Intel i915G User manual

TRADEMARK
All products and company names are trademarks or registered
trademarks of their respective holders.
These specifications are subject to change without notice.
Manual Revision 1.0
June 11, 2004
IntelIntel
IntelIntel
Intel i915Gi915G
i915Gi915G
i915G mainboardmainboard
mainboardmainboard
mainboard
forfor
forfor
for IntelIntel
IntelIntel
Intel SocketSocket
SocketSocket
Socket 775775
775775
775 processorprocessor
processorprocessor
processor
User’User’
User’User’
User’ss
ss
s
ManualManual
ManualManual
Manual
60000025EGA10

ii
DISCLAIMER OF WARRANTIES:
THERE ARE NO WARRANTIES WHICH EXTEND BEYOND THE
DESCRIPTION ON THE FACE OF THE MANUFACTURER LIMITED
WARRANTY. THE MANUFACTURER EXPRESSLY EXCLUDES ALL
OTHER WARRANTIES, EXPRESS OR IMPLIED, REGARDING ITS
PRODUCTS; INCLUDING ANY IMPLIED WARRANTIES OF
MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE OR
NONINFRINGEMENT. THIS DISCLAIMER OF WARRANTIES SHALL
APPLY TO THE EXTENT ALLOWED UNDER LOCAL LAWS IN THE
COUNTRY PURCHASED IN WHICH LOCAL LAWS DO NOT ALLOW OR
LIMIT THE EXCLUSION OF THE IMPLIED WARRANTIES.

iii
80 Port Frequently Asked Questions
Below is a list of some basic POST Codes, possible problems and solutions. For
more detailed information about POST Codes, refer to Appendix E in this manual.
POST CODE Problem Solution
FFh or CFh 1.BIOS chip inserted
incorrectly
2. Incorrect BIOS update
version
3. Mainboard problem
4. Add-on card inserted
incorrectly.
1. Reinsert the BIOS
chip
2. Download the correct
BIOS version update
from the manufacturer's
Web site.
3. Replace mainboard
4. Remove and replace the
add-on card
C1h - C5h 1. Memory module
inserted incorrectly
2. Memory compatibility
problem
3. Memory module
damaged
1. Reinsert memory
module
2. Replace memory
with correct type
3. Replace memory
module
2Dh 1. Error occured in VGA
BIOS
2. VGA card inserted
incorrectly
1. Replace VGA card
2. Reinsert the VGA
card
26h Overclock error Clear CMOS or press the insert
key to power on the system
07h - 12h 1. Init keyboard
controller error
2. RTC error
1. Ensure that the keyboard and
mouse are connected
correctly.
2. Replace the RTC battery.
Initial Keyboard

iv
Table of Contents
Section 1 Introduction
Package Contents ...................................................... 1- 1
System Block Diagram ............................................... 1- 2
Section 2 Specification
Mainboard Specification ............................................ 2- 1
Section 3 Installation
Mainboard Layout ..................................................... 3- 2
Easy Installation Procedure ....................................... 3- 3
CPU Insertion ............................................................. 3- 3
Jumper Settings .......................................................... 3- 5
System Memory Configuration .................................. 3- 6
Expansion Slots .......................................................... 3- 9
Device Connectors..................................................... 3-11
Thermo Stick Function ............................................... 3-17
Power-On/Off (Remote) .............................................. 3-18
External Modem Ring-in Power ON and
Keyboard Power ON Function (KBPO) ..................... 3-18
STR (Suspend To RAM) Function ............................ 3-19
Section 4 BIOS Setup
Main Menu ................................................................ 4- 1
Standard CMOS Setup ............................................... 4- 2
Advanced BIOS Features .......................................... 4- 3
Advanced Chipset Features ...................................... 4- 5
Integrated Peripherals ................................................ 4- 8
Power Management Setup ......................................... 4-13
PNP/PCI Configuration .............................................. 4-16
PC Health Status ........................................................ 4-18
Page

v
Power BIOS Features ................................................. 4-20
Defaults Menu ........................................................... 4-23
Supervisor/User Password Setting ............................ 4-24
Exit Selecting .............................................................. 4-25
Section 5 RAID Configuration (Optional)
Introduction ............................................................... 5- 1
Intel ICH6R RAID Features ....................................... 5- 3
ITE RAID Features..................................................... 5- 3
Enable RAID Function ............................................... 5- 4
Section 6 Driver Installation
Easy Driver Installation .............................................. 6- 1
Realtek Sound Manager Quick User guide ................ 6-2
Appendix Appendix A
Realtek Media Player User’s Guide ............................ A-1
Appendix B
Update Your System BIOS ......................................... B-1
Appendix C (Optional)
Intel Application Accelerator RAID Option ROM ........ C- 1
ITE IT8212 RAID BIOS Setup Utility ........................... C- 3
Appendix D (Optional)
Intel Matrix RAID Quick Guide .................................... D- 1
Appendix E
POST Codes ............................................................... E-1

vi
Page Left Blank

Introduction
Page 1-1
Section 1
INTRODUCTION
1-1 Package Contents
Contents
A. Mainboard
B. User’s manual
C. Floppy drive cable
D. HDD drive cable
E. CD (drivers and utilities)
F. I/O Shield
G. S-ATA data and power cable
H. Game & COM bracket cable
I. ThermoStick cable
Powerpack items (Optional)
J. Mini heatsink
K. Tool Pen
Optional Items
L. Extra USB2.0 port cable
M. S/PDIF Module
B
A
C
D
USER’S
MANUAL
E
F
H
G
M
If you need the optional item, please
contact your dealer for assistance.
I
L
J
K

Introduction
Page 1-2
1-2 System Block Diagram

Features
Page 2-1
Section 2
FEATURES
Mainboard Features
Processor
Support Intel®Pentium 4®5xx series processors up to 4.0+GHz in LGA775
socket with 533/800 MHz front-side system bus
Support Intel®Pentium 4®3xx series processors up to 3.2+GHz in LGA775
socket with 533 MHz front-side system bus
Support Intel 04B or 04A Platform Compatibility Guide
Supports Hyper-Threading Technology
To enable the Hyper-Threading Technology function on your computer
system requires ALL of the following platform components:
)CPU: An Intel®Pentium®4 Processor with HT Technology.
)Chipset: An Intel®Chipset that supports HT Technology.
)BIOS: A BIOS that supports HT Technology and has it enabled.
)OS: An operating system that supports HT Technology.
Performance will vary depending on the specific hardware and software
you use. See <http://www.intel.com/info/hyperthreading> for information
including details on which processor support HT Technology.
Chipset
Intel®i915G Chipset (i915G + ICH6R or ICH6)
- with Intel GMA900 graphics core
Main Memory
Four 184-pin DDR SDRAM DIMM sockets
Support single-sided or double-sided 2.5v DDR-333/400 DIMMs with dual
channel architecture in 256Mb/512Mb/1Gb technologies
Supports up to 4GB memory size
BIOS
Flash EEPROM with Award BIOS
- ACPI v2.0 compliant

Features
Page 2-2
- S3 (Suspend to DRAM) sleep-state support
- SMBIOS (System Management BIOS) v2.2 compliant
- Supports Power failure recovery
- Able to wake the computer from specific states by LAN, Power switch,
PME#, RTC alarm, USB, PS2 K/B, PS2 Mouse, Modem Ring-in COM port
Onboard PCI Devices
LAN --> Integrates 1Gbps Fast Ethernet controller with onboard
Marvell 88E8001 LAN chip
IDE RAID- -> Two additional ATA-133 IDE ports with RAID 0, 1, 0+1
support from onboard ITE IT8212F RAID controller
Legacy IO Controller
Winbond W83627THF LPC IO controller with keyboard, mouse, floppy,
printer, game, serial and IR interface
Support Hardware Monitoring for fan speed monitoring, CPU/System
temperature and ThermoStick temperature
Intelligent fan speed control for CPU-fan (PWM) and Chassis-fan (DC) for
quiet operation
Audio
Eight channel audio with analog and digital output using Realtek ALC850
AC’97CODEC
- AC’97 v2.3 compliant
- Supports CD-In, Aux-In and S/PDIF-in/out interface
- Supports Line-out and Mic-In for front panel
- Supports automatic “jack-sensing”
- Rear panel audio jacks configuration:
roloCkcaJenohP lennahc2 lennahc6 lennahc8
eulBthgiLni-eniLtuo-oeretsraeRni-eniL
emiLtuo-eniLtuo-oeretstnorFtuo-oeretstnorF
kniPni-ciMrefoowbuS&retneCni-ciM
yarGtuo-oeretsediS
kcalB tuo-oeretsraeR
egnarO refoowbuS&retneC
(Optional)

Features
Page 2-3
Peripheral Interfaces
))
))
)At Rear Panel
PS/2 keyboard and mouse ports
One Parallel (printer) port
One S/PDIF-Out Coaxial jack
One S/PDIF-Out Optical
One VGA port
One RJ45 LAN connector
Four USB2.0 ports
Three Audio jacks
))
))
)Onboard connector and pin-header
One floppy drive connector
One ATA-100 IDE connector
Two ATA-133 IDE connectors from IT8212F RAID controller (Optional)
Four extra USB2.0 ports
One CD-IN and One AUX-IN connector
One S/PDIF-in/out connector
One IR connector
One Game port connector
One Serial Port (COM2) connector
Four S-ATA connectors
Three Fan connectors
Front Panel Controller
Supports Reset & Soft-Off switches
Supports HDD & Power LEDs
Supports PC speaker
Supports Front Panel Audio connector

Features
Page 2-4
Expansion Slots
Four PCI connectors compliant with PCI v2.3
Two PCI Express x1 connectors compliant with PCI Express 1.0a
One PCI Express x16 connectors compliant with PCI Express 1.0a
Other BIOS Features
Magic Health – A quick “dashboard” display at POST to show hardware
status. Helps to detect faults early.
EZ Boot – An easy way let end-user can choose to boot from hard drive,
CD-ROM, floppy, …
KBPO – Keyboard power on, turn on the computer from keyboard
PowerBIOS for excellent Overclocking capabilities through
- subtle voltage tuning for CPU, Memory
- subtle frequency tuning on FSB with 1MHz increment
- Supports complete Asynchronous FSB/Memory scheme for overclocking
- Supports Asynchronous clocking between FSB and PCI/PCI-Express
P80P for system debugging
Form Factor
305mm x 245 mm ATX size

Installation
Page 3-1
Section 3
INSTALLATION
Note: Depending on the model you purchased, some components
are optional and may not be available.

Installation
Page 3-2
Mainboard Layout
Note: Depending on the model you purchased, some components
are optional and may not be available.

Installation
Page 3-3
Easy Installation Procedure
The following must be completed before powering on your new system:
3-1. CPU Installation
3-2. Jumper Settings
3-3. System Memory Configuration
3-4. Expansion Slots
3-5. Device Connectors
3-1 CPU Installation
<Figure 1>
Step 1
Carefully remove the plastic protection plate from the
socket.
Step 3
Before inserting the CPU, align the CPU according
to the key slots shown in the picture. Gently place
the CPU into the socket and make sure it is fully
seated.
<Figure 2>
Step 2
Open the socket by releasing
the actuation lever, and press
downwards at the tip shown by
the arrow.
Warning:
The pins inside the CPU socket are fragile and are
easily broken. Be careful not to touch them when
installing the CPU.
<Figure 3>

Installation
Page 3-4
Step 4
a) Put the CPU lid on the socket, and
close the socket by lowering and
locking the actuation lever.
b) Apply thermal compound to the top
of the CPU and into the four holes
around CPU area to install the cooler
as shown.
<Figure 6>
Step 5
Place the CPU cooler on top of the socket.
Press its clips down firmly until it is
completely seated in the hole.
Step 6
a) Rotate the clips 90 degrees to lock
the CPU cooler in place.
b) Plug the cooler fan power into the
mainboard’s CPU fan connector.
The installation is complete.
CAUTION:
• Installing with incorrect CPU cooler and heatsink assemblies may damage the CPU. Use
Intel’s thermal solution shown in the illustrations above: an active heatsink; an extruded
aluminum heatsink base; and a fan attached to the top of the fin array.
• Apply thermal compound or paste to the CPU to avoid CPU overheating and damage.
• In accordance with Intel guidelines specifications, do not install a CPU over 20 times to
avoid damaging the pins on the CPU socket.
<Figure 4> <Figure 5>

Installation
Page 3-5
3-2 Jumper Settings
1
JCMOS:
Settings:
1-2: Normal (Default)
2-3: Clear CMOS
Clear CMOS data Jumper
If the CMOS data becomes corrupted or
you forgot the supervisor or user
password, clear the CMOS data to
reconfigure the system back to the
default values stored in the ROM BIOS.
To CMOS Clear data, please follow the steps below.
1. Turn off the system.
2. Change the jumper from “1-2” to “2-3” position for
a few seconds.
3. Replace the jumper on to the “1-2” position.
4. Turn on the system and hold down the <Del> key
to enter BIOS setup.

Installation
Page 3-6
<Figure 7>
<Figure 8>
3-3 System Memory Configuration
The mainboard accommodates four PC2700/PC3200 184-pin DIMMs (Dual In-line
Memory Modules):
• Supports up to 4.0GB of 333/400MHz DDR SDRAM.
• Supports dual channel memory interface.
• Supports non-ECC memory and non-Registered DIMMs only.
• Supports 256Mb/512Mb/1Gb DDR technologies in x8 and x16 devices only.
• SPD (Serial Presence Detect) scheme for DIMM detection support.
• Supports configurations defined in the JEDEC DDR DIMM specification only.
Memory configurations supported:
• The four DIMM sockets are divided into two Dual Channel pairs according to
the color <Figure 7>. Each dual channel pair has the same color, e.g. DIMM1
and DIMM3. <Figure 8> shows the logical memory layout. We recommend
you to use DIMM sockets of the same color to obtain the best memory
performance.
- Single Channel Flexibility:
Each channel is populated with different amount of memory.
- Dual Channel Advantage:
Both channel populated with same amount of memory.
DDR-A2 DIMM 2
DDR-B2 DIMM 4
Dual Channel 2
Channel A
Channel B
Dual Channel 1
DDR-A1 DIMM 1

Installation
Page 3-7
Follow the recommendation below for memory performance.
MMID1
)tib-46(
MMID2
)tib-821(
MMID3
)tib-821(
MMID4
)tib-821(
1#MMIDSD/SSSD/SSSD/SSSD/SSSD/SSSD/SS
2#MMIDSD/SSSD/SSSD/SSSD/SSSD/SSSD/SS
3#MMIDSD/SSSD/SSSD/SSSD/SSSD/SS
4#MMIDSD/SSSD/SSSD/SSSD/SSSD/SS
* SS: Single-Sided DIMM, DS: Double-Sided DIMM
Note: Using non-compliant memory with higher bus speeds (overclocking) may
severely compromise the integrity of the system.

Installation
Page 3-8
DIMM Module Installation
Figure 9 displays the notch on the DDR DIMM memory module.
DIMMs have 184 pins and one notch that matches with the DDR DIMM socket.
DIMM modules are installed by placing the chip firmly into the socket and
pressing straight down as shown in figure 10 until the white clips close and the
module fits tightly into the DIMM socket (figure 11).
Figure 9 - DIMM notch
Figure 11 - DIMM module clip after installation
To remove the DIMM module press down the white clips and the module is ejected
from the socket.
Figure 10 - DIMM module clips before installation
CENTER KEY ZONE
(2.5 V DRAM)
