Intel S2600IP Configuration guide

Intel®Server Board S2600IP and
Intel® Workstation Board W2600CR
Technical Product Specification
Intel order number G34153-003
Revision 1.1
June, 2012
Enterprise Platforms and Services Division - Marketing

Revision History Intel® Server Board S2600IP and Intel® Workstation Board W2600CR TPS
Revision 1.1
Intel order number G34153-003
ii
Revision History
Date
Revision
Number
Modifications
February, 2012
1.0
Initial release.
June, 2012
1.1
Updated thermal management and environmental summary.
Updated onboard power connectors information.
Disclaimers
Information in this document is provided in connection with Intel®products. No license, express or implied, by
estoppel or otherwise, to any intellectual property rights is granted by this document. Except as provided in Intel's
Terms and Conditions of Sale for such products, Intel assumes no liability whatsoever, and Intel disclaims any
express or implied warranty, relating to sale and/or use of Intel products including liability or warranties relating to
fitness for a particular purpose, merchantability, or infringement of any patent, copyright or other intellectual property
right. Intel products are not intended for use in medical, lifesaving, or life sustaining applications. Intel may make
changes to specifications and product descriptions at any time, without notice.
Designers must not rely on the absence or characteristics of any features or instructions marked "reserved" or
"undefined." Intel reserves these for future definition and shall have no responsibility whatsoever for conflicts or
incompatibilities arising from future changes to them.
This document contains information on products in the design phase of development. Do not finalize a design with
this information. Revised information will be published when the product is available. Verify with your local sales office
that you have the latest datasheet before finalizing a design.
The Intel® Server Board S2600IP and Intel® Workstation Board W2600CR may contain design defects or errors
known as errata which may cause the product to deviate from published specifications. Current characterized errata
are available on request.
This document and the software described in it is furnished under license and may only be used or copied in
accordance with the terms of the license. The information in this manual is furnished for informational use only, is
subject to change without notice, and should not be construed as a commitment by Intel Corporation. Intel
Corporation assumes no responsibility or liability for any errors or inaccuracies that may appear in this document or
any software that may be provided in association with this document.
Except as permitted by such license, no part of this document may be reproduced, stored in a retrieval system, or
transmitted in any form or by any means without the express written consent of Intel Corporation.
Intel, Pentium, Itanium, and Xeon are trademarks or registered trademarks of Intel Corporation.
*Other brands and names may be claimed as the property of others.
Copyright © 2012 Intel Corporation

Intel® Server Board S2600IP and Intel® Workstation Board W2600CR TPS Table of Contents
Revision 1.1
Intel order number G34153-003
iii
Table of Contents
1. Introduction ........................................................................................................................1
1.1 Chapter Outline......................................................................................................1
1.2 Server Board Use Disclaimer.................................................................................1
2. Product Overview...............................................................................................................2
2.1 Product Feature Set...............................................................................................3
2.1.1 Main Board Connector and Component Layout......................................................5
2.1.2 Main Board Rear I/O Layout...................................................................................8
2.1.3 Server Board Mechanical Drawings .....................................................................10
3. Functional Architecture ...................................................................................................19
3.1 Processor Support ...............................................................................................20
3.1.1 Processor Socket Assembly.................................................................................20
3.1.2 Processor Population Rules.................................................................................22
3.1.3 Processor Initialization Error Summary.................................................................22
3.2 Processor Functions Overview.............................................................................25
3.2.1 Intel®QuickPath Interconnect...............................................................................25
3.2.2 Integrated Memory Controller (IMC) and Memory Subsystem..............................26
3.2.3 Processor Integrated I/O Module (IIO)..................................................................32
3.3 Intel®C600-A Chipset Functional overview ..........................................................33
3.3.1 Digital Media Interface (DMI)................................................................................34
3.3.2 PCI Express* Interface.........................................................................................34
3.3.3 Serial ATA (SATA) Controller...............................................................................34
3.3.4 Serial Attached SCSI (SAS)/SATA (SCU) Controller............................................35
3.3.5 AHCI ....................................................................................................................35
3.3.6 Rapid Storage Technology...................................................................................35
3.3.7 PCI Interface........................................................................................................36
3.3.8 Low Pin Count (LPC) Interface.............................................................................36
3.3.9 Serial Peripheral Interface (SPI)...........................................................................36
3.3.10 Compatibility Modules (DMA Controller, Timer/Counters, Interrupt Controller).....36
3.3.11 Advanced Programmable Interrupt Controller (APIC)...........................................36
3.3.12 Universal Serial Bus (USB) Controllers................................................................36
3.3.13 Gigabit Ethernet Controller...................................................................................37
3.3.14 RTC .....................................................................................................................37
3.3.15 GPIO....................................................................................................................37
3.3.16 Enhanced Power Management............................................................................37
3.3.17 Manageability.......................................................................................................37
3.3.18 System Management Bus (SMBus* 2.0) ..............................................................37
3.3.19 Integrated NVSRAM controller.............................................................................38
3.3.20 Virtualization Technology for Directed I/O (Intel®VT-d)........................................38
3.3.21 JTAG Boundary-Scan ..........................................................................................38

Table of Contents Intel® Server Board S2600IP and Intel® Workstation Board W2600CR TPS
Revision 1.1
Intel order number G34153-003
iv
3.3.22 KVM/Serial Over Lan (SOL) Function...................................................................38
3.3.23 On-board SAS/SATA Support and Options..........................................................38
3.4 PCI Subsystem ....................................................................................................39
3.5 Network Interface Controller.................................................................................40
3.5.1 Network Interface.................................................................................................40
3.6 I/O Module Support (not avaiable for Intel®Server Board S2600IP4L and Intel®
Workstation Board W2600CR2L)...........................................................................................41
3.7 SAS ROC Module Support...................................................................................42
3.8 HD Audio Support (Intel®Workstation Board W2600CR Only).............................43
3.9 USB3.0 Support (Intel®Workstation Board W2600CR Only)................................44
3.10 IEEE1394b Support (Intel®Workstation Board W2600CR Only) ..........................45
4. Platform Management Overview .....................................................................................46
4.1 Server Management Function Architecture ..........................................................46
4.1.1 Feature Support...................................................................................................46
4.1.2 Basic and Advanced Features..............................................................................48
4.1.3 Integrated BMC Hardware: Emulex* Pilot III.........................................................49
4.2 Server Management Functional Specifications.....................................................51
4.2.1 BMC Internal Timestamp Clock............................................................................51
4.2.2 System Event Log (SEL)......................................................................................52
4.2.3 Sensor Data Record (SDR) Repository................................................................52
4.2.4 Field Replaceable Unit (FRU) Inventory Device ...................................................52
4.2.5 BMC Beep Codes ................................................................................................52
4.2.6 Diagnostic Interrupt (NMI) Button.........................................................................53
4.2.7 BMC Watchdog....................................................................................................53
4.3 Sensor Monitoring................................................................................................54
4.3.1 Overview..............................................................................................................54
4.3.2 Core Sensor List for EPSD Platforms Based on Intel®Xeon®Processor E5
4600/2600/2400/1600/1400 Product Families.....................................................................54
4.3.3 BMC System Management Health Monitoring......................................................56
4.3.4 Processor Sensors...............................................................................................56
4.4 Thermal and Acoustic Management.....................................................................60
4.4.1 Set Throttling Mode..............................................................................................60
4.4.2 Altitude.................................................................................................................60
4.4.3 Set Fan Profile .....................................................................................................60
4.4.4 Fan PWM Offset...................................................................................................61
4.4.5 Quiet Fan Idle Mode.............................................................................................61
4.4.6 Thermal Sensor Input for Fan Speed Control.......................................................61
4.4.7 Power Supply Status\Health Sensors...................................................................62
4.4.8 System Event Sensor...........................................................................................63
4.5 Platform Management Interface ...........................................................................65
4.5.1 Channel Management..........................................................................................65

Intel® Server Board S2600IP and Intel® Workstation Board W2600CR TPS Table of Contents
Revision 1.1
Intel order number G34153-003
v
4.5.2 User Model...........................................................................................................65
4.5.3 LAN Interface.......................................................................................................66
4.6 BMC Firmware Update.........................................................................................76
4.6.1 The BMC firmware release Number.....................................................................76
4.6.2 Boot Recovery Mode............................................................................................76
4.6.3 Force Firmware Update Jumper...........................................................................77
4.6.4 Fast Firmware Update over USB..........................................................................77
4.7 Advanced Management Feature Support.............................................................78
4.7.1 Enabling Advanced Management Features..........................................................78
4.7.2 Keyboard, Video, Mouse (KVM) Redirection........................................................78
4.7.3 Media Redirection................................................................................................79
4.8 Intel®Intelligent Power Node Manager (NM) ........................................................81
4.8.1 Overview..............................................................................................................81
4.9 EU Lot 6 Mode.....................................................................................................82
5. System Security................................................................................................................84
5.1 BIOS Password Protection...................................................................................84
5.2 Trusted Platform Module (TPM) Support..............................................................85
5.2.1 TPM security BIOS...............................................................................................85
5.2.2 Physical Presence................................................................................................86
5.2.3 TPM Security Setup Options................................................................................86
5.3 Intel®Trusted Execution Technology....................................................................88
6. Connector/Header Locations and Pin-outs ....................................................................90
6.1 Power Connectors................................................................................................90
6.1.1 Main Power Connector.........................................................................................90
6.1.2 CPU Power Connectors.......................................................................................90
6.1.3 Add-in Card Power Connectors............................................................................90
6.2 Front Panel Header and Connectors....................................................................91
6.2.1 Front Panel Header..............................................................................................91
6.2.2 Front Panel USB Connector.................................................................................92
6.2.3 Local Control Panel Connector.............................................................................92
6.3 On Board Storage Connectors.............................................................................92
6.3.1 SATA Connectors: 6Gbps....................................................................................92
6.3.2 Multiport Mini-SAS/SATA Connectors..................................................................93
6.3.3 Intel®RAID C600 Upgrade Key Connector...........................................................94
6.3.4 HSBP_I2C Header...............................................................................................94
6.3.5 HDD LED Header.................................................................................................94
6.3.6 Internal Type- A USB Connector..........................................................................94
6.3.7 Internal eUSB SSD Header..................................................................................95
6.4 Management and Security Connectors ................................................................95
6.4.1 RMM4_Lite Connector .........................................................................................95
6.4.2 RMM4_NIC Connector.........................................................................................95

Table of Contents Intel® Server Board S2600IP and Intel® Workstation Board W2600CR TPS
Revision 1.1
Intel order number G34153-003
vi
6.4.3 TPM Connector....................................................................................................96
6.4.4 PMBus* Connector...............................................................................................96
6.4.5 Chassis Intrusion Header.....................................................................................96
6.4.6 IPMB Connector...................................................................................................96
6.5 FAN Connectors...................................................................................................96
6.5.1 System FAN Connectors......................................................................................97
6.5.2 CPU FAN Connector............................................................................................97
6.6 Serial Port and Video Connectors ........................................................................97
6.6.1 Serial Port A Connector (DB9, for Intel®Server Board S2600IP only) ..................97
6.6.2 Serial Port B Connector........................................................................................98
6.6.3 Video Connector (For Intel®Server Board S2600IP only).....................................98
6.6.4 Internal Video header (For Intel®Workstation Board W2600CR only) ..................99
7. Jumper Blocks................................................................................................................100
7.1 BIOS Default and Password Reset Usage Procedure........................................101
7.1.1 Set BIOS to default (Clearing the CMOS)...........................................................101
7.1.2 Clearing the Password.......................................................................................101
7.2 Force BMC Update Procedure...........................................................................102
7.3 BIOS Recovery Jumper......................................................................................102
7.4 ME Force Update Jumper ..................................................................................103
8. Intel®Light Guided Diagnostics ....................................................................................105
8.1 5-volt Stand-by LED...........................................................................................105
8.2 Fan Fault LED....................................................................................................105
8.3 CPU Fault LED...................................................................................................105
8.4 DIMM Fault LEDs...............................................................................................107
8.5 System ID LED, System Status LED and POST Code Diagnostic LEDs............107
8.5.1 System ID LED...................................................................................................108
8.5.2 System Status LED............................................................................................109
8.5.3 POST Code Diagnostic LEDs.............................................................................110
9. Design and Environmental Specifications....................................................................111
9.1 Products Design Specifications..........................................................................111
9.2 MTBF.................................................................................................................111
9.3 Server Board Power Requirements....................................................................114
9.3.1 Processor Power Support...................................................................................115
9.4 Power Supply Output Requirements ..................................................................115
9.4.1 Output Power/Currents.......................................................................................115
9.4.2 Cross Loading....................................................................................................115
9.4.3 Standby Output..................................................................................................116
9.4.4 Voltage Regulation.............................................................................................116
9.4.5 Dynamic Loading ...............................................................................................116
9.4.6 Capacitive Loading.............................................................................................117
9.4.7 Grounding..........................................................................................................117

Intel® Server Board S2600IP and Intel® Workstation Board W2600CR TPS Table of Contents
Revision 1.1
Intel order number G34153-003
vii
9.4.8 Closed loop stability ...........................................................................................117
9.4.9 Residual Voltage Immunity in Standby mode .....................................................117
9.4.10 Common Mode Noise.........................................................................................117
9.4.11 Soft Starting .......................................................................................................118
9.4.12 Zero Load Stability Requirements ......................................................................118
9.4.13 Ripple/Noise.......................................................................................................118
9.4.14 Timing Requirements.........................................................................................118
Appendix A: Integration and Usage Tips ............................................................................121
Appendix B: BMC Sensor Tables.........................................................................................122
Appendix C: Platform Specific BMC Appendix...................................................................147
Introduction.......................................................................................................................147
Product ID ........................................................................................................................147
IPMI Channel ID Assignments..........................................................................................147
ACPI S3 Sleep State Support...........................................................................................147
Processor Support for Intel®Server Board S2600IP.........................................................147
Supported Chassis...........................................................................................................147
Chassis-specific sensors..................................................................................................148
Hot-plug fan support.........................................................................................................148
Fan redundancy support...................................................................................................148
Fan domain definition .......................................................................................................149
HSC Availability................................................................................................................151
Power unit support............................................................................................................152
Redundant Fans only for Intel®Server Chassis................................................................152
Fan Fault LED support......................................................................................................152
Memory Throttling support................................................................................................153
Introduction.......................................................................................................................153
Product ID ........................................................................................................................153
IPMI Channel ID Assignments..........................................................................................153
ACPI S3 Sleep State Support...........................................................................................153
Processor Support for Intel®Server Board W2600CR ......................................................154
Supported Chassis...........................................................................................................154
Chassis-specific sensors..................................................................................................154
Hot-plug fan support.........................................................................................................154
Fan redundancy support...................................................................................................154
Board specific feature.......................................................................................................154
Fan domain definition .......................................................................................................154
HSC Availability................................................................................................................155

Table of Contents Intel® Server Board S2600IP and Intel® Workstation Board W2600CR TPS
Revision 1.1
Intel order number G34153-003
viii
Power unit support............................................................................................................155
Redundant Fans only for Intel®Server Chassis................................................................155
Fan Fault LED support......................................................................................................155
Memory Throttling support................................................................................................155
Appendix D: POST Code Diagnostic LED Decoder............................................................156
Appendix E: POST Error Messages and Handling..............................................................162
Glossary ................................................................................................................................169
Reference Documents..........................................................................................................172

Intel® Server Board S2600IP and Intel® Workstation Board W2600CR TPS List of Figures
Revision 1.1
Intel order number G34153-003
ix
List of Figures
Figure 1. Intel®Server Board S2600IP........................................................................................2
Figure 2. Intel®Workstation Board W2600CR.............................................................................2
Figure 3. Intel®Server Board S2600IP Major Components.........................................................6
Figure 4. Intel®Server Board S2600IP Rear I/O Layout..............................................................8
Figure 5. Intel®Workstation Board W2600CR Rear I/O Layout...................................................9
Figure 6. Mounting Hole Locations (1 of 2)................................................................................10
Figure 7. Mounting Hole Locations (2 of 2)................................................................................11
Figure 8. Major Connector Pin-1 Locations (1 of 3)...................................................................12
Figure 9. Major Connector Pin-1 Locations (2 of 3)...................................................................13
Figure 10. Major Connector Pin-1 Locations (3 of 3).................................................................14
Figure 11. Primary Side Keep-out Zone....................................................................................16
Figure 12. Primary Side Card-Side Keep-out Zone...................................................................17
Figure 13. Second Side Keep-out Zone....................................................................................18
Figure 14. Intel®Server Board S2600IP Functional Block Diagram...........................................19
Figure 15. Intel®Workstation Board W2600CR Functional Block Diagram................................20
Figure 16. Processor Socket Assembly.....................................................................................21
Figure 17. Processor Socket ILM..............................................................................................21
Figure 18. Integrated Memory Controller Functional Block Diagram..........................................26
Figure 19. DIMM Slot Layout.....................................................................................................30
Figure 20. External RJ45 NIC Port LED Definition ....................................................................41
Figure 21. Supported I/O Module Options.................................................................................42
Figure 22. USB3.0 Discrete Host Controller Block Diagram......................................................44
Figure 23. IEEE 1394b Discrete Host Controller Block Diagram ...............................................45
Figure 24. Integrated BMC Hardware........................................................................................51
Figure 25. High-level Fan Speed Control Process.....................................................................62
Figure 26. Setup Utility –TPM Configuration Screen ................................................................87
Figure 27. Video Connector Pin-out..........................................................................................98
Figure 28. Jumper Blocks (J1C3, J1F1, J1F2, J2F3, J2F2).....................................................100
Figure 29. Stand by LED, Fan Fault LED and CPU Fault LED Location..................................106
Figure 30. DIMM Fault LED’s Location....................................................................................107
Figure 31. Location of System Status, System ID and POST Code Diagnostic LEDs..............108
Figure 32. Power Distribution Block Diagram..........................................................................114
Figure 33. Differential Noise test setup ...................................................................................118
Figure 34. Output Voltage Timing ...........................................................................................119
Figure 35. Turn On/Off Timing (Power Supply Signals)...........................................................120
Figure 36. POST Code Diagnostic LED Decoder....................................................................156

List of Tables Intel® Server Board S2600IP and Intel® Workstation Board W2600CR TPS
Revision 1.1
Intel order number G34153-003
x
List of Tables
Table 1. Product Feature Set......................................................................................................3
Table 2. Mixed Processor Configurations Error Summary.........................................................23
Table 3. UDIMM Support Guidelines.........................................................................................27
Table 4. RDIMM Support Guidelines.........................................................................................28
Table 5. LRDIMM Support Guidelines.......................................................................................28
Table 6. DIMM Nomenclature ...................................................................................................29
Table 7. Intel®RAID C600 Upgrade Key Options......................................................................35
Table 8. Intel®Server Board S2600IP/Workstation Board W2600CR PCI Bus Segment
Characteristics....................................................................................................................40
Table 9. Supported Intel®Integrated RAID Modules..................................................................43
Table 10. Standard Speaker Channels .....................................................................................44
Table 11. Basic and Advanced Features...................................................................................49
Table 12. BMC Beep Codes......................................................................................................52
Table 13. NMI Signal Generation and Event Logging................................................................53
Table 14. Supported BMC FW Health Sensor Offsets...............................................................56
Table 15. Processor Sensors....................................................................................................56
Table 16. Processor Status Sensor Implementation..................................................................57
Table 17. Supported ERR2 Timeout Sensor Offsets.................................................................58
Table 18. Supported CATERR Sensor Offsets..........................................................................59
Table 19. Support MSID Mismatch Sensor Offsets ...................................................................60
Table 20. Supported Power Supply Status Sensor Offsets........................................................62
Table 21. Support System Event Sensor Offsets ......................................................................64
Table 22. Supported Firmware Update Status Sensor Offsets..................................................64
Table 23. Standard Channel Assignments................................................................................65
Table 24. Supported RMCP+ Cipher Suites..............................................................................66
Table 25. Supported RMCP+ Payload Types............................................................................67
Table 26. Factory Configured PEF Table Entries......................................................................71
Table 27. Enabling Advanced Management Features...............................................................78
Table 28. TSetup Utility –Security Configuration Screen Fields................................................88
Table 29. Main Power Connector Pin-out..................................................................................90
Table 30. CPU_1 Power Connector Pin-out..............................................................................90
Table 31. CPU_2 Power Connector Pin-out..............................................................................90
Table 32. Add-in Slot Power Pin-input ("OPT_12V_PWR").......................................................91
Table 33. Front Panel Header Pin-out.......................................................................................91
Table 34. Front Panel USB Connector Pin-out..........................................................................92
Table 35. Local Front Panel Connector Pin-out.........................................................................92
Table 36. SATA 6Gbps Connector Pin-out................................................................................92

Intel® Server Board S2600IP and Intel® Workstation Board W2600CR TPS List of Tables
Revision 1.1
Intel order number G34153-003
xi
Table 37. Multiport SAS/SATA Connector Pin-out ("SCU_0 (0-3)")...........................................93
Table 38. Multiport SAS/SATA Connector Pin-out ("SCU_1 (4-7)")...........................................93
Table 39. Intel®RAID C600 Upgrade Key Connector Pin-out....................................................94
Table 40. HSBP_I2C Header Pin-out........................................................................................94
Table 41. HDD LED Header Pin-out..........................................................................................94
Table 42. Type-A USB Connector Pin-out.................................................................................94
Table 43. eUSB SSD Header Pin-out........................................................................................95
Table 44. RMM4_Lite Connector Pin-out ..................................................................................95
Table 45. RMM4_NIC Connector Pin-out..................................................................................95
Table 46. TPM Connector Pin-out.............................................................................................96
Table 47. PMBus* Connector Pin-out........................................................................................96
Table 48. Chassis Intrusion Header Pin-out..............................................................................96
Table 49. IPMB Connector Pin-out............................................................................................96
Table 50. 6-pin System FAN Connector Pin-out........................................................................97
Table 51. 4-pin System FAN Connector Pin-out........................................................................97
Table 52. CPU FAN Connector Pin-out.....................................................................................97
Table 53. Serial Port A Connector Pin-out.................................................................................97
Table 54. Serial Port B Connector Pin-out.................................................................................98
Table 55. Video Connector Pin-out details................................................................................98
Table 56. Server Board Jumpers (J1C3, J1F1, J1F2, J2F3, J2F2)..........................................100
Table 57. System Status LED.................................................................................................109
Table 58. POST Code Diagnostic LEDs..................................................................................110
Table 59. Server Board Design Specifications ........................................................................111
Table 60. Intel®Server Board S2600IP MTBF Estimate..........................................................112
Table 61. Intel®Workstation Board W2600CR MTBF Estimate...............................................112
Table 62. Intel®Xeon®Processor Dual Processor TDP profile................................................115
Table 63. Minimum Load Ratings............................................................................................115
Table 64. Loading Conditions..................................................................................................116
Table 65.Voltage Regulation Limits.........................................................................................116
Table 66. Transient Load Requirements .................................................................................116
Table 67. Capacitive Loading Conditions................................................................................117
Table 68. Ripples and Noise...................................................................................................118
Table 69. Output Voltage Timing.............................................................................................119
Table 70. Turn On/Off Timing..................................................................................................119
Table 71. Integrated BMC Core Sensors.................................................................................124
Table 72. Intel®Server Board S2600IP - BMC Channel Assignments.....................................147
Table 73. Intel®Server Board S2600IP - Chassis-specific Sensors.........................................148
Table 74. Intel®Server Board S2600IP - Fan Domain Definition.............................................149
Table 75. Intel®Server Chassis P4208/P4216/P4224/P4308 (UPL) Power support................152
Table 76. Intel®Server Chassis R2208/R2216/R2224/R2308/R2312 (BHP) Power support ...152
Table 77. Intel®Workstation Board W2600CR - BMC Channel Assignments..........................153

List of Tables Intel® Server Board S2600IP and Intel® Workstation Board W2600CR TPS
Revision 1.1
Intel order number G34153-003
xii
Table 78. Intel®Workstation Board W2600CR - Chassis-specific sensors ..............................154
Table 79. Intel®Workstation Board W2600CR - Fan domain definition ...................................154
Table 80. Intel®Server Chassis P4304 (UPL) Power support .................................................155
Table 81. POST Progress Code LED Example.......................................................................157
Table 82. POST Progress Codes............................................................................................157
Table 83. MRC Progress Codes .............................................................................................159
Table 84. MRC Fatal Error Codes...........................................................................................160
Table 85. POST Error Codes and Messages..........................................................................162
Table 86. POST Error Beep Codes.........................................................................................167
Table 87. Integrated BMC Beep Codes...................................................................................168

Intel® Server Board S2600IP and Intel® Workstation Board W2600CR TPS List of Tables
Revision 1.1
Intel order number G34153-003
xiii
<This page is intentionally left blank.>

Intel® Server Board S2600IP and Intel® Workstation Board W2600CR TPS Introduction
Revision 1.1 1
Intel order number G34153-003
1. Introduction
This Technical Product Specification (TPS) provides board-specific information detailing the
features, functionality, and high-level architecture of the Intel®Server Board S2600IP and Intel®
Workstation Board W2600CR.
In addition, you can obtain design-level information for a given subsystem by ordering the
External Product Specifications (EPS) for the specific subsystem. EPS documents are not
publicly available and you must order them through your local Intel representative.
1.1 Chapter Outline
This document is divided into the following chapters:
Chapter 1 –Introduction
Chapter 2 –Product Overview
Chapter 3 –Functional Architecture
Chapter 4 –Platform Management Overview
Chapter 5 –System Security
Chapter 6 –Connector/Header Locations and Pin-outs
Chapter 7 –Jumper Blocks
Chapter 8 –Intel®Light Guided Diagnostics
Chapter 9 –Design and Environmental Specifications
Appendix A: Integration and Usage Tips
Appendix B: BMC Sensor Tables
Appendix C: Platform Specific BMC Appendix
Appendix D: POST Code Diagnostic LED Decoder
Appendix E: POST Error Messages and Handling
Glossary
Reference Documents
1.2 Server Board Use Disclaimer
Intel®Server Boards contain a number of high-density VLSI (Very-large-scale integration) and
power delivery components that require adequate airflow for cooling. Intel ensures through its
own chassis development and testing that when Intel®server building blocks are used together,
the fully integrated system meets the intended thermal requirements of these components. It is
the responsibility of the system integrator who chooses not to use Intel developed server
building blocks to consult vendor datasheets and operating parameters to determine the amount
of airflow required for their specific application and environmental conditions. Intel Corporation
cannot be held responsible if components fail or the server board does not operate correctly
when used outside any of the published operating or non-operating limits.

Product Overview Intel® Server Board S2600IP and Intel® Workstation Board W2600CR TPS
2 Revision 1.1
Intel order number G34153-003
2. Product Overview
The Intel®Server Board S2600IP and Intel®Workstation Board W2600CR are Enterprise I/O
Rich platforms for Pedestal and Rack Server and workstation market.
Figure 1. Intel®Server Board S2600IP
Figure 2. Intel®Workstation Board W2600CR

Intel® Server Board S2600IP and Intel® Workstation Board W2600CR TPS Product Overview
Revision 1.1 3
Intel order number G34153-003
2.1 Product Feature Set
Table 1. Product Feature Set
Board Name
Intel®Server Board S2600IP
Intel®Workstation Board W2600CR
Processors
Support for one or two Intel®Xeon®E5-
2600 Processor(s)
8 GT/s Intel®Quick Path Interconnect
(Intel®QPI)
LGA 2011 Socket
Thermal Design Power up to 135 W
Support for one or two Intel®Xeon®E5-
2600 Processor(s)
8 GT/s Intel®Quick Path Interconnect (Intel®
QPI)
LGA 2011 Socket
Thermal Design Power up to 150 W
Chipset
Intel®C600-A chipset with support for optional Intel®C600 RAID Upgrade Keys
Memory
16 DDR3 DIMMs with 800MT/s, 1067MT/s, 1333MT/s,1600MT/s
Eight memory channels (four channels for each processor socket)
Channels A, B, C, D, E, F, G and H
Support for 800/1066/1333/1600 MHz/s Registered DDR3 Memory (RDIMM),
Unbuffered DDR3 memory ((UDIMM) and Load Reduced DDR3 memory (LRDIMM)
DDR3 standard I/O voltage of 1.5V and DDR3 Low Voltage of 1.35V
Slots
Slot 1: PCIe Gen3 x16, connector from first processor.
Slot 2: PCIe Gen3 x8, connector from first processor.
Slot 3: PCIe Gen3 x16, connector from first processor.
Slot 4: PCIe Gen3 x8, connector from second processor.
Slot 5: PCIe Gen3 x16, connector from second processor.
Slot 6: PCIe Gen3 x8, connector, from second processor
Slot 7: PCIe Gen3 x16,connector, from second processor
Slot 8: PCIe Gen2 x4 electrical with x8 physical connector, from second processor
IOM Connector: I/O Module (optional with Flex Cable*)
Notes: The IOM connector is not available for all boards and only supports PCIe Gen1 Speed
SM Conn: SAS Module (optional)
6Gbps or 12Gbps SAS ROC module Options
Ethernet
Intel®I350 Quad 1GbE fully integrated GbE
MAC and PHY Network Controller
Intel®I350 Dual 1GbE fully integrated GbE MAC
and PHY Controller
On-board storage
controllers and
options
One eUSB 2x5 pin connector to support 2mm low-profile eUSB solid state devices
Two 7-pin single port AHCI SATA connectors capable of supporting up to 6 GB/sec
Two SCU 4-port mini-SAS connectors capable of supporting up to 3 GB/sec SAS/SATA
Intel®Integrated RAID module support (Optional)
Intel®RAID C600 Upgrade Key support providing optional expanded SATA/SAS RAID
capabilities
Video
Integrated Matrox* G200 2D Video
Graphics controller
1 Rear VGA port
Integrated Matrox* G200 2D Video
Graphics controller
1 Internal VGA connector

Product Overview Intel® Server Board S2600IP and Intel® Workstation Board W2600CR TPS
4 Revision 1.1
Intel order number G34153-003
Board Name
Intel®Server Board S2600IP
Intel®Workstation Board W2600CR
Audio
None
ALC889 HD Audio (7.1 + S/PDIF Out)
I/O
4 Rear USB2.0 1 Rear Serial A
2 Type A USB2.0 Connectors
1 Internal Serial B
4 Rear USB2.0 2 Rear USB3.0
2 Type A USB2.0 Connector
1 1394b Connector
1 Internal Serial B
Server
Management
Onboard Server Engines* LLC Pilot III* Controller
Support for Intel®Remote Management Module 4 solutions
Intel®Light-Guided Diagnostics on field replaceable units
Support for Intel®System Management Software
Support for Intel®Intelligent Power Node Manager (Need PMBus*-compliant power supply)
Security
Intel®Trusted Platform Module (TPM) - AXXTPME5 (accessory option)
Power-Supply
750W/1200W/1600W Common Redundant Power-Supply with PMBus* Support
Suspend to RAM
(S3)
None
Supported
Form Factor
Custom 14.2'' W x 15.0'' D
Chassis
Pedestal: P4000L chassis
2U Rack: R2000 chassis
Pedestal: P4000L WS chassis

Intel® Server Board S2600IP and Intel® Workstation Board W2600CR TPS Product Overview
Revision 1.1 5
Intel order number G34153-003
2.1.1 Main Board Connector and Component Layout
The following figure shows the layout of the server board. Each connector and major component
is identified by a number or letter, and a description is given below the figure.
Callout
Description
Callout
Description
A
Slot 1, PCI Express* Gen3
AD
DIMM C1/C2/D1/D2
B
RMM4 lite module connector
AE
System Fan connector 1/2/3/4/5/6
C
Slot 2, PCI Express* Gen3
AF
Type A USB connector
D
TPM
AG
Type A USB connector
E
Slot 3, PCI Express* Gen3
AH
ROC Module connector
F
Slot 4, PCI Express* Gen3
AI
LCP connector
G
RMM4 Connector
AJ
Front Panel connector
H
Slot 5, PCI Express* Gen3
AK
Front Panel USB connector
I
Battery
AL
Main Power 4-pin connector
J
Slot 6, PCI Express* Gen3
AM
MinISAS Port B(4-7)
K
Slot 7, PCI Express* Gen3
AN
MiniSAS Port A(0-3)

Product Overview Intel® Server Board S2600IP and Intel® Workstation Board W2600CR TPS
6 Revision 1.1
Intel order number G34153-003
Callout
Description
Callout
Description
L
Slot 8, PCI Express* Gen2
AO
SATA Port 1
M
DIMM E1/E2/F1/F2
AP
SATA Port 0
N
Status LED
AQ
CPLD Update
O
ID LED
AR
IPMB
P
Diagnostic LED
AS
HDD LED
Q
NIC 3/4 (S2600IP only)
AT
ME FRC UPDT
R
USB 2/3, NIC 2
AU
CMOS CLR
S
USB 0/1, NIC 1
AV
BIOS RCVRY
T
VGA Port (S2600IP only)
AW
PASSWD CLR
U
Serial Port A (S2600IP only)
AX
Storage Upgrade Key
V
Processor 2 Power connector
AY
eUSB SSD
W
Processor 2 Fan connector
AZ
HSBP connector
X
DIMM H2/H1/G2/G1
BA
Chassis intrusion
Y
PMBus* connector
BB
Serial B connector
Z
Main Power connector
BC
BMC Force Update
AA
Processor 1 Power connector
BD
I/O Module connector (not available
for S2600IP4L)
AB
DIMM B2/B1/A2/A1
BE
System Fan connector 7
AC
Processor 1 Fan connector
Figure 3. Intel®Server Board S2600IP Major Components
