SIIG CE-KV0011-S2 User manual

1
2x1 USB HDMI KVM Switch
Installation Guide
04-0747C
Introduction
The 2x1 USB HDMI KVM Switch shares one
HDMI display between two HDMI sources.
Key Features and Benefits
• Share an HDTV or display, USB keyboard
& mouse, and microphone between 2 USB/
HDMI computers and devices
• Provides 2 additional USB 2.0 sharing ports
with over-current detection and protection
• Switch between devices via front push
button or hotkey
• Supports 4Kx2K with 36-bit Deep Color
and PC's WUXGA 1920x1200 resolutions
• Supports Dolby True HD and DTS HD
Master Audio formats
• HDMI v1.4 and HDCP compliant
• Video bandwidth: up to 3Gb/s
• Metal housing for better RF shielding

2
Layout
Figure 1: Front Panel Layout
Select
USB Ports USB Keyboard
& Mouse Ports
MIC HDMI
OUTPUT
LED
Package Contents
• 2x1 USB HDMI KVM Switch
• Power adapter
• 2 cable sets
• Installation guide
Compatibility
• Windows, Mac, Linux computers
• Game consoles, Blu-Ray DVD players, and
other CE devices

3
Figure 2: Rear Panel Layout
•Power Jack: Connect to the included power
adapter
•HDMI INPUT: Connect to source device's
HDMI
•MIC: Connect to PC's MIC
•USB Port: Connect to PC's USB port
Power Jack
HDMI
INPUT MIC USB Port
•USB Ports: Connect to other USB devices
•USB Keyboard & Mouse Ports: Connect to
USB keyboard and mouse devices
•MIC: Connect to microphone
•HDMI OUTPUT: Connect to HDMI display
•LED: Indicate which HDMI source is
selected
•SELECT: Switch between the HDMI sources

4
Hardware Installation
1. Power off all devices you plan to connect to
the 2x1 USB HDMI KVM Switch.
2. Connect a monitor/display to HDMI
OUTPUT of the switch by an HDMI cable
(not included).
3. Connect a USB keyboard and a USB mouse
to USB keyboard and Mouse Ports of the
switch.
4. Connect the computer's HDMI connector
to the switch's INPUT 1 connector using
the included HDMI cable.
5. Connect the computer's USB port to the
switch's PC1 connector (USB Type B) using
the included USB cable.
6. Use the included 3.5mm mini-jack audio
cable to connect the computer's microphone
connector to the switch's MIC port
associated with PC1.
7. For the second computer, follow steps 4 to
6 to connect the preferred system/device to
INPUT 2 and PC2.

5
8. Optional: Connect other USB peripherals
you wish to share between the connected
computers/devices to the extra USB ports
on the switch.
9. Connect the power adapter into the switch's
Power Jack.
10. Power up the first computer/device and
wait until it is fully booted up. Make sure
the keyboard and mouse work properly.
11. Once the first computer system is
successfully setup, press the Switch button
and power up the second computer/device
to verify the setup properly.
12. The installation is complete and the 2x1
USB HDMI KVM Switch is ready for use.
Note: At least 1 connected device has to be
a PC with USB port. Otherwise, the
switching mechanism couldn't work. If
you want to connect a DVD player or
game console to this switch, make sure the
PC is connected to HDMI INPUT1.

6
Hotkey
Default setting, all of the following commands
begin by pressing the [Scroll Lock] key twice.
Please Follow the hotkey command listed below
for selected operating functions:
Note:
1. You can change the default setting to [ctrl][ctrl], If you are using a Mac Keyboard
or a keyboard that does not have Scroll Lockkey.
2. Autoscan through each channel for quick screen browsing (default = 15 seconds).
3. You can set the auto scan interval according to the steps. (N = Number, 5~599)
Hot key Definition
[Scroll Lock] + [Scroll Lock] + [Ctrl] + [Enter] Change [Scroll Lock] [Scroll Lock] to [Ctrl][Ctrl]
(Note 1)
[Ctrl] + [Ctrl] + [Scroll Lock] + [Enter] Change[Ctrl] [Ctrl]to [Scroll Lock] [Scroll Lock]
[Scroll Lock]+[Scroll Lock]+[NUMBER1~2]+[Enter] Switch input 1~2 source to output
[Scroll Lock] + [Scroll Lock] + [S] Auto Scan/ Exit Auto Scan mode (Note 2)
[Scroll Lock] + [Scroll Lock] +[I] + [N] + [Enter] Auto Scan Set [N]: 5~599 (Note 3)
[Scroll Lock] + [Scroll Lock] +[+] Auto Scan Interval Add 5 Seconds
[Scroll Lock] + [Scroll Lock] +[-] Auto Scan Interval Subtract 5 Seconds

7
Technical Support and Warranty
QUESTIONS? SIIG’s Online Support has answers! Simply visit our web site at
www.siig.com and click Support. Our online support database is updated daily with
new drivers and solutions. Answers to your questions could be just a few clicks away.
You can also submit questions online and a technical support analyst will promptly
respond.
SIIG offers a 3-year manufacturer warranty with this product. This warranty covers the
original purchaser and guarantees the product to be free of any defects in materials or
workmanship for three (3) years from the date of purchase of the product.
SIIG will, at our discretion, repair or replace (with an identical product or product
having similar features and functionality) the product if defective in materials or
workmanship. This warranty gives you specific legal rights, and you may also have other
rights which vary from state to state. Please see our web site for more warranty details.
If you encounter any problems with this product, please follow the procedures below.
A) If it is within the store's return policy period, please return the product to the store
where you purchased from.
B) If your purchase has passed the store's return policy period, please follow the steps
below to have the product repaired or replaced.
Step 1: Submit your RMA request.
Go to www.siig.com, click Support, then REQUEST A PRODUCT REPLACEMENT
to submit a request to SIIG RMA or fax a request to 510-657-5962. Your RMA request
will be processed, if the product is determined to be defective, an RMA number will
be issued.
Step 2: After obtaining an RMA number, ship the product.
• Properly pack the product for shipping. All accessories that came with the
original package must be included.
• Clearly write your RMA number on the top of the returned package. SIIG will
refuse to accept any shipping package, and will not be responsible for a product
returned without an RMA number posted on the outside of the shipping
carton.
• You are responsible for the cost of shipping to SIIG. Ship the product to the
following address:
SIIG, Inc.
6078 Stewart Avenue
Fremont, CA 94538-3152, USA
RMA #:
• SIIG will ship the repaired or replaced product via Ground in the U.S. and
International Economy outside of the U.S. at no cost to the customer.
