The 9325 (Handheld Display) for strain bridge sensors, is a microprocessor based portable display
instrument. It is designed to interface with any full bridge sensor that has an output sensitivity of up to
480mV/V. Bridge resistances from 85 ohms upwards can be used with the 9325.
This module can either be used as a handheld device or with the addition of optional mounting
accessories, it can be attached to equipment, dashboards, walls, or desks.
Configuration and calibration of the 9325 is achieved using the free PC Toolkit software. limited
configuration and two-point calibration is available via the front panel keypad menu system.
User functions available on the 9325 include:
• Range Selection
• Display Hold/Freeze
• Gross/Net indication selection
• Peak Hold selection
• Trough Hold selection
• TEDS support
The 9325 is powered by two internal non-rechargeable AA alkaline batteries and can also be USB
powered.
Introduction / Overview
There are six calibration ranges available that can be individually calibrated for use with strain bridges
that do not have TEDS capability.
These ranges can be used for connecting to different strain bridges or for different sections of the
same strain bridge (Example: one for compression and one for tension). The ranges are user
selectable and independent of what is physically connected to the handheld.
The number of ranges available and the ability to switch between these ranges can all be controlled
when configuring the handheld.
Each of these ranges will remember settings that contribute to the user experience. Settings such as
selected units and tare values will be remembered and reused as each range is selected again.
In addition, there is also support for TEDS calibration tables in TEDS capable connected devices
where the calibration information is held in the connected sensor. The user experience settings will be
remembered for the last twenty connected TEDS sensors. There is an option to disable TEDS
support on a particular TEDS enabled sensor so the handheld calibration ranges can then be used
instead.
Key Concepts
Calibration Ranges
Interface Inc. www.interfaceforce.com
1
9325 Installation & User Manual 15-402

Calibrated Output = a.x0 + b.x1 + c.x2 + d.x3 + e.x4 + …
Advanced Flexible Multi-Point Calibration
The advanced calibration system for the six calibration ranges supports a very flexible calibrate-
return-calibrate model where a calibration range can be revisited at any time and individual points can
be added or deleted.
There is also no restriction on the order that calibration points can be added in terms of input value.
Points can be added in ascending, descending or random order of input magnitude.
A simple alternative to multi-point calibration is gain & offset, where the gain and offset values are
supplied by the user:
Calibrated Output = offset + gain X input
More flexible polynomial calibration is also supported where x is the m/V input and the coefficients a,
b, c, d, e, ... are supplied by the user:
Display Modes
Display modes determine what is visible on the LCD display and what actions are available from the
set of three soft keys (Keys whose functions are dynamic and will change depending on what mode is
being viewed and local conditions).
There are up to six available display modes that can be cycled through and selected from a library of
different scenarios when using the Toolkit software to configure the handheld.
These display modes are independent to whatever Calibration Range is currently selected.
Decimal Point Position and Resolution
Because the 9325 can handle so many engineering units out of the box and allow conversion
between suitable units the way it handles decimal point positions and resolution (For displays) needed
a complete overhaul compared to the original 9320.
On the original having only two calibration ranges (And no concept of engineering unit conversion),
each range had its own formatting settings for decimal points and resolution and these ranges were
very often used to deliver results from the same strain bridge sensor in two different engineering units.
The new 9325 has six calibration ranges available where each can automatically convert between the
calibrated units and any other unit the user wants to display the values in. Therefore, because each
calibration range can display a whole range of engineering units (Although this can be limited by the
user it still has that capability) setting the decimal position and resolution per range does not work
anymore. I.e. changing from grams to tonnes would be nonsensical if they both shared the setting for
1 decimal place for example. This is even worse for resolution settings when switching between kg
and lbs as the display would no longer count in increments suitable for both units.
So, the new 9325 now supports settings for both decimal point position on a per unit basis and
resolution on a per calibration range basis.
Out of the box the decimal point position for all units has a sensible default but these can easily be
changed using the keypad (until the user chooses to disable that feature) by long presses on the left
and right keys. When you are viewing a particular unit simply adjust with the keys and this setting will
be remembered any time that unit is selected in any calibration range or if a TEDs device is
connected showing that unit. Decimal places can be set from zero to seven.
Interface Inc. www.interfaceforce.com
2
9325 Installation & User Manual 15-402

The resolution is disabled by default, but this is fully adjustable using the Toolkit.
Resolution is stored against each Calibration Range (Or in the case of a TEDS device, per device)
and is set in the base calibrated units for that range.
For the chosen display units resolution snaps to the nearest appropriate 1,2 or 5 multiple in that unit.
i.e.( .0001, .001, .01, .1, 1, 10, 100, .0002, .002, .02, .2, 2, 20, 200, .0005, .005, .05, .5, 5, 50, 500.)
This selection works across all display modes
TEDS (Transducer Electronic Data Sheet)
"Plug and play sensor hardware and software make configuring a smart TEDS sensor as easy as
plugging a mouse into a PC. The technology has greatly improved efficiency and productivity by
completely eliminating manual sensor configuration."
Basic Concept
TEDS is at the heart of the universally accepted IEEE 1451.4 standard for delivering Plug and Play
capabilities to analogue measurement and test instruments. In essence, information in a Transducer
Electronic Data Sheet provides interfacing devices with the critical sensor calibration information in
order to perform accurate and precise measurements every time.
TEDS works in a similar way in which USB computer peripherals immediately work as they are
connected. TEDS enabled equipment maybe swapped and changed without recalibration, saving time
and money.
TEDS holds information such as a sensor manufacturer, model and serial numbers, and more
importantly all the calibration settings determined by the manufacturer.
How it Works
Plug and play is a data acquisition technology that can simplify the configuration of automated
measuring systems by making a sensor’s unique identification data available electronically. As
implemented according to IEEE 1451.4, data in the form of a transducer electronic data sheet (TEDS)
is burned on an electrically erasable programmable read-only memory (EEPROM) chip located on the
sensor, so when a properly adapted signal conditioner interrogates the sensor, it can interpret the self-
identification data. This technology provides a great benefit by eliminating the need for paper
calibration sheets. And because all sensors produced according to the standard will carry the same
basic identically formatted self-identification information, you will be able to mix and match sensors
and applicable signal conditioners across manufacturers.
Advantages
Plug and play sensors are revolutionizing measurement and automation. With Transducer Electronic
Data Sheets (TEDS), your data acquisition system can detect and automatically configure sensors.
This technology provides:
• Reduced configuration time by eliminating manual data entry
• Better sensor tracking by storing data sheets electronically
• Improved accuracy by providing detailed calibration information
• Simplified asset management by eliminating paper data sheets
• Reliable sensor location by identifying individual sensors electronically
Interface Inc. www.interfaceforce.com
3
9325 Installation & User Manual 15-402

9325 Specifics
All standard TEDS devices contain a basic 2-point calibration. TEDS devices can also optionally hold
more than one extended calibration table; template ID=40 (multi-point calibration) or template ID=41
(polynomial calibration). When you first connect a new TEDS device to the 9325 a message will be
displayed stating that a new TEDS device has been detected and that default settings have been
used.
The first detected, valid calibration table from the TEDS device will be selected.
The user can select an alternative calibration table from the menu or Toolkit and this selection will be
remembered and the table will be re-selected next time the device is plugged in.
The 9325 will remember the last twenty connected TEDS devices so will automatically select the most
recently used calibration table and will re-use the User Experience parameters such as Units and tare
values.
There is also an option to ignore TEDS on specific devices so that the 9325 Calibration Ranges can
be used instead of any Calibration Tables held in the connected TEDS device.
In this case the User Experience parameters will be used from the selected Calibration Range. i.e.
The device will act as if there is no TEDS chip until the user re-enables TEDS for this device. When a
TEDS disabled device is connected again it will automatically switch to the last used 9325 Calibration
Range.
Supported TEDS Hardware Devices
DS2431 and compatible devices
DS2433 and compatible devices
DS28EC20 and compatible devices
Note: A 4 Kbit (or larger) device is recommended where additional TEDS calibration templates are to
be included.
Extended TEDS Calibration Options
The 9325 supports up to five extended TEDS calibration tables in addition to the standard 2-point
calibration. These can be any combination of template ID=40 (multi-point calibration) or template
ID=41 (polynomial calibration). This could be used to provide multiple calibrations for the transducer,
for example high range, low range, tension & compression.
Typically, a TEDS-enabled transducer would be supplied with one additional calibration template.
The default behavior is to select the first calibration template, or the standard 2-point if a calibration
template is not found. The user can cycle between all the available calibrations unless this feature
has been restricted.
The TEDS standard allows very large or complex calibration templates to be defined. For practical
reasons the 9325 imposes restrictions on the size and complexity that is allowed.
Multi-Point Calibration (template ID=40)
• Maximum calibration points = 10
Polynomial Calibration (template ID=41)
• Maximum number of segments = 1
• Maximum number of coefficients = 10 (10th order polynomial)
Interface Inc. www.interfaceforce.com
4
9325 Installation & User Manual 15-402

Configuration Customization
Many actions and features of the 9325 can be hidden or disabled. If certain features mentioned in this
manual are not visible on your particular 9325 then these features have most likely been locked /
protected by your supplier.
The flexible configuration customization offered by the handheld in conjunction with the toolkit is a
unique and powerful way to tailor the device to individual requirements.
• User calibration can be locked down in its entirety and be inaccessible without the password
or, using Configuration, only specific calibration ranges may be made available for re-calibration using
the toolkit.
• The availability of calibration ranges, display modes, menu items and other features can be
configured to simply limit the available options to a purely handheld user. The Configuration is left
open so that the handheld can be freely configured again using the toolkit whenever required by
anyone.
• The new ‘personality’ designed using the configuration settings can also be protected behind
a password so that the handheld cannot be reconfigured or re-calibrated by anyone with a toolkit,
unless they know the password. This includes restoring saved settings to a handheld. i.e. the
protected configuration is locked permanently and cannot be changed by anyone without the
password.
• These options allow you to define how the handheld acts and then lock it down to enable
redistribution as a specific device for a specific task knowing that this configuration cannot be
tampered with.
Note: Interface takes the security of protected devices very seriously. Nobody will be able to unlock
any of your protected calibration or configuration without your original password. A forgotten password
cannot be recovered, but the protected sections can be unprotected again. This will involve contacting
your supplier as Interface will need to verify that you have the rights to the protected data. There will
be a charge for this service.
MAKE SURE YOU RECORD ANY APPLIED PASSWORDS!
Interface Inc. www.interfaceforce.com
5
9325 Installation & User Manual 15-402

The following diagram shows how values and flags are generated. This entire block is processed at
the Measurement Rate selected. Some processes (such as the calibration and linearization) are only
shown as a single block due to their complexity.
Measurement Block
Interface Inc. www.interfaceforce.com
6
9325 Installation & User Manual 15-402

User Operation
Keypad
The keypad has some functionality that is fixed, some that can be configured and some that changes
depending on what is on the LCD display. The handheld can optionally sound a beep when keys are
pressed.
The top right key doubles as the power key. Hold this
for approximately two seconds to turn on or off the
handheld.
The three keys along the top of the keypad are soft
keys and relate to the three descriptions shown directly
above them on the LCD display. The action of these
keys will depend on what is currently being viewed.
The navigation keys are used for various purposes
such as selecting the current calibration range,
selecting the current display, navigating the menu
system or editing string and numeric values.
The OK key is used to open the menu (If that has been
allowed in the configuration) and to select menu items
and complete editing sessions.
Later we will explain how to use the keys to navigate
the menu system.
When not in a menu the Up/Down keys can perform
one of a few user definable functions, but the default is
to cycle through all available calibration ranges.
If a TEDS device is attached, then these keys will cycle
through any valid Calibration Tables held in the device.
If there is no TEDS device (or manual override for that
particular TEDS device has been set), then the keys
will cycle through the internal device Calibration
Ranges.In both the menu and the toolkit, the user may
also select an action for a long press. A long press is
where the key is held down for over a second before
being released.
Interface Inc. www.interfaceforce.com
7
9325 Installation & User Manual 15-402

When not in a menu the Left/Right keys can perform
one of a few user definable functions, but the default is
to cycle through all available display modes.
In both the menu and the toolkit, the user may also
select an action for a long press. A long press is where
the key is held down for over a second before being
released.
The OK key is used to open the menu (If that has been
allowed in the configuration) and to select menu items
and complete editing sessions.
The OK key can also be held down for a long press
(Approx one second then released) to cancel any
current editing of values and data.
Interface Inc. www.interfaceforce.com
8
9325 Installation & User Manual 15-402

Display
The 9325 has a monochrome dot matrix backlit display. The display may change depending on the
display mode, However the basic operation and positions of items should remain intuitive.
The example shown below allows up to three values to be displayed, where one is a large primary
value and two are secondary values.
The values for the main, secondary and tertiary items are not indicated on the above diagram to
improve clarity. Other modes such as the menu or editing values will be shown in the appropriate
sections of the manual.
Default Display Modes
The handheld comes with a set of default Display Modes but the user can swap them for up to six
available from a library contained in the Toolkit. The library of Display Modes will grow with new
releases of the Toolkit or may be available for download from our web site.
Simple Mode
Used when you only want a simple single displayed value.
The current calibration range is displayed top right and Gross or Net is displayed above the main
value. Current units are displayed above right of the main value.
Soft keys allow you to select from alternative units and to switch between Gross and a zeroed Net
value. The state of Gross or Net is displayed above the main value to the left.
Interface Inc. www.interfaceforce.com
9
9325 Installation & User Manual 15-402

Cumulative Zeroing
Similar to simple mode, but has the advantage of being continuously able to zero the main display
while still viewing the Gross value.
The Gross value and value of Tare are continuously displayed under the main value.
Soft keys allow you to Zero the main display, switch back to full Gross value or change displayed
units.
Hold
This mode allows you to Hold the main display by using a soft key, while still seeing the Live value
underneath.
The other soft keys allow for the ability to Zero the main display or go back to displaying Gross.
As usual, there is a soft key to allow for Units to be selected.
Min/Max
This display shows the min and max values underneath the large normal value display.
Soft keys allow you to toggle between Zeroed and Gross values as well as Reset the min and
max to the current value. Units selection is also available.
Interface Inc. www.interfaceforce.com
10
9325 Installation & User Manual 15-402

Delta
Similar to Min / Max above, but this mode allows you to focus on the change in value, or noise.
The display shows the Delta (Difference between Min and Max values) as the main value, while
the min and max are displayed underneath.
Soft keys allow the min and max to be Reset to the current value. i.e. zero the Delta. The usual
Units selection is also available.
Go/No Go
This is a very handy display mode for use in conjunction with the Alarm Limits values. The display
simply shows PASS when the value is between those limits and FAIL if the value is outside those
limits.
The High limit, Low limit and actual Value are displayed underneath. Soft keys allow for toggling
between Zero and Gross and the Units can be selected.
Note: As there is only one global alarm that is set in the base units of the currently selected
calibration range, you must ensure that the correct calibration range is selected and that the Alarm
Latch is not active!
Interface Inc. www.interfaceforce.com
11
9325 Installation & User Manual 15-402

Icons
The set of icons displayed along the top left of the display are common to all display modes and have
the following meanings.
A warning is detected. Further
investigation of the warning may be
required either via the keypad or
software. Also displayed when alarm is
triggered.
Battery is low.
The keypad has been locked because
some critical processes are being
performed by the Toolkit or other
software.
The measurement system is operating in
4- wire mode instead of 6-wire mode.
(This feature is only available in certain
versions and is not available to change
by the user.)
The main display is showing the Net
value because a Tare has been
executed.
The temperature is now too low to
operate the LCD at its normal update
rate. A slower update rate has been
applied. Note that internal measurement
(such as peak detection) will not be
affected.
External USB power has been applied.
Shunt Calibration mode is in operation.
The Scale Steady functionality is active
but the reading is not steady.
A TEDs device is detected as being
connected.
The TEDs device is using an internal
calibration range rather that its own
calibration table.
Interface Inc. www.interfaceforce.com
12
9325 Installation & User Manual 15-402

Full Screen Messages
Some errors may be so severe that the value displayed cannot be trusted. In these cases a full
screen message is displayed which will obscure the value displays to ensure that a potentially
invalid value is not acted upon.
Message Reason
Input High The mV/V input exceeds the upper limit for the selected
sensitivity range of the current calibration range.
Input Low The mV/V input is below the lower limit for the selected
sensitivity range of the current calibration range.
Overload The input value exceeds the user level set as overload.
Underload The input value is below the user level set as underload.
TEDS Disconnected
Session Restored
A TEDs device has been disconnected so the handheld is
reverting to the last selected calibration range. (Click OK)
Multiple TEDS
Are Not Supported
More than one TEDs device has been detected and this is not
allowed.
New TEDS Device
Use Session Defaults
A new TEDs device has been detected so default values will be
used for all settings not held in the TEDs device itself.
Known TEDS Device
Session Restored
A TEDs device has been reconnected so all the user settings
from the previous session will be applied. (Click OK)
TEDS Error
Code 0x0000
An error has been detected in the connected TEDs device. See
displayed error code and refer to the error code table in this
manual.
Battery Too Low
Replace Immediately
Battery is too low to start the handheld.
Note: Because the keypad gets locked during toolkit configuration, avoid swapping TEDS
devices while connected to the toolkit, as you will not be able to dismiss any full screen
messages that may appear.
Interface Inc. www.interfaceforce.com
13
9325 Installation & User Manual 15-402

Menu
Menu Basics
The menu is accessed by holding the OK key for around one second. It is possible to lock out the
menu system, so if your handheld does not display a menu it may be that your supplier has locked
this feature. Individual features may also have been hidden by your supplier.
The currently selected menu item is displayed on a dark background and this selection can be
changed by using the up and down keys. Pressing OK will select that item and can either:
• Perform an action (Such as increasing LCD contrast)
• Edit a value (Such as editing an alarm level value)
• Display the items sub menu (Indicated by a following > symbol)
The menu system is a standard hierarchal one but does have some visual clues to help you
navigate.
• If a menu item leads to a sub menu (Another list of items) it will display a ► to the right.
• If a menu item is part of a list where only one item can be selected at a time then the
current active selection is indicated by a leading dot ● to the left. All items that this can apply to are
shown as a ● below for clarity.
• Some items will lead to a displayed value or text which may be edited. See the next
section regarding Editing Values, where this is described. These items are shown with a following
●●● for clarity.
Menu Structure
Menu
System►
Display
Contrast►
Increase
Decrease
Backlight►
Increase
Decrease
Mode►
●Off
●On
●Auto
Menu is activated by holding the OK key for 1 second.
System Menu contains settings for display,user interface and
other system wide settings.
Display handles display and backlight settings.
Contrast allows the LCD contrast to be configured.
Increase instantly increases LCD contrast.
Decrease instantly decreases LCD contrast.
Backlight allows the backlight settings to be configured.
Increase instantly increases brightness.
Decrease instantly decreases brightness.
Mode allows the backlight operation mode to be configured.
Off backlight is always off.
On backlight is always on.
Auto backlight is on, but will turn off after a certain duration when
no keys are pressed. Any key press will turn the backlight on
again.
Interface Inc. www.interfaceforce.com
14
9325 Installation & User Manual 15-402

Duration sets the time after which the backlight will turn off when
Backlight Mode is set to Auto.
Auto-Off Controls whether the handheld turns itself off after a
duration without any key presses.
Mode Select Auto Off mode of operation.
Disabled will disable Auto Off.
Enabled will enable Auto Off.
Timeout display and edit the duration before the handheld turns
off without a key press when Auto Off is enabled. (Only visible
when mode is enabled.)
User Interface allows changes to be made to the way the user
interface behaves.
Key Actions choose what feedback occurs when a valid key
press is detected.
None no feedback.
Beep the sounder will issue a beep.
Keys Up/Down choose the action when the up and down keys
are pressed (When not in the menu).
Range Selection select the next Calibration Range (Only for
non TEDS devices).
Display Selection select the next Display Mode.
Decimal Places increase or decrease the number of decimal
places displayed for all displayed values using the same units as
the main display.
Disabled no action.
Keys Left/Right choose the action when the left and right keys
are pressed (When not in the menu).
Range Selection select the next Calibration Range (Only for
non TEDS devices).
Display Selection select the next Display Mode.
Decimal Places increase or decrease the number of decimal
places displayed for all displayed values using the same units as
the main display.
Disabled no action.
Long Up/Down choose the action when the up and down keys
are pressed and released after around one second (When not in
the menu).
Range Selection select the next Calibration Range (Only for
non TEDS devices).
Display Selection select the next Display Mode.
Decimal Places increase or decrease the number of decimal
places displayed for all displayed values using the same units as
the main display.
Disabled no action.
Long Left/Right choose the action when the left and right keys
are pressed and released after around one second (When not in
the menu).
None no action.
Range Selection select the next Calibration Range (Only for
non TEDS devices).
Display Selection select the next Display Mode.
Decimal Places increase or decrease the number of decimal
places displayed for all displayed values using the same units as
the main display.
Duration●●●
Auto-Off►
Mode►
●Disabled
●Enabled
Timeout●●●
User Interface►
Key Actions►
●None
●Beep
Keys Up/Down►
●Range Selection
●Display Selection
●Decimal Places
●Disabled
Keys Left/Right►
●Range Selection
●Display Selection
●Decimal Places
●Disabled
Long Up/Down►
●Range Selection
●Display Selection
●Decimal Places
●Disabled
Long Left/Right►
●None
●Range Selection
●Display Selection
●Decimal Places
Interface Inc. www.interfaceforce.com
15
9325 Installation & User Manual 15-402

Time & Date allows setting of time and date.
Time Now display time and date.
Set Date display and edit the date.
Set Time display and edit the time.
Date Format choose the format for displayed dates.
About displays information about this product.
Alarm configure settings for the global alarm.
Alarm Cancel only appears when a latched alarm state is
present. Click to retry alarm state.
Alarm Source select the source value the alarm is based on.
Gross base Alarm on Gross value.
Net base Alarm on Net value.
Alarm Mode select the alarm mode.
Normal Alarm only active while value matches trigger criteria.
Latched Alarm remains active until reset is triggered.
Alarm Thresholds set the alarm low and high thresholds.
Alarm Low edit Low Alarm value.
Alarm High edit High Alarm value.
Alarm Trigger select how the alarm is triggered.
Disabled the Alarm is disabled.
Outside Limits Alarm is triggered when the source value is
below the Alarm Low level or above the Alarm High Level.
Inside Limits Alarm is triggered when the source value is higher
than the Alarm Low level and lower than the Alarm High Level.
Above High Alarm is triggered when the source value is above
the Alarm High level.
Below High Alarm is triggered when the source value is below
the Alarm High level.
Above Low Alarm is triggered when the source value is above
the Alarm Low level.
Below Low Alarm is triggered when the source value is below
the Alarm Low level.
Alarm Action select actions to occur when Alarm is triggered.
None no action. (Will still trigger warning icon and Pass/Fail
Display Mode will still operate)
Beep play beep sound.
Flash flashes the main display.
Both play beep sound and flash the main display.
Measurement allows configuration of the various measurement
settings.
Measurement Rate select the required Measurement Rate at
which new values will be generated. The faster the rate the more
this affects battery life. (SPS = Samples Per Second)
One per second.
Three per second.
Ten per second.
Fifty per second.
Time & Date►
Time Now●●●
Set Date●●●
Set Time●●●
Date Format►
●YYYY/MM/DD
●DD/MM/YYYY
●MM/DD/YYYY
About►
Alarm►
**Alarm Cancel**
Alarm Source►
●Gross
●Net
Alarm Mode►
●Normal
●Latched
Alarm Thresholds►
●Alarm Low●●●
●Alarm High●●●
Alarm Trigger►
●Disabled
●Outside Limits
●Inside Limits
●Above High
●Below High
●Above Low
●Below Low
Alarm Action►
●None
●Beep
●Flash
●Both
Measurement►
Measurement Rate►
●1 SPS
●3 SPS
●10 SPS
●50 SPS
Interface Inc. www.interfaceforce.com
16
9325 Installation & User Manual 15-402

One hundred per second.
One thousand two hundred per second.
Two thousand four hundred per second.
Measurement Quality select the desired quality. This will affect
the noise free resolution and battery life.
Low lowest quality.
High high quality.
Current Range configure the System Zero options
System Zero configure the System Zero options
View/Edit Zero display and edit the current Zero value
Zero Now perform a System Zero now.
Remove Zero remove any existing System Zero value.
Tare Value configure the Tare options.
View/Edit Tare display and edit the current Tare value.
Tare Now perform a Tare now.
Remove Tare remove any existing Tare value.
Scale Steady configure the Scale Steady values.
Band display and edit the Scale Steady ± band.
Interval display and edit the time interval over which the value
must be within the band to constitute Scale Steady.
Set Zero Mask display and edit the Zero Mask value. This is
entered in base calibrated units for this range and when the
value is less than this level a zero will be displayed.
Set Resolution display and edit the Resolution value in base
calibrated units for this range. The display will change in
increments of this value.
Set Min Limit display and edit the Minimum user level in base
units for this range. When the value falls below this a full screen
"Underrange" message will be displayed.
Set Max Limit display and edit the Maximum user level in base
units for this range. When the value falls below this a full screen
"Overrange" message will be displayed.
Calibration Alarm is triggered when the source value is below
Calibration Info shows information about the currently selected
calibration range. Information: Name, Mode, Units, Type and last
calibration date.
User Calibration only available when no active TEDS device is
attached.
Range Name only available when no active TEDS device is
attached.
Range 1-6 select a Calibration Range item to display and edit its
text description. Some Calibration Ranges may not be available.
Select Range only available when no active TEDS device is
attached.This allows you to select the current Calibration Range
to use. Some ranges may not be available.
Range 1 select Calibration Range 1.
Range 2 select Calibration Range 2.
Range 3 select Calibration Range 3.
Range 4 select Calibration Range 4.
●100 SPS
●1200 SPS
●2400 SPS
Measurement Quality►
●Low
●High
Current Range►
System Zero►
View/Edit Zero●●●
Zero Now
Remove Zero
Tare Value►
View/Edit Tare●●●
Tare Now
Remove Tare
Scale Steady►
Band●●●
Interval●●●
Set Zero Mask●●●
Set Resolution●●●
Set Min Limit●●●
Set Max Limit●●●
Calibration►
Calibration Info►
User Calibration►
Range Name►
Range 1
Range 2
Range 3
Range 4
Range 5
Range 6
Select Range►
●Range 1
●Range 2
●Range 3
●Range 4
Interface Inc. www.interfaceforce.com
17
9325 Installation & User Manual 15-402
