Intel Atom Pine Trail-D525 User manual

User’s Manual
Manual revision: 1.0
Release Date：January, 2011

i
USER’S NOTICE
COPYRIGHT OF THIS MANUAL BELONGS TO THE MANUFACTURER. NO PART OF THIS MANUAL,
INCLUDING THE PRODUCTS AND SOFTWARE DESCRIBED IN IT MAY BE REPRODUCED, TRANSMITTED
OR TRANSLATED INTO ANY LANGUAGE IN ANY FORM OR BY ANY MEANS WITHOUT WRITTEN
PERMISSION OF THE MANUFACTURER.
THIS MANUAL CONTAINS ALL INFORMATION REQUIRED TO USE THIS MOTHER-BOARD SERIESANDWE
DO ASSURE THIS MANUAL MEETS USER’S REQUIREMENT BUT WILL CHANGE, CORRECT ANY TIME
WITHOUT NOTICE. MANUFACTURER PROVIDES THIS MANUAL “AS IS” WITHOUT WARRANTY OF ANY
KIND, AND WILL NOT BE LIABLE FOR ANY INDIRECT, SPECIAL, INCIDENTIAL OR CONSEQUENTIAL
DAMAGES (INCLUDING DAMANGES FOR LOSS OF PROFIT, LOSS OF BUSINESS, LOSS OF USE OF DATA,
INTERRUPTION OF BUSINESS AND THE LIKE).
PRODUCTS AND CORPORATE NAMES APPEARING IN THIS MANUAL MAY OR MAY NOT BE
REGISTERED TRADEMARKS OR COPYRIGHTS OF THEIR RESPECTIVE COMPANIES, AND THEY ARE
USED ONLY FOR IDENTIFICATION OR EXPLANATION AND TO THE OWNER’S BENEFIT, WITHOUT
INTENT TO INFRINGE.
Environmental Protection Announcement
Do not dispose this electronic device into the trash while discarding. To minimize
pollution and ensure environment protection of mother earth, please recycle.

ii
Environmental Safety Instruction
lAvoid the dusty, humidity and temperature extremes. Do not place the product in
any area where it may become wet.
l0 to 60 centigrade is the suitable temperature. (The figure comes from the request
of the main chipset)
lGenerally speaking, dramatic changes in temperature may lead to contact
malfunction and crackles due to constant thermal expansion and contraction from
the welding spots’ that connect components and PCB. Computer should go
through an adaptive phase before it boots when it is moved from a cold
environment to a warmer one to avoid condensation phenomenon. These water
drops attached on PCB or the surface of the components can bring about
phenomena as minor as computer instability resulted from corrosion and oxidation
from components and PCB or as major as short circuit that can burn the
components. Suggest starting the computer until the temperature goes up.
lThe increasing temperature of the capacitor may decrease the life of computer.
Using the close case may decrease the life of other device because the higher
temperature in the inner of the case.
lAttention to the heat sink when you over-clocking. The higher temperature may
decrease the life of the device and burned the capacitor.

iii
USER’S NOTICE.................................................................................................................. i
ENVIRONMENTAL PROTECTION ANOUNCEMENT...........................................................i
ENVIRONMENTAL SAFETY INSTRUCTION ....................................................................... ii
1 FEATURE OF MOTHERBOARD............................................................................ 1
2 SPECIFICATION .................................................................................................... 2
3 LAYOUT DIAGRAM ...............................................................................................3
3-1 INTERNAL DIAGRAM OF THE BOARD ......................................................3
3-2 THE BACK SIDE OF THE BOARD...............................................................4
3-3 REAR PANEL I/O CONNECTORS............................................................... 5
3-4 FRONT PANEL I/O CONNECTORS.............................................................5
4 I/O CONNECTOR FUNCTION................................................................................6
4-1 REAR I/O CONNECTOR FUNCTION............................................................. 6
4-2 FRONT I/O CONNECTOR FUNCTION........................................................... 7
TABLE OF CONTENT

1
1. Feature of Motherboard
lINTEL® Atom Pine Trail-D525 + NM10 chipset
lOnboard Atom CPU, with low power consumption never denies high performance.
lSupport DDRIII DIMM800 up to 4GB
lOnboard Gigabit LAN Chip
lSupport 2-CH Audio
lSupport USB 2.0 data transport demands
lCompliance with ERP(Energy Using Product) standard
lMini-ITX form factor(170mm x 182mm)

2
2. Specification
CPU
INTEL® Atom Pine Trail-D525
Clock:1.83GHz
Chipset
/ GPU
INTEL® Atom Pine Trail-D525 + NM10 chipset
NVIDIA® ION2(GT218) GPU
Front Side Bus:200 MHz
Memory
(Optional)
2 * SO-DIMMs Sockets for DDRIII 800 up to 4 GB
Ethernet LAN
Realtek Gigabit LAN Chip
Expansion S
lots
1 * PCI Express Mini Card slot
Storage
1 * Serial ATA II 3Gb/s connectors
Audio
2-CH Audio
BIOS
AMI 8MB flash ROM
Front
Panel I
/
O
2 * USB 2.0/1.1 ports
1 * Power button
1 * card reader (SDC/MMC/MS)
1 * Mic and headphone
1 * Power LED
Rear Panel
I
/
O
2 * USB 2.0 ports
1 * LAN port
1 * Antenna Hole
1 * HDMI port & 1 * DVI-I port
1 * Power connector
1 * e-SATA port
Power
1*12V DC-in
Form Factor
Mini-ITX Form Factor (170mm x 182mm)
Certificate
CE,FCC for barebone
CE,FCC,TUV,UL,CCC,CB for power adapter
Comply with ERP stardards

3
3. Layout Diagram
3-1 Internal Diagram of the Board

4
3-2 The Back Side of the Board:

5
3-3 Rear Panel I/O Connectors
3-4 Front Panel I/O Connectors
Card Reader Slot
USB Connectors
Line-out /Optical SPDIF out
shared connector
MIC
Power
Switch
W
/Power LED
R
e
mote Sensor
Antenna Hole
HDMI
Connector
DVI
Connector
E-SATA/USB
Connector
RJ-
45 LAN
USB Connectors
DC12V Jack

6
4. I/O Connector Function
4-1 Rear Panel I/O Connector Function
USB Connector:
There are 3*USB connectors on rear IO panel (one is USB/E-SATA shared connector that functions
according to device connected) to connect USB mouse, keyboard and other USB storage devices to
the system.
RJ-45 Connector:
The connector is standard RJ-45 connector for network. Please connect to the network cable to this
connector.
USB/E-SATA Shared Connector:
The function of this connector depends on different devices connected to this connector through
different cable.
It could function as:
nE-SATA connector when a compatible ESATA hard disk is connected to it through SATA cable.
nUSB connector when a compatible USB device is connected to it through USB cable.
DVI (Digital Visual Interface) Connector:
This interface standard designed to maximize the visual quality of digital display devices such as flat
panel LCD computer displays and digital projectors.
HDMI (High-Definition Multimedia Interface):
This point-to-point interface is for audio and video signals designed as a single-cable solution for home
theater and consumer electronics equipment.
DC12V Jack:
Use this to connect the power adapter to DC12V jack after connecting connector power cord to adapter.
Then Turn on the system either by power switch on front panel or remote control when all necessary
hardware configuration are made.

7
4-2 Front Panel I/O Connector Function
Card Reader Slot:
User can insert the MMC/SD/MS card to the front 3 in 1 card reader.
USB Connectors:
User can connect USB mouse, keyboard and other USB storage devices to the system.
Line-Out /Optical SPDIF out shared Connector:
This connector can function as ordinary audio line-out connector or optical SPDIF out connector
depending on different device connected to it:
nAudio Line-out connector: by connecting stereo speakers or headphones.
nOptical SPDIF out connector: by connecting Realtek 6-Channel HD Audio CODEC w/ SPDIF out
audio output device for superior audio enjoyment.
MIC Connector:
User can connect microphone device to this port.
Power on Switch:
After needed hardware installed and correct configuration made, you can power on the system to enjoy
multi-functions Mini-TOP brings to you.
Remote Sensor
：
This remote sensor receives instruction signal from remote control.
