Intel 82555 User manual

82555 10/100 Mbps LAN Physical Layer
Interface
Networking Silicon
Datasheet
Product Features
■Optimal integration for lower cost solutions
—Integrated 10/100 Mbps single chip
physical layer interface solution
—Complete 10/100 Mbps MII compliance
with MDI support
—Full duplex operation in 10 Mbps and
100 Mbps modes
—IEEE 802.3u Auto-Negotiation support
for 10BASE-T half and full duplex,
100BASE-TX half and full duplex, and
100BASE-T4 configurations
—Parallel detection algorithm for legacy
support of non-Auto-Negotiation
enabled link partner
—Integrated 10BASE-T transceiver with
built in transmit and receive filters
—Glueless interface to T4-PHY for
combination TX/T4 designs with single
magnetics
—Glueless support for 4 LEDs: activity,
link, speed, and duplex
—LED function mapping support via MDI
—Low external component count
—Single 25 MHz clock support for 10
Mbps and 100 Mbps (crystal or
oscillator)
—Single magnetics for 10 Mbps and 100
Mbps operation
—QFP 100-pin package
■Performance enhancements
—Flow control support for IEEE 802.3x
Auto-Negotiation and Bay Technologies
PHY Base* scheme
—Adaptive Channel Equalizer for greater
functionality over varying cable lengths
—High tolerance to extreme noise
conditions
—Very low emissions
—Jabber control circuitry to prevent data
loss in 10 Mbps operation
—Auto-polarity correction for 10BASE-T
—Software compatible with 82557 drivers
■Repeater functionality
—Repeater mode operation
—Support for forced speed of 10 Mbps
and 100 Mbps
—Automatic carrier disconnect for IEEE
802.3u compliance
—Auto-Negotiation enable/disable
capability
—Receive port enable function
—Support for 32 configurable addresses
—Narrow analog side (14 mm) for tight
packing in repeater and switch designs
Document Number: 666252-004
Revision 2.0
March 1998
Notice:
Notice:

82555 — Networking Silicon
ii Datasheet
Revision History
■Low power consumption
—Typical total solution power including
all resistors and magnetics:
- 275 mA 100BASE-TX
- 230 mA 10BASE-T
- 250 mA Auto-Negotiation
—300 mA maximum total solution power
in DTE (adapter) mode
—Power-down of 10BASE-T/100BASE-
TX sections when not in use
■Added modes for design, testing, and
manufacturability
—Test Access Port (TAP)
- NAND Tree
- Board Level Functional Test (BIST)
—Programmable bypass for 4B/5B
encoding/decoding and scrambler/
descrambler
—Diagnostic loopback mode
Revision
Date Revision Description
Jan. 1997 1.0 First external release of the preliminary datasheet
Apr. 1997 1.1 First release edition
Mar. 1998 2.0 General editing
Information in this document is provided in connection with Intel products. No license, express or implied, by estoppel or otherwise, to any intellectual
property rights is granted by this document. Except as provided in Intel's Terms and Conditions of Sale for such products, Intel assumes no liability
whatsoever, and Intel disclaims any express or implied warranty, relating to sale and/or use of Intel products including liability or warranties relating to
fitness for a particular purpose, merchantability, or infringement of any patent, copyright or other intellectual property right. Intel products are not
intended for use in medical, life saving, or life sustaining applications.
Intel may make changes to specifications and product descriptions at any time, without notice.
Designers must not rely on the absence or characteristics of any features or instructions marked "reserved" or "undefined." Intel reserves these for
future definition and shall have no responsibility whatsoever for conflicts or incompatibilities arising from future changes to them.
The 82555 10/100 Mbps LAN Physical Layer Interface may contain design defects or errors known as errata which may cause the product to deviate
from published specifications. Current characterized errata are available on request.
Contact your local Intel sales office or your distributor to obtain the latest specifications and before placing your product order.
Copies of documents which have an ordering number and are referenced in this document, or other Intel literature, may be obtained from:
Intel Corporation
P.O. Box 7641
Mt. Prospect IL 60056-7641
or call 1-800-879-4683.
Copyright © Intel Corporation, 1997
*Third-party brands and names are the property of their respective owners.

Datasheet iii
Networking Silicon — 82555
Contents
1.0 INTRODUCTION..........................................................................................................................1
1.1 Functional Overview........................................................................................................1
1.2 Compliance to Industry Standards ..................................................................................1
2.0 ARCHITECTURAL OVERVIEW...................................................................................................3
2.1 100 Mbps Mode...............................................................................................................3
2.2 10 Mbps Mode.................................................................................................................4
2.3 Media Independent Interface (MII) ..................................................................................5
3.0 PIN DEFINITIONS........................................................................................................................7
3.1 Pin Types .......................................................................................................................8
3.2 Clock Pins ......................................................................................................................8
3.3 Twisted Pair Ethernet (TPE) Pins ...................................................................................8
3.4 Media Independent Interface (MII) Pins .........................................................................8
3.5 Media Access Control/Repeater Interface Control Pins .................................................9
3.6 LED Pins ......................................................................................................................10
3.7 External Bias Pins ........................................................................................................10
3.8 Miscellaneous Control Pins ..........................................................................................11
3.9 Power and Ground Pins ...............................................................................................12
4.0 100BASE-TX ADAPTER MODE OPERATION..........................................................................13
4.1 100BASE-TX Transmit Clock Generation .....................................................................13
4.2 100BASE-TX Transmit Blocks ......................................................................................13
4.2.1 100BASE-TX 4B/5B Encoder ....................................................................13
4.2.2 100BASE-TX Scrambler and MLT-3 Encoder ...........................................14
4.2.3 100BASE-TX Transmit Framing ................................................................15
4.2.4 Transmit Driver ..........................................................................................16
4.3 100BASE-TX Receive Blocks .......................................................................................16
4.3.1 Adaptive Equalizer.....................................................................................17
4.3.2 Receive Clock and Data Recovery ............................................................17
4.3.3 MLT-3 Decoder, Descrambler, and Receive Digital Section......................17
4.3.4 100BASE-TX Receive Framing .................................................................17
4.3.5 100BASE-TX Receive Error Detection and Reporting...............................17
4.4 100BASE-TX Collision Detection ..................................................................................17
4.5 100BASE-TX Link Integrity and Auto-Negotiation Solution...........................................18
4.5.1 Link Integrity...............................................................................................18
4.5.2 Auto-Negotiation ........................................................................................18
4.5.3 Combination Tx/T4 Auto-Negotiation Solution...........................................18
4.6 Auto 10/100 Mbps Speed Selection..............................................................................19
4.7 Adapter Mode Addresses..............................................................................................19
5.0 10BASE-T FUNCTIONALITY IN ADAPTER MODE ..................................................................21
5.1 10BASE-T Transmit Clock Generation..........................................................................21
5.2 10BASE-T Transmit Blocks...........................................................................................21
5.2.1 10BASE-T Manchester Encoder................................................................21
5.2.2 10BASE-T Driver and Filter .......................................................................21
5.3 10BASE-T Receive Blocks............................................................................................21
5.3.1 10BASE-T Manchester Decoder................................................................21
5.3.2 10BASE-T Twisted Pair Ethernet (TPE) Receive Buffer and Filter............21

82555 — Networking Silicon
iv Datasheet
Contents
5.3.3 10BASE-T Error Detection and Reporting.................................................22
5.4 10BASE-T Collision Detection.......................................................................................22
5.5 10BASE-T Link Integrity................................................................................................22
5.6 10BASE-T Jabber Control Function..............................................................................22
5.7 10BASE-T Full Duplex ..................................................................................................23
6.0 REPEATER MODE....................................................................................................................25
6.1 Special Repeater Features............................................................................................25
6.2 Connectivity...................................................................................................................25
7.0 MANAGEMENT DATA INTERFACE..........................................................................................27
7.1 MDI Frame Structure.....................................................................................................27
7.2 MDI Registers................................................................................................................28
7.2.1 MDI Registers 0 - 7....................................................................................28
7.2.2 MDI Registers 8 - 15..................................................................................31
7.2.3 MDI Registers 16 - 31................................................................................31
8.0 AUTO-NEGOTIATION FUNCTIONALITY..................................................................................35
8.1 Description ....................................................................................................................35
8.2 Parallel Detect and Auto-Negotiation............................................................................36
9.0 LED DESCRIPTIONS ................................................................................................................39
10.0 RESET AND MISCELLANEOUS TEST MODES.......................................................................41
10.1 Reset.............................................................................................................................41
10.2 Loopback.......................................................................................................................41
10.3 Scrambler Bypass.........................................................................................................41
10.4 Test Port........................................................................................................................41
11.0 ELECTRICAL SPECIFICATIONS AND TIMING PARAMETERS..............................................43
11.1 Absolute Maximum Ratings ..........................................................................................43
11.2 General Operating Conditions ......................................................................................43
11.3 DC Characteristics ........................................................................................................43
11.3.1 MII DC Characteristics ..............................................................................43
11.3.2 10BASE-T Voltage/Current DC Characteristics ........................................43
11.3.3 100BASE-TX Voltage/Current DC Characteristics ...................................44
11.4 AC Characteristics.........................................................................................................45
11.4.1 MII Clock Specifications.............................................................................45
11.4.2 MII Timing Parameters ..............................................................................46
11.4.3 Repeater Mode Timing Parameters ..........................................................47
11.4.4 Transmit Packet Timing Parameters .........................................................48
11.4.5 Squelch Test Timing Parameters ..............................................................48
11.4.6 Jabber Timing Parameters ........................................................................49
11.4.7 Receive Packet Timing Parameters ..........................................................49
11.4.8 10BASE-T Normal Link Pulse (NLP) Timing Parameters .........................50
11.4.9 Auto-Negotiation Fast Link Pulse (FLP) Timing Parameters ....................50
11.4.10 Reset Timing Parameters .........................................................................51
11.4.11 X1 Clock Specifications ............................................................................51
11.4.12 100BASE-TX Transmitter AC Specification ..............................................52
12.0 82555 PACKAGE INFORMATION.............................................................................................53

Datasheet 1
Networking Silicon — 82555
1.0 Introduction
The 82555 is a highly integrated, physical layer interface solution designed for 10 and 100 Mbps
Ethernet systems based on the IEEE 10BASE-T and 100BASE-TX specifications. 100BASE-TX is
an IEEE 802.3 physical layer specification for use over two pairs of Category 5 unshielded twisted
pair or Type 1 shielded twisted pair cable. 100BASE-TX defines a signaling scheme not only for
100 Mbps, but also provides CSMA/CD compatibility with the 10 Mbps IEEE 802.3 10BASE-T
signaling standard.
1.1 Functional Overview
The 82555 is designed to work in two modes: Data Terminal Equipment (DTE) for adapters and
repeater for hubs and switches. When configured to DTE (adapter) mode, the 82555 incorporates
all active circuitry required to interface 10/100 Mbps Ethernet controllers and CSMA/CD MAC
components to 10 Mbps and 100 Mbps networks. In this and other documents the 82555 may be
referred to as the DTE, Physical Medium Device (PMD), or Physical Layer Medium (PLM). It
supports a direct glueless interface to Intel components such as the 82557 Fast Ethernet controller.
The 82555 also supports the Media Independent Interface (MII) signals as specified in the IEEE
802.3u standard. The figure below shows how the 82555 fits into a 10/100 Mbps Ethernet adapter
design.
When configured to repeater mode, the 82555 incorporates several features that allow it to function
as a Class I or MII level repeater. Section 6.0, “Repeater Mode” on page 25 describes the 82555 in
a repeater type of application.
1.2 Compliance to Industry Standards
When operating in 100 Mbps mode, the 82555 complies with IEEE 802.3u 100BASE-TX
specification. The PMD section with the related changes established in 802.3u 100BASE-TX
complies with ANSI X3.263:1995 TP-PMD, Revision 2.2.
When operating in the 10 Mbps mode, the 82555 complies with the IEEE 802.3 10BASE-T
specification.
Figure 1. 82555 10/100 Mbps Ethernet Solution
Controller/MAC Intel 82555
System Bus Interface
Pair 1
Pair 2
Ma
g
netics

82555 — Networking Silicon
2Datasheet
The 82555 also complies with the IEEE 802.3u Auto-Negotiation and the IEEE 802.3x Full Duplex
Flow Control sections. The MAC interface on the 82555 is a superset of the IEEE 802.3u Media
Independent Interface (MII) standard.

Datasheet 3
Networking Silicon — 82555
2.0 Architectural Overview
The 82555 is an advanced combination of both digital and analog logic which combine to provide a
functional stack between the Media Independent Interface (MII) and the wire through the
magnetics. Figure 2 shows a general block diagram of the 82555 component.
2.1 100 Mbps Mode
In 100BASE-TX mode the 82555 digital subsection performs all signal processing of digital data
obtained from the analog reception and the data to be driven into the analog transmit subsection.
This includes 4B/5B encoding/decoding, scrambling/descrambling, carrier sense, collision
detection, link detection, Auto-Negotiation, data validation, and providing MII to the Media
Access Controller (MAC). The 82555 supports the IEEE defined MII as its MAC interface and
expects the controller to drive the Management Data Input/Output and Management Data Clock
signals to perform the management functions.
In 100BASE-TX mode, the analog subsection of the 82555 performs two functions:
•Transmit: The 82555 converts a digital 125 Mbps stream into MLT-3 format and drives it
through the transmit differential pair onto the physical medium.
Figure 2. 82555 Simplified Block Diagram

82555 — Networking Silicon
4Datasheet
•Receive: The 82555 takes receive analog MLT-3 data from the receive differential pair and
converts it into a digital 125 Mbps stream, recovering both clock and data signals.
2.2 10 Mbps Mode
The 82555 operation in 10BASE-T mode is similar to the 82555 operation in 100BASE-TX mode.
Manchester encoding and decoding is used instead of 4B/5B encoding/decoding and scrambling/
descrambling. In addition, the Transmit Clock and Receive Clock (MII clock signals) provide 2.5
MHz instead of 25 MHz.
Figure 3. 82555 Analog Logic
4b/5b
Encoding
Scrambler
Serialization
MII TX Interface
NRZ to NRZI
NRZI to MLT3
4b/5b
Decoding
De-scrambler
Serial to 5B
MII RX Interface
NRZI to NRZ
MLT3 to NRZI
Magnetics Module
RJ-45 Connector
12345678

Datasheet 5
Networking Silicon — 82555
The 82555 provides a glueless interface to Intel components such as the 82557 Fast Ethernet
Controller, as well as any MII compatible device. Figure 4 shows a schematic-level diagram of the
82557 Fast Ethernet controller implementation connected to the 82555 using the MII interface.
2.3 Media Independent Interface (MII)
The 82555 supports the Media Independent Interface (MII) as its primary interface to the MAC.
The MII Interface is summarized in Table 1.
Figure 4. Intel 82557/82555 Solution
82557
Flash
(optional)
EEPROM
(
optional
)
PCI Bus Si
g
nals
82555
RXD[3:0]
RXC
RXERR
RXDV
CRS
COL
TXD[3:0]
TXC
TXEN
MDC
MDIO
RESET
Table 1. 82555 MII
Signal
Name Description Direction Clock Reference MII Signal Supported by the 82555?
TXC Transmit Clock From 82555
(adapter mode only) -- Yes
TXD[3:0] Transmit Data From MAC TXC Yes
TXEN Transmit Enable From MAC TXC Yes
COL Collision Detect From 82555 Asynchronous Yes
CRS Carrier Sense From 82555 Asynchronous Yes
RXC Receive Clock From 82555 -- Yes
RXD[3:0] Receive Data From 82555 RXC Yes
RXDV Receive Data Valid From 82555 RXC Yes
RXERR Receive Error From 82555 RXC Yes
MDC Management Data
Clock From manager -- Yes
MDIO Management Data
Input/Output From manager MDC Yes

82555 — Networking Silicon
6Datasheet
TXERR Transmit Error
(repeater mode only) From RIC TXC Yes
Table 1. 82555 MII
Signal
Name Description Direction Clock Reference MII Signal Supported by the 82555?

Datasheet 7
Networking Silicon — 82555
3.0 Pin Definitions
All active digital pins are defined to have transistor-to-transistor logic voltage levels except the X1
and X2 crystal signals. The transmit differential and receive differential pins are specified as analog
outputs and inputs, respectively.
The figure below show the pin locations on the 82555 component. The following subsections
describe the pin functions.
Figure 5. 82555 Pin Numbers and Labels

82555 — Networking Silicon
8Datasheet
Pin allocation is based on a 100-lead quad flat package. All pin locations are based on printed
circuit board layout and other design constraints.
3.1 Pin Types
3.2 Clock Pins
3.3 Twisted Pair Ethernet (TPE) Pins
3.4 Media Independent Interface (MII) Pins
Pin Type Description
I This type of pin is an input pin to the 82555.
O This type of pin is an output pin from the 82555.
I/O This type of pin is both an input and output pin for the 82555.
B This pin is used as a bias pin. The bias pin is either pulled up or down with a resistor. The bias pin
may also be used as an external voltage reference.
Symbol Pin Type Name and Function
X1 56 I Crystal Input One. X1 and X2 can be driven by an external 25 MHz crystal.
Otherwise, X1 may be driven by an external MOS level 25 MHz oscillator
when X2 is left floating. (The crystal should have a tolerance of 50 PPM or
better.)
X2 55 O Crystal Output Two. X1 and X2 can be driven by an external 25 MHz
crystal. Otherwise, X1 may be driven by an external MOS level 25 MHz
oscillator when this pin is left floating.
Symbol Pin Type Name and Function
TDP
TDN 47 48 OTransmit Differential Pair. These pins send the serial bitstream for
transmission on an unshielded twisted pair (UTP) cable. The current-driven
differential driver can be two-level (10BASE-T or Manchester) or three-level
(100BASE-TX or MLT-3) signals depending on the operating mode. These
signals interface directly with an isolation transformer.
RDP
RDN 33 34 IReceive Differential Pair. These pins receive the serial bitstream from the
isolation transformer. The bitstream can be two-level (10BASE-T or
manchester) or three-level (100BASE-TX or MLT-3) signals depending on the
operating mode.
Symbol Pin Type Name and Function
RXD3
RXD2
RXD1
RXD0
97
96
95
92
OReceive Data. In 100 Mbps and 10 Mbps mode, data is transferred across
these four lines one nibble at a time.

Datasheet 9
Networking Silicon — 82555
3.5 Media Access Control/Repeater Interface Control Pins
RXC 90 O Receive Clock. The Receive Clock may be either 25 MHz or 2.5 MHz
depending on the 82555’s operating speed (25 MHz for 100 Mbps and 2.5
MHz for 10 Mbps). The Receive Clock is recovered directly from incoming
data and is continuous into the Media Access Controller (MAC). Thus, it must
be resynchronized in 10 Mbps mode at the start of each incoming packet.
RXDV 86 O Receive Data Valid. This signal indicates that the incoming data on the
RSC[3:0] pins are valid.
RXERR 87 O Receive Error. The RXERR signal indicates to the 82555 that an error has
occurred during frame reception.
TXD3
TXD2
TXD1
TXD0
71
70
69
68
ITransmit Data. In 100 Mbps and 10 Mbps mode, data is transferred across
these four lines one nibble at a time.
TXC 60 I/O Transmit Clock. The Transmit Clock may be either 25 MHz or 2.5 MHz
depending on the 82555’s operating speed (25 MHz for 100 Mbps and 2.5
MHz for 10 Mbps). The Transmit Clock outputs a continuous clock into the
MAC that is generated directly from the external clock source in DTE
(adapter) mode. In repeater mode, the TXC is an input signal operating at
either 25 MHz or 2.5 MHz depending on the operating speed, which is
typically clocked by a receiver interface device.
TXEN 79 I Transmit Enable. The Transmit Enable signal indicates to the 82555 that
valid data is present on the TXD[3:0] pins.
TXERR 59 I Transmit Error. The TXERR signal indicates to the 82555 that an error has
occurred during transmissions of a frame.
CRS 82 O Carrier Sense. The Carrier Sense signal indicates to the 82555 that traffic is
present on the link. CRS is an asynchronous output signal.
COL 85 O Collision Detect. The Collision Detect signal operates in half duplex mode
and indicates to the 82555 that a collision has occurred on the link. COL is an
asynchronous output signal to the controller.
MDIO 80 I/O Management Data Input/Output. The MDIO signal is a bidirectional data pin
for the Management Data Interface (MDI).
MDC 81 II Management Data Clock. The MDC signal functions as a clock reference for
the MDIO signal. MDC should operate at a maximum frequency of 2.5 MHz
Symbol Pin Type Name and Function
RXCONG 77 I Receive Congestion. If the following conditions exist, the RXCONG is an
active high and indicates an overrun on the controller receive side:
• Full duplex PHY Base (Bay Technologies) flow control DTE (adapter)
mode
• Full duplex signal (FDX_N) is high
• Full duplex technology is active through Auto-Negotiation
PORTEN 76 I Port Enable. In repeater mode when the PORTEN signal is low, the following
signals will be tri-stated: RXD[3:0], RXC, RXDV, and RXERR.
Symbol Pin Type Name and Function

82555 — Networking Silicon
10 Datasheet
3.6 LED Pins
3.7 External Bias Pins
Note: The resistor values described for the external bias pins are only recommended values and may
require to be fine tuned for various designs.
TXRDY
(TOUT) 4 O This pin is multiplexed and can be used for one of the following:
Transmit Ready. If full duplex and PHY Base (Bay Technologies) flow control
modes are enabled, the TXRDY signal enables transmission while it is
asserted.
TOUT. When the Test Enable signal is activated, this signal functions as the
Test Output port.
FDX_N 5 I/O Full Duplex. In DTE (adapter) mode, this active low output signal reports the
result of the duplex configuration to the MAC. This pin can also operate as
the LED driver and will be an active low for all technologies.
In repeater mode, this signal is used for Auto-Negotiation advertisement to
the 82555’s link partner and activates the PHY Base (Bay Technologies) flow
control if 100BASE-TX full duplex is the highest common technology between
the 82555 and its link partner.
Symbol Pin Type Name and Function
ACTLED 12 O Activity LED. This signal indicates either transmit or receive activity. When
activity is present, the ACTLED is on. When no activity is present, the
ACTLED is off.
LILED 11 O Link Integrity LED. This signal indicates the link integrity. If a valid link is
present in either 10 Mbps or 100 Mbps, the LILED is on; and if an invalid link
is preset, LILED is off.
For a combination design board, the LILED should be connected to the TX
technology LED.
SPEED-
LED 13 O Speed LED
This signal is used to indicate the speed of operation. For 100 Mbps, the
SPEEDLED will be on; and for 10 Mbps, the SPEEDLED will be off.
Symbol Pin Type Name and Function
RBIAS100 44 B Bias Reference Resistor 100. A 634 Ωresistor should be connected from
this pin to ground.
RBIAS10 43 B Bias Reference Resistor 10. A 768 Ωresistor should be connected from
this pin to ground.
PD1 42 I Pull Down One. A 10 KΩresistor should be connected from this pin to
ground.
PD2 100 I Pull Down One. A 1 KΩresistor should be connected from this pin to
ground.
Symbol Pin Type Name and Function

Datasheet 11
Networking Silicon — 82555
3.8 Miscellaneous Control Pins
Symbol Pin Type Name and Function
RESET 1 I Reset. The Reset signal is active high and resets the 82555. A reset pulse
width of at least 1 µs should be used.
FRC100
(MACTYP) 51 I This pin is multiplexed and can be used for one of the following:
Force 100/10 Mbps. In repeater mode, this pin configures the repeater to
either 100 Mbps (active high) or to 10 Mbps (active low).
MAC Type. In DTE (adapter) full duplex mode, if this input signal is high, the
82555 drives 82557 mode. If this input signal is low, the 82555 drives a
generic MII MAC mode.
PHYA4
(TIN) 22 I This pin is multiplexed and can be used for one of the following:
PHY Address 4. In repeater mode, this signal represents the fifth bit for
address port configuration.
TIN. If the Test Enable signal is active, this signal is used as the Test Input
data.
PHYA3
(SLVTRI) 52 I/O This pin is multiplexed and can be used for one of the following:
PHY Address 3. In repeater mode, this signal represents the fourth bit for
address port configuration.
Slave Tri-state. In DTE (adapter) mode, this output operates in conjunction
with the T4 Advanced signal. When both are active, the slave PHY is inactive
and tri-states all its outputs.
PHYA2
(LISTAT) 6 I This pin is multiplexed and can be used for one of the following:
PHY Address 2. In repeater mode, this signal represents the third bit for
address port configuration.
Link Status. In DTE (adapter) mode, if T4 Advance is active, the LISTAT_N
signal is active low and the slave PHY link is valid.
PHYA1
(TEXEC) 25 I This pin is multiplexed and can be used for one of the following:
PHY Address 1. In repeater mode, this signal represents the second bit for
address port configuration.
Test Execute. If Test Enable is asserted, this signal acts as the test
execution command indicating that the pin 22 is being used as the Test Input
pin.
PHYA0
(TCK) 24 I This pin is multiplexed and can be used for one of the following:
PHY Address 0. In repeater mode, this signal represents the first bit for
address port configuration.
Test Clock. If Test Enable is asserted, this signal acts as the Test Clock
signal.
ANDIS
(T4ADV) 54 I This pin is multiplexed and can be used for one of the following:
Auto-Negotiation Disable. In repeater mode, the Auto-Negotiation operates
for management reasons. If this input signal is high, the Auto-Negotiation
operation will be disabled.
T4ADV. In DTE (adapter) mode, this pin enables the combo mode. This
allows the LISTAT and SLVTRI pins to be used as interface to the slave PHY.
SCRMBY 23 I Scrambler/Descrambler Bypass. If SCRMBY is high, the scrambler/
descrambler of TP-PMD will be bypassed.
LPBK 2 I Loopback. When the LPBK signal is high, the 82555 will perform a
diagnostic loopback function.
RPT 50 I Repeater. When the RPT signal is high, the 82555 functions in repeater
mode. When this signal is low, the 82555 runs in DTE (adapter) mode.
TESTEN 21 I Test. If the TESTEN signal is high, the 82555 enables the test ports.

82555 — Networking Silicon
12 Datasheet
3.9 Power and Ground Pins
Symbol Pin Type Name and Function
VCC 7, 9, 15, 17, 19, 27, 29, 31, 36, 38, 40, 45, 58, 62,
64, 66, 73, 75, 83, 88, 93, 98 I Power: +5 V ± 5%
VSS 3, 8, 10, 14, 16, 18, 20, 26, 28, 30, 32, 35, 37, 39,
41, 46, 49, 53, 57, 61, 63, 65, 67, 72, 74, 78, 84, 89,
91, 94, 99
I Ground: 0 V

Datasheet 13
Networking Silicon — 82555
4.0 100BASE-TX Adapter Mode Operation
4.1 100BASE-TX Transmit Clock Generation
A 25 MHz crystal or a 25 MHz oscillator is used to drive the 82555’s X1 and X2 pins. The 82555
derives its internal transmit digital clocks from this crystal or oscillator input. The Transmit Clock
signal is a derivative of the 25 MHz internal clock. The accuracy of the external crystal or oscillator
must be ± 0.0005% (50 PPM).
4.2 100BASE-TX Transmit Blocks
The transmit subsection of the 82555 accepts nibble-wide data on the TXD[3:0] lines when TXEN
is asserted (high). The transmit subsection passes data unconditionally to the 4B/5B encoder as
long as TXEN is active.
The 4B/5B encoder accepts nibble-wide data (4 bits) from the MAC and compiles it into 5-bit-wide
parallel symbols. These symbols are scrambled and serialized into a 125 Mbps bit stream,
converted by the analog transmit driver into a MLT-3 waveform format, and transmitted onto the
Unshielded Twisted Pair (UTP) or Shielded Twisted Pair (STP) wire.
4.2.1 100BASE-TX 4B/5B Encoder
The 4B/5B encoder complies with the IEEE 802.3u 100BASE-TX standard. Four bits are encoded
according to the transmit 4B/5B lookup table. The lookup table matches a 5-bit code to each 4-bit
code.
The table below illustrates the 4B/5B encoding scheme associated with the given symbol.
Table 2. 4B/5B Encoder
Symbol 5B Symbol Code 4B Nibble Code
0 11110 0000
1 01001 0001
2 10100 0010
3 10101 0011
4 01010 0100
5 01011 0101
6 01110 0110
7 01111 0111
8 10010 1000
9 10011 1001
A 10110 1010
B 10111 1011
C 11010 1100
D 11011 1101

82555 — Networking Silicon
14 Datasheet
4.2.2 100BASE-TX Scrambler and MLT-3 Encoder
Data is scrambled in 100BASE-TX in order to reduce electromagnetic emissions during long
transmissions of high-frequency data codes. The scrambler logic accepts 5 bits from the 4B/5B
encoder block and presents the scrambled data to the MLT-3 encoder. The 82555 implements the
11-bit stream cipher scrambler as adopted by the ANSI XT3T9.5 committee for UTP operation.
The cipher equation used is:
X[n] = X[n-11] + X[n-9] (mod 2)
The MLT-3 encoder receives the scrambled Non-Return to Zero (NRZ) data stream from the
scrambler and encodes the stream into MLT-3 for presentation to the driver. MLT-3 is similar to
NRZI coding, but three levels are output instead of two. There are three output levels: positive,
negative and zero. When an NRZ “0” arrives at the input of the encoder, the last output level is
E 11100 1110
F 11101 1111
I 11111 Inter Packet Idle Symbol
(No 4B)
J 11000 1st Start of Packet Symbol
0101
K 10001 2nd Start of Packet Symbol
0101
T 01101 1st End of Packet Symbol
R 00111 2nd End of Packet Symbol
and Flow Control
V 00000 INVALID
V 00001 INVALID
V 00010 INVALID
V 00011 INVALID
H 00100 INVALID
V 00101 INVALID
V 00110 INVALID
V 01000 INVALID
V 01100 INVALID
V 10000 Flow Control S
V 11001 INVALID
Table 2. 4B/5B Encoder
Symbol 5B Symbol Code 4B Nibble Code

Datasheet 15
Networking Silicon — 82555
maintained (either positive, negative or zero). When an NRZ “1” arrives at the input of the encoder,
the output steps to the next level. The order of steps is negative-zero-positive-zero which continues
periodically. The figure below illustrates this process.
4.2.3 100BASE-TX Transmit Framing
The 82555 does not differentiate between the fields of the MAC frame containing preamble, start
of frame delimiter, data and Cyclic Redundancy Check (CRC). When TXEN is asserted, the 82555
accepts data on the MII TXD[3:0] lines, encodes it, and sends it out onto the wire. The 82555
encodes the first byte of the preamble as the “JK” symbol, encodes all other pieces of data
according to the 4B/5B lookup table, and adds the “TR” code after the end of the packet (de-
assertion of TXEN). The 82555 scrambles and serializes the data into a 125 Mbps stream, encodes
it as MLT-3, and drives it onto the wire. If TXERR is asserted during transmission of valid data, the
82555 transmits an invalid “H” symbol.
Figure 6. NRZ to MLT-3 Encoding Diagram
Clock
NRZ
NRZ1
MLT-3
1100 0110
1100 0110
1100 0110

82555 — Networking Silicon
16 Datasheet
4.2.4 Transmit Driver
The transmit differential lines are implemented with a digital slope controlled current driver that
meets the TP-PMD specifications. Current is sunk from the isolation transformer by the transmit
differential pins. The conceptual transmit differential waveform for 100 Mbps is illustrated in the
following figure.
The magnetics module that is external to the 82555 converts ITDP and ITDN to 2.0 Vpp, as required
by the TP-PMD specification. The same magnetics used for 100BASE-TX mode should also work
in 10BASE-T mode. The following is a list of current magnetics modules available from several
vendors:
4.3 100BASE-TX Receive Blocks
The receive subsection of the 82555 accepts 100BASE-TX MLT-3 data on the receive differential
pair. Due to the advanced digital signal processing design techniques employed, the 82555 will
accurately receive valid data from Category 5 (CAT5) UTP and Type 1 STP cable of length well in
excess of 100 meters.
Figure 7. Conceptual Transmit Differential Waveform
(VTDP -VTDN )
+1V
0V
-1V
40mA
ITDP
20mA
0
40mA
20mA
0
ITDN
t
t
t
Table 3. Magnetics Modules
Vendor Model/Type 100BASE-TX 10BASE-T
Delta LF8200A Yes Yes
Pulse Engineering PE-68515 Yes Yes
Pulse Engineering H1012 Yes Yes
