Inter-m PA-2000 User manual

PA-2000/PA-4000/
PA-2000R/PA-4000R
Public Address Amplifier
Copyright 2004 Inter-M Corporation

PA-2000/PA-4000/PA-2000R/PA-4000R Public Address Amplifier
Contents
Welcome ..................................................................................................................................... 3
Unpacking ............................................................................................................................... 3
Warnings .................................................................................................................................. 3
Operation................................................................................................................................. 5
Features ....................................................................................................................................... 6
Front Panel Controls.................................................................................................................... 7
Rear Panel Controls .................................................................................................................. 10
Connection of the Antenna and Grounding Cables............................................................. 13
Impedance Selector ................................................................................................................ 14
Connecting Speakers............................................................................................................... 15
Block Diagram .......................................................................................................................... 16
Specifications............................................................................................................................ 17
2

PA-2000/PA-4000/PA-2000R/PA-4000R Public Address Amplifier
Welcome
A personal welcome to you from the management and employees of Inter-M
Thank you for purchasing this fine Inter-M product. All of us here at Inter-M are dedicated
to providing you with the highest quality products and the best value.
We sincerely trust this product will provide you with years of satisfactory service, but if
anything is not to your complete satisfaction, we will endeavor to make things right.
Welcome to Inter-M, and thank you for becoming a part of our worldwide extended
family!
Unpacking
Although your PA-2000/4000 is neither complicated nor difficult to operate, we
recommend you take a few minutes to read this brief manual and familiarize yourself
with the important information regarding product features, setup and operation.
As with most electronic devices, we strongly recommend you retain the original
packaging. In the unlikely event the product must be returned for servicing, the original
packaging (or reasonable equivalent) is required.
Warnings
Environment
Never place this product in an environment that could alter its performance or reduce its
service life. Such environments are usually characterized by high levels of heat, dust,
moisture, or vibration.
Safety
1. Read these instructions carefully.
2. Follow all instructions.
3. Keep all warnings.
4. Do not operate this apparatus near water.
5. Clean only with a damp cloth.
6. Do not block any of the ventilation openings.
7. Install only in accordance with the instructions in this manual.
3

PA-2000/PA-4000/PA-2000R/PA-4000R Public Address Amplifier
8. Do not install near any heat sources such as radiators, heat registers, stoves, or other
devices (including amplifiers) that produce heat.
9. Do not defeat the safety purpose of the polarized or grounding type plug. A polarized
plug has two blades, with one wider than the other. A grounding type plug has two
blades and a third grounding prong. The wide blade or the third prong is provided for
your safety. If the provided plug does not fit into your outlet, consult an electrician for
replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched, particularly at plugs,
convenience receptacles, and the point where it is attached to the apparatus.
11. Use only the attachments/accessories specified.
12. Use only with a cart, stand, tripod, bracket, or table specified, or sold with the
apparatus. When a cart is used, use caution when moving the cart/apparatus
combination to avoid overturning.
13. Unplug this apparatus during lightning storms or when unused for long periods of
time.
14. Refer all servicing to qualified service personnel. Servicing is required when the
apparatus has been damaged in any way, such as power supply cord or plug is
damaged, liquid has been spilled or objects have fallen into the apparatus, the
apparatus has been exposed to rain or moisture, does not operate normally, or
has been dropped.
4

PA-2000/PA-4000/PA-2000R/PA-4000R Public Address Amplifier
Operation
Make certain that speakers and input sources are properly connected before switching
on.
Keep volume levels at minimum gain before switching on.
NOTE: The system’s operation is delayed by approximately three seconds after pressing
the AC Mains power switch. This is due to the built-in protection circuitry, designed to
protect the speakers and other system components.
5

PA-2000/PA-4000/PA-2000R/PA-4000R Public Address Amplifier
PA-2000/4000/2000R/4000R
Public Address Amplifier
Features
Six Input Channels with Adjustable Input Sensitivity and Individual Level Controls
• Rear-panel level controls adjust each input channel from Mic to Aux level.
Five-Band Graphic Equalizer
• Five-band graphic equalizer allows you to shape the tonal balance of your program
material.
Speaker Select
• Six speaker select switches enable you to select any combination of up to five
speakers.
Tuner Memory (PA-2000R, PA-4000R Only)
• Integrated AM/FM tuner with 16 programmable memory locations to easily store and
recall your favorite preset stations. (Available on the PA-2000R and PA-4000R only.)
Telephone Paging Input/Music-on-Hold (PA-2000R, PA-4000R Only)
• Telephone input for connection with telephone system. Music-on-Hold function
available on PA-2000R and PA-4000R only.
Phono Level Input
• Switchable input level on Channel 6 allows for connection of phono level source.
Announcement Chime and Siren
• Convenient four-tone chime and electronic siren for use with announcements.
6

PA-2000/PA-4000/PA-2000R/PA-4000R Public Address Amplifier
Front Panel Controls
1. Power Switch
Pressing this switch switches the unit on, as indicated by the Power LED above the
switch. Pressing it again switches the unit off.
2. Speaker Selector
These switches are used to select output to any combination of up to five
individual speakers.
3. Siren Button
Pressing this button will activate the siren circuitry. Pressing it a second time will
gradually lower the siren signal, switching it off completely after approximately 2.5
seconds.
7

PA-2000/PA-4000/PA-2000R/PA-4000R Public Address Amplifier
4. Chime Button
Pressing this switch activates the chime circuitry.
5. Master Volume
This knob controls the overall volume of the amplifier’s output signal.
6. CH6 / Phono Volume
This knob controls the volume of Channel 6 or Phono Input, as selected by the
associated rear panel switch.
7. CH1-CH5 Volume
These knobs control the output volume of Channels 1 - 5.
8. Channel 1 Input
This is an input jack for Channel 1. Inserting a connector into this front-panel jack
will override (disconnect) the signal connected to the rear-panel CH1jack.
9. Graphic Equalizer
Each slider controls the cut (decreased gain) or boost (increased gain) for its
associated frequency band. The middle position indicates flat response (no cut or
boost). Moving the slider upwards increases that frequency’s gain, while moving it
down decreases the level of that frequency.
10. Protection Indicator
This LED indicates the state of the amplifier’s protection circuitry. When the
Protection LED is on (illuminated), the protection circuitry is active, indicating that
the unit is not operating normally. This is typically due to overheating or power
limiting. Please check the Input and Output condition of the amplifier.
11. Output Level Display
This 10-segment LED meter indicates the amplifier’s output level in RMS.
12. Tuning Frequency Display (PA-2000R/PA-4000R Only)
This LCD displays the currently selected frequency of the AM/FM tuner.
13. Tuner Power-On Switch (PA-2000R/PA-4000R Only)
To switch the AM/FM tuner on, press this switch
14. Band Selector Switch (PA-2000R/PA-4000R Only)
This switch selects the frequency band for the AM/FM Tuner. Pressing it selects
between AM band, FM band, or FM Mute.
15. Address Select Switches (PA-2000R/PA-4000R Only)
These switches are used to recall previously stored radio frequencies. The eight
switches can store and recall up to 16 frequencies within their A and B banks.
16. SHIFT Switch (PA-2000R/PA-4000R Only)
This switch, used in conjunction with the Address Select Switches (see 15 above),
selects between the two (A and B) banks of memory locations for preset radio
frequencies.
8

PA-2000/PA-4000/PA-2000R/PA-4000R Public Address Amplifier
17. MEMORY Switch (PA-2000R/PA-4000R Only)
This switch, used in conjunction with the Address Select Switches (see 15 above),
is used for entering a selected radio frequency into one of the 16 preset locations.
To enter a frequency into memory:
• Select the desired frequency with the UP or DOWN switches (see 18 below)
• Select the A or B bank with the SHIFT switch (see 16 above)
• Press the MEMORY switch
• Press the Address Select switch for the desired location (see 15 above)
• The current frequency will be stored in the selected memory location
18. UP and DOWN Switches (PA-2000R/PA-4000R Only)
These switches are used to tune the radio frequencies to higher or lower
frequencies. Pressing the UP or DOWN switch once will move to the next available
frequency. Pressing and holding the UP or DOWN switch will tune the frequency
without stopping.
19. Radio Volume (PA-2000R/PA-4000R Only)
Controls the volume level of the radio tuner output.
9

PA-2000/PA-4000/PA-2000R/PA-4000R Public Address Amplifier
Rear Panel Controls
1. AC Power Cable
Connect this cable to your AC outlet.
2. Speaker Output Terminal
These terminals connect up to five speakers in 4, 8or High Impedance mode.
NOTE: Only speakers connected to the High-Impedance terminals are controlled
by the front-panel Speaker Selector switches.
3. Link Out
This line-level output connects the unit with an external mixdown deck or other
recording source.
4. Link In
This line-level input connects the unit with an external mixer for expanded input
channels.
5. Preamp Output
This output connects the unit with an external power amplifier. Inserting a plug
into the Preamp Out jack will disconnect signal to the unit’s power amp, sending
the output of the internal mixer to the external amplifier.
6. Amp In
This input connects an external mixer or preamp with the unit’s power amp.
Inserting a plug into the Amp In jack will disconnect all input signal from the unit’s
internal mixer. Only signal from the external source will be heard.
10

PA-2000/PA-4000/PA-2000R/PA-4000R Public Address Amplifier
7. GND Terminal
This grounding terminal is provided for connecting with the chassis of a turntable
or other input device to reduce hum and other ground loop noise. It may also be
connected to a true earth ground, such as an AC third-pin ground or water pipe,
to further reduce ground loop noise.
8. CH6/PHONO Selector Switch
This switch is used to select the input level for Channel 6. When set to Mic/Aux
position, CH6 input is set to Mic/Aux level. When set to PHONO, CH6 input is at
Phono level.
NOTE: When the CH6 Input selector is set to PHONO, the input gain of CH6 is
unaffected by that channel’s Input Gain Control.
9. Input Gain Controls
These knobs control the input levels for each of the six input channels. When
adjusting the input gain, make certain that the levels are not set too high, or
distortion will result.
The approximate levels for these controls are as follows:
MIC mic level (-50dB ~ -70dB)
MIC ATT instrument level (-30dB ~ -50dB)
AUX line level (-20dB ~ -30dB)
10. Channel 1-5 Inputs
Channel 1-5 inputs are provided on balanced ¼” connectors. Optionally, the
inputs for these channels are available as balanced three-pin XLR connectors,
unbalanced RCA connectors or screw terminals. Transformer balanced inputs are
also available.
11. Channel 6 Input
Channel 6 input is provided on dual RCA connectors, for use with a CD, Cassette
or Phono input.
NOTE: When both inputs are used the signal is summed and combined.
12. Telephone Input Terminals
These terminals are provided for connection with a telephone exchange system
for paging purposes.
NOTE: When the telephone input is active, all other input signals except AMP IN
are muted.
13. EXT Mute
When these two terminals are shorted, signals from Input Channels 3-6, tuner and
turntable are muted. Signals fron Channel 1, Channel 2, Link In and Chime are not
muted.
14. EXT Chime
When these two terminals are shorted, the four-tone chime circuitry is activated.
15. Fuse Holders
This holder contains the AC overload protection fuse. If the fuse has blown out,
replace it with a fuse of the same type and rating, as shown below.
11

PA-2000/PA-4000/PA-2000R/PA-4000R Public Address Amplifier
If the fuse continues to blow, refer servicing to a qualified service technician.
AC Fuse Ratings
Model 100VAC – 120 VAC 230VAC-240VAC
PA-2000/PA-
2000R
2A / 250V 1A / 250V
PA-4000/PA-
4000R
4A / 250V 2A / 250V
16. Impedance Selector Switch
Selects between low impedance settings of 70V or 25V. Note that this switch is
only active when the speakers are connected to the COM terminal and one or
more of the SP1-SP5 terminals. When the speakers are connected to the COM
terminal and either the 4or 8terminal, this switch is non-functional.
Impedance Ratings
Model 70 Volt 25 Volt
PA-2000/PA-2000R 83.510.4
PA-4000/PA-4000R 41.85.4
12

PA-2000/PA-4000/PA-2000R/PA-4000R Public Address Amplifier
Connection of the Antenna and Grounding Cables
Install a standard FM dipole antenna by connecting one lead to the terminal marked
300, and the other lead to the terminal marked Ground. (See Figure 1.)
If you are installing a 75coaxial FM antenna, connect the center conductor to the
terminal marked 75, and the shield conductor to the terminal marked Ground. (See
Figure 1.)
Connect the single conductor of an AM antenna to the terminal marked AM.
Connecting the terminal marked Ground to an earthed ground will help cut down on
radio frequency noise and interference. (See Figure 2.)
13

PA-2000/PA-4000/PA-2000R/PA-4000R Public Address Amplifier
Impedance Selector
To change from high impedance (70V) to high impedance (25V), loosen screw (#2) and
remove the holder, then set the switch to 25V. Then tighten screw (#2), insert the holder
in the opposite direction and tighten screw (#1). See figure 3 below.
To change from high impedance (70V) to high impedance (25V), loosen screw (#1) and
remove the holder, then set the switch to 70V. Then tighten screw (#1), insert the holder
in the opposite direction and tighten screw (#2). See figure 3 below.
NOTE: If speakers are connected to the GND and 4or 8terminals, the Impedance
Selector switch is inactive.
14

PA-2000/PA-4000/PA-2000R/PA-4000R Public Address Amplifier
Connecting Speakers
Before connecting speakers to your PA-2000/PA-4000 unit, be sure to disconnect the AC
power cable. Make certain that the total impedance is not less than the rated
impedance indicated.
For 4speakers, connect in parallel, with the negative (-) connectors to the 4terminal
and the positive (+) connectors to the COM terminal. See Figure 4 below.
For 8speakers, connect in parallel, with the negative (-) connectors to the 8terminal
and the positive (+) connectors to the COM terminal. See Figure 5 below.
For high-voltage distributed systems, connect with matching transformer as per Figure 6
below. Be certain that the total impedance does not equal less than the rated
impedance.
15

PA-2000/PA-4000/PA-2000R/PA-4000R Public Address Amplifier
Block Diagram
16

PA-2000/PA-4000/PA-2000R/PA-4000R Public Address Amplifier
Specifications
AMPLIFIER SECTION
Rated Output Power (THD 1%) PA-2000/PA-2000R: 60W (RMS)
PA-4000/PA-4000R: 120W (RMS)
Input Sensitivity/Impedance
CH 1~CH 6 0.25mV~80mV/600
Phono (CH6) 2mV/22K
Link In 100mV/15k
Telephone In 0.775V/600
Amp In 1V/47k
Frequency Response 60Hz–20kHz
T.H.D (at 1kHz Rated Output) Less than 0.5%
S/N 105dB
Graphic Equalizer
(100Hz, 330Hz, 1KHz, 3.3KHz, 10KHz) ±12dB
Speaker Output/Impedance 120W: 4, 8, 42(70V), 83(100V)
60W: 4, 8, 83(70V), 165(100V)
Link Out/Impedance 500mV/600
Music On Hold/Impedance (2000R/4000R only) 0.775V/600
Preamp Out/Impedance 1V/600
TUNER SECTION
Tuning Range FM: 87.5 – 108 MHz
AM: 522 – 1710 KHz
Antenna Input FM: 300, BAL or 75UNBAL
Usable Sensitivity FM: 2µV
AM:4µV
S/N FM: 65dB
AM:50dB
GENERAL
Power Source AC 110V–240V, 50/60Hz
Power Consumption PA-2000/PA-2000R: 130W
PA-4000/PA-4000R: 230W
Weight PA-2000: 10kg (22 lbs.)
PA-4000: 12kg (26.4 lbs.)
Dimensions PA-2000: 420(W)x 100(H)x 320(D) mm
16.5(W) x 3.9 (H) x12.6 (D) in
PA-4000: 420(W)x 133(H)x 320(D) mm
16.5(W) x 5.2 (H) x12.6 (D) in
Specifications and design subject to change without notice for improvements.
17

PA-2000/PA-4000/PA-2000R/PA-4000R Public Address Amplifier
Inter-M, Ltd. (Korea) began operations in 1983.
Since then, Inter-M has grown to become one of the largest manufacturers
of professional audio and commercial sound electronics equipment in the world.
Inter-M has gained worldwide recognition for its own branded products,
as well as private label manufacturing of electronics sold under other names (OEM).
The company is no longer just a Korean company, but rather a global company
that is truly international in scope, with factories and offices in Korea and China,
and sales and marketing operations located in Japan, Europe, and the U.S.A.
With more than 850 employees around the globe, Inter-M is well-poised for further growth and
expansion.
INTER-M AMERICAS, INC.
1 EAST BEACON LIGHT LANE, CHESTER, PA, USA 19013-4409
TEL: [phone], FAX: [phone]
Home Page:http://www.inter-m.net, E-mail: [email protected]
INTER-M Corporation
SEOUL OFFICE: 653-5 BANGHAK-DONG, DOBONG-KU, SEOUL, KOREA
TEL: [phone]~8, FAX: [phone]
Home Page:http://www.inter-m.com, E-mail: [email protected]
0604PA20004000R PRINTED IN KOREA
18
