Marmitek SM10 User manual

Smart Solutions at Home
Universal X-10 transmitter
SM10™
Emisor X-10 universal
ES Modulo trasmettitore universale
X-10
IT
• Maakt van een maak/verbreek contact een X-10 signaal
• Schakel verlichting in bij een alarm
• Zender voor via het lichtnet aansturen van apparatuur
en verlichting welke aangesloten zijn op Marmitek X-10
modules. Schakelt automatisch alle verlichting (aan
of knipperend) bij alarm, zonder extra leidingen te
leggen. Schakelen van apparatuur en verlichting vanuit
elke locatie in huis zonder extra kabels. Als “trigger”
voor de SM10 kan vrijwel elk signaal worden gebruikt:
het sluiten van een contact (relais, schakelaar of alarm-
paneel), maar ook elke spanning tussen de 6 en 18 V
(b.v. beltrafo of versterkt audiosignaal).
• Transforma un contacto normalmente abierto/cerrado
en una señal X-10
• Encender la iluminación en caso de alarma.
• Emisor para manejar aparatos y iluminación conectados
a Marmitek módulos X-10 por la red de alumbrado.
En caso de alarma conmuta automáticamente toda la
iluminación (encendida o intermitente) sin necesidad
de tirar cables. Manejar aparatos y iluminación desde
cualquier lugar en casa sin cables adicionales. Casi cada
señal puede emplearse como ‘trigger’ para el SM10:
el cerrar de un contacto (relé, interruptor o panel de
alarma) o tensiones entre los 6 y los 18 V (p.e. transfor-
madores para timbres o una señal audio amplificada).
• Converte un contatto di chiusura/apertura in un segnale
X-10
• Accende le luci in caso di un allarme
• Trasmettitore per il comando sulla linea elettrica di
elettrodomestici e lampade collegati ai moduli X-10 di
Marmitek. Commuta automaticamente tutte le luci (per
accenderle o farle lampeggiare) in caso di un allarme,
senza stendere cavi addizionali. Commutazione di
elettrodomestici e luci da ogni luogo della casa senza
cavi addizionali. Si può usare quasi ogni segnale come
“trigger” dell‘SM10: la chiusura di un contatto (relè,
interruttore o pannello allarme), ma anche ogni voltag-
gio tra 6 e 18 V (p.e. un trasformatore campanello o
segnale audio amplificato).
• Transforms a make/break contact into an X-10 signal
• Switches the lights on when the alarm goes off
• Sender for controlling appliances and lights, that are
plugged into the Marmitek X-10 modules, through the
existing house wiring. Automatically switches all lights
(on or flashing) in case of alarm, without running any
extra wires. Switch appliances and lights from every
location in your home without extra cables. You can use
almost every signal as a “trigger” for the SM10: contact
closure (relays, switch of alarm keypad), but also any
voltage between 6 and 18 (e.g. doorbell transformer or
amplified audio signal)
Universal X-10 sender
EN
• Stellt mit einem Schalt-/Unterbrechungskontakt ein
X-10 Signal her
• Schaltet bei einem Alarm die Beleuchtung ein
• Sender zum Steuern über das Lichtnetz von Geräten
und Beleuchtung, die auf Marmitek X-10 Module
angeschlossen sind. Schaltet automatisch bei Alarm alle
Lampen (ein oder blinkend) ohne zusätzliche Verkabe-
lung. Schalten von Geräten und Beleuchtung von jeder
Stelle im Haus ohne zusätzliche Verkabelung. Als Aus-
löser des SM10 kann praktisch jedes Signal verwendet
werden: Das Schliessen eines Kontaktes (Relais, Schalter
oder Alarmzentrale), aber auch jede DC-Spannung
zwischen 6 und 18 V (z.B. Telefontrafo oder verstärkets
Audiosignal).
Universeller X-10 Sender
DE
Universele X-10 zender
NL
• Transforme un contact de fermeture/d’interruption en
un signal X10
• Actionne l’éclairage en cas d’alarme
• Émetteur pour actionner appareils et éclairage raccor-
dés à des modules X10 de Marmitek par le réseau élec-
trique. Allume automatiquement l’éclairage (en marche
ou en code) en cas d’alarme, sans poser de câbles
additionnels. Changer appareils et éclairage depuis
toutes les pièces de la maison sans câbles additionnels.
En tant que déclencheur pour le SM10 n’importe quel
signal peut être utilisé : la fermeture d’un contact (re-
lais, interrupteur ou tableau d’alarme) mais aussi toute
tension entre 6 et 18V (par exemple Beltrafo ou signal
audio renforcé).
Emetteur universel X10
FR

SM10™ Europlug Art. nr. 08943
UK Plug Art. nr. 09552
Universal box size (LxWxH) 90 x 74 x 144 mm with euroslot
SM10™
Technical data Also available
Set includes
Order information
© MARMITEK 22800/20101027
Smart Solutions at Home
www.marmitek.com
Connects to an existing system and turns on lights when tripped. It has 3 modes of
operation:
In mode 1 the SM10 will turn On all Lamp Modules and Wall Switch Modules set to
its House code, and will also turn On any other Modules set to its Unit code, a stereo
connected to an Appliance Module, for example. All Lamp Modules and Wall Switch
Module are left in the On state when the system is deactivated, but the Module set to
the same Unit code as the SM10 will turn Off.
In mode 2 the SM10 will FLASH all lights connected to Lamp Modules or Wall Switch
Modules. All Lamp and Wall Switch Modules will be left in the On state when the
system is de-activated but Appliance
modules set to the same House code as the SM10 will turn Off.
In mode 3 the SM10 will turn ON any Module set to the same House Code and Unit
Code as the SM10 when the system is activated and turns it OFF when the input con-
tact is opened.
Set the input switch to A for triggering the interface by a low voltage input (6-18 V AC,
DC or audio), to B for triggering the interface by a dry contact closure. Do not connect
220V to the input terminal!
The SM10 has a test button which allows you to activate it whether or not it is con-
nected to a system. The All light off button allows you to turn off anything which has
been turned on by the interface.
To install the SM10 (is expected to be installed inside the security controller panel) :
• Connect the system output to the screw terminals.
• Connect the flying lead to the 230V power supply, most likely at the 230V side of
the transformer.
• Flash all the lights in your home when your existing burglar alarm trips.
• Blast your stereo when your alarm trips.
• Connect the SM10 directly to a magnetic switch to turn on lights when a door or
window opens, i.e., you don’t have to own a burglar system.
• Trigger it from sensors such as a photo cell to turn on lights when it gets dark, from
a motion detector to turn on lights when someone enters a room, from a micro
phone to turn on lights or appliance when a sound from an intruder is detected,
from a moisture sensor to sound an alarm if your basement is flooded, from a
garage door opener to turn on lights when you open your garage door, etc.
Supply 230VAC 50 Hz
Power consumption < 2 W
Signal transmission > 2,5Vpp, 120 kHz ± 2kHz
X-10 transmission 1 pulse burst at 0˚ ,60˚ and 120˚
Sends X-10 Key codes All units Off, All Lights On, On, Off.
For use in a 3 phase installation FD10 (3x) or CAT4000 required.
Input impedance > 180 Ohm (P-N) for 120 kHz
Connectors Screw connectors for switch contact.
Surrounding temperature -10°C to +50°C (business premises)
-20°C to +70°C (warehouse)
Dimensions 55x90x38mm
Visit www.marmitek.com for our complete product range.
