Insignia NS-55D510NA19 User manual

QUICK SETUP GUIDE
55"1080p
60Hz DLED TV
NS55D510NA19
FEATURES
B
YourT V has fourVESA mounting holes on the back. If you attach a wall-mount bracket to the
back of your TV, the bracket must be securely attached, using all four holes. If you do not
use all four mounting holes, your TV may fall and cause property damage or personal injury.
See the documentation that came with your wall-mount for complete mounting instructions.
A
1START HERE
How do I attach the stand to my TV? (not for wall mounting)
You’ll need: Soft surface and Phillips screwdriver
Place your TV face-down on a cushioned, clean surface.
Align the screw holes on the TV stands with the holes on the bottom of your TV, then secure each stand to your TV with two of
the provided screws.
WALL MOUNT
How do I prepare my TV for wall mounting? (not for use with a TV stand)
You’ll need: Soft surface and Phillips screwdriver
OR
Before you mount your TV, make sure that:
• You remove the stand.
• The bracket supports the weight of yourTV.
A Carefully place your TV face-down on a cushioned, clean surface.
BSee the instructions that came with your wall mount for more information
about how to correctly mount your TV.
Note: Images do not necessarily represent the exact design of your television.
Power indicator
Remote control sensor
VIDEO AUDIO R
L
VESA Mounting Pattern
VESA mount(mm): 400x400mm-M6,12mm length
NS-55D510NA19
VIDEO AUDIO R
L
M5 screws (15 mm length)
2MAKING CONNECTIONS
How do I watch TV (cable, satellite, or antenna) or connect a device, such as a DVD or Blu-ray player,
game console, or tablet?
WHICH CABLES DO YOU HAVE?
HDMI (BEST)
Best video quality
AV (GOOD)
COAXIAL (GOOD)
Multi-purpose jacks: You can plug any device that uses HDMI into any HDMI jack.
However, certain devices must be connected to the HDMI 1(ARC) jack. See the instructions
that came with your ARC device for more information.
AUDIO/VIDEO OUT
Before using your new product, please read these instructions to prevent any damage.
INCLUDED ACCESSORIES
Remote control and two AAA batteries
TV stands
M5 screws (15 mm length) (4 pcs.)
!
FIND YOUR USER GUIDE ONLINE!
1 Go to www.insigniaproducts.com.
2 Use the search bar to nd NS-55D510NA19.
3 Select Support & Downloads.
4 Next to User Guide, select the language you want.
STOP
Do not plug your power cord in until all
other devices have been connected.
GAME
ASPECT
CC
ACC
AAA
+
AAA
+
C
M
Y
CM
MY
CY
CMY
K
NS-55D510NA19_17-0905 _QSG_V1_EN_Final.ai 1 12/27/2017 2:26:51 PMNS-55D510NA19_17-0905 _QSG_V1_EN_Final.ai 1 12/27/2017 2:26:51 PM

Note: See the instructions that
came with your speakers or
soundbar for more information.
V1 ENGLISH 17-0905
ONEYEAR LIMITED WARRANTY
Visit www.insigniaproducts.com for details.
NEED ADDITIONAL HELP?
Check out our Support Community at
http://community.insigniaproducts.com/ for
helpful information from other
Insignia TV owners.
WE’RE HERE FOR YOU
www.insigniaproducts.com
For customer service, call:
877-467-4289 (U.S./Canada )
U.S. and Canada:
INSIGNIA is a trademark of Best Buy and its
aliated companies.
Registered in some countries.
Distributed by Best Buy Purchasing, LLC
7601 Penn Ave South, Richeld, MN 55423 U.S.A.
©2018 Best Buy. All rights reserved.
Made in China
From yourTV's Audio menu, select
Audio Format/Audio Delay, then
set Audio Format to PCM.
SOUNDBAR
OPTICAL
AUDIO IN
USING ANALOG AUDIO
AUDIO IN
3CONNECTING AUDIO DEVICES
How do I connect my TV to external speakers?
USING DIGITAL AUDIO
OR
USING YOUR REMOTE CONTROL
I already have a universal remote control. How do I make it control this TV?
If you already have a universal remote control that you would like to program to work with your TV and don’t want to use the included
Insignia remote control, see the table below for common codes.
AT&T Uverse
Cablevision
Charter
Comcast
Cox
DirecTV
Dish Network
RCA
Rogers
Time Warner
Verizon
1034, 1035, 1040, 1398, 1465, 1596, 1437, 1507, 12049, 11641, 11564, 11326, 11423, 11892, 11517, 10171, 10463, 11385,
11660, 11963, 12184, 13227
068, 069, 078, 096, 100, 164, 168, 229, 026
2002, 1204, 1423, 1517, 0171, 1963, 0463, 1463, 0842, 1326, 167, 415, 424, 450, 456, 461, 507, 523, 567, 577, 586
10463, 10171, 11204, 11326, 11463, 11517, 11641, 11780, 11785, 11892, 11963, 12002, 01877, 00276, 01982, 01376, 00810,
01187, 01106, 00877, 00476
1326, 1463
10463, 10171, 11204, 11326, 11517, 11564, 11641, 11963, 12002, 11463, 12049
834, 720, 222, 898, 365, 777, 754
135, 12049, 11423, 11564, 10171, 10463, 11810, 11892, 11963, 12184, 12417
0463, 1326, 2049, 1785, 1780, 1423, 1963
400, 450, 461, 456, 10463, 1463, 0463
0198, 0490
UNIVERSAL REMOTE CONTROL CODES
For an up-to-date list of codes for other cable providers and universal remote brands, visit www.insigniaproducts.com/remotecodes
GAME
ASPECT
CC AC C
Recall
Returns to the previous
channel.
GAME
Adjusts the picture for the
ultimate gaming
experience.
INPUT
Opens the INPUT SOURCE list.
Power
Numbers
Enter channel numbers
or the parental controls
password.
MENU
Opens the TV menu.
ENTER
or changes.
EXIT
Closes the TV menu.
SLEEP
Sets the sleep timer.
INFO*
Opens a TV status banner.
ACC
Opens the Accessibility
menu.
MUTE
Mutes the sound.
Enters a digital
sub-channel number
(for example 4.1).
FAVORITE
Opens the Favorite Channel
List.
CC
Turns closed captioning
Arrows
Navigate in on-screen
menus.
Channel
Changes the TV channels.
ASPECT
Changes how the picture
is displayed on the screen.
Volume
Changes the volume.
Selects the video mode.
Media controls
INlink: Control HDMI-CEC
devices
connected to your TV.
AUDIO
Selects the audio mode.
Easy Setup • Choose your Menu Language
English
Français
Español
2 Remove the remote control cover
and install the batteries.
3 Press on your remote control.
4 Follow the on-screen instructions.
4TURNING ON MY TV
When can I turn on my TV?
WHEN YOUR TV IS IN PLACE:
1 Plug the power cord into a power outlet.
AAA
+
AAA
+
Input Source
TV
HDMI1
HDMI2
HDMI3
AV
USB(Photos)
C
M
Y
CM
MY
CY
CMY
