Intertek MAXX AIR H1026 Operation and maintenance manual
[1]
QTY Printed
SKU / Document #
©2020 VENTAMATIC, LTD. MODEL H1026 MANUAL 1214/REV
H1026
Portable Workspace
Forced Air Heater
ANSI/UL 1278 MOVABLE AND WALL OR CEILING HUNG ELECTRIC ROOM HEATERS
DO NOT DISCARD THIS MANUAL
CUSTOMER: PLEASE RETAIN THIS MANUAL FOR FUTURE USE
INTENDED USE: This product is intended only for indoor household or oce
use. It is NOT intended for industrial or commercial use.
DO NOT USE OUTDOORS
WARNING! IF THE INFORMATION IN THIS MANUAL IS NOT FOLLOWED EXACTLY, A
FIRE MAY RESULT CAUSING PROPERTY DAMAGE, PERSONAL INJURY OR LOSS OF LIFE.
FOR YOUR SAFETY
DO NOT STORE OR USE
GASOLINE OR OTHER
FLAMMABLE VAPORS OR
LIQUIDS IN THE VICINITY
OF THIS OR ANY OTHER
APPLIANCE
INSTALLATION INSTRUCTIONS AND OPERATOR’S MANUAL
Made in China
2018 HeTR Model H1026 Manual rev.1
[2]
PLEASE READ AND SAVE THESE IMPORTANT SAFETY INSTRUCTIONS
When using electrical appliances, basic precautions should always be followed to reduce
the risk of re, electrical shock, and injury to persons, including the following:
1. Read all instructions before using this heater.
2. This heater is hot when in use. To avoid burns, do not let bare skin touch hot surfaces. If provided, use
handles when moving this heater. Keep combustible materials, such as furniture, pillows, bedding,
papers, clothes and curtains at least 3 feet (0.9m) from the heater.
3. Extreme caution is necessary when any heater is used by or near children, pets or invalids and
whenever the heater is left operating unattended.
4. If possible always unplug this appliance when not in use.
5. Do not operate any heater with a damaged cord or plug or after the heater malfunctions, has been
dropped or damaged in any manner.
6. Any repairs to this appliance should be carried out by a qualied service person.
7. Under no circumstances should this appliance be modied. Parts having to be removed for servicing
must be replaced prior to operating this appliance again.
8. Do not use outdoors.
9. Use your heater only in dry environments. This heater is not intended for use in bathrooms, laundry
areas and similar indoor locations. Never locate the heater where it may fall into a bathtub or other
water container. Do not use your heater outdoors. Do not use near sinks, swimming pools or other
damp areas such as ooded basements, garages, etc or anyplace where the heater could come in
contact with water.
10. Do not use this heater in elevated locations, such as on shelves, raised platforms, etc.
11. Do not run cord under carpeting. Do not cover cord with throw rugs, runners, or similar coverings.
Arrange cord away from trac area and where it will not be tripped over.
12. To disconnect heater, rst turn controls to o, then remove plug from outlet. Always unplug the
heater when not in use.
13. Connect to a properly grounded outlet only.
14. This appliance, when installed, must be electrically grounded in accordance with local codes, with the
current CSA C22.0 Canadian Electrical codes or for USA installations, follow local codes or for USA
installations, follow local codes and the National Electric code ANSI/NFPA No. 70.
15. Do not insert or allow foreign objects to enter any ventilation or exhaust opening as this may cause an
electrical shock or re, or damage the heater.
16. To prevent a possible re, do not block air intakes or exhaust in any manner. Do not use on soft
surfaces, like a bed, where openings may become blocked.
17. This appliance has hot and arcing or sparking parts inside. Do not use it in areas where gasoline,
paint or ammable liquids are used or stored. This appliance should not be used as a drying rack for
clothing, nor should Christmas stockings or decorations be hung or near it.
18. Use this heater only as described in this manual. Any other use not recommended by the
manufacturer may cause re, electric shock, or injury to persons.
19. Always plug heaters directly into a wall outlet/receptacle. Never use with an extension cord or
relocatable power strip.
20. Do not use this heater with missing, damaged, or broken legs.
21. SAVE THESE INSTRUCTIONS
IMPORTANT INSTRUCTIONS
[3]
ALWAYS OBSERVE THESE SAFETY PRECAUTIONS WHEN OPERATING YOUR
ELECTRIC HEATER
ALWAYS Read all instructions before operating.
ALWAYS Locate your electric heater away from furniture or loose hanging drapes.
ALWAYS Keep the rear grill away from walls or drapes so as not to block the air intake. (If
applicable)
ALWAYS Unplug electric heater when not in use.
ALWAYS Use electric heater on a at dry surface.
ALWAYS Use on 110-120 volt 60Hz AC power supply.
ALWAYS Route the cord so it will not be walked on tripped over or pinched by furniture.
ALWAYS Keep electrical cords, drapes and other furnishings away from your electric heater.
ALWAYS Keep your electric heater clean and the lter free of dust. (If applicable)
ALWAYS Use indoors only.
NEVER Place drapes, clothing or towels over electric heater to dry.
NEVER Use in the presence of explosive or ammable vapors such as gas or paint.
NEVER Plug another electrical appliance into the same circuit. Blown fuses, tripped circuits
and re hazards may result.
NEVER Use water or liquids to clean your electric heater.
NEVER Let bare skin touch hot surfaces as this may cause burns.
NEVER Leave electric heater unattended.
NEVER Leave electric heater when children or pets are present.
NEVER Locate electric heater where it may fall into a bath tub or other water containers.
NEVER Operate electric heater with a damaged cord, plug or after the heater malfunctions, or
has been dropped or damaged in any manner.
NEVER Run cord under carpeting or cover with throw rugs or runners.
NEVER Insert or allow foreign objects to enter any ventilation or exhaust openings, as this may
cause an electrical shock, re or damage.
IMPORTANT INSTRUCTIONS
[4]
OPERATING INSTRUCTIONS
Note: When using the heater for the rst time, you may notice a slight emission of smoke.
This is normal and will stop after a short time. The heating element is made of steel and
was coated with a layer of protective oil during production.
1. Position the fan heater so that it stands on a rm level surface (When
used as portable) and at a safe distance from wet locations and ammable
objects.
2. Connect the fan heater to the proper electrical power. See grounding
instructions.
3. Set the power settings knob to fan or heating Position.
4. Set the thermostat dial to the maximum temperature.
5. Once the room reaches the desired temperature, turn the thermostat dial
back until heating element turns o. The heater will cycle automatically
around this present temperature. To increase temperature, turn the
thermostat knob clockwise. To lower temperature, turn the thermostat
counterclockwise.
SAVE THESE INSTRUCTIONS
IMPORTANT: Read all instructions and warnings carefully before installation
and use. Failure to follow these instructions may result in a possible electric
shock, injury to persons, fire hazard and will void the warranty.
Electrical outlet wiring must comply with local building codes and other
applicable regulations to reduce the risk of fire, electrical shock and injury
to persons.
Setting Function
Unit is O
Fan Runs - Half Power Heat
Fan Runs - Full Power Heat
[5]
Grounding Instructions:
1. Make sure the heater is switched OFF before plugging the heater into the
outlet.
2. Connect to properly grounded outlets only.
3. Note: The power cord has a polarized plug (with one blade wider than the
other) that will only t in a polarized outlet one way.
4. If it does not insert easily try reversing the plug.
5. If it still does not t contact your electrician to replace your outlet.
6. DO NOT defeat the safety purpose of the polarized plug.
Automatic Overheat Safety Control
This heater is equipped with an internal heat limiting thermostat and
overheat protection circuit. When a potential overheat temperature is
reached, the system will automatically shut the heater o. Unplug heater
allow to cool down for 10 minutes, and then restart.
Cleaning and Maintenance
Any electrical repairs or rewiring of this unit should be carried out by a
licensed electrician and in accordance with national and local codes.
Before cleaning the appliance, disconnect it from the power outlet and let it
cool down.
In order to protect the enclosure, don’t splash water onto the heater, and
never use a solvent like gasoline, isoamyl acetate, toluene, etc. to clean
the heater. DO NOT open the heater or attempt to clean the inside of this
appliance.
SAVE THESE INSTRUCTIONS
Do not use this appliance if any part of it has been under water.
Immediately call a qualified service technician to inspect the appliance and
replace any part of the electrical system which has been under water.
CAUTION:
RISK OF ELECTRIC SHOCK
DO NOT OPEN - NO SERVICEABLE PARTS INSIDE
[6]
SPECIFICATIONS
Model: H1026 (All specications +5% / -10% tolerance)
BTU’s per/Hour 5120
Voltage 120V
Watts 1500
Amps 15
Heating Area (ft²) 160
TROUBLE SHOOTING
PROBLEM CAUSE SOLUTION
Do not feel heat or air
ow
No power to heater Check power connection
to heater
Desired room
temperature reached
Thermostat will shut
o heater once desired
room temperature is
reached
Auto-Reset has tripped Cool down for a few
minutes to restart
Heater has fan only
setting
Set to run on full power
for heating
LIMITED WARRANTY STATEMENT
This warranty is underwritten by Falco Insurance Company and is extended to the original retail purchaser of this model or, if this
unit is purchased and requires installation by a building contractor, to the original owner of the home. No subsequent purchaser of
the unit or of a home in which it is installed is entitled to any of the benefits of this warranty.
This product is warranted against defects in materials and workmanship for a period of one (1) year from the date of original retail
purchase. No other parts or components are warranted. There is no warranty for defects caused by abuse, faulty installation, or the
like.
Repairs or replacement parts supplied under this warranty are warranted only for the period of this warranty; that is, one (1) year
from the date of the original retail purchase of the unit.
In the event of a defect or malfunction, we will replace or repair the defective part or component only and return the new or
repaired part to you freight prepaid.
You must bear all other expenses incurred in obtaining repairs, including labor required for field repair or replacement, and the
cost of shipping the defective part to us. You must also bear the cost of repair to or replacement of any part or component and the
shipping charges incurred for the repair or replacement and return to you of any part or component not covered by this warranty,
including parts or components damaged by you.
The company reserves the right to demand and receive written evidence of the date of purchase before undertaking its obligations
under this warranty. The right to demand and receive written evidence of date of purchase extends to all licensed dealers of
Ventamatic, Ltd. products.
You should, therefore, retain your sales slip and attach a copy of it to the warranty claim.
To start a warranty claim you must:
Contact Ventamatic, Ltd.
An RGA (Returned Goods Authorization) form is required for returns to the factory to ensure your return can be processed
efficiently and quickly. Please contact Ventamatic, Ltd. toll-free at 800-433-1626 or via web at www.MYMAXXAIR.com to obtain an
RGA and follow the instructions given.
There is no informal dispute settling mechanism available in the event of a controversy involving this warranty.
Any and all implied warranties which may exist terminate upon the expiration of this warranty one (1) year from the date of the
original retail purchase. Some states do not allow limitations on how long an implied warranty lasts, so this limitation may not apply
to you.
Ventamatic, Ltd. is not liable to you for incidental or consequential damages arising out of defect or malfunction of a unit or its
installation or out of any alleged breach of this warranty. Some states do not allow the exclusion or limitation of incidental or
consequential damages, so this limitation may not apply to you.
This warranty gives you specific legal rights and you may also have other rights which may vary from state to state.
rev.4/19
