Intelbras XFF 1 User manual

Operation Manual
XFF 1 / XFF 2
SC / UPC and SC / APC field assembly connector
Congratulations, you have just purchased a product with Intelbras quality and safety.
This assembly procedure applies to the 2 × 3 mm optical drop cable.
1. Assembly kit and tools
Key for closing the
connector
Field Connector XFF 1 or XFF 2
Screw cap for fixing
the cable to the connector
Fiber cleaning
paper
Template for
cutting the fiber
Assembly kit
Fiber optic
stripper
Drop Cable Stripper
Cleaver
Assembly tools
2. Assembly Steps
2.1. Preparing the fiber
2. Insert the fiber cable into the screw cap
50 to 60 mm
Cable entry
1. Remove the Drop Cable jacket
3. Insert the cable into the assembly
template, up to the indicated marking
Remove the fiber sheath with the stripping
pliers.
4. Check fiber integrity
Move the fiber with your fingertips to all sides
respecting the maximum 60° curvature
5. Clean the fiber optic with the paper
provided in the assembly kit
6. Insert the cable into the assembly
template by aligning it with the indicated
part
7. Cut the fiber
Use a cleaver to make the cut in the
optical fiber
8. Follow this fiber specification for
assembly into the connector
35.1 ± 1 mm
24 ± 2 mm

2.2. Assembling the connector
Unlock
1. Move the key to the indicated
position to unlock
2. Insert the fiber into the connector until
you notice a slight bend in the fiber
3. Secure the cable to the connector by
screwing the fastening cap.
4. Attach the fiber optic to the connector by
moving the key to the end of the field
connector.
Remove the key after attaching the cable to
the connector.
2.3. Disassembling the connector
1. Mount the locking key on the connector
Insert the connector's locking key into the right
end of the connector
3. Unscrew the cap
2. Unlock the fiber
Move the locking key to the indicated
position
4. Remove the fiber optic from the connector
The field connector can be reused up to 5
times.
Warranty Terms
It is hereby expressly stated that this contractual warranty is conferred under the following conditions:
Name of client:
Client signature:
Invoice No.:
Date of purchase:
Model: Serial No.:
Retailer:
1. All parts, pieces and components of the product are guaranteed against eventual manufacturing defects,
which they may eventually present, for a period of 1 (one) year - this being 90 (ninety) days of legal
guarantee and 9 (nine) months of contractual guarantee -, as from the date of purchase of the product by
the Consumer, as shown on the invoice for the purchase of the product, which is an integral part of this
Term throughout the entire national territory. This contractual warranty includes the free replacement of
parts, pieces, and components that present manufacturing defects, including the expenses for the labor
used in this repair. If no manufacturing defect is found, but defect(s) arising from improper use, the
Consumer will bear these expenses.
2. The product´s installation should be done according to the Product Manual and/or Installation Guide.
If your product requires installation and configuration by a qualified technician, look for a competent
and specialized professional, considering that the costs for these services are not included in the
product’s price.
3. Once the defect is confirmed, the Consumer must immediately contact the nearest Authorized
Service listed by the manufacturer - only these are authorized to examine and repair the defect
during the warranty period foreseen herein. If this is not done, this warranty will be void, since it will
be characterized as a violation of the product.
4. In the event that the Consumer requests home assistance, he or she must go to the nearest
Authorized Service to inquire about the technical visit fee. If it is necessary to remove the product,
the resulting expenses, such as transportation and security costs to and from of the product, will be
the Consumer´s responsibility.
5. The warranty will totally lose its validity in the occurrence of any of the following hypotheses: a) if
the defect is not of manufacturing, but caused by the Consumer or by third parties not related to the
manufacturer; b) if the damage to the product comes from accidents, disasters, nature agents
(lightning, flooding, landslides, etc.), humidity, voltage in the electrical network (overvoltage caused
by accidents or excessive fluctuations in the network), installation/use in disagreement with the
user’s manual or resulting from the natural wear and tear of the parts and components; c) if the
product has suffered chemical, electromagnetic, electrical or animal (insects, etc.) influence; d) if the
product’s serial number has been tampered with or scraped; e) if the device has been breached.
6. This warranty does not cover data loss, therefore it is recommended, if applicable to the product, that
the Consumer make a backup copy of the data on the product on a regular basis.
7. Intelbras is not responsible for the installation of this product, nor for any attempts of fraud and/or
sabotage on its products. Keep the software updates and applications used up-to-date, if relevant, as well
as the network protections required for protection against intrusions (hackers). The equipment is
guaranteed against vices within its normal conditions of use, and it is important to be aware that, because
it is an electronic equipment, it is not free of frauds and scams that may interfere with its correct operation.
These being the conditions of this supplemental warranty term, Intelbras S/A reserves the right to alter
the general, technical and aesthetic characteristics of its products without prior notice.
The manufacturing process of this product is not covered by the requirements of ISO 14001.
All images in this manual are illustrative.
