Intercon CO-TA-I4870B User manual

Assembly Instructions
HARDWARE CHECK LIST PARTS CHECK LIST
Quantity PART NAME Quantity PART NAME
12 Nut 1 Top
12 Flat Washer 1 Pedestal
12 Lock Washer 4 Leg
1 Wrench
Step 1. Turn the pedestal upside down. Do not remove the plastic bolt
protectors for this step.
Step 2. Remove the plastic bolt protectors from the hanger bolts on the legs.
Attach each leg to the pedestal using eight Nuts, eight Flat Washers and
eight Lock Washers and tighten firmly with the wrench provided. (Figure 1)
Step 3. Turn the assembled pedestal base right side up and place it in your
desired location. Adjust the leg levelers at the bottom of each leg so that the
pedestal remains solid without rocking. Remove the plastic bolt protectors
before doing the next step.(Figure 3)
S
Thank you for purchasing this quality product. Carefully check all packing material for small parts which may have
come loose inside the carton during shipment. Keep all hardware out of the reach of children. Study all of the
instructions and drawings carefully before assembly. Check that all of the connections are tight and the product
does not wobble before using.
Model: CO-TA-I4078B-BRU-TOP
Model: CO-TA-I4870B 48 x48-70" BFLY Table TOP
Model: CO-TA-I4870B 48 x48-70" BFLY Table BASE
Figure 1
Figure 2
Please remove 2pcs metal brackets secured the slides to the
bottom of the top before the next step. (Figure 2)
Step 4. Place the open table top over the pedestal and align the
holes in the table mounting boards with the bolts on the pedestal.
Set the table down on the top of the pedestal. (Figure 3)
Step 5. Attach the pedestal to the mounting board as shown using
four Nuts, four Flat Washers and six Lock Washers. Tighten all nuts
firmly with the wrench provided. (Figure 3)
Step 6. Close the table top gently and latch all locks on the bottom
of the table top.
*Check that all legs are tight and the table does not wobble before
using.
Note: To extend the table, unlatch the locks on the bottom of the
table top. Pull the table top apart gently and place the leaves into the
open table top. Latch all locks on the bottom of the table top
Figure 3

Assembly Instructions
HARDWARE CHECK LIST PARTS CHECK LIST
Quantity PART NAME Quantity PART NAME
12 Nut 1 Top
12 Flat Washer 1 Pedestal
12 Lock Washer 4 Leg
1 Wrench
Step 1. Turn the pedestal upside down. Do not remove the plastic bolt
protectors for this step.
Step 2. Remove the plastic bolt protectors from the hanger bolts on the legs.
Attach each leg to the pedestal using eight Nuts, eight Flat Washers and
eight Lock Washers and tighten firmly with the wrench provided. (Figure 1)
Step 3. Turn the assembled pedestal base right side up and place it in your
desired location. Adjust the leg levelers at the bottom of each leg so that the
pedestal remains solid without rocking. Remove the plastic bolt protectors
before doing the next step.(Figure 3)
S
Thank you for purchasing this quality product. Carefully check all packing material for small parts which may have
come loose inside the carton during shipment. Keep all hardware out of the reach of children. Study all of the
instructions and drawings carefully before assembly. Check that all of the connections are tight and the product
does not wobble before using.
Model: CO-TA-I4078B-BRU-TOP
Model: CO-TA-I4260B 42 x42-60" BFLY Table TOP
Model: CO-TA-I4260B 42 x42-60" BFLY Table BASE
Figure 1
Figure 2
Please remove 2pcs metal brackets secured the slides to the
bottom of the top before the next step. (Figure 2)
Step 4. Place the open table top over the pedestal and align the
holes in the table mounting boards with the bolts on the pedestal.
Set the table down on the top of the pedestal. (Figure 3)
Step 5. Attach the pedestal to the mounting board as shown using
four Nuts, four Flat Washers and six Lock Washers. Tighten all nuts
firmly with the wrench provided. (Figure 3)
Step 6. Close the table top gently and latch all locks on the bottom
of the table top.
*Check that all legs are tight and the table does not wobble before
using.
Note: To extend the table, unlatch the locks on the bottom of the
table top. Pull the table top apart gently and place the leaves into the
open table top. Latch all locks on the bottom of the table top
Figure 3
