Intercoax Ipify ECP-2704T-1R-PKG User manual

www.intercoax-emea.com
ECP-2704T-1R-PKG
QUICK INSTALL GUIDE
www.intercoax-emea.com
CONTACT
For in-depth manuals, datasheets and
other documents, please visit:
www.intercoax-emea.com
For Technical Support, please contact:
[email protected]
For other inquiries, please contact:
[email protected]
INTERCOAX EMEA NV
Krijtestraat 45A
9041, Ghent
Belgium
www.intercoax-emea.com
HARDWARE (RX)
www.intercoax-emea.com
HARDWARE (TX)
LED Indicators
Indicator Color Function
BNC Join EoC Devices connected
PWR 56VDC input connected
Quality
LINK Good data connection
Poor data connection
PWR Good power supply condition
Additional adapter required
Data Flashes when data is transferred
PoE PoE power supply status
DC OUT DC OUT switch is ON
LED Indicators
Indicator Color Function
BNC Join EoC Devices connected
PWR 56VDC input connected
Quality
LINK Good data connection
Poor data connection
PWR Good power supply condition
Additional adapter required
Data Flashes when data is transferred
PoE PoE power supply status
DC OUT DC OUT switch is ON

1. Connect IP Devices to TX unit 2. Connect Switch to RX
3. Connect Coax Cable 4. Connect Power
BLUE
BLUE
Power Supply on RX and/or TX
(available for sale)
