Inter-m PAM- 360A User manual

PAM-240A/360A
AMPLIFIER

Ref No Part No Description Value Qty
BD301-302 2058100979 DIODE BRIDGE (KBP01G/KBP153G) KPBP 152 2
C205 C305 3539152311-A CAP CE X 1500PF 16V M AXIAL 0.0015 2
C327-330 C336-339 3509472530-T CAP CE F 0.0047UF 50V Z 0.0047/50 8
C323 C325 3529104531-A CAP CE F 100000PF 50V Z 0.1 2
C208 C308 C341 3529103531-A CAP CE F 10000PF 50V Z 0.01 3
C216-217 C316-317 3509102231-A CAP CE YB 1000PF 50V K AXIAL 1000P 4
C202 C302 C320 3509101231-A CAP CE B 100PF 50V K AXIAL 100P 3
C206-207 C306-307 3509220130-T CAP CE SL 22PF 50V J 22P 4
C204 C304 3509330130-T CAP CE SL 33PF 50V J 33P 2
D206 D209 D214 D306
D309 D315
D201-205 D207-208
D301-302 D304-305
D307-308
D210-211 D310-311 2058322100 DIODE 1SS145 ROHM ISS 142 4
D212-213 D312-313 2058100110 DIODE RL207 PYUNG CHANG RL207 4
C201 C301 3409810971-T CAP AF NP 1UF 50V 6 P 1/50 NP 2
C209 C309 C318 C321 3409210071-T CAP AF RSG 10UF 50V 5 P 10/50 5
C334
C218-219 3409810141-T CAP AF NP 100UF 25V 100/25 NP 2
C203 C220 C303 3409210141-T CAP AF RSG 100UF 25V 6 P 100/25 3
C324 3409210171-T CAP AF RSG 100UF 50V 8 P 100/50 1
C335 3408210261 CAP RSG 1000UF 35V SNAP 16 P 1000/35 1
C212-213 C312-313 3409222901-T CAP SG 2.2UF 160V 2.2/160 4
C319 3409222071-T CAP AF RSG 22UF 50V 5 P 22/50 1
C332 3409222171-T CAP AF RSG 220UF 50V SG 10 P 220/50 1
C333 3409247071-T CAP AF RSG 47UF 50V 6 P 47/50 1
C322 3419547177 CAP E SD 470UF 50V (10P) 470/50 1
C326 3419582266 CAP AF HE 8200UF 35V 105'C 8200/35 1
C210-211 C310-311 3609103120-T CAP MA 0.01UF 100V 0.01/100(M) 4
C214-215 C314-315 3609104122-T CAP MA 0.1UF 100V J SMALL 0.1/100(M) 4
IC202 2118050410 IC TA7317P TOSHIBA TA 7317P 1
IC301 2118010590 IC NJM4558D JRC 4558 1
IC302 2118011905 KIA7815API-U 7815 1
L201 L301 2648099940 COIL INDUCTOR 1.2UH 1.2uH 2
PO301 2438007993 POSISTOR PTFM04BE222Q2N34B0 BE222TS 1
PO302 2438007995 POSISTOR PTFM04BH471Q2N34B0 BE471TS 1
R244-245 R250-251
R344-345 R350-351
R210 R310 3009000973 RES CF 0 1/5W JN 02
R365 3009122973 RES CF 1.2K 1/5W J N 1.2K 1
R201 R301 3009101973 RES CF 100 1/5W J N 100 2
3058828786 RES CE 0.82 5W J T 0.82 5W 8
2058304100 DIODE IN4148M 1N 4148 13
2058100996 DIODE RECTIFIER LT1N4006(4007) 1N 4006 6
Electrical Parts List (PAM-240A/360A)
AMP B'D (4005177600)

R234 R237 R334 R337 3089101275 RES NFR 100 1/4W J R PHILKO FR 100 4
R260 3009104973 RES CF 100K 1/5W J N 100K 1
R261 R360 R363 3009103973 RES CF 10K 1/5W J N 10K 3
R223 R226 R323 R326 3001154953 RES CF 150K 1/5W FN 150K 1% 4
R229-230 R329-330 3009153973 RES CF 15K 1/5W J N 15K 4
R364 3009102973 RES CF 1K 1/5W J N 1K 1
R231 R331 3009222973 RES CF 2.2K 1/5W J N 2.2K 2
R355-356 3009204973 RES CF 200K 1/5W J 200K 2
R224-225 R324-325 3002200953 RES CF 20K 1/5W F N 20K 1% 4
R214 R314 3009221973 RES CF 220 1/5W J N 220 2
R218 R220 R240 R243
R246 R249 R318 R320
R340 R343 R346 R349
R203 R255-258 R303
R358-359
R233 R333 3009271973 RES CF 270 1/5W J N 270 2
R209 R309 3002270953 RES CF 27K 1/5W FN 27K 1% 2
R241-242 R247-248 3039271575-T RES MO 270 2W J RADIAL 3.3K 2W 8
R341-342 R347-348
R213 R217 R219 R313
R317 R319
R357 3009334973 RES CF 330K 1/5W J N 330K 1
R238-239 R338-339 3039330575-T RES MO 33 2W J RADIAL 33 2W 4
R227-228 R327-328 3009333973 RES CF 33K 1/5W J N 33K 4
R235-236 R335-336 3009163973 RES CF 16K 1/5W JN 16K 4
R253 R353 3089479275 RES NFR 4.7 1/4W J R PHILKO FR 4.7 2
R252 R352 R354
R254
R202 R206 R211-212
R215-216 R221-222
R302 R306 R311-312
R315-316 R321-322
R204-205 R207-208 3009561973 RES CF 560 1/5W J N 560 8
R304-305 R307-308
R361-362 3009563973 RES CF 56K 1/5W J N 56K 2
R232 R332 3009681973 RES CF 680 1/5W J N 680 2
R259 3009822973 RES CF 8.2K 1/5W J N 8.2K 1
RL301 5528009950 RELAY HR-CR3A23 DC 24VH CR323 1
VR201 VR301 3248347110 RES SEMI RH0614C100471 470 2
Q209 Q212 Q309 Q312 2008405999 TR NPN 2SC4001 NEC 2SC 4001 4
Q219 Q221 Q319 Q321 2028407122 TR NPN 2SC5200 TOSHIBA 2SC 5200 4
Q210 Q310 2008405990-T KRC102M-AT KRC 102M 2
Q204-206 Q215
Q304-306 Q315
Q324-325
Q214 Q217 Q314 Q317 2028410884 TR NPN 2SC4793 TOSHIBA 2SC4793 5
2008606108-T KTC3200-BL-AT KTC3200BL 10
3009473973 RES CF 47K 1/5W J N 47K 16
3039479575-T RES MO 4.7 2W J RADIAL 54.7/2W
3009331973 RES CF 330 1/5W J N 330 6
3009223973 RES CF 22K 1/5W J N 22K 8
3079220275 RES NFR 22 1/4W JR PHILKO FR 22 12

Q323
Q207 Q213 Q307 Q313 2008005999 TR PNP 2SA 1546 NEC 2SA 1546 4
Q220 Q222 Q320 Q322 2028107118 TR PNP 2SA1943 TOSHIBA 2SA 1943 4
Q211 Q311 2008606102-T KRA102M-AT KRA 102M 2
Q201 Q208 Q216 Q301
Q308 Q316
Q218 Q318 2028110941 TR PNP 2SA1837 TOSHIBA 2SA1837 2
Q202-203 Q302-303 2008206106-T KTA2400-GR-AT KTA 2400G 4
ZD201-202 ZD301-302 2058502056 DIODE ZENER UZ-5.6BM(1N5232B) UZ 5.6BM 4
ZD303 2058501076 DIODE ZENER UZ-7.5B(1N5236B) UZ 7.5BM 1
AN310A(AN310B) 4355747010 CON ASS'Y,SH,5P,BH0640,BH0640, 5P 1
AN302 4428595006 CON WAFER,BOX(M),6P,ST 6P 1
CN1 4428595005 CON WAFER,BOX(M),5P,ST 5P 1
CN204 CN303-304 4428595003 CON WAFER A2505WV2-03P 3P 3
CN202-203 4428595004 CON WAFER,BOX(M),4P,ST 4P 2
CN301 4355923805 WAFER LW(3.96) 5P JIS 5P 1
CR716 3509271231-A CAP CE B 270PF 50V K AXIAL 270p 1
CR702-704 CR701 3539104531-A CAP CE Y 100000PF 50V Z AXIAL 0.1 4
CR710 CR709 3529470311-A CAP CE SL 47PF 50V J AXIAL 47p 2
CR712 CR715
CR705-706
CR714 3509561231-A CAP CE B 560PF 50V K AXIAL 560p 1
CR717 3529100311-A CAP CE SL 10PF 50V J AXIAL 10p 1
CR707-708 3509101231-A CAP CE B 100PF 50V K AXIAL 100p 2
CR711 3509820231-A CAP CE B 82PF 50V K AXIAL 82p 1
C101-102 C109-111
C718 C724 C733 C737
C750 C752 C765 C781
C705 C703 3409222171-T CAP AF RSG 220UF 50V SG 10 P 220/50 2
C707-712 C714-715
C717 C719 C721 C107
C726-727 C734 C736
C738 C743 C105
C756-758 C761
C763-764 C766-767
C772 C778 C706 C790
C745 C744 3409247991-T CAP AF RSG 4.7UF 100V 5 P 4.7/100 2
C747 3409247871-T CAP AF RSG 0.47UF 50V 5 P 0.47/50 1
C748 C716 C720 C760
C732 C762 C713
C735 C723
C701 3408247171 CAP RSA 470UF 50V SNAP 13 P 470/50 1
C753-754 C746 3409247971-T CAP AF RSG 4.7UF 50V 5 P 4.7/50 3
C768-769 C728 C775
C751 C749 C725
2008206104-T KTA1268-BL-AT KTA 1268BL 6
83409210971-T CAP AF RSG 1UF 50V 5 P 1/50
22/50 9
3409210071-T CAP AF RSG 10UF 50V 5 P
3409222071-T CAP AF RSG 22UF 50V 5 P
10/50 31
4
3409247071-T CAP AF RSG 47UF 50V 6 P 47/50 13
3529300311-A CAP CE SL 30PF 50V J AXIAL 30p
MAIN B'D <4005177700>

C722
C774 C773 C779-780 3409210141-T CAP AF RSG 100UF 25V 6 P 100/25 4
C702 3409210171-T CAP AF RSG 100UF 50V 8 P 100/50 1
C759 3409233071-T CAP AF RSG 33UF 50V 6 P 33/50 1
C729-730 3609333120-T CAP MA 0.033UF 100V J 0.033(M) 2
C731 C742 3609122120-T CAP MA 0.0012UF 100V J 0.0012(M) 2
C741 3609472120-T CAP MA 0.0047UF 100V J 0.0047(M) 1
C770 3609102120-T CAP MA 0.001UF 100V 0.001(M) 1
C771 C777 3609104122-T CAP,FILM,POLYESTR,SM,0.1UF,100 0.1(M) 2
C776 3609103120-T CAP MA 0.01UF 100V 0.01(M) 1
CR748 3509472530-T CAP CE F 0.0047UF 50V Z 0.0047/50 1
D704 D707 D715 2058100996 DIODE RECTIFIER LT1N4006(4007) IN4006 3
D701-703D705 D708-714 D7
0
2058304100 DIODE IN4148M IN4148 12
C792-793 3409810971-T CAP,E,NP,NP,85C,1UF,50V,M,5X11 1/50 NP 2
C791 3409210071-T CAP AF RSG 10UF 50V 5 P 10/50 1
FB101-102 2648609900 FERITE BEAD H5B ferrite bead 2
IC702 2128740209 IC BXA4230K 유진 IC BXA4230K 1
IC703-705 IC707-708 2118010590 IC NJM4558D JRC 4558 5
IC706 2118012032 IC NJM4560D JRC 4560D 1
IC701 2128610400 IC 7824 COMMON 7824 1
IC709 2128610900 IC KA7815 COMMON 7815 1
CH1 4438193710 JACK,XLR(F),1U,3P,AN XLR JACK 1
C755 3609822120-T CAP MA 0.0082UF 100V 0.0082/100 1
C739-740 3609104122-T CAP,FILM,POLYESTR,SM,0.1UF,100 0.1/100(M) 2
R705 3039152575-T RES MO 1.5K 2W J RADIAL 1.5K 2W 1
R706 R757 3009332973 RES CF 3.3K 1/5W J N 3.3K 2
R751-753 R767-768
R801 R813
R709-711 R716-718
R754 R834-835
R720 R764 R775 R713 3009183973 RES CF 18K 1/5W J N 18K 4
R724-725 R728
R733-734 R738
R721-722 R793 R799
R829 R723 R840 R714 R931
R729 R739 3009133973 RES CF 13K 1/5W J N 13K 2
R740 R770 R778-779 3009302973 RES CF 3K 1/5W J N 3K 4
R744 R760 R774 3009100973
R787 R828 R735
R758-759 R762-763
R741 R731 R742
R783-784 R732 R727
R810 R819-820
R823-824 R726 R832
R736-737
R730 R761 3009202973 RES CF 2K 1/5W J N 2K 2
3009563973 RES CF 56K 1/5W J N 56K
RES,MF,10,1/5W,5%,AX N,TA 10 6
20
3009153973 RES CF 15K 1/5W J N 15K 15
3009473973 RES CF 47K 1/5W J N 47K 9
3009103973 RES CF 10K 1/5W J N 10K 7

R780 3009152973 RES CF 1.5K 1/5W J N 1.5K 1
R781 R776-777 3009331973 RES CF 330 1/5W J N 330 3
R766 R747 3009123973 RES CF 12K 1/5W J N 12K 2
R786 3009392973 RES CF 3.9K 1/5W J N 3.9K 1
R748 3009222973 RES CF 2.2K 1/5W J N 2.2K 1
R788 R932 3009224973 RES CF 220K 1/5W J N 220K 2
R789 R796 R815 R771
R830
R795 3009106973 RES CF 10M 1/5W J N 10M 1
R790 3009225973 RES CF 2.2M 1/5W J N 2.2M 1
R797 R791 3009334973 RES CF 330K 1/5W J N 330K 2
R800 R805-806 809
R745-746 R794
R808 R821 3009274973 RES CF 270K 1/5W J N 270K 2
R811 R769 R712 R719 3009223973 RES CF 22K 1/5W J N 22K 4
R798 R792 R755 R803 R814 3009472973 RES CF 4.7K 1/5W J N 4.7K 5
R707 3009221973 RES CF 220 1/5W J N 220 1
R822 R772-773
R825-827 R782 R765
R804 R785 R756 3009752973 RES CF 7.5K 1/5W J N 7.5K 3
R750 3009561973 RES CF 560 1/5W J N 560 1
R749 3009203973 RES CF 20K 1/5W J N 20K 1
R831 R816 3009683973 RES CF 68K 1/5W J N 68K 2
R715 R812 R708 3009220973 RES CF 22 1/5W J N 22 3
R817 3009330973 RES CF 33 1/5W J N 33 1
R818 3009101973 RES CF 100 1/5W J N 100 1
R743 3009303973 RES CF 30K 1/5W J N 30K 1
R807 3009105973 RES CF 1M 1/5W J N 1M 1
R930 3009181973 RES CF 180 1/5W J N 180 1
R701 3039100575-T RES MO 10 2W JR 10/2W 1
R703-704 R802 3039479575-T RES MO 4.7 2W J RADIAL 4.7/2W 3
R702 3059569786 RES,CE,WW,5.6,5W,5%,RA R 5.6/5W 1
RLY1-3 5528999700 RELAY 876AN2-2C-S 24VDC 24VDC 3
Q701 2028406114 TR,PW,NPN,5A,100V,KTD2059,TO-2 D2059 1
Q702 2028406113 TR,PW,NPN,3A,60V,KTD2058,TO-22 D2058 1
Q703-705 Q707-708 2008606104-T TR NPN KTC3198-Y-AT TO-92 C3198 5
Q709 Q706 2008606101-T KTC3198L-BL-AT C3198BL 2
SVR701-702 3248310220 RES SEMI RH0615C100102 1K 2
SVR703-704 3248347320 RES RH0615C100473 47K 2
VR701-707 3228074710 VR,ROT,HOR,1U,BUSH,L22.5,10K,A 10KA 7
VR708-709 3228074910 VR RK09K115020153B 50KB 2
ZD701 2058502180 DIODE ZENER UZ-18BM(1N5248B) 18BM 1
ZD703 2058502056 DIODE ZENER UZ-5.6BM(1N5232B) 5.6BM 1
AN1 4355799516 CON ASS'Y,FL,5P,5395,5264,360M 5p 1
CN4 4428598313 CON WAFER,LOCK(M),13P,ST 13P 1
AN310 4355463412 CON ASS'Y 2P 250MM 2P
3009102973 RES CF 1K 1/5W J N 1K 8
73009104973 RES CF 100K 1/5W J N 100K
3009393973 RES CF 39K 1/5W J N 39K 5

CN6 4428595002 CON WAFER,BOX(M),2P,ST 2P 1
CN301 4428595002 CON WAFER,BOX(M),2P,ST 2P 1
AN203 4355801214 CON ASS'Y,FL,4P,5264,BH0640,30 4P 1
AN311 4355463501 CON ASS'Y 4P 80MM 4P
CN5 4428595004 CON WAFER A2505WV2-04P 4P 1
AN8, 9 4428598304 CON WAFER,LOCK(M),4P,ST 4P 2
CN7, CN10 4428595005 CON WAFER,BOX(M),5P,ST 5P 2
R922 3009103973 RES CF 10K 1/5W J N 10K 1
R910-913 R917
R919-920
R904 3009184973 RES CF 180K 1/5W J N 180K 1
R902 3009223973 RES CF 22K 1/5W J N 22K 1
R907-909 R915 3009272973 RES CF 2.7K 1/5W J N 2.7K 4
R906 3009393973 RES CF 39K 1/5W J N 39K 1
R901 3009394973 RES CF 390K 1/5W J N 390K 1
R905 R921 3009473973 RES CF 47K 1/5W J N 47K 2
R903 3009683973 RES CF 68K 1/5W J N 68K 1
R923 3009752973 RES CF 7.5K 1/5W J N 7.5K 1
C903 3409210971-T CAP AF RSG 1UF 50V 5 P 1/50 1
C901-902 C904 3409247971-T CAP AF RSG 4.7UF 50V 5 P 4.7/50 3
IC901-902 2118030405 IC,DRIVER,LED METER,KIA6966S,S KTA6966S 2
U1 2128770100 IC EM57P300AP(KOREAN) EM57P300 1
Q902 2008405990-T KRC102M-AT KRC 102M 1
Q901 2008606104-T TR NPN KTC3198-Y-AT TO-92 C3198 1
R914 3002180953 RES CF 18K 1/5W FN 18K 1% 1
LED1 2308000135 LTL-1CHEO11A LITEON POWER 1
LED2 2308000135 LTL-1CHEO11A LITEON PROT 1
LED3 2300032105 LED,RND 3.1MM,GRN,DIF,1U,ST2.5 -19 1
LED4 2300032105 LED,RND 3.1MM,GRN,DIF,1U,ST2.6 -14 1
LED5 2300032105 LED,RND 3.1MM,GRN,DIF,1U,ST2.7 -11 1
LED6 2300032105 LED,RND 3.1MM,GRN,DIF,1U,ST2.8 -8 1
LED7 2300032105 LED,RND 3.1MM,GRN,DIF,1U,ST2.9 -6 1
LED8 2300032105 LED,RND 3.1MM,GRN,DIF,1U,ST2.10 0 1
LED9 2300032105 LED,RND 3.1MM,GRN,DIF,1U,ST2.11 2 1
R844 3009182973 RES CF 1.8K 1/5W J N 1.8K 1
R843 3009333973 RES CF 33K 1/5W J N 33K 1
R841 3009564973 RES CF 560K 1/5W J N 560K 1
R842 3009683973 RES CF 68K 1/5W J N 68K 1
C792-793 3409810971-T CAP AF NP 1UF 50V 6 P 1/50 NP 2
CR740-743 3509102530-T CAP CE B 0.001UF 50V J 0.001/50 4
CR722 3539103521-A CAP CE YF 10000PF 50V Z AXIAL 0.01 1
CR718-721
CR744-745
CR713 3539472331-A CAP CE X 4700PF 16V M AXIAL 0.0047 1
D801 2058502043 DIODE ZENER UZ-4.3BM(1N5229B) UZ 4.3BM 1
63569104933-T CAP MONO CE 0.1UF 50V 0.1/50
3009122973 RES CF 1.2K 1/5W J N 1.2K 7
DISPLAY & LED B'D <4005177740/4005177750>

ZD704 2058502056 DIODE ZENER UZ-5.6BM(1N5232B) 5.6BM 1
AN4 4355462118 CON ASS'Y 16P 420MM PAM-240A/3 16P 1
AN302 4355801021 CON ASS'Y,FL,6P,5264,BH0640,51 6P 1
CN403 4428595003 CON WAFER A2505WV2-03P 3P 1
TER1 4465997605 TERMINAL,SCREW,5P,10MM,2/ST terminal 1
JACK3-4 4438097310 JACK PHONE 4P jack 2
CR726-727 3539102231-A CAP CE YP 1000PF 50V K AXIAL 1000p 2
C108 3609272120-T CAP MA 0.0027UF 100V J 0.0027(M) 6
C103 C104 C106 3409222071-T CAP AF RSG 22UF 50V 5 P 22/50 18
CR109 3509271231-A CAP CE B 270PF 50V K AXIAL 270p 6
CR106-107 3509121231-A CAP CE B 120PF 50V K AXIAL 120p 12
CR108 3529050311-A CAP CE SL 5P 50V C AXIAL 5p 6
CR110 3529330311-A CAP CE SL 33PF 50V J AXIAL 33P 6
CR103-105 CR102 3539102231-A CAP CE YP 1000PF 50V K AXIAL 1000p 24
CR101 3539103521-A CAP,CE,SEMI,Y5V,0.01UF,50V,Z,A 0.01 1
IC101-102 2168220989 IC NJM 2068L JRC 2068L 6
R124 3009100973 RES CF 10 1/5W J N 10 6
R109 R110 3009221973 RES CF 220 1/5W J N 220 12
R106 R108 3009332973 RES CF 3.3K 1/5W J N 3.3K 12
R121 3009154973 RES CF 150K 1/5W J N 150K 6
R125 3009470973 RES CF 47 1/5W J N 47 6
R120 3009184973 RES CF 180K 1/5W J N 180K 6
R119 R122 3009272973 RES CF 2.7K 1/5W J N 2.7K 2
R111 R114 3009132973 RES CF 1.3K 1/5W J N 1.3K 12
R115 3003220953 RES CF 2.2K 1/5W F N 2.2K 1% 6
R118 3004274953 RES CF 274 1/5W FN 274 1% 6
R101-102 3009682973 RES CF 6.8K 1/5W J N 6.8K 12
R103-104 3009474973 RES CF 470K 1/5W J N 470K 12
R105 R107 3009430973 RES CF 43 1/5W J N 43 12
R117 3009000973 RES CF 0 1/5W JN 0 6
R113 R112 R116 R123 3009103973 RES CF 10K 1/5W J N 10K 24
VR101 3228074810 VR RK09K111020153C 50KC 6
VR102-104 3238089910 VR,ROT,HOR,1U,L22.5,50K,B,CC 50KB 18
IC1 2118010590 IC NJM4558D JRC 4558 1
BD601 2058100103 DIODE,BR,25A,400V,KBPC2504,KBP KBPC 2504W 1
D607-611 2058100996 DIODE RECTIFIER LT1N4006(4007) 1N 4006 5
D601-606 D612-616 2058304100 DIODE IN4148M 1N 4148 11
CR601 3549472407 CAP,CE,AC,Y2/X1,4700PF,250VAC, 0.0047/400V 1
CR604-605 3529560311-A CAP,CE,TEMP,SL,56PF,50V,J,AX,T 56P/50V 2
CR602-603 3619474153 CAP POLY TM 0.47UF 250V 0.47/250 2
C783-784 C789 3409210059-T CAP,E,SM,RG,105C,10UF,50V,M,5X 10/50 3
C782 C785 3409222071-T CAP AF RSG 22UF 50V 5 P 22/50 2
C601-602 3419022205 CAP AF RSG 22UF 50V 5 P 2200/160 2
Q601-610 2008606108-T KTC3200-BL-AT KTC3200BL 10
SPEAKER SELECTOR B'D <4005177710>
INPUT B'D <4005411800>

R601-610 R850-851
R854-855 R859
R614 R618 R622 R626
R630
R637-638 3009472973 RES,MF,4.7K,1/5W,5%,AX N,TA 4.7K 2
R612-613 R616-617
R620-621 R624-625
R628-629
R852-853 R856 R860 3009563973 RES CF 56K 1/5W J N 56K 4
R611 R615 R619 R623
R627 R861
RL601-605 5528007500 RELAY DH24D2-0 24V (DAIICHI) DH24D2 24V 5
SW1 4648098410 SW PS-5-W7AV POWER SW 1
SW606 4628984010 SW,PUSH,HOR,DPDT,NS,1U,BKT,L17 SW 1
SW607 4628098510 SW PUSH SPUL19X2M021 SW 1
AN6 4355857810 CON ASS'Y,DS,2P,5295,5264,200M 2P 1
CN310 4428595002 CON WAFER,BOX(M),2P,ST 2P 1
CN311 4428595004 CON WAFER,BOX(M),4P,ST 4P 1
CN401 4428595006 CON WAFER,BOX(M),6P,ST 6P 1
CN601 4355923805 WAFER LW(3.96) 5P JIS 5P 1
CN604 4428596612 CON WAFER,LOCK(M),12P,ST 12P 1
CN605 4428595007 CON WAFER A2505WV2-07P 7P 1
CN606 4355923801 CON WAFER B3P-VH JST(3.96) JST 3P 1
CN607 4355923803 CONNECTOR WAFER 03P(J.ST) 3P 1
P603 4355789213 CON ASS'Y,DS,1P,250T08,P2.6,27 1P 1
P604-605 4355789313 CON ASS'Y,DS,1P,250T08,P2.6,27 1P 2
P606 4355789413 CON ASS'Y,DS,1P,250T08,P2.6,27 1P 1
IC401 2118010590 IC NJM4558D JRC 4558 1
ZD705 2058502056 DIODE ZENER UZ-5.6BM(1N5232B) 5.6BM 1
R402-403 R407 R409 3009103973 RES CF 10K 1/5W J N 10K 4
R404-406 R408 3009123973 RES CF 12K 1/5W J N 12K 4
R927 3009225973 RES,MF,2.2M,1/5W,5%,AX N,TA 2.2M(1/5W) 1
C403 3409222071-T CAP AF RSG 22UF 50V 5 P 22/50 1
C401-402 C404 3409247071-T CAP AF RSG 47UF 50V 6 P 47/50 3
C1000 3549472407 CAP,CE,AC,Y2/X1,4700PF,250VAC, (100+0.33) 1
CR407 3529560311-A CAP CE SL 56PF 50V J AXIAL 56P 1
CR405-406 CR731-732 3509102231-A CAP CE YB 1000PF 50V K AXIAL 1000P 4
CR723 3539103521-A CAP CE YF 10000PF 50V Z AXIAL 0.01 1
J1-2 4438097310 JACK PHONE 4P PHONE 4P 2
JK401 4438192010 D-SUB JK 15P D-SUB 15P 1
CN8 4355923804 CONNECTOR WAFER 04P (J.ST) 4P 1
SGND 4355462210 CON ASS'Y YL/GN 200MM 1P 1
AC1 4448599010 AC INLET (B'D IN TYPE) 220V 1
AN5 4355747117 CON ASS'Y,SH,4P,5264,BH0640,35 4P 1
AN301 4355763617 CON ASS'Y,DS,12P,BH0640,BH0640 12P 1
5
3009100973 RES CF 10 1/5W J N 10 6
3009473973 RES CF 47K 1/5W J N 47K 10
3009103973 RES,MF,10K,1/5W,5%,AX N,TA
3009332973 RES CF 3.3K 1/5W J N
POWER IN B'D <4005177720>
10K 15
3.3K

AN401 4355801018 CON ASS'Y,FL,6P,5264,BH0640,42 6P 1
AN403 4428595003 CON WAFER A2505WV2-03P 3P 1
R501-506 3009392973 RES CF 3.9K 1/5W J N 3.9K 6
LD501-506 2306050101-T LED RED BL-B5138 RED 6
AN605 4355820500 CON ASS'Y,FL,7P,35022,5264,100 7P 1
CR746-747 CR749-756 3509103530-T CAP CE F 0.01UF 50V Z 0.01/50 10
R637-638 3009472973 RES CF 4.7K 1/5W J N 4.7K 2
TER601 4465997605 TERMINAL SCREW (D 5P) TERMINAL SCREW 1
AN604 4428596612 LOCK WAFER LW-1143-12P 12P 1
AN202 4355801214 CON ASS'Y 4P FLAT 300MM PAM 4P 1
SW609 4618001110 SW SV10020-0202-9T-SN SW 1
2828054500 TRANS POWER PAM-240A 120V pam-240a <E군-120V>
2828054510 TRANS P0WER PAM-240A 220V
p
am-240a <시판-220V
>
2828054520 TRANS POWER PAM-240A 230V pam-240a <R군-230V>
2828054530 TRANS POWER PAM-240A 240V pam-240a <C,D군-240V>
2828054400 TRANS POWER PAM-360A 120V pam-360a <E군-120V>
2828054410 TRANS POWER PAM-360A 220V
p
am-360a <시판-220V
>
2828054420 TRANS POWER PAM-360A 230V pam-360a <R군-230V>
2828054430 TRANS POWER PAM-360A 240V pam-360a <C,D군-240V>
4308997310 AC CORD SET,3P,7A,250VAC,K,220 시판
4308996710 AC CORD,3P,10A,250VAC,V,2500MM C군
4308998000 AC CORD SET,3P,7.5A,250VAC,SAA D군
4308999310 AC CORD SET,3P,10A,125VAC,U,20 E군
4308999410 AC CORD SET,3P,16A,250VAC,V,22 R군
5508412239 FUSE,20MM,T,1A,250V,K/U/CS/J pam-240a/360a <전군>1
5508412729 FUSE,20MM,T,2A,250V,K/U/CS/J pam-240a/360a <전군>2
5508413239 FUSE,20MM,T,4A,250V,K/U/CS/J -240a/360a <시판, C, D,
5508413539 FUSE,20MM,T,6.3A,250V,K/U/CS/J pam-240a <E군>
5508213739 FUSE,20MM,F,8A,250V,K/U/CS/J pam-360a <E군>
PT (PAM-240A)
AC CORD
ASS'Y
TERMINAL B'D <4005177760>
SPEAKER LED B'D <4005177770>
1
FUSE (AMP B'D)
FUSE (MAIN B'D)
1
1
PT (PAM-360A)
1
