Inter-fab TANNING LEDGE TABLES Programming manual

Retrofit_Table-IM Rev. 5/15
30” Table w/Umbrella Hole
TANNING LEDGE TABLES FOR GUNITE RETROFIT/AFTERMARKET
Ass mbly & Installation Instructions
INSTALLS IN
3 EASY STEPS!
1.
2.
3.
INTER-FA B , INC. 30 5 0 S. ALVERNON WAY • TUCSON, AZ 85713
520.790.7040 • 8 0 0 . 7 3 7 . 5 3 8 6 • FAX [phone] • i n t r - f a b . c o m
WARNING: IMPORTANT INSTALLATION INFORMATION
The installation of this product should be done only by a licensed and professional installer. Installation should
be done strictly in conformance with all local buildin codes, electrical codes and other buildin and safety laws
and re ulations. Amon other thin s, that your installer should carefully analyze the need to bond the product
to prevent an electrical hazard. Failure to properly install this product could result in a dan erous condition,
includin but not limited to electrical or structural hazards. Inter-Fab, Inc. disclaims all liability arisin from the
installation and the user assumes all risk associated with the installation.

1
Retrofit_Table-IM Rev. 5/15
I N S T A L L A T I O N M A N U A L RE TR OF I T TAB LES
INTENDED USE INSTRUCTIONS
1. Everyone who uses this Table must understand and follow these instructions.
2. If installed in a pool with divin equipment or a pool slide, the table installation must not interfere with the
divin or slidin safety envelope.
3. Be familiar with the shape and depth of the pool or spa before you install the table. This table should only
be used in the shallow end of the pool or spa.
4. To avoid entrapment, do not swim under or near table.
5. Do not climb on or han from any part of the table, support poles, or umbrella.
6. Do not stand, jump or dive from any part of the table.
7. No rou hhousin or horseplay should be allowed around the table at any time.
8. CAUTION: Table tops are slippery when wet.
9. Do not drink alcohol in pool or spa.
10. Do not take chances and inspect the table at l ast once a year for parts that may become loose, dama ed,
weakened or broken. If necessary, before usin the table a ain, have it inspected and repaired by a competent
professional familiar with pool/spa tables.
11. When removin the table, be sure to remove the 1.50” adapter. This will prevent any possible injury from
trippin on the adapter.
12. For use in 1.50” anchors only on pools sundecks or tannin led es.
13. 1.50” plastic umbrella anchor not included.
Figur 1: 16” PL Table w/Umbrella Hole, Pole Receiver, 18” Support Pole, 1.50” Adapter 30” Table w/Umbrella
Hole, Pole Receiver, 18” Support Pole, 1.50” Adapter
Pole Recei er
Clear Umbrella Ring Cap
18” Support Pole
1.50” Adapter
30” Table w/Umbrella Hole16” Table w/Umbrella Hole

2
Retrofit_Table-IM Rev. 5/15
I N S T A L L A T I O N M A N U A L RE TR OF I T TAB LES
ASSEMBLY & INSTALLATION INSTRUCTIONS FOR TABLES:
1. Locate the support pole receiver. NOTE: whit int rnal ring nd g ts glu d into tabl flang . See Figure 2.
2. Place the support pole receiver on top of the support pole. NOTE: th support pol will h lp facilitat
th gluing of th support pol r c iv r into th tabl flang . See Figure 3.
3. Lay the table upside down on the cardboard box to prevent scratchin . Use PVC lue (not included) to
permanently attach the support pole receiver to the table flan e. Use the support pole to fully seat the
receiver into the flan e. See Figure 4 and Figure 5.
4. When the receiver is fully inside the flan e, the support pole can then be removed. See Figure 6.
5. An umbrella (not included) may be used by removin the clear cap from the table rommet. (Maximum
umbrella pole size is 1-5/8” or 1.625”).
6. Install the 1.50” adapter into existin deck anchor. Slide support pole over 1.50” adapter and set table on
support pole.
7. When removin the table be sure to remove the 1.50” adapter.
NOTE: If a shorter table height is desired, determine height required, cut the support pole with a hacksaw
and deburr.
Figur 2: Pole ReceiverFigur 3: Pole Receiver on Support Pole
Figur 4: Pole Receiver Shown with Table Flange Figur 5: Pole Receiver Attached to Table Flange
Figur 6: Properly Glued Pole Receiver Shown

3
