Intercoax Ipify EUP-2704R-4T-PKG User manual

www.intercoax-emea.com
EUP-2704R-4T-PKG
QUICK INSTALL GUIDE
www.intercoax-emea.com
CONTACT
For in-depth manuals, datasheets and
other documents, please visit:
www.intercoax-emea.com
For Technical Support, please contact:
[email protected]
For other inquiries, please contact:
[email protected]
INTERCOAX EMEA NV
Krijtestraat 45A
9041, Ghent
Belgium
www.intercoax-emea.com
HARDWARE (RX)
www.intercoax-emea.com
HARDWARE (TX)
LED Indicators
Indicator Color Function
BNC Join EoC Devices connected
PWR 56VDC input connected
Quality
LINK Good data connection
Poor data connection
PWR Good power supply condition
Additional adapter required
Data Flashes when data is transferred
PoE PoE power supply status
DC OUT DC OUT switch is ON
LED Indicators
Indicator Color Function
BNC Join EoC Devices connected
PWR 56VDC input connected
Quality
LINK Good data connection
Poor data connection
PWR Good power supply condition
Additional adapter required
Data Flashes when data is transferred
PoE PoE power supply status
DC OUT DC OUT switch is ON

1. Connect IP Devices to TX units
Power Supply on RX and optionally TX
(available for sale)
2. Connect Switch to RX
3. Connect UTP Cables and BTE 4. Connect Power
BLUEBLUEBLUEBLUE
BLUE
