Inter-m HDRC-Z440 User manual

Operation Manual
20X FULL HD MEGAPIXEL
HD-SDI SPEED DOME CAMERA
HDRC-Z440

!
!
"#$! (!%!)!&#!% % "!)$! %#
All of the co-workers here at Inter-M are dedicated to providing excellent products with inherently
good value, and we are delighted you have purchased one of our products.
We sincerely trust this product will provide years of satisfactory service, but if anything is not to your
complete satisfaction, we will endeavor to make things right.
Welcome to Inter-M, and thank you for becoming part of our worldwide extended family!
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAutION
CA TION: TO RED CE THE RISK OF ELECTRIC SHOCK.
DO NOT REMOVE COVER (OR BACK).
NO SER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO Q ALIFIED SERVICE PERSONNEL.
WARNING
To prevent fire or shock hazard, do not
expose the unit to rain or moisture.
*WARNING FOR YO R PROTECTION PLEASE READ THE FOLLOWING-WATER AND MOIST RE: nit should not be used near
water(e.g. near a bathtub, washbowl, kitchen sink, laundry tub, in a wet basement, or near a swimming pool, etc). Care should be taken
so than objects do not fall and liquids are not spilled into the enclosure through openings.
*CLASS 2 WIRING (Adjacent to speaker terminal): The speaker output of this apparatus can exceed 10 Watts and could be a shock injury.
Connection to speakers should be performed by a skilled person.
*Do not install this equipment in a confined space such as a book case or similar unit.
*This apparatus shall not be exposed to dripping or splashing and no objects filled with liquids, such vases, shall be placed on the apparatus.
*This apparatus shall be connected to a mains socket outlet with a protective earthing connection.
*
It has heed to be easy to disconnect the device. To disconnect the device from power, separate AC input cable from inlet or unplug the AC Cord.
CAutION
*These servicing instructions are for use by qualified service personnel only. To reduce the risk of electric shock, do not perform any servicing
other than that contained in the operating instructions unless you are qualified to do so.
NOtE
*This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual,
may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference
in which case the user will be required to correct the interference at his own expense.
This symbol is intended to alert the user to the
presence of uninsulated “dangerous voltage” within
the product’s enclosure that may be of sufficient
magnitude to constitute a risk of electric shock to
persons.
This symbol is intended to alert the user to the
presence of important operation and maintenance
(servicing) instructions in the literature accompanying
the appliance.
Caution: To prevent electric shock do not use this (polarized) plug
with an extension cord, receptacle or other outlet unless
the blades can be fully inserted to prevent blade exposure.
Attentions: Pour prévenir les chocs électriques ne pas utiliser cette
fiche polarisée avec un prolongateur, une prise de
courant on une autre sortie de courant, sauf si les lames
peuvent étre insérées à fond sans en laisser aucune
partie à découvert.

"
Although your HDRC-Z440 is neither complicated nor difficult to operate, we recommend you take a few
minutes to read this brief manual and familiarize yourself with the important information regarding product
features, setup and operation.
As with most electronic devices, we strongly recommend you retain the original packaging. In the unlikely
event the product must be returned for servicing, the original packaging (or reasonable equivalent) is
required.
$%%!
'#! %
Never place this product in an environment which could alter its performance or reduce its service life.
Such environments usually include high levels of heat, dust, moisture, and vibration.
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.
. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (includ-
ing amplifiers) that produce heat.
9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two
blades with one wider than the other. A grounding type plug has two blades and a third grounding
prong. The wide blade or the third prong are provided for your safety. If the provided plug does not fit
into your outlet, consult an electrician for replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles,
and the point where they exit from the apparatus.
11. Only use attachments/accessories specified by the manufacturer.
12. Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the
apparatus. When a cart is used, use caution when moving the cart/apparatus
combination to avoid injury from tip-over.
13. Unplug this apparatus during lightning storms or when unused for long periods of time.
14. Refer all servicing to qualified service personnel. Servicing is required when the
apparatus has been damaged in any way, such as power-supply cord or plug is
damaged, liquid has been spilled or objects have fallen into the apparatus, the
apparatus has been exposed to rain or moisture, does not operate normally, or
has been dropped.
S3125A
S3125A

Figure 1 – Typical System Configuration
push
remove window assemble bubble ring ass'y
push
remove camera window
bubble ring ass'y
screw
Figure 2 –Assemble bubble ring ass’y (Optional)
Note: It is recommended to remove camera window for improving picture quality when you use bubble ring
ass’y.

Chapter 2 — Installation and Configuration
2.1 Package Contents
The package contains the following.
HD-SDI Speed Dome Camera ………………………1
Bubble Ring ………………………1(Optional)
Instruction Manual (This Document) ………………………1
Plate Adaptor ………………………1
16 Pin Cable ………………………1
The HD-SDI Speed dome camera is for use in surface mounting applications and the mounting surface
should be capable of supporting loads up to 10lb (4.5kg).
The HD-SDI Speed dome camera ’s base should be attached to a structural object, such as hard wood, wall
stud or ceiling rafter that supports the weight of the HD-SDI Speed dome camera.
Figure 3 – Installation
Figure 4 –Dimension

2.2 Basic Configuration of 20x HD-SDI Speed Dome Camera System
Figure 5 – Basic installation diagram
The HD-SDI Speed dome camera must be installed by qualified service personnel in accordance with all
local and federal electrical and building codes. The system should be installed according to Figures 5
through 9.
AC+
AC-
AC+
AC-
FGND
(Rx+)
(Rx-)
Rx(Tx)+
Rx(Tx)-
GND

Figure 6 – Layout of Switches
2.3 Setting Dome Camera (Dip Switch)
Figure 7 – One Cable Baud Rate
Figure 8 – Composite Video Signal
Figure 9 – Setting Dome Camera Termination
SW1
1
2
9000bps
ON
ON
10 kbps
ON
OFF
20 kbps
OFF
ON
40 k bps
OFF
OFF
SW1
3
PAL
ON
NTSC
OFF
SW1
4
Terminated
ON
Not Terminated
OFF

Figure 10 - Termination Diagram

2.4 Setting Dome Camera Address (ID)
To prevent damage, each HD-SDI Speed dome camera must have a unique address (ID). When installing
multiple HD-SDI Speed dome cameras using a multiplexer, it is suggested that the dome camera address
match the multiplexer port number.
If you want to set the address more than 3999, you should contact the service provider.
Refer to ‘Dome Configuration – DOME ID’ section for detailed information.
2.5 Setting Dome Camera Protocol
If a dome camera is to be installed with a Fastrax keyboard controller,
select the default protocol.
Consult service personnel if a dome camera is installed with device other than a keyboard controller.
Refer to ‘Dome Configuration – DOME ID’ section for detailed information.
2.6 Connections
• Connecting to the RS485
The HD-SDI Speed dome camera can be controlled remotely by an external device or control system,
such as a control keyboard, using RS485 half-duplex serial communications signals. Connect Marked Rx+,
Rx- to Tx+, Tx- of the RS485 control system.
• Connecting Video out connector
Connect the video out (BNC) / HD-SDI out connector to the monitor or video input.
• Connecting Alarms
AL1 to 4 (Alarm In)
You can use external devices to signal the HD-SDI Speed dome camera to react on events. Mechanical or
electrical switches can be wired to the AL (Alarm In) and GND (Ground) connectors..
GND (Ground)
Connect the ground side of the Alarm input and/or alarm output to the GND connector.
Alarm Output 1 to 2
The HD-SDI Speed dome camera can activate external devices such as buzzers or lights. Connect the device
to the Alarm Out and COM (Common) connectors.
• Connecting the Power
Connect the power of 24VAC or 12VDC to the HD-SDI Speed dome camera.
When using a 12VDC adapter, connector the positive(+) pole to the ‘+’ position and
the negative(-) pole to the ‘-‘ position.
Use satisfy clause 2.5 of IEC60950-1/UL60950-1 or Certified/Listed Class 2 power source only.

2.7 Getting Started
Once installed apply power to the dome camera. The dome camera will start a configuration sequence.
OSD Position
AF AE
001
EMPTY DATA
DOMEID:0001
360.0,090.0
ALARM:1
INFORMATION
DISPLAY
FUNCTION
UNDER RUNNING
ALARM DISPLAY
CAMERA TITLE
CAMERA ID
PAN & TILT ANGLE
PRESET TITLE
AREA TITLE
STATUS of
FOCUS and AE

Chapter 3 — Program and Operation
3.1 Dome Camera Selection
Before you program or operate a dome camera, you must select the dome camera by pressing the dome
camera No. + CAM
Example: Pressing 1 , 0 and CAM key sequentially will select dome camera 10. The selected dome camera
ID will be displayed on the LCD monitor of the keyboard controller.
3.2 Accessing the On-Screen Menu Utility
You can call up the On-screen menu utility on your monitor by pressing MENU key on the keyboard
controller, the following On-screen menu utility will appear:
DOME MENU
AUTO SCAN
PRESET
TOUR
PATTERN
PRIVACY ZONE
CAMERA
DOME COMMUNICATION
ALARM
DOME SETUP
EXIT

3.3 How to control the On-Screen Menu Utility
Function
Button
Call the On-screen menu utility
MENU
Navigate through the menu items.
Joystick up or down
Go into the sub-menu items.
Joystick left or right
or IRIS Open
Change value.
Enter the editing title mode.
Joystick left or right or
Zoom handle twist or
Tele , Wide
Change value of angle
CTRL + Joystick
Enter the changing angle mode.
IRIS Open
Exit the changing angle mode.
IRIS Close
Escape (EXIT)
ESC
3.4 Auto Scan (Shortcut: SCAN)
The Auto scan supports up to 17 programmed angles at user-programmable speeds. Follow these steps to
program Auto Scan:
NUMBER :01 -08, 10-17, 09:AUTO PAN
mode
TITLE :up to 12 characters.
MODE :NORMAL, VECTOR, RANDOM (AUTO PAN mode :NORMAL, RANDOM only)
NORMAL: Move from start point to end point in panning only.
VECTOR: Move from start point to end point including tilt and zoom simultaneously and
linearly. In some model, the zoom is fixed at wider angle and the zoom magnification
information is not displayed.
RANDOM: Move randomly between the start point and the end point.
SPEED : 1 - 13 step, the lower number means the slower speed.
SCAN DIR : Set the scan direction, CCW(Counter Clock Wise), CW(Clock Wise)
SWAP : Swap the start point for the end point.
DWELL : Set the dwell time at the both end, 01 – 99 seconds
AUTO SCAN SETUP
NUMBER : 01
TITLE : A01
MODE : NORMAL
SPEED : 5 STEP
START ANGLE : ----- -----
END ANGLE : ----- -----
SCAN DIR : CCW
SWAP : OFF
DWELL : 03 SEC
SAVE AND EXIT

2. Select the” NUMBER” and set the desired number by pushing the Joystick left or right.
3. Select the “TITLE” and twist the Joystick to enter the title edit mode.
4. Twist the Joystick by changing the alphanumeric characters and move the next position. Or move down
to the character table and press CTRL or IRIS OPEN at the desired character then the cursor position
moves to the next position automatically. Push the Joystick left or right at the “ALL DELETE” field to delete
all characters. Push the Joystick left or right at the “EXIT” field to finish title edit menu.
5. Select “MODE” and “SPEED”.
6. Select “START ANGLE”. Hold down the CTRL key while selecting the start position using the Joystick.
Current panning position will be displayed. Release CTRL key to complete the selection of the start
position. Or Press IRIS Openthen the “CTRL” displays. Move the desired position and the zoom position.
Press IRIS Close then the “CTRL” disappears. To adjust at the 0.1 degree interval, twist the Joystick at the
pan field and the tilt field. To adjust at the one zoom interval, twist the Joystick at the zoom field.
7. Select “END ANGLE.” Hold down the CTRL key while moving the Joystick to select the end position. The
end position angle should be larger than start position. Release the CTRL key to complete the selection of
the end position. Or Press IRIS Open then the “CTRL” displays. Move the desired position and the zoom
position. Press IRIS Close then the “CTRL” disappears. To adjust at the 0.1 degree interval, twist the
Joystick at the pan field and the tilt field. To adjust at the one zoom interval, twist the Joystick at the zoom
field.
8. Set “SCAN DIR” to CCW or CW.
9. Select “SWAP”. Set to ON, to exchange the start angle and the end angle.
10.Set “DWELL TIME”.
11.Select Save and Exit and push the Joystick to the right or press IRIS Open. Press ESC or IRIS Close to
exit the program without saving.
Pressing the HOME key delete stored data at the angle field.
To set the position using the preset position:
a. Before entering the Auto Scan menu, select a preset position as a starting point for
Auto Scan.
Example: 2 + PRST and do step 1 to 4. In step 5, just press the Ctrl key at the start angle position, the
current position will be displayed as a start position.
b. Save and exit from the menu.
c. In normal mode, call a preset to be the end point of scan. Press 3 + PRST then press Scan key to enter
the Auto Scan menu. Move the cursor position to END ANGLE. Just press CTRL key at the end angle
position. Save and exit from the menu.
TITLE EDIT MENU
CTRL KEY
A01
$
A B C D E F G H I J
K L M N O P Q R S T
U V W X Y Z 0 1 2 3
4 5 6 7 8 9
ALL DELETE
EXIT (ESC TO EXIT)
1. Press the SCAN key to enter the auto scan menu directly. Or press the MENU key to display the main
menu on the monitor. Scroll to Auto Scan and push the Joystick to the right.

The setting procedure is the same as above.
NOTE: 09:AUTO-PAN mode(Endless panning)
3.5 Preset (Shortcut: PRST)
If you need to view specific places routinely, you should program presets. A preset is a programmed video
scene with automatic pan, tilt, zoom, focus, and AE settings. Once programmed, placing the number
position and pressing a PRST button on your controller calls up that preset automatically. In addition, presets
may be assigned to alarm actions or
as the “home” position for the dome camera. As many as 240 presets, whose positions are saved in the
dome’s firmware, may be programmed.
There are three pages of preset menu. Each page has 80 presets. Pages can be scrolled
by pushing the Joystick to the Left or Right on the first or last No. of Preset.
-: blank preset position
$ : position has the preset
! : Current cursor position
Follow steps below to store the Preset positions:
1. Press the PRST key to enter the preset menu directly. Or press the MENU key to display the main menu
on the monitor. Scroll to preset and push the Joystick to the right.
2. Select the blank preset position to be stored by pushing the Joystick up, down, right,
or left.
3.After selecting a blank position, press and hold CTRL, Use the Joystick to control the direction of the
camera and lens.
4.After aiming the camera (view direction and lens control), release CTRL. The cursor will be on the Title
then twist the Joystick handle or Press Tele or Wide Key to edit the preset title. Follow the procedure of
the auto scan above to edit titles.
5.Select “CAMERA SET” and pushing the Joystick left or right. Then the preset camera setup displays.
AUTO SCAN AREA SETUP
CTRL KEY
NUMBER01
START: ----- -----
END : ----- -----
EXIT
PRESET SETUP
NUMBER : 001 CTRL KEY
TITLE : ---
CAMERA SET
DWELL : --- SEC 1234567890
----------
----------
----------
NEXT PAGE
SAVE AND EXIT

PRESET CAMERA SETUP
FOCUS : AUTO
MOTION : OFF
MOTION SETUP
AE SETUP
SAVE AND EXIT
Set FOCUS: AUTO, MANUAL, ONE PUSH
Set MOTION: OFF, ON
Select “MOTION SETUP” and pushing the Joystick left or right. Then the MOTION setup displays.
MOTION SETUP
SENSITIVITY : 12
POSITION : ALL
DELAY : 00 SEC
OUTPUT : OFF
HOLD TIME : 03 SEC
EXIT
Set SENSITIVITY: 1~15
Set POSITION: ALL, CENTER
Set DELAY: 0~5 SEC
Set OUTPUT: OFF, OUT1, OUT2
Set HOLD TIME: 3~99 SEC
Select “AE SETUP” and pushing the Joystick left or right. Then the AE setup displays. Refer to the AE
SETUP in the camera setup.
6.Set “DWELL TIME”(03-99second)
7.To select the next page of presets, scroll the page by pushing the Joystick to the Left
on the first and last columns of the menu.
8.Repeat steps 2 through 7 for each additional preset position.
9. Select Save and Exit by pushing the Joystick to the right. Press ESC to exit the Preset menu without saving.
NOTE: Press the HOME key at programmed preset position($) to delete a programmed preset view.
The position, which is marked with $, already has the preset view assigned. To review the stored preset,
press PRST key on the $,The camera will show the stored preset scene.
PRESET AREA SETUP
CTRL KEY
NUMBER 001
PAN TILT
000.0 000.0
EXIT
Press SCAN key on the angle field to display with the small OSD. Then the screen will show as below.

Hold down the CTRL key while selecting the desired scene using the Joystick. Current position will be
displayed. Release CTRL key to complete. Or Press IRIS Open then the “CTRL” displays. Move the desired
position and the zoom position. Press IRIS Close then the “CTRL” disappears. Select Exit and push the
Joystick to the right.
3.6 Shortcut of Preset Program
After selecting the desired scene, press No. (1 to 240), and press CTRL and PRST subsequently. The current
view will be stored to the selected preset number if the preset number is empty. If selected preset number is
not empty, “OVER WRITE” message will be displayed on the monitor and select the “OK” and push the
Joystick to the right to overwrite.
Example: 1 , 0 , 1 + CTRL + PRST will store current view as preset No. 101. In this case, focus will be
programmed as Auto, dwell time will be set to 3 second, and the current AE mode will be programmed.
3.7 Tour (SHORTCUT: TOUR)
There are 8 programmable Tours. Each Tour consists of up to 42 Preset positions, Patterns, Scans or other
Tours (second-level). Using second-level tours, it can be expanded to over 300 functions in a single tour.
--- : blank position
SCAN TYPE : NORMAL/ VECTOR
DWELL : 03-99 Sec
003 : Preset (1~240)
A08 : Auto Scan (1~8,10~17)
P01 : Pattern (1~8)
T02 : Tour (1~8)
TOUR SETUP
NUMBER :01
TITLE : T01
SCAN TYPE : NORMAL
SPEED : 5 STEP
TOUR FUNC
SAVE AND EXIT
TOUR FUNC SETUP
DWELL : -- SEC
003 A08 --- --- ---
--- --- --- --- ---
--- --- P01 --- ---
--- T02 --- --- ---
--- --- --- --- ---
--- --- --- --- ---
--- --- --- --- ---
--- --- --- --- ---
EXIT

Follow the steps below to program the Tours:
1. Press MENU to display the main menu on the monitor. Scroll to Tour and push the Joystick to the right
to enter the Tour menu. Or just press the TOUR key on the keyboard.
2. Select the” NUMBER” and set the desired number by pushing the Joystick left or right.
3. Choose a blank position to be programmed by pushing the Joystick up, down, right,
or left.
4.To add a stored preset, twist the Joystick then the stored preset number displays.
5. To place functions other than preset, press TOUR, PTRN, or SCAN for Tour, Pattern
or Auto Scan respectively.
6. You can also overwrite the programmed number and to remove a stored number from the Tour, press
the HOME key on the stored number, a blank position mark (---) will be displayed.
7.Repeat Step 2 through 5 for each desired position. Each title will be displayed on top
of the line.
8. To edit the title, follow the procedure of the auto scan above to edit titles
9. Select Save and Exit and push the Joystick to the right. Press ESC to exit the program without saving.
You can expand the Tour sequence by calling other programmed tours.
NOTE: The speed applies in the vector mode only.
NOTE: In the Tour mode, in conjunction with preset and Auto Scan, you can make the camera travel from a preset
position to another preset position at a specific speed.
Example: Preset 001>002>003>004>005>006, Auto Scan 01 starts at preset 002, ends at preset 003,
Auto Scan 02 starts at preset 005, ends at preset 006; Tour 001, 002, A01, 004, A02.
1 2 2~3 4 5~6, repeat
where : Quick move, ~ : Programmed speed
To change the dwell time of the preset in the tour:
Use the Joystick to move the cursor to a stored preset position. By pressing PRST key, the camera will move
to the stored Preset view and the cursor moves to the dwell time field. After changing the dwell time, press
PRST key and the cursor moves to the preset number.
To assign the functions other than preset in the tour when the function key is not existed:
Use the Joystick to move the cursor to a stored preset position. Pressing CTRL key or
IRIS OPEN key will change the preset number to other function (auto scan, pattern, tour, preset) with the first
programmed number. To change the number, twist the joystick or press Tele or Wide key.

3.8 Pattern (Shortcut: PTRN)
The Pattern feature records user control of the selected dome camera. Up to four 8 patterns can be stored
and played back by pressing No.+ PTRN keys subsequently.
Follow steps below to program the Pattern:
1. Press MENU to display the main menu on the monitor. Scroll to Pattern and push the Joystick to the
right to enter the pattern menu. Or just press the PTRN key on the keyboard.
2. Select the desired pattern to be programmed by pushing the Joystick Up or Down. If the pattern is not
000, a pattern has already been recorded. Patterns can be overwritten.
3.Press and hold down the CTRL key while controlling the camera direction and zoom with the Joystick.
The dome will be automatically recorded until you release the CTRL key. Or Press IRIS Open then the
“CTRL” displays. Move the position and the zoom position. Press IRIS Close then the “CTRL”
disappears.
4.Select Save and Exit and push the Joystick to the right. Press ESC to exit the program without saving.
5.To edit the title, follow the procedure of the auto scan above to edit titles.
NOTE: Press the HOME key at any programmed position to delete the pattern.
NOTE: If total recording time reaches 500 seconds, it will automatically stop for a moment.
Press PTRN key on the title field to display with the small OSD. Then the screen will show as below.
The setting procedure is the same as above.
PATTERN SETUP
N TITLE SEC PERCENT
01 : P01 000 00.0
02 : P02 000 00.0
03 : P03 000 00.0
04 : P04 000 00.0
05 : P05 000 00.0
06 : P06 000 00.0
07 : P07 000 00.0
08 : P08 000 00.0
SAVE AND EXIT
PATTERN AREA SETUP
CTRL KEY
NUMBER 01
000 00.0%
0001 01.0%
EXIT

3.9 Privacy Zone
Hide up to 12 unwanted scenes in a camera.
PRIVACY ZONE SETUP
N CTRL KEY
01 ON BLOCK BLACK
02 ON BLOCK GRAY
03 ON BLOCK BLACK
04 ON BLOCK BLACK
05 ON BLOCK BLACK
06 ON BLOCK BLACK
NEXT
SAVE AND EXIT
1. Place the cursor at the title field.
2. Holding down the CTRL key displays the privacy area menu while selecting the position using the
Joystick. Current position will be displayed. Release CTRL key to complete the selection of the position.
Or Press IRIS Open then the privacy area menu displays. Move the desired position. Press IRIS Close
then the “CTRL” disappears and returns to the previous menu.
3.Place the cursor at the title field. Twist the Joystick to enter the title edit mode. Follow the procedure of
the auto scan above to edit titles.
4.To turn the stored zone On or Off, twist the Joystick handle or press Tele or Wide Key.
5. Set the method, “BLACK” or “GRAY”
6.Select the Save and Exit option by pushing the Joystick up or down. Save and exit the program by
pushing the Joystick to the right. Press ESC to exit the program without saving.
Press the HOME key to delete programmed privacy zone at the title field.
PRIVACY AREA MENU
CTRL KEY
NUMBER 001
354.8 344.8
EXIT

3.10 Camera Menu
CAMERA SETUP
FOCUS CONTROL
WB CONTROL
AE CONTROL
CAMERA CONTROL
SHARPNESS : 10
DIGITAL ZOOM : OFF
IMAGE FLIP : OFF
PRESET FREEZE : OFF
RESOLUTION : 720P/60
SAVE AND EXIT
• FOCUS CONTROL
MODE AUTO /MANUAL / ONE PUSH / CONSTANT MANUAL
Use manual mode in normal use.
SENSITIVITY NORMAL / LOW
NORMAL: Use this option when shooting fast motion.
LOW: Offers better focus stability. In low luminance conditions, Auto Focus stops
operation even when brightness changes, enabling stable images of moving
objects.
FOCUS LIMIT This distance is approximate value and the focus operate from the setting value.
CAUTION: Avoid continuous, 24-hour use of the auto focus. This will shorten the lifespan of the lens.
• WB (White Balance) CONTROL
MODE ATW / MANUAL / OUTDOOR AUTO / SODIUM AUTO / SODIUM AUTO /
INDOOR / OUTDOOR
ATW Auto tracing white balance. (2000 to 10000° K)
MANUAL Control of R and B gain
OUTDOOR AUTO Auto mode specifically for outdoors.
SODIUM AUTO Auto mode that is compatible with sodium vapor lamps
SODIUM Fixed mode specifically for sodium vapor lamps
AUTO Computes the white balance value output using color information
from the entire screen automatically. (3000 to 7500 °K)
INDOOR 3200 K base mode
OUTDOOR 5800 K base mode
RGAIN 0 ~ 255
BGAIN 0 ~ 255
RGAIN / BGAIN modes are controllable only in MANUAL Mode
FOCUS SETUP
MODE : AUTO
SENSITIVITY : NORMAL
FOCUS LIMIT : 1M
SAVE AND EXIT
WB SETUP
MODE : ATW
R GAIN :213
B GAIN :174
SAVE AND EXIT
Table of contents
Other Inter-m Security Camera manuals

Inter-m
Inter-m IDI-540P Installation manual

Inter-m
Inter-m VCD-740 User manual

Inter-m
Inter-m VBC-410 User manual

Inter-m
Inter-m VCD-412VIM User manual

Inter-m
Inter-m VCD-741VI User manual

Inter-m
Inter-m VDC-272 User manual

Inter-m
Inter-m VCD-412 User manual

Inter-m
Inter-m VCD-412 User manual

Inter-m
Inter-m IDG-541P User manual
