
1. Mast/Pole Mounting Kit (Part No: MMK0001)
2. Fiber Optic Waterproof (Part No: FOWC0001)
3. Waterproof RJ45 Coupler Kit (Part No: WRCK0001)

Page | 10
System Specifications:
Contacting Inscape Data Sales and Support Offices
For more information about Inscape Data Corporation products, applications, support, and for a current sales office
listing, visit our web site: http://www.inscapedata.com
U.S. Headquarters
Here’s how to reach us if you’d like to place an order or if you have questions, concerns, or need support
Telephone
Postal Mail
North and South America
Customer Service and Orders:
Main: [phone]
Fax: [phone]
Monday - Friday
9:00 AM - 5:00 PM
Pacific Time UTC -7:00
Inscape Data Corporation
1620 Oakland Road, Suite D101
San Jose, CA 95131
U.S.A.
ELECTRICAL PIN OUT DIAGRAM

Page | 11
