Intel MAX 10 FPGA User manual

MAX 10 FPGA Device Overview
M10-OVERVIEW
2017.02.21
Subscribe
Send Feedback

Contents
1 MAX® 10 FPGA Device Overview...................................................................................... 3
1.1 Key Advantages of MAX 10 Devices...........................................................................3
1.2 Summary of MAX 10 Device Features ...................................................................... 4
1.3 MAX 10 Device Ordering Information.........................................................................5
1.3.1 MAX 10 Device Feature Options.................................................................... 6
1.4 MAX 10 Device Maximum Resources ........................................................................6
1.5 MAX 10 Devices I/O Resources Per Package ............................................................. 7
1.6 MAX 10 Vertical Migration Support............................................................................ 7
1.6.1 MAX 10 I/O Vertical Migration Support...........................................................8
1.6.2 MAX 10 ADC Vertical Migration Support......................................................... 8
1.7 Logic Elements and Logic Array Blocks.......................................................................9
1.8 Analog-to-Digital Converter......................................................................................9
1.9 User Flash Memory............................................................................................... 10
1.10 Embedded Multipliers and Digital Signal Processing Support......................................10
1.11 Embedded Memory Blocks....................................................................................11
1.12 Clocking and PLL.................................................................................................11
1.13 FPGA General Purpose I/O....................................................................................12
1.14 External Memory Interface................................................................................... 12
1.15 Configuration......................................................................................................13
1.16 Power Management............................................................................................. 13
1.17 Document Revision History for MAX 10 FPGA Device Overview.................................. 13
Contents
MAX 10 FPGA Device Overview
2

1 MAX® 10 FPGA Device Overview
MAX® 10 devices are single-chip, non-volatile low-cost programmable logic devices
(PLDs) to integrate the optimal set of system components.
The highlights of the MAX 10 devices include:
• Internally stored dual configuration flash
• User flash memory
• Instant on support
• Integrated analog-to-digital converters (ADCs)
• Single-chip Nios II soft core processor support
MAX 10 devices are the ideal solution for system management, I/O expansion,
communication control planes, industrial, automotive, and consumer applications.
Related Links
MAX 10 FPGA Device Datasheet
1.1 Key Advantages of MAX 10 Devices
Table 1. Key Advantages of MAX 10 Devices
Advantage Supporting Feature
Simple and fast configuration Secure on-die flash memory enables device configuration in less than 10 ms
Flexibility and integration • Single device integrating PLD logic, RAM, flash memory, digital signal
processing (DSP), ADC, phase-locked loop (PLL), and I/Os
• Small packages available from 3 mm × 3 mm
Low power • Sleep mode—significant standby power reduction and resumption in less than
1 ms
• Longer battery life—resumption from full power-off in less than 10 ms
20-year-estimated life cycle Built on TSMC's 55 nm embedded flash process technology
High productivity design tools • Quartus® Prime Lite edition (no cost license)
• Qsys system integration tool
• DSP Builder for Intel® FPGAs
• Nios® II Embedded Design Suite (EDS)
1 MAX® 10 FPGA Device Overview
Intel Corporation. All rights reserved. Intel, the Intel logo, Altera, Arria, Cyclone, Enpirion, MAX, Nios, Quartus
and Stratix words and logos are trademarks of Intel Corporation or its subsidiaries in the U.S. and/or other
countries. Intel warrants performance of its FPGA and semiconductor products to current specifications in
accordance with Intel's standard warranty, but reserves the right to make changes to any products and services
at any time without notice. Intel assumes no responsibility or liability arising out of the application or use of any
information, product, or service described herein except as expressly agreed to in writing by Intel. Intel
customers are advised to obtain the latest version of device specifications before relying on any published
information and before placing orders for products or services.
*Other names and brands may be claimed as the property of others.
ISO
9001:2008
Registered

1.2 Summary of MAX 10 Device Features
Table 2. Summary of Features for MAX 10 Devices
Feature Description
Technology 55 nm TSMC Embedded Flash (Flash + SRAM) process technology
Packaging • Low cost, small form factor packages—support multiple packaging
technologies and pin pitches
• Multiple device densities with compatible package footprints for seamless
migration between different device densities
• RoHS6-compliant
Core architecture • 4-input look-up table (LUT) and single register logic element (LE)
• LEs arranged in logic array block (LAB)
• Embedded RAM and user flash memory
• Clocks and PLLs
• Embedded multiplier blocks
• General purpose I/Os
Internal memory blocks • M9K—9 kilobits (Kb) memory blocks
• Cascadable blocks to create RAM, dual port, and FIFO functions
User flash memory (UFM) • User accessible non-volatile storage
• High speed operating frequency
• Large memory size
• High data retention
• Multiple interface option
Embedded multiplier blocks • One 18 × 18 or two 9 × 9 multiplier modes
• Cascadable blocks enabling creation of filters, arithmetic functions, and image
processing pipelines
ADC • 12-bit successive approximation register (SAR) type
• Up to 17 analog inputs
• Cumulative speed up to 1 million samples per second ( MSPS)
• Integrated temperature sensing capability
Clock networks • Global clocks support
• High speed frequency in clock network
Internal oscillator Built-in internal ring oscillator
PLLs • Analog-based
• Low jitter
• High precision clock synthesis
• Clock delay compensation
• Zero delay buffering
• Multiple output taps
General-purpose I/Os (GPIOs) • Multiple I/O standards support
• On-chip termination (OCT)
• Up to 830 megabits per second (Mbps) LVDS receiver, 800 Mbps LVDS
transmitter
External memory interface (EMIF) 1Supports up to 600 Mbps external memory interfaces:
continued...
1 EMIF is only supported in selected MAX 10 device density and package combinations. Refer to
the External Memory Interface User Guide for more information.
1 MAX® 10 FPGA Device Overview
MAX 10 FPGA Device Overview
4

Feature Description
• DDR3, DDR3L, DDR2, LPDDR2 (on 10M16, 10M25, 10M40, and 10M50.)
• SRAM (Hardware support only)
Note: For 600 Mbps performance, –6 device speed grade is required.
Performance varies according to device grade (commercial, industrial, or
automotive) and device speed grade (–6 or –7). Refer to the MAX 10
Device Data Sheet or External Memory Interface Spec Estimator for more
details.
Configuration • Internal configuration
• JTAG
• Advanced Encryption Standard (AES) 128-bit encryption and compression
options
• Flash memory data retention of 20 years at 85 °C
Flexible power supply schemes • Single- and dual-supply device options
• Dynamically controlled input buffer power down
• Sleep mode for dynamic power reduction
1.3 MAX 10 Device Ordering Information
Figure 1. Sample Ordering Code and Available Options for MAX 10 Devices
V : Wafer-Level Chip Scale (WLCSP)
E : Plastic Enhanced Quad Flat Pack (EQFP)
M : Micro FineLine BGA (MBGA)
U : Ultra FineLine BGA (UBGA)
F : FineLine BGA (FBGA)
Family Signature
Package Type
WLCSP Package Type
36 : 36 pins, 3 mm x 3 mm
81 : 81 pins, 4 mm x 4 mm
EQFP Package Type
144 : 144 pins, 22 mm x 22 mm
UBGA Package Type
169 : 169 pins, 11 mm x 11 mm
324 : 324 pins, 15 mm x 15 mm
FBGA Package Type
256 : 256 pins, 17 mm x 17 mm
484 : 484 pins, 23 mm x 23 mm
672 : 672 pins, 27 mm x 27 mm
MBGA Package Type
153 : 153 pins, 8 mm x 8 mm
Package Code
Operating Temperature
FPGA Fabric
Speed Grade Optional Suffix
Indicates specific device
options or shipment method
6 (fastest)
7
8
10M 16 DA U 484 I 7 G
SC : Single supply - compact features
:
:
:
:
SA : Single supply - analog and flash features
with RSU option
DC Dual supply - compact features
DF Dual supply - flash features with RSU option
DA Dual supply - analog and flash features
with RSU option
Feature Options
02 : 2K logic elements
04 : 4K logic elements
08 : 8K logic elements
16 : 16K logic elements
25 : 25K logic elements
40 : 40K logic elements
50 : 50K logic elements
Member Code
10M : MAX 10
G : RoHS6
ES : Engineering sample
P : Leaded package
C : Commercial (T = 0° C to 85° C)
I : Industrial (T = - 40° C to 100° C)
A : Automotive (T = - 40° C to 125° C)
J
J
J
Note: The –I6 and –A6 speed grades of the MAX 10 FPGA devices are not available by
default in the Quartus Prime software. Contact your local Intel sales representatives
for support.
Related Links
Intel FPGA Product Selector
Provides the latest information about Intel FPGAs.
1 MAX® 10 FPGA Device Overview
MAX 10 FPGA Device Overview
5

1.3.1 MAX 10 Device Feature Options
Table 3. Feature Options for MAX 10 Devices
Option Feature
Compact Devices with core architecture featuring single configuration image with self-configuration capability
Flash Devices with core architecture featuring:
• Dual configuration image with self-configuration capability
• Remote system upgrade capability
• Memory initialization
Analog Devices with core architecture featuring:
• Dual configuration image with self-configuration capability
• Remote system upgrade capability
• Memory initialization
• Integrated ADC
1.4 MAX 10 Device Maximum Resources
Table 4. Maximum Resource Counts for MAX 10 Devices
Resource Device
10M02 10M04 10M08 10M16 10M25 10M40 10M50
Logic Elements (LE) (K) 2 4 8 16 25 40 50
M9K Memory (Kb) 108 189 378 549 675 1,260 1,638
User Flash Memory (Kb) 296 1,248 1,376 2,368 3,200 5,888 5,888
18 × 18 Multiplier 16 20 24 45 55 125 144
PLL 2 2 2 4 4 4 4
GPIO 160 246 250 320 360 500 500
LVDS Dedicated
Transmitter
9 15 15 22 24 30 30
Emulated
Transmitter
73 114 116 151 171 241 241
Dedicated Receiver 73 114 116 151 171 241 241
Internal Configuration Image 1 2 2 2 2 2 2
ADC — 1 1 1 2 2 2
2 The maximum possible value including user flash memory and configuration flash memory. For
more information, refer to MAX 10 User Flash Memory User Guide.
1 MAX® 10 FPGA Device Overview
MAX 10 FPGA Device Overview
6

1.5 MAX 10 Devices I/O Resources Per Package
Table 5. Package Plan for MAX 10 Single Power Supply Devices
Device Package
Type M153
153-pin MBGA
U169
169-pin UBGA
E144
144-pin EQFP
Size 8 mm × 8 mm 11 mm × 11 mm 22 mm × 22 mm
Ball Pitch 0.5 mm 0.8 mm 0.5 mm
10M02 112 130 101
10M04 112 130 101
10M08 112 130 101
10M16 — 130 101
10M25 — — 101
10M40 — — 101
10M50 — — 101
Table 6. Package Plan for MAX 10 Dual Power Supply Devices
Device Package
Type V36
36-pin
WLCSP
V81
81-pin
WLCSP
U324
324-pin
UBGA
F256
256-pin
FBGA
F484
484-pin
FBGA
F672
672-pin
FBGA
Size 3 mm × 3
mm
4 mm × 4
mm
15 mm × 15
mm
17 mm × 17
mm
23 mm × 23
mm
27 mm × 27
mm
Ball
Pitch
0.4 mm 0.4 mm 0.8 mm 1.0 mm 1.0 mm 1.0 mm
10M02 27 — 160 — — —
10M04 — — 246 178 — —
10M08 — 56 246 178 250 —
10M16 — — 246 178 320 —
10M25 — — — 178 360 —
10M40 — — — 178 360 500
10M50 — — — 178 360 500
Related Links
•MAX 10 General Purpose I/O User Guide
•MAX 10 High-Speed LVDS I/O User Guide
1.6 MAX 10 Vertical Migration Support
Vertical migration supports the migration of your design to other MAX 10 devices of
different densities in the same package with similar I/O and ADC resources.
1 MAX® 10 FPGA Device Overview
MAX 10 FPGA Device Overview
7

1.6.1 MAX 10 I/O Vertical Migration Support
Figure 2. Migration Capability Across MAX 10 Devices
• The arrows indicate the migration paths. The devices included in each vertical
migration path are shaded. Some packages have several migration paths. Devices
with lesser I/O resources in the same path have lighter shades.
• To achieve the full I/O migration across product lines in the same migration path,
restrict I/Os usage to match the product line with the lowest I/O count.
Device
Package
V36 V81 M153 U169 U324 F256 E144 F484 F672
10M02
10M04
10M08
10M16
10M25
10M40
10M50
Note: To verify the pin migration compatibility, use the Pin Migration View window in the
Quartus Prime software Pin Planner.
1.6.2 MAX 10 ADC Vertical Migration Support
Figure 3. ADC Vertical Migration Across MAX 10 Devices
The arrows indicate the ADC migration paths. The devices included in each vertical
migration path are shaded.
Device
Package
M153 U169 U324 F256 E144 F484 F672
10M04
10M08
10M16
10M25
10M40
10M50
Dual ADC Device: Each ADC (ADC1 and ADC2) supports 1 dedicated analog input pin and 8 dual function pins.
Single ADC Device: Single ADC that supports 1 dedicated analog input pin and 16 dual function pins.
Single ADC Device: Single ADC that supports 1 dedicated analog input pin and 8 dual function pins.
1 MAX® 10 FPGA Device Overview
MAX 10 FPGA Device Overview
8

Table 7. Pin Migration Conditions for ADC Migration
Source Target Migratable Pins
Single ADC device Single ADC device You can migrate all ADC input pins
Dual ADC device Dual ADC device
Single ADC device Dual ADC device • One dedicated analog input pin.
• Eight dual function pins from the ADC1 block of the
source device to the ADC1 block of the target device.
Dual ADC device Single ADC device
1.7 Logic Elements and Logic Array Blocks
The LAB consists of 16 logic elements (LE) and a LAB-wide control block. An LE is the
smallest unit of logic in the MAX 10 device architecture. Each LE has four inputs, a
four-input look-up table (LUT), a register, and output logic. The four-input LUT is a
function generator that can implement any function with four variables.
Figure 4. MAX 10 Device Family LEs
Row, Column,
And Direct Link
Routing
data 1
data 2
data 3
data 4
labclr1
labclr2
Chip-Wide
Reset
(DEV_CLRn)
labclk1
labclk2
labclkena1
labclkena2
LE Carry-In
LAB-Wide
Synchronous
Load
LAB-Wide
Synchronous
Clear
Row, Column,
And Direct Link
Routing
Local
Routing
Register Chain
Output
Register Bypass
Programmable
Register
Register Chain
Routing from
previous LE
LE Carry-Out
Register Feedback
Synchronous
Load and
Clear Logic
Carry
Chain
Look-Up Table
(LUT)
Asynchronous
Clear Logic
Clock &
Clock Enable
Select
DQ
ENA
CLRN
1.8 Analog-to-Digital Converter
MAX 10 devices feature up to two ADCs. You can use the ADCs to monitor many
different signals, including on-chip temperature.
1 MAX® 10 FPGA Device Overview
MAX 10 FPGA Device Overview
9

Table 8. ADC Features
Feature Description
12-bit resolution • Translates analog signal to digital data for information processing, computing,
data transmission, and control systems
• Provides a 12-bit digital representation of the observed analog signal
Up to 1 MSPS sampling rate Monitors single-ended external inputs with a cumulative sampling rate of 25
kilosamples per second to 1 MSPS in normal mode
Up to 17 single-ended external inputs
for single ADC devices
One dedicated analog and 16 dual function input pins
Up to 18 single-ended external inputs
for dual ADC devices
• One dedicated analog and eight dual-function input pins in each ADC block
• Simultaneous measurement capability for dual ADC devices
On-chip temperature sensor Monitors external temperature data input with a sampling rate of up to 50
kilosamples per second
1.9 User Flash Memory
The user flash memory (UFM) block in MAX 10 devices stores non-volatile information.
UFM provides an ideal storage solution that you can access using Avalon Memory-
Mapped (Avalon-MM) slave interface protocol.
Table 9. UFM Features
Features Capacity
Endurance Counts to at least 10,000 program/erase cycles
Data retention • 20 years at 85 ºC
• 10 years at 100 ºC
Operating frequency Maximum 116 MHz for parallel interface and 7.25 MHz for
serial interface
Data length Stores data up to 32 bits length in parallel
1.10 Embedded Multipliers and Digital Signal Processing Support
MAX 10 devices support up to 144 embedded multiplier blocks. Each block supports
one individual 18 × 18-bit multiplier or two individual 9 × 9-bit multipliers.
With the combination of on-chip resources and external interfaces in MAX 10 devices,
you can build DSP systems with high performance, low system cost, and low power
consumption.
You can use the MAX 10 device on its own or as a DSP device co-processor to improve
price-to-performance ratios of DSP systems.
You can control the operation of the embedded multiplier blocks using the following
options:
• Parameterize the relevant IP cores with the Quartus Prime parameter editor
• Infer the multipliers directly with VHDL or Verilog HDL
System design features provided for MAX 10 devices:
1 MAX® 10 FPGA Device Overview
MAX 10 FPGA Device Overview
10
