Intel BLKDG43GT Configuration guide

Intel® Desktop Board
DG43GT
Technical Product Specification
July 2009
Order Number: E71069-001US
The Intel®Desktop Board DG43GT may contain design defects or errors known as errata that may cause the product to deviate from published
specifications. Current characterized errata are documented in the Intel Desktop Board DG43GT Specification Update.

Revision History
Revision Revision History Date
-001 First release of the Intel®Desktop Board DG43GT Technical Product
Specification.
July 2009
This product specification applies to only the standard Intel®Desktop Board DG43GT with BIOS
identifier GTG4310H.86A.
Changes to this specification will be published in the Intel Desktop Board DG43GT Specification
Update before being incorporated into a revision of this document.
INFORMATION IN THIS DOCUMENT IS PROVIDED IN CONNECTION WITH INTEL®PRODUCTS. NO LICENSE,
EXPRESS OR IMPLIED, BY ESTOPPEL OR OTHERWISE, TO ANY INTELLECTUAL PROPERTY RIGHTS IS
GRANTED BY THIS DOCUMENT. EXCEPT AS PROVIDED IN INTEL’S TERMS AND CONDITIONS OF SALE FOR
SUCH PRODUCTS, INTEL ASSUMES NO LIABILITY WHATSOEVER, AND INTEL DISCLAIMS ANY EXPRESS OR
IMPLIED WARRANTY, RELATING TO SALE AND/OR USE OF INTEL PRODUCTS INCLUDING LIABILITY OR
WARRANTIES RELATING TO FITNESS FOR A PARTICULAR PURPOSE, MERCHANTABILITY, OR INFRINGEMENT
OF ANY PATENT, COPYRIGHT OR OTHER INTELLECTUAL PROPERTY RIGHT. UNLESS OTHERWISE AGREED IN
WRITING BY INTEL, THE INTEL PRODUCTS ARE NOT DESIGNED NOR INTENDED FOR ANY APPLICATION IN
WHICH THE FAILURE OF THE INTEL PRODUCT COULD CREATE A SITUATION WHERE PERSONAL INJURY OR
DEATH MAY OCCUR.
Intel Corporation may have patents or pending patent applications, trademarks, copyrights, or other
intellectual property rights that relate to the presented subject matter. The furnishing of documents and
other materials and information does not provide any license, express or implied, by estoppel or otherwise,
to any such patents, trademarks, copyrights, or other intellectual property rights.
Intel may make changes to specifications and product descriptions at any time, without notice.
Designers must not rely on the absence or characteristics of any features or instructions marked “reserved”
or “undefined.” Intel reserves these for future definition and shall have no responsibility whatsoever for
conflicts or incompatibilities arising from future changes to them.
Intel®desktop boards may contain design defects or errors known as errata, which may cause the product
to deviate from published specifications. Current characterized errata are available on request.
Contact your local Intel sales office or your distributor to obtain the latest specifications before placing your
product order.
Copies of documents which have an ordering number and are referenced in this document, or other Intel
literature, may be obtained from:
Intel Corporation
P.O. Box 5937
Denver, CO 80217-9808
or call in North America 1-800-548-4725, Europe 44-0-1793-431-155, France 44-0-1793-421-777,
Germany 44-0-1793-421-333, other Countries 708-296-9333.
Intel, the Intel logo, Core, Pentium, Xeon, and Celeron are registered trademarks of Intel Corporation or its
subsidiaries in the United States and other countries.
* Other names and brands may be claimed as the property of others.
Copyright © 2009, Intel Corporation. All rights reserved.

iii
Preface
This Technical Product Specification (TPS) specifies the board layout, components,
connectors, power and environmental requirements, and the BIOS for the Intel®
Desktop Board DG43GT. It describes the standard product and available
manufacturing options.
Intended Audience
The TPS is intended to provide detailed, technical information about the Intel Desktop
Board DG43GT and its components to the vendors, system integrators, and other
engineers and technicians who need this level of information. It is specifically not
intended for general audiences.
What This Document Contains
Chapter Description
1 A description of the hardware used on the board
2 A map of the resources of the board
3 The features supported by the BIOS Setup program
4 A description of the BIOS error messages, beep codes, and POST codes
5 Regulatory compliance and battery disposal information
Typographical Conventions
This section contains information about the conventions used in this specification. Not
all of these symbols and abbreviations appear in all specifications of this type.
Notes, Cautions, and Warnings
NOTE
Notes call attention to important information.
CAUTION
Cautions are included to help you avoid damaging hardware or losing data.

Intel Desktop Board DG43GT Technical Product Specification
iv
Other Common Notation
# Used after a signal name to identify an active-low signal (such as USBP0#)
GB Gigabyte (1,073,741,824 bytes)
GB/s Gigabytes per second
Gb Gigabit (1,073,741,824 bits)
Gb/s Gigabits per second
KB Kilobyte (1024 bytes)
Kb Kilobit (1024 bits)
kb/s 1000 bits per second
MB Megabyte (1,048,576 bytes)
MB/s Megabytes per second
Mb Megabit (1,048,576 bits)
Mb/s Megabits per second
xxh An address or data value ending with a lowercase h indicates a hexadecimal value.
x.x V Volts. Voltages are DC unless otherwise specified.
* This symbol is used to indicate third-party brands and names that are the property of their
respective owners.

v
Contents
1Product Description
1.1 Overview.......................................................................................... 9
1.1.1 Feature Summary .................................................................. 9
1.1.2 Board Layout ....................................................................... 11
1.1.3 Block Diagram ..................................................................... 13
1.2 Legacy Considerations...................................................................... 14
1.3 Online Support................................................................................ 14
1.4 Processor ....................................................................................... 15
1.5 System Memory .............................................................................. 16
1.5.1 Memory Configurations ......................................................... 17
1.6 Intel®G43 Express Chipset............................................................... 19
1.6.1 Intel G43 Graphics Subsystem ............................................... 19
1.6.2 USB ................................................................................... 22
1.6.3 ATA Support ........................................................................ 23
1.7 Real-Time Clock Subsystem .............................................................. 24
1.8 Legacy I/O Controller....................................................................... 25
1.8.1 Serial Port........................................................................... 25
1.8.2 Parallel Port......................................................................... 25
1.9 Audio Subsystem............................................................................. 26
1.9.1 Audio Subsystem Software .................................................... 27
1.9.2 Audio Connectors and Headers ............................................... 27
1.10 LAN Subsystem............................................................................... 28
1.10.1 Intel®82567V Gigabit Ethernet Controller................................ 28
1.10.2 LAN Subsystem Software....................................................... 29
1.10.3 RJ-45 LAN Connector with Integrated LEDs .............................. 29
1.10.4 Intel®Remote Wake Technology............................................. 30
1.11 Hardware Management Subsystem .................................................... 30
1.11.1 Hardware Monitoring and Fan Control...................................... 30
1.11.2 Fan Monitoring..................................................................... 31
1.11.3 Chassis Intrusion and Detection.............................................. 31
1.11.4 Thermal Monitoring .............................................................. 32
1.12 Power Management ......................................................................... 33
1.12.1 ACPI ..................................................................... 33
1.12.2 Hardware Support ................................................................ 36
1.12.3 ENERGY STAR*, E-Standby, and EuP Compliance...................... 39
2Technical Reference
2.1 Memory Map................................................................................... 41
2.1.1 Addressable Memory............................................................. 41
2.2 Connectors and Headers................................................................... 44
2.2.1 Back Panel Connectors .......................................................... 45
2.2.2 Component-side Connectors and Headers ................................ 46
2.3 BIOS Configuration Jumper Block....................................................... 56

Intel Desktop Board DG43GT Technical Product Specification
vi
2.4 CMOS Clear Header ......................................................................... 58
Mechanical Considerations ....................................................................... 59
2.4.1 Form Factor......................................................................... 59
2.5 Electrical Considerations................................................................... 60
2.5.1 Power Supply Considerations ................................................. 60
2.5.2 Fan Header Current Capability................................................ 60
2.5.3 Add-in Board Considerations .................................................. 61
2.6 Thermal Considerations.................................................................... 61
2.7 Reliability ....................................................................................... 63
2.8 Environmental ................................................................................ 63
3Overview of BIOS Features
3.1 Introduction ................................................................................... 65
3.2 BIOS Flash Memory Organization....................................................... 66
3.3 Resource Configuration .................................................................... 66
3.3.1 PCI* Autoconfiguration.......................................................... 66
3.4 System Management BIOS (SMBIOS)................................................. 67
3.5 Legacy USB Support ........................................................................ 68
3.6 BIOS Updates ................................................................................. 69
3.6.1 Language Support ................................................................ 69
3.6.2 Custom Splash Screen .......................................................... 69
3.7 BIOS Recovery................................................................................ 70
3.8 Boot Options................................................................................... 70
3.8.1 CD-ROM Boot ...................................................................... 70
3.8.2 Network Boot....................................................................... 70
3.8.3 Booting Without Attached Devices........................................... 71
3.8.4 Changing the Default Boot Device During POST ........................ 71
3.9 Adjusting Boot Speed....................................................................... 71
3.9.1 Peripheral Selection and Configuration..................................... 71
3.9.2 BIOS Boot Optimizations ....................................................... 72
3.10 BIOS Security Features .................................................................... 73
4Error Messages and Beep Codes
4.1 Speaker ......................................................................................... 75
4.2 BIOS Beep Codes ............................................................................ 75
4.3 Front-panel Power LED Blink Codes.................................................... 76
4.4 BIOS Error Messages ....................................................................... 76
4.5 Port 80h POST Codes ....................................................................... 77

Contents
vii
5Regulatory Compliance and Battery Disposal Information
5.1 Regulatory Compliance..................................................................... 83
5.1.1 Safety Standards.................................................................. 83
5.1.2 European Union Declaration of Conformity Statement................ 84
5.1.3 Product Ecology Statements................................................... 85
5.1.4 EMC Regulations .................................................................. 89
5.1.5 Product Certification Markings (Board Level)............................. 90
5.2 Battery Disposal Information............................................................. 91
Figures
1. Major Board Components.................................................................. 11
2. Block Diagram ................................................................................ 13
3. Memory Channel and DIMM Configuration ........................................... 18
4. Back Panel Audio Connectors ............................................................ 27
5. LAN Connector LED Locations............................................................ 29
6. Thermal Sensors and Fan Headers ..................................................... 32
7. Location of the Standby Power Indicator LED....................................... 39
8. Detailed System Memory Address Map ............................................... 42
9. Back Panel Connectors ..................................................................... 45
10. Component-side Connectors and Headers ........................................... 46
11. Connection Diagram for Front Panel Header ........................................ 52
12. Connection Diagram for Front Panel USB Headers ................................ 54
13. Connection Diagram for IEEE 1394a Header ........................................ 55
14. Location of the BIOS Configuration Jumper Block ................................. 56
15. CMOS Clear Header ......................................................................... 58
16. Board Dimensions ........................................................................... 59
17. Localized High Temperature Zones..................................................... 62
Tables
1. Feature Summary.............................................................................. 9
2. Board Components Shown in Figure 1 ................................................ 12
3. Supported Memory Configurations ..................................................... 16
4. HDMI Port Status Conditions ............................................................. 21
5. DVI Port Status Conditions................................................................ 21
6. Audio Jack Retasking Support ........................................................... 26
7. LAN Connector LED States ................................................................ 29
8. Effects of Pressing the Power Switch .................................................. 33
9. Power States and Targeted System Power........................................... 34
10. Wake-up Devices and Events ............................................................ 35
11. System Memory Map ....................................................................... 43
12. Component-side Connectors and Headers Shown in Figure 10................ 47
13. Front Panel Audio Header for HD Audio............................................... 48
14. Front Panel Audio Header for AC ’97 Audio .......................................... 48
15. Serial ATA Connectors...................................................................... 48
16. Serial Port Header ........................................................................... 48
17. Parallel Port Header ......................................................................... 49

Intel Desktop Board DG43GT Technical Product Specification
viii
18. S/PDIF Header ................................................................................ 49
19. Chassis Intrusion Header.................................................................. 50
20. Processor (4-Pin) Fan Header ............................................................ 50
21. Front and Rear Chassis (3-Pin) Fan Header ......................................... 50
22. Processor Core Power Connector........................................................ 51
23. Main Power Connector...................................................................... 51
24. Front Panel Header .......................................................................... 52
25. States for a One-Color Power LED...................................................... 53
26. States for a Two-Color Power LED...................................................... 53
27. Alternate Front Panel Power LED Header............................................. 54
28. BIOS Setup Configuration Jumper Settings.......................................... 57
29. Recommended Power Supply Current Values ....................................... 60
30. Fan Header Current Capability........................................................... 60
31. Thermal Considerations for Components ............................................. 62
32. Intel Desktop Board DG43GT Environmental Specifications.................... 63
33. BIOS Setup Program Menu Bar.......................................................... 66
34. BIOS Setup Program Function Keys.................................................... 66
35. Acceptable Drives/Media Types for BIOS Recovery ............................... 70
36. Boot Device Menu Options ................................................................ 71
37. Supervisor and User Password Functions............................................. 73
38. BIOS Beep Codes ............................................................................ 75
39. Front-panel Power LED Blink Codes.................................................... 76
40. BIOS Error Messages ....................................................................... 76
41. Port 80h POST Code Ranges.............................................................. 77
42. Port 80h POST Codes ....................................................................... 78
43. Typical Port 80h POST Sequence........................................................ 81
44. Safety Standards............................................................................. 83
45. Lead-Free Board Markings ................................................................ 88
46. EMC Regulations ............................................................................. 89
47. Product Certification Markings ........................................................... 90

9
1Product Description
1.1 Overview
1.1.1 Feature Summary
Table 1 summarizes the major features of Intel Desktop Board DG43GT.
Table 1. Feature Summary
Form Factor MicroATX (9.60 inches by 9.60 inches [243.84 millimeters by
243.84 millimeters])
Processor Support for the following:
•Intel®Core™2 Quad processor Q6000/Q8000/Q9000 Series in an LGA775
socket
•Intel®Core™2 Duo processor E4000/E5000/E6000/E8000 Series in an LGA775
socket
•Intel®Pentium®Dual-Core processor E2000/E5000 Series in an LGA775 socket
•Intel®Celeron®Dual-Core processor 400/1000 Series in an LGA775 socket
•Intel®Xeon®processor 3000/X3000 Series in an LGA775 socket
Memory •Four 240-pin DDR2 SDRAM Dual Inline Memory Module (DIMM) sockets
•Support for up to 16 GB of system memory using non-ECC DDR2 800 or
667 MHz DIMMs
Chipset Intel®G43 Express Chipset, consisting of:
•Intel®82G43 Graphics and Memory Controller Hub (GMCH)
•Intel®82801JIB I/O Controller Hub (ICH10)
Audio 10-channel (7.1 + 2) audio subsystem using Realtek ALC888S high definition
audio codec
Video Integrated graphics:
•Intel®Graphics Media Accelerator X4500 (Intel®GMA X4500) onboard graphics
subsystem with support for:
―Analog displays (via a DVI-I to VGA adapter)
―Digital displays (DVI-I and HDMI)
•External graphics:
―PCI Express x16 add-in graphics card connector
―PCI Express x1 add-in graphics card connectors
―PCI conventional add-in graphics card connector
Legacy I/O Control Winbond W83627DHG-A based Legacy I/O controller for hardware management
and serial, parallel, and PS/2* ports
continued

Intel Desktop Board DG43GT Technical Product Specification
10
Table 1. Feature Summary (continued)
Peripheral
Interfaces
•Twelve USB 2.0 ports:
―Six ports are implemented with stacked back panel connectors
―Six ports are routed to three separate front panel headers
•Two IEEE 1394a ports:
―One back panel port
―One front panel header
•Four internal Serial ATA (SATA) interfaces
•One Parallel ATA (PATA) connector
•One parallel port header
•One serial port header
•PS/2 keyboard/mouse port on the back panel
LAN Support Gigabit (10/100/1000 Mb/s) LAN subsystem using the Intel®82567V Gigabit
Ethernet Controller
BIOS •Intel®BIOS (resident in the SPI Flash device)
•Support for Advanced Configuration and Power Interface (ACPI), Plug and Play,
and SMBIOS
Instantly Available
PC Technology
•Support for PCI* Local Bus Specification Revision 2.3
•Support for PCI Express* Revision 1.1
•Suspend to RAM support
•Wake on PCI, PCI Express, PS/2 devices, serial port, front panel, USB ports,
and LAN
Expansion
Capabilities
•One PCI Express 2.0 x16 bus add-in card connector
•Two PCI Express 1.0 x1 bus add-in card connectors
•One PCI Conventional bus connector
Hardware Monitor
Subsystem
•Intel®Quiet System Technology (Intel®QST) implemented through the Intel®
Management Engine (Intel®ME) in ICH10
•Voltage sense to detect out of range power supply voltages
•Thermal sense to detect out of range thermal values
•Three fan headers
•Three fan sense inputs used to monitor fan activity

Product Description
11
1.1.2 Board Layout
Figure 1 shows the location of the board’s major components.
Figure 1. Major Board Components
Table 2 lists the components identified in Figure 1.

Intel Desktop Board DG43GT Technical Product Specification
12
Table 2. Board Components Shown in Figure 1
Item/callout
from Figure 1 Description
A Front panel audio header
B PCI Conventional bus add-in card connector
C IEEE 1394a header
D PCI Express x1 connector
E PCI Express x16 connector
F Battery
G PCI Express x1 connector
H Back panel connectors
I Processor core power connector (2 X 2)
J Rear chassis fan header
K LGA775 processor socket
L Processor fan header
M Intel 82G43 GMCH
N DIMM Channel A sockets
O Front chassis fan header
P DIMM Channel B sockets
Q Serial port header
R Parallel port header
S Main power connector (2 x 12)
T Front panel header
U Intel 82801JIB I/O Controller Hub (ICH10)
V Serial ATA connectors (4)
W Alternate front panel Power LED header
X Front panel USB header
Y Front panel USB header
Z Front panel USB header
AA Parallel ATA connector
BB Clear CMOS header
CC Chassis intrusion header
DD BIOS setup configuration jumper block
EE Speaker
FF S/PDIF header

Product Description
13
1.1.3 Block Diagram
Figure 2 is a block diagram of the board’s major functional areas.
Figure 2. Block Diagram

Intel Desktop Board DG43GT Technical Product Specification
14
1.2 Legacy Considerations
This board differs from other Intel®Desktop Board products, with specific changes
including (but not limited to) the following:
•No floppy drive connector
•No parallel port connector on the back panel
•The serial port header is located near the DIMM sockets and may require a
specialized chassis or cabling solution to use
1.3 Online Support
To find information about… Visit this World Wide Web site:
Intel Desktop Board DG43GT http://www.intel.com/products/motherboard/DG43GT/index.htm
Desktop Board Support http://support.intel.com/support/motherboards/desktop
Available configurations for the Intel
Desktop Board DG43GT
http://www.intel.com/products/motherboard/DG43GT/index.htm
Supported processors http://processormatch.intel.com
Chipset information http://www.intel.com/products/desktop/chipsets/index.htm
BIOS and driver updates http://downloadcenter.intel.com
Tested memory http://support.intel.com/support/motherboards/desktop/sb/CS-
025414.htm
Integration information http://www.intel.com/support/go/buildit

Product Description
15
1.4 Processor
The board is designed to support the following processors:
•Intel®Core™2 Quad processor Q6000/Q8000/Q9000 Series in an LGA775 socket
•Intel®Core™2 Duo processor E4000/E5000/E6000/E8000 Series in an LGA775
socket
•Intel®Pentium®Dual-Core processor E2000/E5000 Series in an LGA775 socket
•Intel®Celeron®Dual-Core processor 400/1000 Series in an LGA775 socket
•Intel®Xeon®processor 3000/X3000 Series in an LGA775 socket
Other processors may be supported in the future. This board is designed to support
processors with a maximum wattage of 95 W. The processors listed above are only
supported when falling within the wattage requirements of the board. See the Intel
web site listed below for the most up-to-date list of supported processors.
For information about… Refer to:
Supported processors http://processormatch.intel.com
CAUTION
Use only the processors listed on the web site above. Use of unsupported processors
can damage the board, the processor, and the power supply.
NOTE
Use only ATX12V-compliant power supplies.
For information about Refer to
Power supply connectors Section 2.2.2.3, page 51

Intel Desktop Board DG43GT Technical Product Specification
16
1.5 System Memory
The board has four DIMM sockets and supports the following memory features:
•1.8 V DDR2 800 MHz and DDR2 667 MHz SDRAM DIMMs
•Two independent memory channels with interleaved mode support
•Unbuffered, single-sided or double-sided DIMMs with the following restriction:
Double-sided DIMMs with x16 organization are not supported.
•16 GB maximum total system memory (with 2 Gb memory technology). Refer to
Section 2.1.1 on page 41 for information on the total amount of addressable
memory.
•Minimum total system memory: 512 MB
•Non-ECC DIMMs
•Serial Presence Detect
NOTE
To be fully compliant with all applicable DDR SDRAM memory specifications, the board
should be populated with DIMMs that support the Serial Presence Detect (SPD) data
structure. This allows the BIOS to read the SPD data and program the chipset to
accurately configure memory settings for optimum performance. If non-SPD memory
is installed, the BIOS will attempt to correctly configure the memory settings, but
performance and reliability may be impacted or the DIMMs may not function under the
determined frequency.
Table 3. Supported Memory Configurations
DIMM
Type
SDRAM
Technology
Smallest usable
DIMM (one x16
Single-sided
DIMM)
Largest usable
DIMM (one x8
Double-sided
DIMM)
Maximum capacity
with four identical
x8 Double-sided
DIMMs
DDR2 667 512 Mb 256 MB 1 GB 4 GB
DDR2 667 1 Gb 512 MB 2 GB 8 GB
DDR2 667 2 Gb 1024 MB 4 GB 16 GB
DDR2 800 512 Mb 256 MB 1 GB 4 GB
DDR2 800 1 Gb 512 MB 2 GB 8 GB
DDR2 800 2 Gb 1024 MB 4 GB 16 GB
For information about… Refer to:
Tested Memory http://support.intel.com/support/motherboards/desktop/sb/
CS-025414.htm

Product Description
17
1.5.1 Memory Configurations
The Intel 82G43 GMCH supports the following types of memory organization:
•Dual channel (Interleaved) mode. This mode offers the highest throughput for
real world applications. Dual channel mode is enabled when the installed memory
capacities of both DIMM channels are equal. Technology and device width can vary
from one channel to the other but the installed memory capacity for each channel
must be equal. If different speed DIMMs are used between channels, the slowest
memory timing will be used.
•Single channel (Asymmetric) mode. This mode is equivalent to single channel
bandwidth operation for real world applications. This mode is used when only a
single DIMM is installed or the memory capacities are unequal. Technology and
device width can vary from one channel to the other. If different speed DIMMs are
used between channels, the slowest memory timing will be used.
•Flex mode. This mode provides the most flexible performance characteristics.
The bottommost DRAM memory (the memory that is lowest within the system
memory map) is mapped to dual channel operation; the topmost DRAM memory
(the memory that is nearest to the 16 GB address space limit), if any, is mapped
to single channel operation. Flex mode results in multiple zones of dual and single
channel operation across the whole of DRAM memory. To use flex mode, it is
necessary to populate both channels.
For information about… Refer to:
Memory Configuration Examples http://www.intel.com/support/motherboards/desktop/sb/
cs-011965.htm

Intel Desktop Board DG43GT Technical Product Specification
18
Figure 3 illustrates the memory channel and DIMM configuration.
Figure 3. Memory Channel and DIMM Configuration
NOTE
Regardless of the memory configuration used (dual channel, single channel, or flex
mode), Channel A must always be populated. This is a requirement of the Intel
Management Engine.

Product Description
19
1.6 Intel®G43 Express Chipset
The Intel G43 Express chipset consists of the following devices:
•Intel 82G43 Graphics and Memory Controller Hub (GMCH) with Direct Media
Interface (DMI) interconnect
•Intel 82801JIB I/O Controller Hub (ICH10)
The GMCH component provides interfaces to the CPU, memory, and the DMI
interconnect. The component also provides integrated graphics capabilities supporting
3D, 2D, and display capabilities. ICH10 is a centralized controller for the board’s I/O
paths.
The chipset supports the following features:
•Onboard graphics
•Dynamic Video Memory Technology
•USB
•Serial ATA
For information about Refer to
The Intel G43 Express chipset http://www.intel.com/products/desktop/chipsets/index.htm
Resources used by the chipset Chapter 2
1.6.1 Intel G43 Graphics Subsystem
The Intel G43 Express chipset contains two separate, mutually exclusive graphics
options. Either the Intel GMA X4500 graphics controller (contained within the 82G43
GMCH) is used, or a PCI Express x16 add-in card can be used. When a PCI Express
x16 add-in card is installed, the Intel GMA X4500 graphics controller is disabled.
1.6.1.1 Intel®Graphics Media Accelerator X4500 Graphics
Controller
The Intel GMA X4500 graphics controller features the following:
•High quality texture engine
⎯DirectX10* and OpenGL* 2.0 compliant
⎯Shader Model 4.0
•3D Graphics Rendering enhancements
⎯1.6 dual texture GigaPixel/s max fill rate
⎯16-bit and 32-bit color
⎯Vertex cache
•Video
⎯Hi-Definition playback (partial hardware acceleration for MPEG-2, full hardware
acceleration for VC1 and AVC)
⎯Dynamic Video Memory Technology (DVMT) 5.0 uses system memory based on
the operating system and the amount of memory installed

Intel Desktop Board DG43GT Technical Product Specification
20
•Display
⎯Supports digital and analog displays up to 1920 x 1200 at 60 Hz refresh
(WUXGA) and 2560 x 1600 at 60 Hz refresh (WQXGA) respectively; also
supports 1920 x 1080 resolution for full High Definition video playback quality
⎯Dual independent display support (HDMI and DVI-I)
1.6.1.2 Dynamic Video Memory Technology (DVMT 5.0)
DVMT enables enhanced graphics and memory performance through highly efficient
memory utilization. DVMT ensures the most efficient use of available system memory
for maximum 2-D/3-D graphics performance. The amount of system memory
allocated to DVMT varies depending on the amount of total system memory installed
as well as the operating system being used. For Windows Vista*, a minimum of
128 MB can be allocated to DVMT and a maximum of over 2 GB can be allocated to
DVMT with the correct amount of memory installed. DVMT returns system memory
back to the operating system when the additional system memory is no longer
required by the graphics subsystem.
DVMT will always use a minimal fixed portion of system physical memory (as set in the
BIOS Setup program) for compatibility with legacy applications. An example of this
would be when using VGA graphics under DOS. Once loaded, the operating system
and graphics drivers allocate additional system memory to the graphics buffer as
needed for performing graphics functions.
NOTE
The use of DVMT requires operating system driver support.
1.6.1.3 Configuration Modes
The video modes supported by this board are based on the Extended Display
Identification Data (EDID) modes of the monitor to which the system is connected.
Standard monitors are assumed.
