Insignia NS-32D311NA15 User manual

QUICK SETUP
GUIDE
32" LED TV
NS-32D311NA15
Included accessories
Which cables do you have?
Your TV has several dierent jacks for connecting devices. For the
best video quality, use the best available connection.
Note: You can also connect a DVI device to your TV. See your online User Guide for
connection instructions.
Note: Images may not necessarily represent the exact design of your television.
Features
Front view
Back view
OVER
HDMI video/audio
Component video and analog audio
Composite video and analog audio (AV)
Coaxial video/audio
STOP!
Do not plug your
power adapter in
until all other devices
have been
connected.
Multipurpose jacks: You can plug any
device that uses HDMI into any HDMI
jack. However, certain devices must be
connected to the HDMI1 (MHL) or
HDMI2 (ARC/DVI) jack. See the
instructions that came with your MHL,
ARC, or DVI device for more information.
Note: The HDMI2 (ARC/DVI) jack is a
shared jack. This means you can only
connect one DVI or ARC device at a
time.
Note: The component video and AV
jacks are shared. This means you can
connect only one component video or
AV device at a time. We suggest using
HDMI if your device supports it.
Using an HDMI cable (BEST)
How do I connect my TV to an antenna or cable wall jack?
MAKING CONNECTIONS
- OR -
How do I prepare my TV for wall mounting?
(not for use with a TV stand)
You’ll need: A soft surface to lay the TV on.
A Carefully place your TV face-down on a cushioned, clean surface to protect the screen from damages and scratches.
B See the instructions that came with your wall mount for more information about how to correctly mount your TV.
START HERE
How do I attach the stand to my TV?
(not for wall mounting)
You’ll need: A Phillips screwdriver and a soft surface to lay the TV on.
A Carefully place your TV face-down on a cushioned, clean surface to
protect the screen from damages and scratches.
B
Secure the stand column to your TV with the ve provided M4 × 8 mm screws
(the short screws).
C Secure the TV stand to the stand column with the four provided B4 × 18 mm
screws (the long screws).
Note: Connect the yellow video cable
connector to the green VIDEO/Y jack
on the back of your TV.
Using component cables (BETTER)
- OR -
Using an AV cable (GOOD)
Remote control
and two AAA batteries
T
Stand column
V stand
B
AC
B4 × 18 mm screws
M4 × 8 mm screws Front
How do I watch TV (cable or satellite receiver) or connect a device such as a DVD or
Blu-ray Disc player, game console, Roku Streaming Stick™, or MHL-enabled device?
DC IN
Thank you
for purchasing this state-of-the-art
Insignia television. We hope you enjoy
the quality and reliability of this
television for years to come.
Roku Ready®
Your TV is certied to work with the
Roku Streaming Stick™.
Instantly stream 1000+ entertainment
channels, including Netix, Hulu Plus,
Pandora, and more. Connect the
Streaming Stick (not included) to the
purple MHL port on your TV and enjoy.
FIND YOUR
USER GUIDE ONLINE!
We are going green so a copy of your
User Guide is not provided in the box
but is available online.
Go to www.insigniaproducts.com,
then click Support & Service. Enter your
model number in the box under Manual,
Firmware, Drivers & Product Information,
then click .
Power indicator
Remote control sensor
INPUTMENU CH CHVOL+-LOV
Note: The control buttons are on the
bottom edge of the screen.
(ARC/DVI) (OPTICAL)
(MHL)
CABLE
VIDEO QUALITY
BEST
BETTER
GOOD
GOOD
JACK TYPE CABLE CONNECTOR
Before using your new product, please read these instructions to prevent any damage.
Component cable option
AV cable option
AUDIO/ VIDEO
OUT
AUDIO/VIDEO OUT
DC IN PC / DVI
AUDIO IN VGA ANT / CABLE
Power adapter
B4 screws (18 mm length)
(4 pcs. )
M4 screws (8 mm length)
(5 pcs.)
(ARC/DVI) (OPTICAL)
(ARC/DVI) (OPTICAL)
(MHL)
DC IN
(MHL)
(ARC/DVI)
(MHL)
(ARC/DVI) (OPTICAL)
(MHL)

32" LED TV IQUICK SETUP GUIDE I NS-32D311NA15
One-year limited warranty
Visit www.insigniaproducts.com for details.
Need additional help?
See your online User Guide! This
comprehensive guide includes everything
from basic how-to steps to more advanced
features. A copy of your User Guide is not
provided in the box but is available online.
Go to www.insigniaproducts.com,
then click Support & Service. Enter your
model number in the box under Manual,
Firmware, Drivers & Product Information,
then click .
Check out our Support Community
http://community.insigniaproducts.com/
for helpful information from other Insignia
TV owners.
We’re here for you
www.insigniaproducts.com
For customer service, call:
877-467-4289 (U.S./Canada)
INSIGNIA is a registered trademark of BBY Solutions, Inc.
Registered in some countries.
Distributed by Best Buy Purchasing, LLC,
7601 Penn Ave South, Richeld, MN 55423 U.S.A.
©2014 BBY Solutions, Inc.
All Rights Reserved
1-877-467-4289
www.insigniaproducts.com
Using digital audio
Using analog audio
Note: Refer to the instructions that came
with your speakers for more information.
Note: Refer to the instructions that came
with your speakers for more information.
I already have a universal remote control. How do I make it control this TV?
Using your remote control
The best time to turn on your TV is after you have attached
the TV stand or wall-mounted your TV and
connected all devices.
1 Plug the AC power adapter into the DC IN
connector on the back of your TV.
2 Plug the other end of the adapter into a
power outlet.
3 Install the remote control batteries.
Remove the remote control cover and
install the batteries, matching
the + and - symbols.
4Press (power) on your remote control.
5Follow the on-screen instructions.
UNIVERSAL REMOTE TV CODES
CABLE BOX, SATELLITE BOX, OR OTHER SET-TOP BOX
Cablevision 068, 069, 078, 096, 100, 164, 168, 229, 026
2002, 1204, 1423, 1517, 0171, 1963, 0463, 1463, 0842, 1326, 167, 415, 424, 450, 456, 461,
507, 523, 567, 577, 586
Comcast 10171, 11204, 11326, 11463, 11517, 11641, 11780, 11785, 11892, 11963, 12002
Cox 1326, 1463
Direct TV 10171, 11204, 11326, 11517, 11564, 11641, 11963, 12002
Dish Network 720
Time Warner 400, 450, 461, 456, 10463, 1463, 0463
Tivo 0091
Verizon 0198, 0490
One for All 0054
Philips 0198, 0490
RCA 135
Sony 068, 069, 078, 096
CONNECTING AUDIO DEVICES
How do I connect my TV to external speakers?
For an up-to-date list of codes for other
cable providers and universal remote brands,
scan this QR code or visit
www.insigniaproducts.com/remotecodes
TURNING ON MY TV
When can I turn on my TV?
UNIVERSAL REMOTE CONTROLS
