Intermec NORAND 600 User manual

NORANDRR600 Series IndustrialMobileComputer
USER’SGUIDE
""""""""""""""""""""""""""""
PN:961-054-014
RevisionC
March2000

"NOTICETheinformationcontainedhereinisproprietaryandisprovidedsolelyforthe
purpose ofallowingcustomersto operateandserviceIntermecmanufactured
equipmentandisnot tobereleased,reproduced,orusedforanyotherpurpose
withoutwrittenpermissionofIntermec.
DisclaimerofWarranties.Thesamplesourcecodeincludedinthisdocumentis
presentedfor reference only.Thecodedoesnotnecessarilyrepresentcomplete,
tested programs.Thecodeisprovided“ASISWITHALL FAULTS.”ALL
WARRANTIESARE EXPRESSLY DISCLAIMED,INCLUDING THE
IMPLIEDWARRANTIESOFMERCHANTABILITY AND FITNESS FORA
PARTICULARPURPOSE.
Wewelcomeyour commentsconcerningthispublication.Althougheveryefforthas
beenmadetokeepitfree oferrors,somemayoccur.Whenreportingaspecific
problem,pleasedescribeitbrieflyandincludethebooktitleand partnumber,as
well astheparagraphorfigurenumberandthepagenumber.
Sendyour commentsto:
IntermecTechnologiesCorporation
PublicationsDepartment
550 SecondStreetSE
CedarRapids,IA52401
INTERMEC,NORAND,NOR*WARE,andPEN*KEYareregisteredtrademarks
ofIntermecTechnologiesCorporation.
Ó1999 IntermecTechnologiesCorporation.All rightsreserved.
Acknowledgments
MicrocleanII isaregisteredtrademarkofForesightInternational.
Microsoft,MS,andMS-DOS,Windows,Windows95 andWindowsCE are
registeredtrademarksofMicrosoftCorporation.
SanDiskisatrademarkofSanDiskCorporation.

NORANDR600 SeriesIndustrialMobileComputerUser’sGuide i
CONTENTS
""""""""""""""""""""""""""""
SECTION1
General Information
About thisUser’sGuide1-1..............................
IndustrialMobileComputerDescription1-2...............
ComputerKeyboard1-5..............................
Display1-6..........................................
Battery1-6..........................................
Memory1-7.........................................
[Gold]Key1-8.......................................
ON/OFF (SuspendandResume)Key1-9...............
SerialPort1-9.......................................
Resetting1-10........................................
CustomerResponseCenterandProductService1-10........
FactoryService1-10..................................
CRC (CustomerResponseCenter)1-11.................
Specifications1-12.......................................
SECTION2
Operation
GettingStarted2-1......................................
ChargingtheBattery2-2................................
InstallingCompactFlashCard(Models602 and603)2-4....
RemovingtheCompactFlashCard2-5....................
InstallingaModemCard2-6.............................
BootingYourComputer2-6..............................
ForDOSApplications2-6............................
ForWindowsCE Applications2-6.....................
InstallingWindowsCE Components2-7...............
RunningWindowsCE andtheDemoApplication2-9.......
DownloadingfromHostComputer2-9....................

CONTENTS
ii NORANDR600 SeriesIndustrialMobileComputerUser’sGuide
Opening yourApplication2-9............................
SECTION3
RoutineCare and Maintenance
LowBatteryIndication3-1...............................
CleaningYourComputer3-2.............................
CaseandDisplay3-2................................
SECTION4
Troubleshooting
TroubleshootingTable4-1................................
RelatedPublications4-3.................................
RepairService4-4.......................................
APPENDIXA
ConnectorPin-Outs
16-PinDockingConnectorA-1............................
APPENDIXB
NorandRR Utilities Program
EntryPointB-1.........................................
Pop-UpMenusB-1......................................
Drop-DownListsB-2....................................
AlphanumericFieldsB-3.................................
TitleScreenB-4.........................................
LanguageSelectionB-5..................................
CommunicationsMenu B-6...............................
Option1BEGINCOMM SESSIONB-7................
IfusingPSROM0C V2.xx:B-17........................
IfusingPSROM0C V3.xx:B-17........................
Option2COMM SETTINGB-18.......................
Option3UNITIDB-22................................
Option4NETWORKPARAMETERSB-22..............
Option4MODEMPARAMETERSB-24.................

CONTENTS
NORANDR600 SeriesIndustrialMobileComputerUser’sGuide iii
Option5NETWORKINTERFACE B-28................
Option5PHONENUMBER B-29......................
Option9ADVANCEDUTILITIESB-30.................
FIGURES
Figure1-1FrontandBackView1-3......................
Figure1-2Top,Bottom,andSideView1-4.................
Figure1-3 16-KeyKeyboard1-5..........................
Figure1-4CompactFlashCardSlot1-8...................
Figure1-5Resetting yourComputer1-10...................
Figure2-1ComputerBeingConnectedtoaWall
Charger2-2............................................
Figure2-2PowerStatusLED2-3.........................
Figure2-3AccessingtheCompactFlashCardSlot2-4......
Figure2-4RemovingCompactFlashCard2-5..............
TABLES
Table1-1GoldLegendKeypadFunctions1-8..............
Table4-1BasicTroubleshooting4-1.......................

CONTENTS
ivNORANDR600 SeriesIndustrialMobileComputerUser’sGuide

NORANDR600 SeriesIndustrialMobileComputerUser’sGuide 1-1
Section 1
General Information
""""""""""""""""""""""""""""
About thisUser’sGuide
Section 1
Containsgeneral informationabout thecomponentsofyour
600 SeriesIndustrialMobileComputer.Thisincludes
telling you howtheuserguideisorganized,asummaryof
thesections,andthespecifications.
Section 2
Tellsyou howtoprepareforusing your computer.
Section 3
Containsroutinemaintenanceinformationforyour
computer.Routinemaintenanceincludesrechargingthe
battery,andcleaningthecomputer.
Section 4
Takesyouthroughprocedurestousewhentroubleshooting
your computer.This sectiondoesnotcontainall
troubleshootingthatcanbedonebyanauthorized
CustomerSupportSpecialist,butdoescontaininformation

SECTION1GeneralInformation
1-2NORANDR600 SeriesIndustrialMobileComputerUser’sGuide
toaidyouindeterminingthelevelofassistanceyoumay
need.
AppendixA
Pin-outsforthe externalconnectors.
AppendixB
NORANDRUtilitiesProgram’swill beaddedatalater
date.
Glossary
Containsdefinitionstowordsorphrasesusedinthisuser’s
guide.
Index
Analphabeticallylistingofthesubjectsand pagenumbers
containedinthisuser’sguide.
IndustrialMobileComputerDescription
IndustrialMobileComputersareusedinthemarketplace
toperformawidevarietyoftasks.The600 Series
IndustrialMobileComputerprovidesfeaturesandbenefits
thatinclude:
"Rugged design
"Fastdataprocessing
"Touchscreendisplay
"Signaturecapture
Additionally,your computerhastheabilitytouse:

SECTION1GeneralInformation
NORANDR600 SeriesIndustrialMobileComputerUser’sGuide 1-3
"CompactFlashcards
"InternalmodemwithCompactFlashcardsizeandfor-
mat
Thefollowingdescriptionswill familiarizeyouwiththe
name,function,andlocationsofthecomponents.
Figure1-1,andFigure1-2,onpages1-3,and1-4,show
youthesekeycomponents.
Touchscreen
display
Keypad
Stylus
FrontBack
Power
status
Scanindicator
Figure 1-1
Frontand Back View

SECTION1GeneralInformation
1-4NORANDR600 SeriesIndustrialMobileComputerUser’sGuide
CompactFlash
cardslot
Models 602/603
Scannerlens
Models
602/603
Docking
connector
Figure 1-2
Top,Bottom,and SideView
Speaker
Charger
jack
Scroll down
key
Scroll up key
Scanner
button
Action key
Top End
BottomEnd
SideView

SECTION1GeneralInformation
NORANDR600 SeriesIndustrialMobileComputerUser’sGuide 1-5
ComputerKeyboard
ThisIndustrialMobileComputerprovidesa16key
keyboard.All keyswiththe exceptionofthe[I/O]and
[Gold]keysareprogrammableforindividualfunctions.
Figure1-3onpage1-5detailsthebasickeyboardlayout.
Figure 1-3
16-Key Keyboard
ENTER
Backlight
(Gold+3)
Numeric
keys
Esc (Escape)
Gold
BkSp(Back Space)
Tab
ON/OFF
(Suspend/Resume)

SECTION1GeneralInformation
1-6NORANDR600 SeriesIndustrialMobileComputerUser’sGuide
Display
ThisIndustrialMobileComputeroffersaneasytoread
LiquidCrystalDisplay(LCD)withtouchscreen.The
displayshows statusmessages,keyed-inentries,customer
orproductlists,calculations,and promptsfor responses.
Thetouchscreencanbeusedwithastylus,oryourfinger
tochoosefunctions,recordsignatures,orenterdata.
AdjustContrast
Toadjust thedisplaycontrastlevel,hold downthe[Gold]
keyand press eithertoincreasetodecrease.
Backlight (Models 602 and 603)
YourIndustrialMobileComputerdisplayfeaturesa
backlight.Backlightingprovidesagreatbenefitindark
conditions.Backlightingdoes,however,reducebatterylife,
therefore,turnoff thebacklightwhen notneeded.
BacklightOn/Off
Toturnthebacklighton,hold downthe[Gold]keyand
press thekey.Toturnthebacklightoff,hold down
the[Gold]and press thekeyagain.
Battery
"NOTE:It isimportant tocharge yourIndustrialMobileComputerforatleast
4 hoursbeforeyou useit the first time.
ThisIndustrialMobileComputerusesa 1550 mAhlithium
ionrechargeablebattery.
Ifyour computergoesintoashutdownmodebecause oflow
batterycondition,your computerwill notoperate.Your
computerdoesthisto ensurethat thedataisprotected.

SECTION1GeneralInformation
NORANDR600 SeriesIndustrialMobileComputerUser’sGuide 1-7
Althoughthebatterywill protect thedata againstloss for
upto72 hours,itisbest toputyourunitonacharging
sourcewhenyoufirstdetectlowbattery.
Memory
Three typesofmemoryareavailablewiththisIndustrial
MobileComputer:
"MainMemoryDRAM
"FlashROM
"CompactFlashCards(Models602 and603)
MainMemory
StandardmainmemoryDRAM configurationis8
megabytes(MB) forthemodel601 and16 MBfor Models
602 and603.Memoryandtherealtimeclockisprotected
upto72 hoursby your computershuttingdownoperation
afterdetectinglowbattery.
FlashROM
The512KFlashROMstorestheBIOS.
CompactFlashCards
YourIndustrialMobileComputeremploysaninternalcard
slot.TheinternalslotisaCompactFlashTypeIstorage
device.Thisdeviceactsasthebootdriveforthesystem.
ThisCompactFlashcardisnotexternallyaccessible.
Additionally,Models602 and603 provideanexternalcard
slot.The externalslotisanexpansionTypeII slot.This
TypeII slotisaccessibleat thetopofthecomputer.Itcan
beusedforanadditionalCompactFlashstoragecard,ora
CompactFlashmodem.Amodemcardmustprovidethe
RJ-11 jack.However,sincepartofthemodem(because of
theRJ-11)extendsbeyondthetopoftheunititbecomes
vulnerabletobreakageifdropped.

SECTION1GeneralInformation
1-8NORANDR600 SeriesIndustrialMobileComputerUser’sGuide
Figure 1-4
CompactFlashCardSlot
Cardslot
[Gold]Key
Hold downand press desiredgoldkeyfunctions.Continue
tohold downthe[Gold]keyforeachgoldlegendkeystroke
youwishtomake.
Gold Legend Keypad Functions
Holdingdownthe[Gold]Keyandthenagoldlegendkey
allowsadditionalkeypadfunctions.Thesefunctionsare
describedinTable1-1onpage1-8.
Table1-1
Gold Legend Keypad Functions
Gold+IconResult
1Increasesdisplayscreencontrast
2Decreasesdisplayscreencontrast
3TogglesBacklightonandoff
TabHome
4PgUpPageUp
5YUparrow

SECTION1GeneralInformation
NORANDR600 SeriesIndustrialMobileComputerUser’sGuide 1-9
Table1-1(continued)
Gold Legend Keypad Functions
Gold+ResultIcon
6PgDnPageDown
DEL.(period)
7ALeftarrow
8BDownarrow
9"Rightarrow
ESCAlt
0Ctrl(control)
EnterEnd
ON/OFF (Suspend and Resume)
Key
InordertoconservepoweryourIndustrialMobile
Computermayautomaticallysuspendwhentherehasbeen
noactivityforasetperiodoftime.Thesuspendtimecanbe
programmedthroughthesetup parametersforyour
computer.
Toforceasuspend,press the[I/O]key,orakeythat maybe
definedasthesuspendkey,andholdthekeydownforthree
seconds.Toresume operation,press the[I/O]key.
SerialPort
Your computer canaccess serialdevicesthroughthedock’s
RS-232 serialport,usingone oftheseaccessories:
"Aserialcableplugsintoandlatchestothedocking
connectorand providesastandardPCcompatible
DB-9(male)serialport.
"Adatasychronouscableplugsintoandlatchestothe
dockingconnectorand providesaDB-9(female)which
canbepluggedintoastandardPCserialport.

SECTION1GeneralInformation
1-10 NORANDR600 SeriesIndustrialMobileComputerUser’sGuide
"The600 SeriesSingle/VehicleDockprovidesastan-
dardPCcompatibleDB-9(male)serialport.
"The600 SeriesMultidockconvertsthesignalsfrom
thecomputer’sRS-232 serialport toRS-485 and
bringsoutanRS-485 bustotwoDB-9femaleconnec-
torscompatiblewithNorandRS-485 networking.
Resetting
Intherare event thatyourIndustrialMobileComputer
failstorespondtoyourinput,it maybenecessaryto
“reset.”Toresetpress the[Gold],[Esc],and[0]keysat the
sametime,holdthekeysdownforthree seconds,andyour
computerwill reboot.Resettingtakesyoutothestartup
screen.
Figure 1-5
Resetting yourComputer
Resetkeys
CustomerResponse Centerand Product
Service
FactoryService
Ifyourunitisfaulty,youcanshipit toyournearest
authorizedServiceCenterforfactory-qualityservice.The
address andtelephonenumberareincludedontheProduct
ServiceInformationCardshippedwithyourproduct.

SECTION1GeneralInformation
NORANDR600 SeriesIndustrialMobileComputerUser’sGuide 1-11
CRC (CustomerResponse Center)
TheNorandMobileSystemsDivisionofIntermec
TechnologiesCorporationCRC (technicalsupport),
telephonenumber:1-800-755-5505 (USAorCanada)or
1-425-356-1799.
Email:[email protected] Ifyouwant toEmail a problem
orquestiontotheCRCbe sure toincludethefollowing
informationinyourmessage:
Yourname
Thecompanyname
Thecompanyaddress
PhonenumberandEmail address whereyouorthe
customer canbecontacted
Problemdescriptionorquestions(bespecific)
Alsoifthe equipmentwaspurchasedthroughaVAR please
includetheVAR information

SECTION1GeneralInformation
1-12 NORANDR600 SeriesIndustrialMobileComputerUser’sGuide
Specifications
Size:9.1cm(3.6inches)wide
15.5cm(6.1inches)long
3.0cm(1.2inches)tall
Temperature:
RecommendedOperating:0to+50_C(32 to+122_F)
ExtremeOperating:--20 to+60_C(--4to+140_F)
StorageTemperature:--20 to+60_C(--4to+140_F)
Weight:312 g(11 ounces.)
Humidity:5to95%noncondensing
StaticProtection:17 kV(airdischarge)8kV(currentinjection)
Battery:3.8V,1550 mAhlithiumionbattery
HoursofOperation:8--10 hours
ChargingTemperature:0to+50_C(32 to+122_F)
Communication:
Interface:RS-232,RS-485,Ethernet10BASE-T(through
Dock)
Protocol:NorandProprietaryCommunicationsProtocol
(NPCP)
SystemComponents:
FLASH:512KFLASHarray(standard)
RAM:8Megabytes(601)16 MB(602/603)
OperatingSystem:MS--DOS,WindowsCE,and
Windows95 (future)
CardOptions:CompactFlashTypeII
Display:953 cm(3.75 inches);240 (wide)320 (long)
pixels,monochromeLCD

NORANDR600 SeriesIndustrialMobileComputerUser’sGuide 2-1
Section 2
Operation
""""""""""""""""""""""""""""
This sectiontellsyou howto:
"Chargethebattery
"“Power-up”your600 SeriesIndustrialMobile
Computer
"Install CompactFlashcards
Getting Started
Unpackyour600 SeriesIndustrialMobileComputerand
inspectitforsignsofphysicaldamagefromshipmentor
storage.
Whenyoustartusing your computeroranytimethatall
powerhasbeencompletelyremoved,youare“coldbooting”
it.Themethodyou usedependsonyourapplication.
Forexampleyoumaydownloadtheapplicationand data
intoyour computer. Or,youmayuseCompactFlashcardsto
loadtheapplicationand data.
Dependingonthemethodyouareusing,theresultwill be
thesamebut thestepsyougothroughmay varyfrom the
waythisuser’sguidepresentsthematerial.

SECTION2Operation
2-2NORANDR600 SeriesIndustrialMobileComputerUser’sGuide
Charging theBattery
Charging yourbatterypackcanbedone eitherinadockor
usinganacwall charger connectedtoyour computer.
Figure2-1onpage2-2showsyour computerbeing
connectedtoanac charger.Figure2-2onpage2-3shows
thecomputerandexplainsthePowerStatusconditionsthat
youmightsee duringthechargingprocess.
Normaltimetorechargeyourbatterypackisfourhours.
Whenyourbatteryisfullychargedyour computershould
run about8--10 hours.
Figure 2-1
ComputerBeing ConnectedtoaWall Charger
12
Thefollowingdeviceschargethebatterywhenseatedin
theunit.
"Single/Vehicledock
"Multidock
