IB Pulse
Contents
1 – Introduction 3
Description 3
Personal Precautions 3
Testing Out-of-Vehicle 3
Testing In-Vehicle 3
Connecting To A Battery 3
Symbols Conventions 3
Wi-Fi Hub 4
Included Components 4
Connections 4
Wi-Fi Hub Location 4
Wi-Fi Hub Installation 5
Wi-Fi Hub Troubleshooting 5
IB Pulse 6
Front 6
Back 6
Navigation 6
Initial IB Pulse Power Up 6
Setting User Preferences 7
Charging Dock 8
Front 8
Side 8
Charging Dock Mounting (Optional) 8
2 – VIN Scan In Vehicle Testing 9
Inspecting the Battery 9
Battery Test 9
Battery Test Results 11
Battery Decisions 11
System Test 12
System Test Results 12
Cranking Health Decisions 13
Charging Health Decisions 13
Battery Replacement 13
Reset 13
Lookup Replacement 13
3 – Out Of Vehicle Test 14
Battery Test 14
Battery Test Decisions 14
Battery Test Results 15
4 – Menu 16
Settings 16
Wi-Fi 16
Adding A Wi-Fi Network 16
Deleting A Wi-Fi Network 16
Email 16
Auto Email 16
Add Email Address 16
Edit Email Address 16
Deleting An Email Address 16
Favorites 16
Printers 17
Auto Print 17
Add Printer 17
Deleting A Printer 17
Default Printer 17
Languages 17
System Language 17
Test Result Language 17
Email Language 17
Print Language 17
Display 18
Brightness 18
Auto Brightness 18
Sleep Time 18
Dim Time 18
Shop Info 18
Users 18
Add User 18
Editing A User 18
Deleting A User 18
Date Time 19
Select Time Format 19
Select Date Format 19
Select Time Zone 19
Set Date 19
Set Time 19
Test Settings 19
Temperature Units 19
Default Test Mode 19
Create MDCA Log File 19
Software Update 19
Relocation Mode (Admin Only) 19
About 20
Tester Software Version 20
Promotions 20
Promotion Samples 20
Appendix 21
Battery Information Screen Descriptions 21
Scanning Tips 21
Wi-Fi Printer Setup/Troubleshooting 22
Product Specications 23
IB Pulse 23

3
1 – IntroductionIB Pulse
Description
The IB Pulse provides a complete analysis of 12-volt and 6-volt
vehicle batteries and 12-volt and 24-Volt starting/charging
systems. Using patented conductance technology, the IB
Pulse will display battery condition (Good, Replace, Good-
Recheck Soon, etc.) as well as voltage and available cranking
power based on the temperature of the battery. The IB Pulse
can perform battery tests on Automobile, Group 31 , Lawn &
Garden, Marine, Powersports and Commercial 4D/8D batteries.
The IB Pulse integrates the in-vehicle battery test along with the
starting and charging system test. The charging system analysis
takes multiple measurements while the charging system is
exercised under varying conditions to determine if it can charge
the battery while supplying the necessary power for the electrical
system. Test results can be displayed on the full-color screen,
printed, or via email.
Personal Precautions
Risk of explosive gases.
Never smoke or allow a spark or ame
in the vicinity of a battery.
Batteries can produce a highly explosive
mix of hydrogen gas and oxygen, even
when the battery is not in operation.
Always work in a well-ventilated area.
PROPOSITION 65 WARNING: Battery posts, terminals
and related accessories contain lead and lead com-
pounds, chemicals known to the state of California to
cause cancer and reproductive harm. Batteries also
contain other chemicals known to the state of California
to cause cancer. Wash hands after handling.
Inspect the battery for damage and check the electrolyte
level. If the electrolyte level is too low, replenish it and fully
charge the battery. Always use the necessary safety precautions
when working with batteries to prevent severe injury or death.
Follow all manufacturers’ instructions and BCI (Battery Council
International) safety recommendations, which include the
following precautions:
•Battery acid is highly corrosive. If acid enters your eyes, im-
mediately ush them thoroughly with cold running water for
at least 15 minutes and seek medical attention. If battery
acid gets on your skin or clothing, wash immediately with a
mixture of water and baking soda.
•Always wear proper safety glasses or face shield when work-
ing with or around batteries.
•Keep hair, hands, and clothing as well as the tester cords
and cables away from moving engine parts.
•Remove any jewelry or watches before you start servicing
the battery.
•Use caution when working with metallic tools to prevent
sparks or short circuits.
•Never lean over a battery when testing, charging, or jump
starting.
Testing Out-of-Vehicle
The preferred battery test location is in the vehicle. However
when testing out of the vehicle:
•Always disconnect the negative cable from the battery rst
and reconnect it last.
•Always use a carry tool or strap to lift and transport the battery.
Failure to properly install lead terminal adapters,
or using adapters that are dirty or worn, may cause
false test results.
When testing side-post or Group 31 batteries, always use
lead terminal adapters provided with the tester—do not
test at the battery’s steel bolts. To avoid damage, never
use a wrench to tighten the adapters more than ¼ turn.
Testing In-Vehicle
The preferred test position is at the battery posts. If you must
test at a remote-post location, it should have both a positive
and negative post. Otherwise, you must remove the battery and
perform an out-of-vehicle test.
At the start of the test, make sure all vehicle accessory loads are off,
the key is not in the ignition, and the doors are closed.
Connecting To A Battery
Do not connect the tester to a voltage source
greater than 30 Vdc.
Connect the clamps to the tester: the red clamp to the positive
(+) terminal and the black clamp to the negative (–) terminal.
If you connect the clamps in the wrong polarity (positive to
negative or negative to positive), the tester displays CLAMPS
REVERSED! Reconnect the clamps.
To make sure both sides of the clamps are gripping the
terminals, rock each clamp back and forth. A poor connection will
prevent testing, and the tester will display the message CHECK
CONNECTION. If the message reappears after you have correctly
reconnected the clamps, clean the terminals and reconnect.
Symbols Conventions
Symbol Description
The safety symbol with the words CAUTION, WARNING,
or DANGER indicates instructions for avoiding hazardous
conditions and personal injury.
The wrench symbol indicates procedural notes and
helpful information.
1 – Introduction

4
1 – Introduction IB Pulse
Wi-Fi Hub
The Wi-Fi Hub is required at every shop using an IB Pulse battery
tester. The Hub transmits its own Wi-Fi signal and easily connects
to existing Internet hardware devices. Once paired with an
IB Pulse, it automatically downloads local shop information;
transmits test data wirelessly to a printer or via email; and allows
IB Pulse software updates.
Included Components
•IB Pulse Wi-Fi Hub
•Four (4) Antennas
•10 ft Ethernet cable
•Power Supply
•Quick Start Guide
Connections
12V Power Supply: Utilize the power supply included with the Wi-
Fi Hub. Any other power supply can cause damage to the unit.
Reset Button: Push & release to reset the device. Push & hold
for 5 seconds, then release to install factory presets.
SIM Card Access: Slide the door to access the SIM holder.
Version 1
Version 2
LAN Port(s): NOT USED
WAN Port: Utilize the WAN port on the front of the Wi-Fi Hub
and connect the open WAN port on the existing shop router
using the supplied Ethernet cable. Solid Green indicates link
has been established with stores router, ashing green indicates
data is being transmitted.
RS-232 Port: NOT USED IN VERSION 2
USB Port: NOT USED IN VERSION 2
Antennas: The Hub includes easy to attach and adjust antennas
for maximum reception.
Mounting Holes: Use the mounting holes to attach the Wi-Fi
Hub to a wall or secure location.
NOTE: Screws not included.
Wi-Fi: Orange: Wi-Fi is connected / Off: No Wi-Fi
Power: Yellow: Power is connected / Off: unit is off
Signal Strength: Indicates the level of cellular signal.
• One (1) green bar: Signal is poor
• Five (5) green bars: Signal is very strong.
Wi-Fi Hub Location
•Select a central location: The Wi-Fi Hub communicates in all
directions. To optimize coverage, place the device in a cen-
tral location where the IB Pulse will be used. Avoid placing
in a closet or behind concrete walls.
•Raise the Hub: The Hub signal angles downward, so mount
the Wi-Fi Hub as high as possible to maximize coverage.
•Avoid other electronics: Select a location away from other
electronics and large metal objects.

5
1 – IntroductionIB Pulse
Wi-Fi Hub Troubleshooting
The following troubleshooting information is not inclusive and is meant as a guide only. Other issues and solutions may arise that
are not stated here. The following description of terms are provided for reference as used in the following troubleshooting chart.
Issue Probable Cause Remedy
No lights displaying on front of
Wi-Fi Hub Device is not connected to a power source
• Check power source connection
• If there is no LED activity, unplug the device and
wait several minutes before restarting
No red light, amber light on
Red light on, amber light off
No green lights displayed
Not connecting to the Internet
• Check Hub connection and setup
• Check Ethernet WAN connections
• Unplug the Wi-Fi Hub and wait several minutes
before restarting
Wi-Fi connection drops or disconnects
intermittently Wi-Fi signal strength insufcient
• Check Wi-Fi strength
• Ensure all antennas are securely attached
• Move Wi-Fi Hub to a more central location
• Move away from interference from metal objects
and walls
Cannot email battery test results IB Pulse is not connected to the Wi-Fi Hub
• Check Hub connection and setup
• Move closer to the Wi-Fi Hub
• Check Ethernet WAN connections
• Unplug the Wi-Fi Hub and wait several minutes
before restarting
• Delete the Wi-Fi Hub and then reconnect
Dealer/Shop information did not
download to IB Pulse IB Pulse is not connected to the Wi-Fi Hub
• Check Hub connection and setup
• Check Ethernet connections
• Unplug the Wi-Fi Hub and wait several minutes
before restarting
• Delete the Wi-Fi Hub and then reconnect
Software update doesn’t complete or
shows unavailable IB Pulse is not connected to the Wi-Fi Hub
• Check Hub connection and setup
• Ensure IB Pulse is charged at a minimum of 40%
• Place IB Pulse in charging dock during update
attempt
• Check Ethernet connections
• Unplug the Wi-Fi Hub and wait several minutes
before restarting
No Wi-Fi Hub listed in the Wi-Fi
section of the IB Pulse Wi-Fi Hub was never paired during setup
• Connect Wi-Fi Hub
• Go to Setting, then Wi-Fi and select the plus
“+” button
• Select available Hub listed in section. Displayed
in a HUB-xxxxxxxx format.
Wi-Fi Hub Installation
1. Hand-tighten the four antennas. For best coverage, posi-
tion the antennas at a 45-degree angle from the base.
2. Plug the power supply into the Wi-Fi Hub and into a wall
outlet.
NOTE: Select a non-switched outlet that is not
powered off at night.
3. Insert the Ethernet cord cable into the WAN port on the
front of the Hub and into an open port on your router. If
a longer cable is required, ensure it is a CAT-5, CAT-5e, or
CAT-6 type.
4. The Wi-Fi Hub boots up and automatically connects to the
Internet.
NOTE: The start-up process may take up to ve
(5) minutes.

6
1 – Introduction IB Pulse
IB Pulse
Front Back
Navigation
The IB Pulse features a touch screen for accessing various function s
and options.
The arrow buttons ( ) at the bottom of the tool can also
be used for highlighting and selecting.
Press ■to enter a selection.
Initial IB Pulse Power Up
1. Press the I/O Power button on the top of the tester to power
it up.
2. Select Next >to begin the setup process.
3. Date Time: Select the correct time zone, date, and time and
select Next >.
NOTE: Time zone, date, and time must be cor-
rectly set in order for the IB Pulse to connect to
the WI-FI Hub.
4. Connect To Hub: When only one HUB is detected, the tool
automatically detects and congures to the HUB. If more
than one HUB is available, identify the last 4 digits of the HUB
IMEI (on the back label) and select from the displayed list.
Last Four Digits
Once connected, the tester automatically searches for any
software updates.
5. Software Update: Installs any available updates.
Power Button
Light Sensor
Charging Indicator
Touchpanel Display
Keypad
Auxiliary Charge Port
Scan Light
Barcode Scanner
Temperature Sensor
Clamp Holster
Battery Compartment
Cable Connection

7
1 – IntroductionIB Pulse
6. Add Bluetooth Printer (Optional Equipment): Select Yes to
add .
• Turn the printer on.
• Tap the displayed printer name to select it.
• Tap Next > to connect.
• A conrmation message is displayed when successful.
NOTE: Not all Wi-Fi and Bluetooth printers are
supported by the IB Pulse. For a complete list of
supported printers, go to:
www.interstatebatteries.com/ibpulse
Add Wi-Fi Printer (Optional Equipment): Select Yes to add .
NOTE: A Wi-Fi Printer can be added at any time
once the IB Pulse setup process is complete.
See "Printers" in Chapter 4 - Menu -> Settings.
• A conrmation message is displayed when successful.
7. Shop Info: Review and edit information as needed. The in-
formation listed will appear on battery test, emails, and print
outs
8. Complete: The Complete screen is displayed at the end of
the setup process. Select the Begin checkmark to continue.
The Home Screen is displayed.
Setting User Preferences
Refer to Chapter 5 - Menu -> Settings ( ) to adjust the IB Pulse
default setting and parameters.

8
1 – Introduction IB Pulse
Charging Dock
Front
Power Supply Connection
Wall Mounting Bracket
Side
Charging Dock Mounting (Optional)
1. Release the two (2) holding tabs on the bottom of the Charg-
ing Dock to remove the wall mounting plate.
2. Use four (4) screws to securely mount the plate onto a wall or
other vertical surface.
3. Slide the dock onto the wall mount until the holding tabs lock.
4. Connect the Power Supply to the jack on the Charging Dock.
5. Guide the Power Supply wire through the wire channel mold-
ed into the bottom of the Charging Dock.
The Charging Dock is now ready to use.

9
2 – VIN Scan In Vehicle TestingIB Pulse
Use the IB PulseTM to perform a battery test with two simple
scans.
Scanning the vehicle VIN and battery barcodes pre-populates
vehicle information and the battery information into the tester,
providing the information needed to run an accurate battery
test. Scanning the VIN or selecting the year, make, and model
also provides:
•Battery Location Diagrams for nding the battery location
within the vehicle.
•Electronics Reset Instructions to access vehicle electronics
reset instructions for most major vehicle brands.
•Recommended Batteries to match and recommend batter-
ies by part number
By default, the IB Pulse is congurated to test in-vehicle
automotive batteries using test parameters determined by
vehicle VIN or the year, make, and model of the vehicle being
tested. A System Test is also available.
Select
<
at any time during the test to return to the previous
screen or to return to the Main Menu.
1VW76C56AHQ123548
8811477121 31
Step 1:
Scan VIN
Step 2:
Scan Battery
Barcode
Step 3:
Connect clamps
to the battery
Inspecting the Battery
Visually inspect the battery before testing for the following:
•Cracked, buckled, or leaking case. If you see any of these
defects, replace the battery.
•Corroded, loose, or damaged cables and connections. Re-
pair or replace them as needed.
•Corrosion on the battery terminals, and dirt or acid on the
case top. Clean the case and terminals using a wire brush
and a mixture of water and baking soda.
•Low electrolyte level. If the electrolyte level is too low, add
distilled water to ll to ½" above the top of the plates and
fully charge the battery. Do not overll!
•Corroded or loose battery tray and hold-down xture. Tight-
en or replace as needed.
Battery Test
1. Power on the IB Pulse tester.
2. If the function is enabled, select a User from the displayed list.
3. If the function is enabled, enter the Job Number and select
Next >.
4. The main test screen is displayed.
Out of
Vehicle
For testing batteries not electrically connected
to a vehicle. This test bypasses VIN entry.
See Chapter 4 - Out Of Vehicle Test.
Last Test
Most recent test result history. Select a
displayed result for specic details. Select Full
Test History to access test totals searchable
by vehicle, user, or test results.
Test
Modes
Automotive (only option with IB Pulse XP)
Marine
Group 31
Powersports
Lawn & Garden
Commercial 4D/8D
Menu
Access tester settings, defaults and
Promotion information.
See Chapter 5 - Menu.
5. The active Test Mode is displayed below the VIN scan win-
dow. Tap Test Modes to change it.
NOTE: Select to change the Test Mode. VIN
is not used for Marine, Powersports, Lawn &
Garden, and Commercial 4D/8D applications.
2 – VIN Scan In Vehicle Testing

10
2 – VIN Scan In Vehicle Testing IB Pulse
6. Scan VIN or QR code. Use the camera view window to align
the scanner on the back of the tool with the vehicle's VIN
barcode, usually located in the right corner of the vehicle's
front windshield or on the driver’s side door frame.
Barcode
Scanner
Driver's Door Frame
Windshield
Select the ashlight icon if more light is required.
Flashlight On Flashlight Off
Enter VIN: VIN scan is always preferred. If necessary, use the
displayed keypad to manually enter the VIN. Select Next >
to continue.
Y/M/M: Select to manually enter year, make, and model data.
7. Scan the battery. Aligning the battery barcode within the
camera view window and scan the battery barcode. The bat-
tery temperature is measured at the same time.
Manual Entry: If a battery barcode is not in the tester
database, not scannable, or the battery data is not available,
select Manual Entry to enter the Battery Units, Rating, Type,
and Post Location.
Refer to the Appendix in back of this manual for specic
battery parameter information.
Battery Location: Select Battery Location to display the
battery location in the vehicle based on vehicle year, make,
and model determined by the scanned VIN or information
entered manually.
8. Connect the IB Pulse clamps to the battery posts and select
Start.
IMPORTANT: If the entered VIN is a start-stop
vehicle and the IB Pulse has been paired to a IB
Pulse XP module, connect the IB Pulse XP to the
battery.
The IB Pulse XP module is paired to the IB Pulse
using a Bluetooth connection. See Chapter 2 -
VIN Scan In Vehicle Testing.
9. If prompted, capture the battery temperature.

11
2 – VIN Scan In Vehicle TestingIB Pulse
Align the battery within the camera view window and hold
the sensor on back of tester 6 to 12 inches from battery
surface.
10. Tap Capture to capture the live reading temperature and
begin the test.
Battery Test Results
Use
<
and >to view the battery test results, cranking health,
and the test record for the vehicle tested.
The dots at the bottom of the results screen indicate additional
screens are available. Use <or >to move between screens.
 Screen 1 Screen 2 Screen 3
Send Results Via email or through a congured printer.
Done
Exit the test and return to the Home Screen. For
Replace Battery decisions, select to continue
or to access the Reset Electronics checklist.
Look Up
Replacement
Select to display recommended replacement
batteries.
System Test
Continue to the System Test.
Battery Decisions
Decision Description
Good
Battery
The battery is in good condition. Recommend retesting
the battery in 90 days or at next service opportunity.
Good
Recharge
Battery good, but low on charge. Fully charge for optimal
performance and life. Check for causes of low charge.
Good -
Recheck
Soon
The battery performance has started to decline and
may fail to start the vehicle. Consider replacing the
battery before it is exposed to temperature extremes.
Charge
& Retest
(Analysis
Unavailable)
State of charge too low for diagnosis. Fully charge &
retest.
Replace
Battery
Battery no longer meets minimum standards &
replacement is recommended. It is likely to fail soon,
especially if exposed to temperature extremes.
Frozen
Battery
Completely thaw battery before retesting, charging or
starting the vehicle. See Danger warning below.
Bad Cell –
Replace
Bad cell detected. Replace immediately. See Danger
warning below.
Risk of explosive gases. Can cause death or
serious personal injury.
Never attempt to charge a frozen battery or a
battery with a bad cell. The battery must be
replaced.

12
2 – VIN Scan In Vehicle Testing IB Pulse
System Test
System Test
For the System Test, follow the instructions displayed
on the IB Pulse tester screen.
1. After the System Test is initialized, start the vehicle's engine
when prompted and leave it running for 15 seconds.
The IB Pulse will detect the engine start and analyze the
cranking voltage and time.
2. Turn off the engine when prompted.
System Test Results
Use
<
and >to view the battery test results, cranking health,
and the test record for the vehicle tested.
The dots at the bottom of the results screen indicate additional
screens are available. Use <or >to move between screens.
 Screen 1 Screen 2 Screen 3
Battery Results
Battery Results (cont.)
Cranking Result
Select to view the Cranking Voltage results.
Charging Result
Select to view the Charging and Ripple Voltage test results.

13
2 – VIN Scan In Vehicle TestingIB Pulse
Cranking Health Decisions
Decision Action
Cranking
Normal
Starter voltage normal & battery is fully charged.
Low
Voltage
Starter voltage low & battery is fully charged.
Charge
Battery
Starter voltage low & battery is discharged. Fully charge
& repeat test.
Replace
Battery
For REPLACE or BAD CELL, replace battery before
testing starter.
No Start Engine didn’t start & test was aborted or vehicle starting
prole not detected & Starter Test was skipped.
Charging Health Decisions
Decision Action
Charging
Normal
The output from the alternator is normal.
No
Output
No output detected. Check belts to ensure alternator is
rotating when engine is running.
• Check all alternator connections including to the
battery. Clean or replace if necessary and retest.
• If the belts and connections are in good working
condition, replace alternator or external voltage
regulator.
Low
Output
Alternator not providing enough current to power
electrical loads and charge the battery.
• Check belts to ensure the alternator is rotating with
the engine running.
• Check alternator connections to and from the
battery. If loose or heavily corroded, clean or
replace the cable and retest.
High
Output
Alternator voltage to the battery exceeds normal limits
of a functioning regulator.
• Check for loose and normal ground connections.
If no connection problems are found, replace the
regulator.
The normal high limit of a typical automotive regulator
is 14.5 volts +/–0.5. Refer to the manufacturer
specications for the correct limit, which may vary by
vehicle type.
Battery Replacement
Battery
Replacement
The Battery Replacement option is given following a
Replace Battery decision. Use Battery Replacement
to access the Reset Electronics checklist and to look
up correct replacement Interstate battery options.
1. Select Done following a Replace Battery decision. The op-
tion to replace the battery is given.
Battery Replacement can also be accessed through the Last
Test function when Replace Battery is selected.
2. Select Yes to continue.
Based on the entered VIN, any battery replacement notices
and warnings are displayed.
Reset
Reset
Displays a checklist of vehicle-specic procedures
to ensure the vehicle electronics are functioning
properly following the installation of a new battery.
1. Select .
2. Select each module and perform the reset procedures to
ensure the vehicle electronics function properly.
3. Check each item in the list after it has been completed.
4. Select < to go back to the Reset Electronics screen.
Lookup Replacement
Lookup
Replacement
Displays a list of recommended replacement batteries
based on the entered data during the testing
process.
1. Select the Reset icon.
A list of recommended replacement batteries based on the
entered VIN is displayed.
2. Tap Xto close the window and return to the Battery Re-
placement screen.

14
3 – Out Of Vehicle Test IB Pulse
Out Of
Vehicle
Use Out Of Vehicle Test to perform tests on
batteries disconnected and/or removed from a
vehicle, using test parameters determined by
the scanned barcode on the battery. Battery
parameters can also be entered manually.
Select <to return to the previous screen or to return to the
Main Menu at any time during the test.
Battery Test
1. Connect the IB Pulse tester clamps to the battery terminals.
2. At the Home Screen, select a User from the displayed list.
3. At the main testing screen select the Out of Vehicle icon.
4. Scan the battery barcode. The battery temperature is mea-
sured at the same time.
If a battery barcode is not available, tap Manual Entry to
enter the Battery Units, Rating, Type, and Post Location.
If prompted, capture the battery temperature by holding
the sensor on back of tester 6 to 12 inches from battery
surface and tap .
The test begins once the battery temperature is captured.
Battery Test Decisions
Decision Description
Good
Battery
The battery is in good condition. Recommend retesting
the battery in 90 days or at next service opportunity.
Good
Recharge
Battery good, but low on charge. Fully charge for
optimal performance and life. Check for causes of low
charge.
Good –
Recheck
Soon
The battery performance has started to decline and may
fail to start the vehicle. Consider replacing the battery
before it is exposed to temperature extremes.
Charge &
Retest
State of charge too low for diagnosis. Fully charge &
retest.
Replace
Battery
Battery no longer meets minimum standards &
replacement is recommended. It is likely to fail soon,
especially if exposed to temperature extremes.
Frozen
Battery
Completely thaw battery before retesting, charging or
starting the vehicle. See Danger warning below.
Bad Cell –
Replace
Bad cell detected. Replace immediately. See Danger
warning below.
Risk of explosive gases. Can cause death or
serious personal injury.
Never attempt to charge a frozen battery or a bat-
tery with a bad cell. The battery must be replaced.
3 – Out Of Vehicle Test

15
3 – Out Of Vehicle TestIB Pulse
Battery Test Results
Use
<and >
to view the battery test results, cranking health,
and the test record for the vehicle tested. The dots at the
bottom of the results screen indicate additional screens are
available. Use <or >to move between screens.
 Screen 1 Screen 2 Screen 3
Send Results Via email or through a congured printer.
Done
Exit the test and return to the Home Screen.

16
4 – Menu IB Pulse
Settings
Sengs
Use the Settings functions to adjust and customize
the IB Pulse to match shop requirements. Select
<to return to the previous screen. Swipe up or
down on the screen to scroll, or use or on
the keypad.
Wi-Fi
Use Wi-Fi to view, add, and delete all available Wi-Fi
Hub connections.
Select to access Wi-Fi Hub functions.
Wi-Fi Hub Connected Wi-Fi Communicating
Add: Add a detected
Wi-Fi Hub
Reload: Re-scan for
detectable Wi-Fi Hubs
Additional Menu Options
Adding A Wi-Fi Network
1. Select to add a Wi-Fi Hub.
A list of detected wireless networks is displayed. The icon
indicates a Wi-Fi Hub.
2. Select a displayed Wi-Fi Hub . The IB Pulse will automatically
congure the tester to the Wi-Fi Hub .
3. Select Next >to return to the Wi-Fi screen. The selected
Wi-Fi Hub is displayed.
Deleting A Wi-Fi Network
1. Select next to a displayed network.
2. Select to delete the network and select Yes to conrm.
Email
Add, edit, and delete email addresses used for test
results.
Select to access Email functions.
✩Select/Deselect Favorite Additional Menu Options
Add Email Auto Email
Delete Selected Address Edit Address
Send Test Email
Auto Email
1. Select to view the list of entered email addresses.
2. Select an addresses to automatically send test results. A
green dot indicates the selected address.
3. Select Xto exit and return to the email list.
Add Email Address
1. Select to add an email address.
2. Use the displayed keypad to enter the contact name and
email address.
3. Select to add the address to the email list or Cancel to
exit and return to the email list.
Edit Email Address
1. Select next to a displayed email address.
2. Select to edit the address.
3. Use the displayed keypad to edit the contact name and
email address.
4. Select to add the address to the email list or Cancel to
exit and return to the email list.
Deleting An Email Address
1. Select next to a displayed email address.
2. Select to delete the address and tap Yes to conrm or
Cancel to exit and return to the email list.
Favorites
1. Tap ✩to select an email address add it as a Favorite.
2. Tap ✩✩to deselect and remove a Favorite email address.
NOTE: A maximum of three (3) email addresses
may be selected as Favorite.
4 – Menu

17
4 – MenuIB Pulse
Printers
The Printer Setup function detects and displays a list of
connected and available Wi-Fi and Bluetooth printers.
Select to access the Printer Setup functions.
NOTE: To connect a Wi-Fi printer, Wi-Fi network
communication must be successfully established be-
fore any printers can be detected and setup.
Additional Menu Options Add Printer
Delete Selected Printer Auto Print
Printer Setup Bluetooth Printer
Print Test Page Wi-Fi Printer
Auto Print
1. Select to view a list of connected printers.
2. Select one of the displayed printers to automatically print-
out test results at the conclusion of a successful test. A
green dot indicates the selected printer.
3. Select Xto exit and return to the printer list.
Add Printer
1. Select to add a Wi-Fi or Bluetooth printer.
2. Select the printer type, Wi-Fi or Bluetooth.
For A Wi-Fi Printer
•The IB Pulse must be connected to the same shop
Wi-Fi network as the Printer
•The printer is Wi-Fi capable
•The printer is supported by the IB Pulse
NOTE: Not all Wi-Fi and Bluetooth printers
are supported by the IB Pulse. For a com-
plete list of supported printers, go to:
www.interstatebatteries.com/ibpulse
Select Use Email Address or Continue to Wi-Fi.
For Email Address: Enter the Name and Email Address of
the target printer and select Next to add it to the Printer list.
For Wi-Fi Printer: Conrm the following.
• The Wi-Fi printer is powered up
• The IB Pulse is connected to the same Wi-Fi network.
• The selected Wi-Fi network as internet access.
NOTE: A Warning message is displayed if no Wi-Fi
printer has been detected on the Wi-Fi Hub being
used by the IB Pulse. Tap Settings to select a dif-
ferent Wi-Fi Hub or add a new Hub. See Settings/
Wi-Fi in this chapter for additional information.
After the IB Pulse adds the printer, it will switch back to the
HUB network.
NOTE: A test print can be completed by selecting
next to the printer name in the printers list.
NOTE: Refer to the Wi-Fi Printing section in the
Appendix of this manual for additional Wi-Fi
printer connection information.
For a Bluetooth Printer: Power on the printer and make sure
it is within 10 feet of the IB Pulse tester.
3. Select Next >to connect to the selected printer. A mes-
sage is displayed when the conguration is successful.
4. Select Next >to return to the printer list.
Deleting A Printer
1. Select next to a displayed printer.
2. Select to delete the printer and tap Yes to conrm.
Default Printer
Select to select a default printer from the displayed list.
If any of the printers are set for Autoprint, the Battery and System
Test results are automatically printed out at the end of each
completed test.
Languages
Select the default language for System, Test Results,
Email, and Print functions.
Select to access the Language settings.
System Language
Select the technician System Language default for the IB Pulse to
display on the tool screen.
Test Result Language
Select the Test Result language default for all tests and results
displayed on the tester screen.
Email Language
Select the default language for all tests and results sent via email.
Print Language
Select the default language for all tests and results printed using
a congured printer.

18
4 – Menu IB Pulse
Display
Adjust the IB Pulse display including the Brightness,
Sleep Time, and Dim Time. Auto Brightness can also
be turned on and off.
Select to access the Display functions.
Brightness
Adjust the display Brightness by tapping and holding the slider,
then moving it right or left to make the screen brighter or darker.
Auto Brightness
Enable and disable Auto Brightness by taping on the check box.
Sleep Time
Adjust the amount of elapsed time before the IB Pulse goes into
a power saving (Sleep) mode. Default = 2 minutes.
Dim Time
Adjust the amount of elapsed time before the IB Pulse goes into
a power saving (Dim) mode. Select :30 seconds, 1 minute, or
Never. Default = :30 seconds.
Shop Info
Access default Shop Information including Store Name,
address, and phone number.
Select to access the Shop Info.
Use the on screen keypad to enter the store name, address, and
phone number.
Users
Add, edit, or delete Users.
Select to access Users functions.
Edit Users Additional Menu Options
Delete Users
Add User
1. Select to add a User.
2. Use the on screen keyboard display to enter a User Name.
3. Select Done or Next > .
4. The new User name is displayed on the Users screen.
Editing A User
1. Select next to the User to be edited.
2. Select to edit the User Name.
3. Use the on screen keyboard display to edit the User Name.
4. Select Done or Next > .
5. The new User name is displayed on the Users screen.
Deleting A User
1. Select next to the User to be deleted.
2. Select to delete the selected user.
The deleted User name is removed from the displayed list.

19
4 – MenuIB Pulse
Date Time
Adjust the IB Pulse Date and Time format and the Time
Zone in which the tester will be used. The date and time
can also be set. Select the boxes to change the values.
Select to access Date Time functions.
Tap to access. Scroll up/
down to set the day,
month, and year
Additional Menu Options
Select Time Format
12 or 24 hour format
Select Date Format
MM/DD/YYYY Month/Day/Year
DD/MM/YYYY Day/Month/Year
YYYY/DD/MM Year/Day/Month
Select Time Zone
Time zone in which the IB Pulse tester is being used.
Set Date
Select or to enter the month, day, and year. Select Done
to exit.
Set Time
Select or to enter the hours, minutes, and AM/PM. Select
Done to exit.
Select <to return to the Date Time screen.
Test Settings
Set the default Test Settings for Temperature Units and
Test Mode.
Select to access the Test Settings defaults.
Select the boxes to change the values.
Temperature Units
0F
Default Test Mode
Automotive
Create MDCA Log File
Temperature Units
Default temperature units used when measuring battery
temperature.
Default Test Mode
The selected test default: Automotive, Marine, Group 31,
Powersports, Lawn & Garden, Commercial 4D/8D
Create MDCA Log File
The MDCA function is used for technical support purposes.
Select <to return to the Test Settings screen.
Software Update
Use this function to check via the Internet connection
for any updates to the tester software.
Select to check for any software updates.
NOTE: Wi-Fi network communication must be suc-
cessfully established before a software update can
proceed.
Relocation Mode (Admin Only)
Use this function to return the tool to the original as built
conguration including all history and test settings.
Select to activate Relocation Mode.
IMPORTANT: All previous modications to the
original settings will be overwritten.

20
4 – Menu IB Pulse
About
For technical assistance, replacement parts, or service,
call 877.464.3318.
Serial Number IB Pulse SW Version
Wi-Fi MAC Address Tester SW Version
Conguration Version
Tester Software Version
Select ©to display software attribution and copyright
information. The tester must be connected to the Internet.
Promotions
Promoons
The Promotions displayed on the IB Pulse are
created and controlled by Interstate Batteries.
Users do not have the ability to delete or change
any promotion or promotion schedule.
•Promotions can be automatically displayed whenever a user
logs into the IB Pulse.
•More than one Promotion can be active at one time.
•Every promotion has a specic start and end date.
•View all active Promotions at Menu -> Promotions. Expired
Promotions are removed and cannot be displayed.
•Promotions can be setup for a specic number of displays
for each user. For example, a Promotion will display for the
rst ve days a user logs into the IB Pulse, but still valid be-
yond that time.
•Promotions can also be emailed or printed using a Wi-Fi
printer. Promotions emailed or printed prior to expiration,
are invalid after the expiration date.
NOTE: Promotions cannot be printed using a
Bluetooth printer.
Promotion Samples
