ASSEMBLY INSTRUCTION
Thank you for purchasing this quality product. Be sure to check all packing material carefully for small parts which may have
come loose inside the carton during shipment. Identify and count all parts and compare with the parts list below.
Please keep all hardware out of reach of small children.
ASSEMBLY TIPS:
1.Remove hardware from box and sort by size.
2.Please check to see that all hardware and parts are present prior start of assembly.
3.Please follow attached instructions in the same sequence as numbered to assure fast and easy assembly.
1.Don't attempt to repair or modify parts that are broken or defective. Please contact the store immediately.
2.This product is for home use only and not intended for commercial establishments.
WARNING!
MADE IN VIETNAMPAGE 1 OF 2
DESCRIPTION : KING / CAL KING PANEL BED
ITEM NO: EB-BR-4160K-WSN-HB
C D E F G
J K L
5 6 7
H
8 9 10 11
STEP 1
EB-BR-4160KS-WSN-FB
EB-BR-4160QK-WSN-RS
1
5
4
11
1
4
5
2
D
B
KD LEG- LEFT
1 PC
KD LEG- RIGHT
1 PC
SUPPORT RAIL
1 PC
FOOTBOARD
1 PC
Q/K SIDE RAIL
2 PCS
CK SIDE RAIL
2 PCS
SLAT ( A )
4 PCS
CENTER LEG
8 PCS
CONCEAL PANEL ( A )
2 PCS
CONCEAL PANEL ( B )
2 PCS
1 2 3
4
BOLT 1/4" x 57MM
8 PCS
BOLT 1/4" x 38MM
4 PCS
BOLT 5/16" x 90MM
8 PCS
SPRING WASHER 1/4"
12 PCS
FLAT WASHER
1/4" x 18mm
12 PCS
CURVED WASHER
8 PCS
SPRING WASHER 5/16"
8 PCS
HEX NUT 5/16"
8 PCS
WOOD SCREW
8 x 25MM
16 PCS
WRENCH
1 PC
ALLEN KEY M4
1 PC
I
SLAT ( B )
1 PC
EB-BR-4160CK-WSN-RS

COMPLETE ASSEMBLY
STEP 2
ASSEMBLY TIPS:
1.Remove hardware from box and sort by size.
2.Please check to see that all hardware and parts are present prior start of assembly.
3.Please follow attached instructions in the same sequence as numbered to assure fast and easy assembly.
1.Don't attempt to repair or modify parts that are broken or defective. Please contact the store immediately.
2.This product is for home use only and not intended for commercial establishments.
WARNING!
MADE IN VIETNAMPAGE 2 OF 2
STEP 4
STEP 3
F
10
8
7
6
3
G
H
I
Screwdriver - Not provided
9
K
L
L
K
J
KING SIDE RAIL ASSEMBLY CAL KING SIDE RAIL ASSEMBLY
KING BED CAL KING BED
