Operating Instructions
Motor ExVENT 30xx
COM141824651Ien-2 • 03/12/2019

www.intertec.info
Page 2 / 7 COM141824651Ien-2
INTERTEC-Hess GmbH · Raffineriestr. 8 · 93333 Neustadt/Donau · Germany · [phone] · [email protected]
Table of contents
1 Use ...........................................................................................................................................................................3
2 Explanation of symbols for warnings and signal words .................................................................................... 3
3 Safety information ..................................................................................................................................................3
4 Technical Data ........................................................................................................................................................3
5 Installation...............................................................................................................................................................4
6 Connection..............................................................................................................................................................5
7 Commissioning.......................................................................................................................................................5
8 Troubleshooting .....................................................................................................................................................5
9 Directions for use ...................................................................................................................................................6
10 Maintenance............................................................................................................................................................6
11 Deinstallation .........................................................................................................................................................6
12 Disposal...................................................................................................................................................................6
13 EU declaration of conformity ................................................................................................................................ 6
14 Further information and service ........................................................................................................................... 7

www.intertec.info
Operating Instructions Motor ExVENT 30xx
COM141824651Ien-2 Page 3 / 7
INTERTEC-Hess GmbH · Raffineriestr. 8 · 93333 Neustadt/Donau · Germany · [phone] · [email protected]
1 Use
ExVENT 30xx electro motors are manufactured accord-
ing to Directive 2014/34/EU and serve as drives for fans,
pumps, gear units or other devices. ExVENT 30xx is ap-
proved for Ex zone 1 of equipment category G in tem-
perature class T4.
EC type examination certificates PTB 10 ATEX 2023
with appendices and supplements in German and Eng-
lish, as well as IEC Scheme Certificate IECEx PTB
11.0016X.
See http://www.intertec.info
2 Explanation of symbols for warnings
and signal words
The safety information warns the user about risks and
provide information on how risks can be avoided.
Safety information can be found at the start of the
chapter before the instructions which may lead to a haz-
ardous situation. Additional safety information can be
found at the beginning of this manual.
Safety instructions which must be adhered to are high-
lighted as follows:
DANGER
DANGER
This sign is warning about an extremely hazardous situ-
ation which, if not heeded, will lead to death or serious ir-
reversible injury.
WARNING
WARNING
This sign is warning about a hazardous situation which,
if not heeded, may lead to death or serious irreversible
injury.
CAUTION
NOTICE
This sign is warning about a hazardous situation which,
if not heeded, may lead to slight, reversible injury.
NOTICE
NOTE
It is essential to pay attention to this safety advice as you
may otherwise incur material damage.
INFO
Important notes and useful additional information.
3 Safety information
CAUTION
Risk of injury
There is a risk of injury on rotating and/or hot compon-
ents.
4 Technical Data
Rated voltage max. 230 V AC
Permitted operating voltage max. 250 V AC
Special voltages with corresponding power adjustment
and component selection are possible
Rated current (in compli-
ance with VDE 0298)
max. 1 A
Rated output 25 W
Ambient temperature - 60 to + 60
Max. permitted operating
temperature at rated opera-
tion
- 40 to + 60
Insulation class H
Temperature class T4
Rated speed 3000 rpm
Installation position optional
Connecting cable Silicon cable, notch- and
oil-resistant,
3 x 1.5 mm², Ø 8.4 mm
Cable length 1 m / optional 3 m
Dimensions H x W x D 75 x 120 x 117 mm
ExVENT 30xx L 175 PA.. .. Fan blade Ø 175 mm

www.intertec.info
Operating Instructions Motor ExVENT 30xx
Page 4 / 7 COM141824651Ien-2
INTERTEC-Hess GmbH · Raffineriestr. 8 · 93333 Neustadt/Donau · Germany · [phone] · [email protected]
ExVENT 30xx .. .. without fan blade
INFO
You will find the precise technical data for your in-
strument on the label.
Type
Rated voltage/Operating voltage Rated output
Ø Blade
Illustration1: Label Motor ExVENT
5 Installation
NOTICE
Risk of Damage
When removing from the packaging and during trans-
port, the connection line must not be stressed or bent.
Any installation location can be chosen. The installation
must be carried out on the bearing bracket. 2 mm thick
spacers must be placed beneath the mounting flanges to
prevent abrasion of the auxiliary fan.
The operating temperatures must be adhered to, other-
wise the thermal fuse will be triggered.
The connection line must be permanently installed up to
the inlet in the on-site junction box, taking the permiss-
ible bending radius = 5 x outer diameter into considera-
tion.
The connection line must be connected in a housing that
complies with the requirements of a recognized type of
protection in accordance with EN 60079-0 section 1 if
the connection is made in a potentially explosive atmo-
sphere.
The nameplate must always remain easily legible.
Bracket
Illustration2: ExVent 30xx 2D front view
Air direction
Illustration3: ExVent 2D side view

www.intertec.info
Operating Instructions Motor ExVENT 30xx
COM141824651Ien-2 Page 5 / 7
INTERTEC-Hess GmbH · Raffineriestr. 8 · 93333 Neustadt/Donau · Germany · [phone] · [email protected]
br=brown bl=blue gn/ye=green/yellow
Ex terminal box
br bl gn/ye
ExVENT 30xx
PA
Illustration4: ExVent 30xx circuit diagram
6 Connection
INFO
The device may only be connected up and secured by a
trained person, taking into account the "rated voltage"
and "rated current" specified on the nameplate.
A fuse corresponding to its rated voltage (max. 3 x IB ac-
cording to lEC 60127-2-1) or a motor protection switch
with short-circuit and thermal instantaneous release (set-
ting to rated current) must be upstream of each electric
motor. In the case of very low rated currents of the elec-
tric motor, the fuse with the lowest current value accord-
ing to the specified IEC-standard is sufficient. The fuse
must be housed in the associated power supply unit or
separately upstream. The fuse rated current must be the
same as or greater than the specified maximum working
voltage of the electric motor. The breaking capacity of
the fuse link must be the same as or greater than the
maximum short-circuit current expected at the place of
installation (normally 1500 A). A connection box with a
melting fuse can be used for example.
Additional equipotential bonding is required. The ter-
minal block designated for this purpose has the ground
sign.
7 Commissioning
If the electric motor was installed according to the
guidelines specified under section Installation [}Page 4]
and section Connection [}Page 5] and it is guaranteed
that no foreign bodies can reach the rotating compon-
ents, then the electric motor can be switched on.
A thermal safety fuse is integrated that disconnects the
motor from the mains for reasons of explosion protection
in the event of external heating or blockage. This also
occurs if these installation instructions are not complied
with.
We recommend a thermostat upstream at temperatures
ranging from 40°C.
8 Troubleshooting
DANGER
Risk of fatal injury from electric current!
If contact is made with live components, there is the risk
of fatal injury.
For this reason, switch off the voltage supply, secure
against being switched on again and check that no more
voltage is present.
INFO
Repairs may only be carried out by the manufacturer
(INTERTEC-Hess) in all cases.
Do not disassemble the device! Opening the units will
render the warranty invalid.
Fault: Remedial action:
Connection
Connection line not con-
nected properly
Check connection
Mains voltage has a dif-
ferent frequency than
230-250 V AC 50 Hz
Check mains voltage and fre-
quency
Fan used for cooling:
Power supply is interrup-
ted by external thermo-
stat
Room air is cooler than the
temperature set on the ther-
mostat
Connecting cable is
damaged
The connecting cable must be
protected mechanically
Fan blade
Foreign bodies in the fan
blade
Remove foreign bodies –
make sure that the fan can
move freely

www.intertec.info
Operating Instructions Motor ExVENT 30xx
Page 6 / 7 COM141824651Ien-2
INTERTEC-Hess GmbH · Raffineriestr. 8 · 93333 Neustadt/Donau · Germany · [phone] · [email protected]
Fault: Remedial action:
Blocked fan blade over-
heats the motor –
thermal safety fuse is
triggered
Device must be replaced
Auxiliary fan blocked Use spacers to create space
Temperature
Temperature of suction
medium is greater than
+60°C – thermal safety
fuse is triggered
The temperature of the
pumped medium must always
be less than +60°C
Device must be replaced
Fault alarm is triggered Cause: Motor blocked
Device must be replaced
9 Directions for use
To preserve the operational capability and to prevent un-
planned downtimes of the device, please observe the
following measures:
•Bearing/drive shaft:
Both must be kept free of contamination, visual in-
spection at 3-month intervals, or at even shorter in-
tervals if necessary
•Filter mat:
When used as a filter fan, carry out regular inspec-
tions for contamination, replace if necessary
•Corrosion:
Highly aggressive media must be avoided
•Pump clean air:
If the air is very dusty, you must use a filter upstream
•Distance between rotating elements:
The distance of the rotating elements in the axial and
radial direction must not be less than 2 mm from the
fan housing.
10 Maintenance
Depending on the degree of contamination of the envir-
onment the auxiliary fan of ExVENT 30xx must be
cleaned at regular intervals to avoid overheating.
INFO
Repairs may only be carried out by the manufacturer
(INTERTEC-Hess) in all cases.
Do not disassemble the device! Opening the units will
render the warranty invalid.
11 Deinstallation
Disassembly may only be carried out by a trained per-
son.
DANGER
Risk of fatal injury from electric current!
If contact is made with live components, there is the risk
of fatal injury.
For this reason, switch off the voltage supply, secure
against being switched on again and check that no more
voltage is present.
Disconnect connection line from the clamps and from the
connection socket, disconnect device from bracket and
remove it.
12 Disposal
Disassemble the components of the product, taking the
applicable local labour protection and environmental reg-
ulations into consideration and make sure that the com-
ponents are recycled:
• Scrap metal
• Send plastic elements to recycling
• Sort other components according to their material
properties and dispose of them.
NOTICE
Environmental damage may be caused if dis-
posed of incorrectly!
Electrical scrap and electronics components are subject
to hazardous waste treatment and must only be dis-
posed of by certified specialists!
The local community authorities or specialist waste dis-
posal companies can provide information on environ-
mentally friendly disposal.
13 EU declaration of conformity
The manufacturer, INTERTEC-Hess GmbH, Raffiner-
iestrasse 8, 93333 Neustadt/Donau, Germany, hereby
declares in sole responsibility that the product
Product / Type designation:
ExVENT3025

www.intertec.info
Operating Instructions Motor ExVENT 30xx
COM141824651Ien-2 Page 7 / 7
INTERTEC-Hess GmbH · Raffineriestr. 8 · 93333 Neustadt/Donau · Germany · [phone] · [email protected]
complies with the provisions of the following directives
2014/34/EU (ATEX), 2014/30/EU (EMC), 2011/65/EU
(RoHS), 2012/19/EU (WEEE) complies with the following
standards, harmonized standards, where appropriate
and/or standardized documents:
EN 60079-0:2012+A11:2013
EN 60079-18:2015
EN ISO 80079-36:2016
EN ISO 80079-37:2016
EN 14986:2017
Harmonized Standard (RoHS):
DIN EN 50581:2012
Designation:
2572
II 2 G Ex h mb IIB+H2 T4 Gb
PTZ 18 ATEX 0050 X
Neustadt, May 25th, 2018
Dipl.-Ing. Martin Hess, Managing Director
14 Further information and service
If the information contained in this instruction manual
should not be sufficient in any way, then INTERTEC
would be glad to be at your disposal to provide further in-
formation and service.
Please contact your INTERTEC contact person or dir-
ectly contact
INTERTEC-Hess GmbH
Raffineriestr. 8
93333 Neustadt/Donau
Germany
Phone: [phone]
e-mail: [email protected]
Website: www.intertec.info
Warranty
The legally defined warranties and warranty periods of
24 months are applicable to our scope of supply and ser-
vices.
You will find more detailed information in the manufac-
turer warranty from INTERTEC for heating systems and
accessories.
These instructions do not claim to take all
designs, options or changes into consid-
eration, even in association with installa-
tion, operation or maintenance. INTER-
TEC does not accept responsibility for
providing information about changes
made retrospectively.
