Hyundai H170VC User manual

GASOLINE ENGINE
H170VC

1
PREFACE
Thank you for choosing a small general gasoline engine of our company.
The manual gives information with respect to operation and maintenance
of the
H170VC
general ga soline engine, and be sure to read
insure user’s safety and get the best results of the engine operation. If a
problem should arise or if you have any questions about your gasoline
engine, consult an authorized our company servicing dealer.
The vertical shaft gasoline engine products in this Owner's Manual are
mainly used for the lawn mower and mini tiller.
All information and diagrams of this manual are in accordance with the
newest products at the publishing time. If revision and other change of
the information descried in this manual are a little different from the
actual status, our company will explain it. Our company reserves the right
to make change at any time without notice and without incurring any
obligation. No part of this publication may be reproduced without written
permission.
This manual should be considered a permanent part of the generator and
should remain with the generator if resold.
it
carefully

5
9. Refuel the fuel tank not too full so as to avoid fuel’s spilling out. If there
is spilled fuel around, be sure to clean it thoroughly before starting.
10. Do not run the engine in airtight or ill-ventilated places.
11.
the engine stops. Never touch it, or you may get burns. Transport or
store the engine with it cooling down entirely.
12.Inclination of gasoline engine which indicates the included angle
between crankcase cover and level is less than 26°during its runing.
If that is over 26°,oil will flow into combustion chamber and burn
with white smoke, which will cause gasoline engine has lower power
and higher emission.
13. Safe warning label:
Please carefully read warning label before operating. Our company will
not assume any responsibility for person hurt, or equipment damaged
caused by disregarding this warning label.
SAFETY PRECAUTIONS

6
II. PARTS DESCRIPTION
1. Feature
MUFFLER
SPARK PLUG
CARBURETOR
AIR CLEANER FUEL TANK
CAP
STARTER GRIP
FUEL TANK
OIL DIPSTICK

7
2. Model No.
MODEL NO.
FINISHED
PRODUCT NO.
PARTS DESCRIPTION
SER. NO.

8
III. PRE-OPERATE INSPECTION
1.Engine Oil
Engine oil is a key factor in deciding the engine’s performance. Do not
apply engine oil with additives or 2-stroke gasoline engine oil, because
they haven’t enough lubrication, and may shorten the engines service life.
Check the engine with it stopped on a level ground.
L5.0~L3.0:yticapaclioenignE
Engine oil recommended: SAE15W-40
As viscosity varies with regions and temperatures, SJ class oil is
recommended.
Check method:
1) Remove the dipstick and clean it.
2) Reinsert the dipstick into the oil Filling hole without screwing it, and
check oil level.
3) If the oil level is too low, add the recommended engine oil up to the
oil upper level.
4) Reinstall the dipstick.
PRE-OPERATE INSPECTION
