Instanta Titan Pro Bulk User manual

Titan Pro Bulk Water Boiler
MOD18
INSTALLATION and USER INSTRUCTION MANUAL
Serial Number: __________
IB18 - Issue: 3

CONTENTS
1.0 INTRODUCTION
2.0 ACCESSORIES (check list)
3.0 WARNING AND PRECAUTIONS
4.0 INSTALLATION
4.1 Work surfaces and location
4.2 Water connection
4.3 Electrical connection
4.4 Overflow/waste
5.0 INITIAL COMMISSIONING
6.0 USER INSTRUCTIONS
6.1 Daily Operating Instructions
6.2 Cleaning
6.3 Maintenance
7.0 TECHNICAL SPECIFICATION
8.0 DE-SCALING
9.0 FAULT DIAGNOSIS (service warning light)
1.0 INTRODUCTION
Your new Water Boiler is designed to give years of trouble-free service provided that
the instructions contained in this manual are followed.
Instanta products are energy efficient, simple to operate and easy to service.
Installation is straightforward but it is recommended that this, be carried out by a
properly qualified fitter.
2.0 ACCESSORIES
The new boiler is supplied with the following components and should be verified
before installation:
1. Non-toxic flexible hose assembly (WRAS approved)
2. One chrome plated swivel-dispense arm (2 if requested on order)
IMPORTANT: Please read carefully all the instructions before commencing
with the installation and commissioning of the appliance.

3.0 WARNINGS AND PRECAUTIONS
Please read the following carefully before commencing work on this equipment.
A competent installation engineer, in accordance with the installation instructions of
this appliance and all relevant local and national standards including the following
must install this appliance:
Health and Safety at Work Acts
IEE regulations
Local and National Building Regulations
BS Codes of practice
Water Supply Regulations
Your new water boiler is designed to provide a constant source of near boiling water
for the preparation of hot drinks. THIS IS VERY HOT
All personnel must be provided with sufficient and appropriate training in the safe
use of this appliance.
In line with Health & Safety requirements we recommend that a risk assessment be
carried out after the boiler has been installed.
A warning notice displayed next to the machine is often helpful in notifying users that
the appliance contains and dispenses near-boiling water.
During normal use of the boiler, certain surfaces will become hot (especially the draw
off taps and swivelling dispense arms). Care should be taken to avoid potential injury
from burns and scalding whilst operating the appliance.
Scale formation within hot water appliances is problematic and more so in hard water
areas. Damage to the appliance caused by excessive scale build-up may invalidate
the warranty –see notes on de-scaling.
Drawings, parts list, circuit/wiring diagrams are the sole property of Instanta Limited
and must not be reproduced without their consent.
This appliance is not intended for use by persons (Including Children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning use of the appliance by a
person responsible for their safety. Children should be supervised to ensure they do
not play with the appliance

4.0 INSTALLATION
Qualified personnel must carry out all installation work.
4.1 WORK SURFACES AND LOCATION:
a) Ensure that the work surface upon which the appliance is to be sited is capable of
sustaining the working weight of the appliance:
oTotal Boiler weight when full = 175kg
b) The work surface must have a minimum depth of 600mm
c) Consideration should be given for servicing requirements –If
electrical/water/waste services are brought up through the work surface, ensure
there is sufficient cable slack and movement for the flexible inlet hose/ overflow pipe,
to allow access in the event of maintenance/service work.
d) Location of boiler - Ensure that access to the appliance is unrestricted to allow
safe user operation
e) Avoid obstruction of the vent hole in the top lid. Do not site the appliance directly
beneath wall cupboards, other wall mounted appliances and low ceilings that are
susceptible to damage from steam/water vapour.
4.2 WATER CONNECTION
Your machine has been supplied with a WRAS approved non-toxic hose for
connection to a suitable drinking water supply. The fittings are ¾” BSP.
A 15mm stop valve should be fitted between the water supply and the hose so that
the machine can be isolated.
The water supply must have a pressure not exceeding 7.0bar (96psi) and no
lower than 2bar (28psi). If your water pressure exceeds 7bar, a suitable pressure
reduction valve will need to be fitted to the water supply to bring it to a level that the
machine can cope with. If in doubt, consult your water supply company.
In hard water areas it is advisable to fit a scale reducer to limit scale deposits.
Important: We regret that Instanta cannot be held responsible for scale related
problems or for machine malfunction where the water pressure exceeds or is less
than the limits above.
4.3 OVERFLOW/WASTE
Due to advanced electronic features on the appliance it is unlikely that an overflow
will occur. However, during normal operation and under certain conditions, small
quantities of water vapour and steam are emitted from the rear vent/overflow
connection. This vent/overflow connection MUST be directed to a suitable waste.

Any pipe used to connect the overflow connection to a waste must have a
continuous fall and have a minimum internal bore of 13mm. An air gap must be
provided within 1metre of the appliance. Failure to provide an air gap within this
distance could cause an air lock, which would stop the water discharging in the event
of an overflow.
IMPORTANT: While reasonable precaution is taken to prevent an overflow, Instanta
cannot be held responsible for any damage caused as a result of incorrect
installation or blockage of the overflow.
Failure to connect the overflow-outlet to a permanent waste or drain, could lead to
property damage from flooding.
If in all circumstances, it is absolutely not possible to direct the boiler overflow-outlet
to a permanent waste or drain, then the mains water supply to the boiler should be
isolated and the unit switched off whenever it is left unattended for long periods (e.g.
overnight).
4.4 ELECTRICAL CONNECTION
All electrical work must comply with all relevant wiring regulations and be carried out
by a qualified electrician.
a) The MOD18 boiler is supplied with a 2mtr long, 3-phase, Neutral and Earth lead
for connection to a suitable power supply. The five wires are coloured and should be
configured (latest European Standard) as follows:
Brown = Phase-1
Black = Phase-2
Grey = Phase-3
Blue = Neutral
Green/Yell = Earth
b) The appliance should be wired into a non-inductive breaker, fused at 32A per
phase. The isolation switch for the appliance must not be obstructed and be within
easy reach

5.0 INITIAL COMMISSIONING OF THE BOILER
Remove protective plastic coating from all surfaces
Attach a swivel-dispense arm to each of the draw-off taps
Ensure that the taps are both in the closed position
With all appropriate services connected, turn on the water supply
Switch on the electricity supply at the isolation switch.
Switch the machine on at the black rocker switch (front panel). The green
“power” and amber “ready” lights will illuminate briefly. The power light will
then be constantly illuminated to indicate mains supply. (All boilers have low
voltage switching for user safety).
The machine will start to fill with water. After approximately 4 ½ minutes, the
red “service” light will flash 6 times and the boiler will stop filling. Note: This is
an electronic fault-diagnosis check, which only happens on initial priming of
the boiler from empty. To continue, switch the machine off and then back on
again –the machine will continue to fill.
Upon the water reaching the lower water sensor, the solenoid valve will close
and the elements will begin to heat.
When the correct temperature (factory-set between 96 and 98^C) has been
reached, the amber ready light will illuminate. This takes approximately 10
minutes.
Upon reaching the correct temperature, the boiler will call for more water. The
machine will not fill completely all at once but in short, controlled bursts that
are electronically controlled to obtain maximum output, temperature and
efficiency. Note: The heating elements remain on while the solenoid is
energised to maximise performance.
This heat/fill cycle will continue until the water reaches the top water level
sensor. This takes approximately 35 minutes. Thereafter the machine goes
into "idle" mode, pulsing the heating element periodically to maintain
temperature.
Water can be manually dispensed via the two outlet taps on the front of the
unit
When the volume of stored water in the tank reduces, this is picked up via the
top operating sensor and the unit reverts back to "heat/fill" mode thus
maintaining a constant supply of near-boiling water
Note to installation engineer
Instruct the end user on the operating features of the appliance.
Instruct the end user how to isolate all services in case of emergency.
Instruct the end user on cleaning and de-scaling of the appliance
Advise end user that these instructions must be retained in a safe place

6.0 USER INSTRUCTIONS
6.1 DAILY OPERATING INSTRUCTIONS
a) In daily use, switch the machine on and wait until the amber “ready” light
illuminates. Once the “ready” light illuminates the boiler is ready for use.
b) Heat-up time from cold depends on the volume of stored water in the boiler
from the previous day. As a guide, assuming the tank is full, heat-up time from
cold will take approximately 39minutes.
NOTE: This is the maximum time taken to heat the full boiler capacity. This
provides an immediate rapid delivery of 135 litres.
c) Each tap is fitted with a swivel-dispense arm. This should be aligned to the
desired position before opening the tap.
d) To dispense hot water, pull the tap handle forward. Hot water will be
dispensed at a steady flow until the handle is released.
NOTE: The tap handle can be revolved to either of two operating positions:
1) Self-closing mode –handle will return to closed position on release.
2) Lock-open mode (for filling larger containers) –handle will have to be
manually returned to the closed position. IMPORTANT: Whilst the handle
is in the locked open position the boiler must not be left unattended.
e) WARNING: Care should always be taken to avoid injury whilst operating this
boiler as the water temperature is maintained at near-boiling point.
6.2 CLEANING
The external surfaces of the machine can be kept clean by wiping with a damp cloth.
A good quality stainless steel cleaner will keep the machine in its original condition.
The plastic top trim may also be cleaned with a damp cloth. Do not use abrasive
material on the outer surface of the machine.
6.3 MAINTENANCE
The boiler should be periodically checked for scale build-up. The frequency depends
upon hardness of the water and whether or not an effective scale reducer is fitted.
It is advisable to keep a spare tap spring and washer in case of emergencies.
Apart from scale removal no regular maintenance should be required.

7.0 TECHNICAL SPECIFICATIONS
Voltage: 400/430V 3-phase, 50/60 Hz
Supply: AC
Amps: 30A per phase
Rated Input: 18.0 KW
Front fuses required: 3 x 32A
Mains Water Pressure: Between 2.0 and 7.0 bar (28 –96psi)
Fill type: Automatic
Materials: All non-metallic materials in contact with water are WRAS
approved
Max Draw-Off: 135 Litres (238 UK pints)
Recovery per minute: 3.4 Litres
Recovery to full capacity: 39 minutes
Draw-off speed: 135 Litres in 11 minutes (using both taps)
Heat up time from cold: 45 minutes (to full capacity)
Temperature: 98^C (factory set)
Width: 660mm
Height: 892mm
Depth: 550mm
Weight (empty): 52kg
Weight (full): 175kg
Machine construction: Outer casing and tank constructed from combination of
type 304 and 316 stainless steel.
All boilers have electronic control of the main functions. This means that the
temperature is controlled precisely within given parameters. The circuit constantly
monitors the operation of the machine and warns the user via the service light if any
abnormal circumstances have been detected.
If the service light flashes refer to the diagnosis codes at the back of this manual.
Other technical information available:
Spare Parts List: Order Ref: INS-MOD18SP
Service/Maintenance Manual: Order Ref: INS-MOD18SVC
Please order direct from Instanta Limited, Spares Department: 01704 501114

8.0 DE-SCALING THE BOILER
It is recommended that the appliance be de-scaled regularly:
To de-scale the machine, first isolate from the electrical power supply.
Remove outer lid (insert the tip of a screwdriver into gap between case and lid
and twist on each corner).
Remove inner tank lid (6 screws)
Lift out both baffle plates from the inside of the tank
Using a suitable de-scaling agent, add the solution to the water inside the
tank. NOTE: Some de-scaling compounds may cause hot water to erupt. It is
advisable to add the solution a little at a time and follow the manufacturers
instructions closely.
Allow time for the de-scaling solution to neutralise (This will depend on how
heavy the scale deposits are). In the case of severe scale deposits it may be
necessary to repeat the de-scaling process.
On completion of successful de-scaling, evacuate the tank via the taps. To
completely empty the contents below the tap level, the drain tap (situated
behind the clip-on front panel) can be opened. Once complete, REMEMBER
to close the drain tap.
Ensure all traces of de-scaler are removed before using the boiler again.
Flush tank with copious amounts of clean cold water.
Examine the water level sensors for scale build-up - clean thoroughly as
necessary using a non-metallic scourer.
When de-scaling is complete, replace internal tank baffle plates, tank lid and
main outer lid.
Rather than frequently de-scaling the machine it may be preferable to install an
effective scale reducer or WRAS approved water softener. This will reduce the
frequency of de-scaling but will not remove scale completely in some areas.
9.0 FAULT DIAGNOSIS (Service Warning Light)
The boiler has a red “service” warning light facility. The light is designed to help
identify the cause of any malfunction. If the circuit senses a problem, the red
“service” light will flash a number of times and then pause and repeat the sequence.
Count the number of flashes between pauses and refer to the following table:
Serious problems will disable the boiler whilst less serious conditions will allow the
boiler to continue functioning until a convenient time arises for the fault to be
rectified.

NUMBER OF
FLASHES
BETWEEN
PAUSES
MEANING
ACTION
1 Constant
Water level sensor has scaled up
at normal level and machine has
filled to a higher level
Clean Sensing Probes
2
Operating level sensor has been
detected but lower level sensor
has not
Clean Sensing Probes
3
Overfill level sensor has been
detected but other sensors have
not
Clean Sensing Probes
4
Danger level sensor has been
detected and machine functions
have been shut down
Clean Sensing Probes
5
Boiler has overheated
Call Instanta service
department
Quoting the Serial Number
6
Boiler has failed to fill in the
allotted time. Possible causes:
1. Water supply turned off.
2. Water inlet valve has failed.
3. Blockage in water inlet pipe.
4. Pipe connecting inlet valve to
boiler has become detached.
Check water supply
If in order call Instanta service
department quoting the Serial
Number
7
The temperature sensor has
become disconnected or the
heating element(s) have failed.
Call Instanta service
department
Quoting the Serial Number
8 or 9
Fault on temperature sensor.
Call Instanta service
department
Quoting the Serial Number
10
Heating element(s) faulty or a
system fault.
Call Instanta service
department
Quoting the Serial Number
11
The water supply has been
interrupted and the level has
fallen to a point at which the
heating element(s) could be
damaged.
Check water supply
If in order call Instanta service
department quoting the Serial
Number
12
The machine has over-boiled and
the level has fallen to a point at
which the element(s) could be
damaged.
Call Instanta service
department
Quoting the Serial Number
INSTANTA LIMITED, Canning Road, Southport, Merseyside PR9 7SN
Tel: [phone] Fax: [phone]
