insize IST-2WM Series User manual

MN IST- -2WM SERIES-E
V0
IST-2WM SERIES
TORQUE WRENCH
OPERATION MANUAL

1 2
12
6
57
TORQU ES
NEWTO N-METER
16
20
24
28
18
22
26
30
14
0.4 01.60.8
34
1 Wrench head 2 Tough and robust steel tube with chrome-plated
3 Torque value scale 4 Handle 6 Change the direction
7 Torque set and lock ring
5 Square driver
0.4 01.60.8
After the first using or being left unused for longer time and it is
required to use once again, be sure to use higher torque to
operate for 5~10 times so that the components within may be fully
lubricated by the special-purpose lubricant oil. When it is not
used, be sure to set the torque to the lowest value.
Attention
Don’t use the wrench as a hammer.
Don’t use the wrench in any liquid.
Don’t keep applying pressure after reaching the preset torque,
otherwise, the work piece may be damaged.
Description
Structure:
1.6
Operation
Pull and hold the to the position as below shown.lock ring
Choose the required torque and turn the handle to set the
required torque.
2
1
3Release the lock ring as shown after set.
4Apply force on the handle of torque wrench and then stop
applying force upon hearing “click” sound.
Note: Only use the torque wrench in clockwise that you can hear the
“click” sound when reach the preset torque.
Maintenance
1Do not shake violently or drop wrench.
2Do not leave this wrench in any place exposed to excessive heat,
humidity, dust, sand.
3Do not use organic solvents, such as alcohol or paint thinner
when cleaning the wrench.
4When the wrench is not used for an extended period of time, put
the wrench in box for storing.
