Intel SYS7180VE User manual

SYS7180VE
PICMG Single Board Computer
For socket 478 CPU With VGA/ LAN
(Pentium 4™&Celeron™&Intel® Celeron®DTM CPU)
User’s Manual

Copyright
This document is copyrighted, © 2004. All rights are reserved. The original
manufacturer reserves the right to make improvements to the products
described in this manual at any time without notice.
No part of this manual may be reproduced, copied, translated or transmitted in
any form or by any means without the prior written permission of the original
manufacturer. Information provided in this manual is intended to be accurate
and reliable. However, the original manufacturer assumes no responsibility for
its use, nor for any infringements upon the rights of third parties that may result
from such use.
Acknowledgments
IBM/AT and PS/2 are trademarks of International Business Machines
Corporation.
Award is a registered trademark of Award Software International, Inc.
Intel®, Celeron™, Pentium 4™ and Pentium 4™ are registered trademarks of
Intel Corporation.
Microsoft Windows is a registered trademark of Microsoft Corporation.
All Other product names or trademarks are properties of their respective
owners.
Liability
The obligation of the warrantor is solely to repair or replace the product. In no
event will the warrantor be liable for any incidental or consequential damages
due to such defect or consequences that arise from inexperienced usage, misuse,
or malfunction of this device.
Additional Information and Assistance
1. The manufacturer recommends using a grounded plug to ensure proper
motherboard operation. Care should be used in proper conjunction
with a grounded power receptacle to avoid possible electrical shock.
All integrated circuits on this motherboard are sensitive to static
electricity. To avoid damaging components from electrostatic
discharge, please do not remove the board from the anti-static packing
before discharging any static electricity to your body, by wearing a
wrist-grounding strap. The manufacturer is not responsible for any
damage to the motherboard due to improper operation.
2. Visit the Grantech web site at www.grantech.com.tw where you can
find the latest information about the product.
3. Contact your distributor, sales representative, or Grantech's customer
service center for technical support if you need additional assistance.
Please have the following information ready before you call:
•Product name and serial number
•Description of your peripheral attachments
•Description of your software (operating system, version, application, etc.)
•A complete description of the problem
•The exact wording of any error messages

Table of Contents
SYS7180VE User’s Manual i
Table of Contents
CHAPTER 1 INTRODUCTION ...............................................1
1.1 SPECIFICATION....................................................................1
1.2 CHECK LIST ........................................................................1
1.3 DESCRIPTION ......................................................................2
1.4 POWER REQUIREMENTS ......................................................2
1.5 CONNECTOR & JUMPER LOCATION .........................................4
1.6 BLOCK DIAGRAM....................................................................5
CHAPTER 2 HARDWARE INSTALLATIONS ......................6
2.1 INSTALLATION PROCEDURE .................................................6
2.2 CPU INSTALLATION:...........................................................7
2.3 MAIN MEMORY INSTALLATION: DIMM1/2.........................8
2.4 JUMPER SETTINGS:............................................................10
2.5 CONNECTORS SETTING: ....................................................12
2.5.1 FRONT PANEL CONNECTOR: J1 .........................................13
2.5.2 USB CONNECTOR: USB1-2 USB3-4 ...............................14
2.5.3 PARALLEL PORT CONNECTOR: LPT ..................................15
2.5.4 SERIAL PORT CONNECTOR:COM1/COM2........................16
2.5.5 IDE PORT CONNECTOR: IDE1/ IDE2................................16
2.5.6 FLOPPY DISK CONNECTOR: FLOPPY...............................17
2.5.7 ADAPTER CONNECTOR FOR 10/100 LAN: LAN1..............18
2.5.8 ADAPTER CONNECTOR FOR GIGALAN: LAN2 ...............19
2.5.9 EXTERNAL KEYBOARD/MOUSE CONNECTOR:...................20
Table of Contents
ii SYS7180VE User’s Manual
2.5.10 VGA CONNECTOR:.......................................................21
2.5.11 KEYBOARD / MOUSE CONNECTOR:...............................21
2.5.12 CPU FAN CONNECTOR:...............................................21
2.5.13 ACPI CONNECTOR: J2..................................................22
CHAPTER 3 BIOS SETUP......................................................24
3.1 INTRODUCTION .................................................................24
3.2 MAIN MENU .....................................................................26
3.3 STANDARD CMOS SETUP.................................................28
3.4 ADVANCED BIOS FEATURES SETUP..................................30
3.5 ADVANCED CHIPSET FEATURES SETUP .............................34
3.6 INTEGRATED PERIPHERALS ...............................................38
3.7 POWER MANAGEMENT SETUP...........................................43
3.8 PNP/PCI CONFIGURATION SETUP .....................................49
3.9 PC HEALTH STATUS ..........................................................51
3.10 DEFAULTS MENU ..............................................................51
3.11 SUPERVISOR/USER PASSWORD SETTING ...........................52
3.12 EXIT SELECTING ...............................................................52
3.13 POST MESSAGES .............................................................53
3.14 POST BEEP ......................................................................53
3.15 ERROR MESSAGES ............................................................53
Appendix…………………………………………………………..59

CHAPTER 1 – Introduction
SYS7180VE User’s Manual 1
Chapter 1 Introduction
1.1 Specification
Processor Support Intel® PentiumTM 4 CPU up to 3.06 GHz
Support Intel® CeleronTM CPU up to 2.60 GHz
Support Intel® Celeron®DTM CPU up to 2.80 GHz (Prescott core)
Chipset Intel®82845GV chipset supports 400/533MHz FSB
Memory Two 184-pin DDR DIMMs socket, up to 2GB of 266/333MHz
DDR SDRAM
BIOS Award4MbitPnPflashBIOS
VGA Integrated in 845GV, AGP4X
Sharememoryupto64MBwithsystemmain-memory
LAN LAN1: Intel® 82562ET Ethernet controller, supports 10/100M
Base-T
LAN2: (optional)Intel®82540EM Ethernet controller, supports
10/100/1000 Base-T
Wake On LAN support
USB Four USB ports, Hi-speed USB 2.0
Super I/O Mini-DIN: 1x PS/2 keyboard/mouse connector
RJ-45: 10/100/1000Mb Ethernet connector
Female DB-15: VGA connector
Box-header: 2* Serial port (2x5Pin);
1*FDD (2x17Pin); 2* EIDE (2x20Pin);
Pin-header: 1*Parallel port (2x13Pin)
Watchdog System reset or non- maskable interrupt software programmable
time I interval and jumper selectable (64-level)
Operating temperature 0°C ~60°C
Relative humidity 10%~90% non-condensing at temperature of 40BC or
104BF
1.2 Check List
Please check that your package is complete and contains the items below. If you
discover damaged or missing items, please contact your dealer.
 SYS7180VE CPU card
 Utility CD for SYS7180VE
 Installation Guide
 IDE cable *2
 FDD cable *1
CHAPTER 1 – Introduction
2 SYS7180VE User’s Manual
 PS/2 1 to 2 adapter *1
 Com extension cables with bracket *1
 Com, Printer extension cables with bracket *1
 +12V power cable *1
 USB cable *1（Special for SYS7180VE）
 Jumper Short Pin: 6 pcs
1.3 Description
The SYS7180VE is a motherboard based on Intel 845GV chipset and is fully
designed for PC environment. It features socket 478 compatible with Intel’s processor.
This card accommodates up to 2GB of DDR memory.
The SYS7180VE comes with on board CPU temperature sensor to protect your
processor from overheating (Winbond W83627HF chipset). Wired for Management
(WFM) 2.0 specification compliance.
The SYS7180VE has a LAN connector that uses Intel ICH4 integrated with Intel
82562ET (AOL & 10/100) controller.
1.4 Power Requirements
Your system requires a clean, steady power source for reliable performance of the
high frequency CPU on the SYS7180VE Industrial CPU card, the quality of the power
supply is even more important. For the best performance makes sure your power supply
provides a range of 4.75 volts minimum to 5.25 volts maximum DC power source.
Power Consumption
For typical configurations, the CPU card is designed to operate with at least a 200W
power supply. A higher-wattage power supply should be used for heavily-loaded
configurations. The power supply must meet the following requirements:
 Rise time for power supply: 2 ms to 20 ms
 Minimum delay for reset to Power Good: 100 ms
 Minimum Power down warning: 1 ms

CHAPTER 1 – Introduction
SYS7180VE User’s Manual 3
 3.3 V output must reach its minimum regulation level within 20ms of the +5V
output reaching its minimum regulation level
The following table lists the power supply’s tolerances for DC voltages:
DC Voltage Acceptable Tolerance
+3.3 V ± 5 %
+5 V ± 5 %
+5 VSB (standby) ± 5 %
-5 V ± 5 %
+12 V ± 5 %
-12 V ± 5 %
CHAPTER 1 – Introduction
4 SYS7180VE User’s Manual
1.5 Connector & Jumper Location

CHAPTER 1 – Introduction
SYS7180VE User’s Manual 5
1.6 Block Diagram
PCI TO ISA
Bridge
W83629D
W83629D
GIGA LAN
Connector
ICH4
Processor
PWM
PICMG PCI/ISA SLOT
VGA CRT
CONNECTOR
SOCKET 478
P4 PROCESSOR
AC'97
CODEC
CTRL
DATA
IDE Secondary
GMCH
COM1
Floppy COM2
AC'97 LINK
DDR 266 Mhz
RAID Secondary IDE
IDE Primary
Modules
FirmWare Hub
LAN 10/100
RJ45-Connector
W83627HF
Audio
Connector
DDR266
RS232 /
422 /
485
DATA
PHY
82562EM
UDMA66/100
USB I/F
CTRL
Keyboard
LPC
SUPER-I/O
BROOKDALE-G
RAID IDE
CONTROLLER
PDC20265R RAID Primary IDE
CLOCK
ICS950220
AGTL+ BUS
ADDR
Mouse
ADDR
USB 2.0
PORT 1-6 GIGA LAN
CONTROLLER
82540
LPC INTERFACE
Parallel
PCI CNTRL + PCI ADDR/DATA
RS232
FCBGA760
IrDA
CHAPTER 2 –Hardware Installations
6 SYS7180VE User’s Manual
Chapter 2 Hardware Installations
This chapter provides information on how to use the jumpers and connectors on
the SYS7180VE in order to set up a workable system.
2.1 Installation procedure
2.1.1 Insert the system BIOS (if not already installed) genteelly. Pay attention to
the position of pin 1 of BIOS socket.
2.1.2 Install the processor with correct orientation.
2.1.3 Insert the DRAM module with correct orientation.
2.1.4 Mount the Fan on the top of the processor and connect it to FAN connector.
2.1.5 Insert all external cables except for flat panel. (Hard disk, floppy, keyboard,
Mouse, LAN, etc.)
2.1.6 Prepare a CRT monitor for CMOS setup.
2.1.7 Confirm the power supply is off.
2.1.8 Turn on the power.
Note: The CMOS memory may be in an undefined state at power-on after a period of no
battery backup.

CHAPTER 2 –Hardware Installations
SYS7180VE User’s Manual 7
2.2 CPU Installation:
The SYS7180VE Industrial CPU Card supports a single Intel®P4 CeleronTM or
Celeron DTM processor and Pentium 4TM processor. The processor’s VID pins
automatically program the voltage regulator on the CPU card to the required processor
voltage. The host bus speed is automatically selected. The processor connects to the CPU
card through the 478-pins socket.
The CPU card supports the processors listed in table below:
P4 CeleronTM processor
Host Bus frequency Cache size
400MHz 128KB
Pentium 4TM processor
Host Bus frequency Cache size
400MHz / 533MHz 512KB
Celeron DTM processor
Host Bus frequency Cache size
533MHz 256KB or 1M
The socket-478 comes with a lever to secure the processor. Make sure the notch on
the corner of the CPU corresponds with the notch on the inside of the socket.
After you have installed the processor into the socket 478, check if the
configuration setup for the CPU type and speed are correct. The CPU should always have a
Heat Sink and a cooling fan attached to prevent overheating.
Note: Ensure that the CPU heat sink and the CPU top surface are in total contact to avoid
CPU overheating problem that would cause your system to hang or be unstable.
CHAPTER 2 –Hardware Installations
8 SYS7180VE User’s Manual
2.3 Main Memory Installation: DIMM1/2
The SYS7180VE Industrial CPU Card supports two single-side or double-sided
DDR266/333 unregistered, DIMM 184-pin sockets for a maximum total memory of 1GB.
Using the non-ECC DDR SDRAM DIMMS.
The CPU card supports the following memory features:
• 184-pin DIMMs with gold-plated contacts
• 266MHz and 333MHz non-ECC DDR SDRAM
• Un-buffered single or double-sided DIMMs in the following sizes:
SDRAM
SYNCHRONOUS DRAM (SDRAM) improves memory performance through
memory access that is synchronous with the memory clock. Burst transfer rates at x-1-1-1
timing can be achieved using SDRAM, while asynchronous memory subsystems are
typically limited at x-2-2-2 transfer rates.
The CPU card supports single or double-sided DIMMs in the following sizes:
DIMM size Non-ECC configuration
16MB 2Mbit x 64
32MB 4Mbit x 64
64MB 8Mbit x 64
128MB 16Mbit x 64
256MB 32Mbit x 64
Note: All memory components and DIMMs used with the SYS7180VE CPU card must
comply with the PC SDRAM Specification. These include: the PC SDRAM Specification
*memory component specific), the PC Unbuffered DIMM Specification, and the PC Serial
Presence Detect Specification.

CHAPTER 2 –Hardware Installations
SYS7180VE User’s Manual 9
Chipset
Intel 82845GV GMCH overview
The features:
 400/533 MHz PSB (100/133MHz bus clock)
 32-bit addressing for access to 2GB of memory space up to 2GB of 266MHz
or 333 MHz DDR SDRAM.
 Supports only for un-buffered non-ECC DIMMs.
 Hub Interface:
- Supports Hub Interface 1.5
- 266MB/s point-to-point Hub Interface to the ICH4.
- 1.5V operation.
 AGP Interface
- Supports a single 1.5VAGP 2.0 compliant device.
 Integrated Graphics
- 3D Setup and Render Engine.
- 2D Graphics.
 Analog Display Support
 Digital Display Channels
CHAPTER 2 –Hardware Installations
10 SYS7180VE User’s Manual
2.4 Jumper Settings:
Jumper Default setting
Jumper setting
FSB FSB setting: auto Short 1-2
JCC Clear CMOS：Normal mode Short 2-3
JAV BIOS write-protect: disabled Open
J4 AT or ATX select: AT Short 1-2
2.4.1 FSB Setting:
Options Setting
400 Short 2-3
533 Open
123
Auto (default) Short 1-2
2.4.2 Clear CMOS Setting: JCC
Options Settings
Normal Short 2-3 (default)
Clear CMOS Short 1-2
1
2
3
JCC
2.4.3 BIOS Write-protect Setting：JAV
Options Settings
Disable Open (default)
Enable Short 1-2
JAV

CHAPTER 2 –Hardware Installations
SYS7180VE User’s Manual 11
2.4.4 AT/ATX Power Setting：J4
Options Settings
AT Short 1-2 (default)
ATX Short 2-3
1
2
3
J4
2.4.5 Watchdog Setting: JWD
Options Setting
IRQ11 Short 1-2
Reset Short 2-3 (default)
123
Disabled Open
CHAPTER 2 –Hardware Installations
12 SYS7180VE User’s Manual
2.5 Connectors Setting:
Connectors Label Connectors Label
Primary IDE Connector IDE1 ACPI Connector J2
Secondary IDE Connector IDE2 VGA Connector VGA
FDD Connector FLOPPY PS/2 Mouse Connector MS
Printer Port Connector LPT PS/2 Keyboard Connector KB
USB 1_2 Connector USB1_2 Keyboard/Mouse
Connector MKB
USB 3_4 Connector USB3_4 CPU Fan Connector CPUFAN
DDR1 184P Connector DIMM1 DDR2 184P Connector DIMM2
COM1 Connector COM1 COM2 Connector COM2
Ethernet 1 RJ-45
Connector
LAN1 Ethernet 2 RJ-45
Connector LAN2
Flat Panel Connector J1 ATX +12V Power
Connector
J3

CHAPTER 2 –Hardware Installations
SYS7180VE User’s Manual 13
2.5.1 Front Panel Connector: J1
This header can be connected to a front panel power switch. The front panel
connector includes headers for these I/O connections:
Power switch
Power LED
This header can be connected to an LED that will light when the computer is
powered on.
Hard drive activity LED
This header can be connected to an LED to provide a visual indicator that data is
being read from or written to an IDE hard drive. For the LED to function properly, the IDE
drive must be connected to the onboard IDE controller.
Speaker
A speaker can be installed on the SYS7180VE as a manufacturing option. The
speaker is enabled by a jumper on pins 2, 4, 6, 8 of the front panel connector. Removing
the jumper can disable the onboard speaker, and an offboard speaker can be connected in
its place. The speaker (onboard or offboard) provides error beep code information during
the POST in the event that the computer cannot use the video interface. The speaker is not
connected to the audio subsystem and does not receive output from the audio subsystem.
19 17 15 13 11 9 7 5 3 1
20 18 16 14 12 10 8 6 4 2
1-3-5: POWER LED 2-4-6-8: SPEAKER 7-9: KEYLOCK
13-14:POWER ON 15-16: GREEN LED 17-18: RESET
19-20: IDE LED
PIN1—POWER LED+ PIN5—POWER LED-
PIN15—GREEN LED+ PIN16—GREEN LED-
PIN19—IDE LED- PIN20—IDE LED+
CHAPTER 2 –Hardware Installations
14 SYS7180VE User’s Manual
2.5.2 USB Connector: USB1-2 USB3-4
Note: USB cable is special designed for SYS7180VE
The Universal Serial Bus (USB) that allows plug and play computer peripherals
such as keyboard, mouse, joystick, scanner, printer, modem/ISDN, CD-ROM and floppy
disk drive to be automatically detected when they are attached physically without having to
install drivers or reboot.
The USB connectors allow any of several USB devices to be attached to the
computer. Typically, the device driver for USB devices is managed by the operating
system. However, because keyboard and mouse support may be needed in the Setup
program before the operating system boots, the BIOS supports USB keyboards and mice.
The CPU card has four USB ports; one USB peripheral can be connected to each
port. For more than four USB devices, an external hub can be connected to either port. The
four USB ports are implemented with stacked back panel connectors. The CPU card fully
supports the universal host controller interface (UHCI) and uses UHCI-compatible
software drivers.
USB features includes:
 Self-identifying peripherals that can be plugged in while the computer is running
 Automatic mapping of function to driver and configuration
 Support for synchronous and asynchronous transfer types over the same set of wires
 Support for up to 127 physical devices
 Guaranteed bandwidth and low latencies appropriate for telephony, audio and other
applications
 Error-handling and fault-recovery mechanisms built into the protocol
