INTEX®OWNER’S MANUAL
Pool Volleyball Set for Intex®Oval Pools
099IO-R0-1108
I PORTANT SAFETY RULES
Read, Understand and Follow All Instructions Carefully Before Installing and Using this Product.
• POOL AND POOL ACCESSORIES ARE TO BE ASSEMBLED AND DISASSEMBLED BY ADULTS ONLY.
• USE ONLY UNDER COMPETENT SUPERVISION.
• WHEN NOT IN USE REMOVE FROM THE POOL AND STORE IN A SAFE PLACE INDOORS.
• DO NOT USE DURING WINDY AND GUSTY DAYS.
• FOLLOW THESE RULES TO AVOID SERIOUS INJURY OR PROPERTY DAMAGE.
• USE ONLY MANUFACTURER SUPPLIED BALLS. PROFESSIONAL ATHLETIC BALLS ARE NOT
RECOMMENDED.
• YOU MUST FIRST SET UP AND FILL THE POOL WITH WATER FOLLOWING THE POOL OWNER'S
MANUAL BEFORE INSTALLING.
• DO NOT CLIMB, HANG, PULL, PUSH OR GRAB ANY PART OF THE STRUCTURE. THE STRUCTURE
IS NOT DESIGNED TO SUPPORT USER BODY WEIGHT.
• REMOVE THE STRUCTURE BEFORE PLACING A POOL COVER OVER THE POOL.
ALWAYS FOLLOW ALL SAFETY RULES. CARELESSNESS, OR LACK OF ATTENTION, CAN HAVE
SERIOUS CONSEQUENCES, SUCH AS PARALYSIS OR OTHER PER ANENT INJURIES.
WARNING
REF. NO. DESCRIPTION QTY. SPARE PARTS NO.
1 CONTROL SCREW 4 10545
2 POLE BRAC ET 2 10684
3 X-LONG PIN (WITH 2 EXTRA) 4 10110
4 U-BOLT A 2 10686
5U-BOLT 2 10544
6 NUT 8 10657
7 POLE 2 10685
8 VOLLEYBALL POLE END PLUG 2 10539
9 VOLLEYBALL NET FASTENER 4 10535
10 VOLLEYBALL NET 1 10866
11 VOLLEYBALL 1 10541
PARTS LIST
PARTS REFERENCE
Before assembling your product, please take a few minutes to check the contents and become
familiar with all the parts.
1
3
2
4
7
89
10
6
5
1234
5678
9 1110
NOTE: Drawings for illustration purpose only. May not reflect actual product. Not to scale.
For illustrative purposes only.

99IO
(99IO) ENGLISH POOL VOLLEYBALL SET MANUAL (FOR OVAL POOL) SIZE: 4.875” X 7.25” 08/12/2010 (99IO) ENGLISH POOL VOLLEYBALL SET MANUAL (FOR OVAL POOL) SIZE: 4.875” X 7.25” 08/12/2010
99IO
SAVE THESE INSTRUCTIONS
Page 3
SAVE THESE INSTRUCTIONS
Page 4
1. Attach a Pole Bracket (2), a U-Bolt (5) and
aU-Bolt A (4) to the oval pool center
"U-shape" leg along the length of the pool.
Make sure the Pole Bracket (2) is securely
attached to the "U-shape" leg.
2. Secure the Pole Bracket (2) to the
"U-shape" leg with the U-bolt (5),
U-bolt A (4) and four Nuts (6).
3. Attach two Volleyball Net Fasteners (9) to
the Volleyball Pole (7). Ensure the
Volleyball Net Fasteners (9) are facing
outward.
Set Up Instructions
IPORTANT: Before proceeding to the next step ensure the pool is fully set up and filled with water
following the pool owner's manual. 4. Insert the assembled volleyball pole into
the Pole Bracket (2). Secure the pole to the
bracket with a Long Pin (3). Clockwise
screw in the two Control Screws (1) to
adjust the pole vertically position.
NOTE: Adjust the pole inclination by
adjusting the two Control Screws (1). Do
not over tighten or use tool such as pliers.
5. Locate the opposite "U-shape" leg and
attach the second Pole Bracket (2) to the
"U-shape" leg, repeat steps #1 to #4.
6. Attach one side of the Volleyball Net (10)
starting from the top Volleyball Net
Fastener (9) and then the bottom fastener.
Loop the rope around the fastener (9)
several times and secure the end of the
rope to the two notches in the fastener.
NOTE: Adjust the length of the rope to be
looped around the fasteners depending on
the size of the pool. Repeat this procedure
for the other pole.
Set Up Instructions (cont.)
6
4
5
6
Fig (2)
Fig (3)
Fig (4)
2
9
1
3
7
1
2
Pool “U shape”
leg
4
5
Fig (1)
21
1
2
3
Vertical Adjustment
Fig (6)
Fig (5)
9
10
1
2
