Firmwareupdate:Download/InstallinstructionsforTVModel:NS‐L46Q120‐10A
Systemrequirements:acomputerwithanopenUSBport,USB2.0flashdrive(stick),broadband
internetaccessandoperatingsoftwareofWindowsXP,WindowsVista,Windows7orMacOS10.3or
newer.Thisoptionisnotrecommendedwithdial‐uporDSLservicewithabitratelowerthan256kbps.If
theinstructionsprovidedbelowdonothelp,callInsigniaCustomerSupportat(877)467‐4289for
assistance.
First:Downloadtheupdatefile
1. InsertUSBflashdriveintotheopenUSBportonyourcomputer.
2. Downloadfirmware(ZipFile);ifapop‐upwindowopenstellingyoutoopen,saveorcancel,click
SaveandsavethefiletoyourUSBflashdrive.Note:Fileneedstobesavedontherootdirectory.
Note:Filesizeisapproximately3.5MB.Estimateddownloadtimeis1‐2minutes(witha1.5
Mbpsbroadbandconnection).
3.UnzipthefileandsaveastwoseparatefilesonyourUSBdrive.
4.DeletethezipfilefromyourUSBdrive.
5.AftersavingthefirmwaretoyourUSBflashdrive;removetheUSBflashdrivefromyour
computer.
Second:UpgradingtheTVSoftwarewithaUSBFlashDrive(Stick)
1. MakesureyouTV’sACcordissecurelypluggedintoawalloutletandtheunitisturnedoff.This
canbeverifiedbyaredindicatorlightonthebottomfrontoftheTV.
2. InserttheUSBflashdrivecontainingthefirmwarethatwasdownloadedintotheTV’sUSB
serviceportlocatedonthebackoftheTV.Note:Thisportmaybecoveredbyarubberflap,you
mayneedtoflipopentherubberflap(Seephotobelow).

3. TurntheTVonusingtheremotecontrolorpowerbuttononthesideoftheTV.
4. Ascreensimilartotheonebelowwillappear(Note:ifthereisno“Pleasewait…”menu
displayed;youcanturnyourTVoff,thenturntheunitbackon):



5. Thesoftwareupdatewillthenbeginautomatically;theprogressbarwillfilltwotimes.Thefirst
timethebarwillbeblue;thesecondtimeitwillbered/orange.Seeimageofsecondprogress
barbelow:

Note:DONOTTURNTHEPOWEROFFORUNPLUGDURINGTHEUPDATE
Note:Duringthesoftwareupdate,aprogressbarwillappeardisplayingtheprogressofthe
update;thisupdatetakesapproximatelyone(1‐2)minutes.
6. Oncetheupdatehascompleted,ascreenaskingyouto“ChooseyourmenuLanguage”will
appear.Whenyouseethisscreendonotselectalanguagepleasemovetostep7.
7. TurnoffyourTVviatheremotecontrolorthepowerbuttononthesideoftheTV.
8. RemovetheUSBflashdrive(stick)fromtheTV.
9. PoweryourTVbackon.OncetheTVispowereduptheprocessiscompleteandyouwillseethe
same“Chooseyourmenulanguage”screenandrefertoyouruser’smanualforTVsetup.
Note:Itisrecommendedthatyouerase/deletetheupdatefilefromtheUSBflashdriveusing
yourcomputerpriortousingtheUSBflashdriveagain.
Note:Youwillneedtoreprogramyourfavoritechannelsandanycustomsettingsthatyoumay
havesetup.
Note:Ifyouexperienceanyissueswhileperformingthisupgrade,callInsigniaCustomerSupport
at(877)467‐4289forassistance.


May2010
