Interlogix ACL800FL-RU2 User manual

© 2018 United Technologies Corporation. P/N 1073496A• REV 00.01 • ISS 4JUL18
Interlogix is part of UTC Climate, Controls & Security, a unit of United Technologies Corporation. All rights reserved.
ACL800FL-RU2 –Remote Relay Unit -
Installation Manual
Description / Operation
The ACL800FL-RU2 is remote relay control unit for
ACL870SU-BS and ACL870FL-BS biometric readers. If secure
installation is needed, the reader can be connected to this
remote relay unit located in a secured area. It has two relay
outputs and two RTE button inputs.
The connection between the reader and the remote relay unit
is done via RS485. Once the reader and the remote relay unit
are paired, the reader will only use the relays on the
ACL800FL-RU2.
The device is already preset for use with the biometric readers.
Specifications
Output
2 Relays (3 A at 24 VAC/VDC)
Push button input
2
Door time
Pulse (1 to 60 s) or Toggle
Buzzer ON/OFF
Yes (follows the reader buzzer)
Operating voltage
9 to 14 VDC
Current consumption
80 mA at 12 VDC max
Mounting
DIN Rail or wall mount
IP rating
IP31
Operating environment
Temperature
Relative humidity
0 to +40°C
noncondensing
PCB dimensions ( W x
H )
32 x 86 mm,
4 fixing holes Ø 3mm
Housing
DIN Rail or Wall mount, plastic, size 2 unit
Weight shipping
Weight product
120 g
50 g
Dimension
90 x 37 x 33 mm
Application Diagram
Figure 1: Application diagram
Secured Area
R485s (max. 50 m)
Outside
Reader

2 / 4 P/N 1073496A• REV 00.01 • ISS 4JUL18
Figure 2: Application diagram
Wiring
Figure 3: Terminal block description
Power supply (9 to 14 VDC)
Power supply to the reader
Push button inputs
RS485

P/N 1073496A• REV 00.01 • ISS 4JUL18 3 / 4
Wiring reader with remote relay RU2
Figure 4: Wiring
- Connect the door lock on the RU2 relay
- The reader and the ACL800FL-RU2 should be connected with 4 wires: +, -, A and B (RS485). Max. 50 m.
Pairing reader with ACL800FL-RU2
Figure 5: Pairing
1. Put the jumper to closed position. ACL800FL-RU2 beeps continuously and the red LED blinks.
2. Put the jumper to open position.
3. Wait for beep + OK beep (short + short + long beep)
After the OK beep, the coupling is done.
12 VDC
+
-
1N4007
+
-
R 2u
Violet
Pink
COMNO
A (RS485)
B (RS485) +12V
GND
GND
+12V
max. 50 m
Reader
12 VDC
+
-
1N4007
+
-
R 2u
Violet
Pink
COM
NO
A(RS485)
B (RS 485) +12V
GND
GND
+12V
Reader

4 / 4 P/N 1073496A• REV 00.01 • ISS 4JUL18
