(188PO) MODEL CS8110 SALTWATER SYSTEM ENGLISH 7.5” X 10.3” PANTONE 295U 06/28/2013
English
OWNER’S MANUAL
Krystal Clear
Saltwater System®
Model CS7110
IMPORTANT
SAFETY RULES
Read, understand, and follow
all instructions carefully before
installing and using this product.
Don’t forget to try these other fine Intex products: Pools, Pool
Accessories, Inflatable Pools and In-Home Toys, Airbeds and
Boats available at fine retailers or visit our website listed below.
Due to a policy of continuous product improvement, Intex
reserves the right to change specifications and appearance,
which may result in updates to the instruction manual without
notice.
For illustrative purposes only.
IMPORTANT!
DO NOT RETURN PRODUCT TO STORE
To purchase parts and accessories or to obtain non-technical assistance, Visit
www.intexcorp.com
For technical assistance and missing parts call us toll-free (for U.S. and Canadian Residents):
1-800-234-6839
Monday through Friday, 8:30am to 5:00pm Pacific Time 188-*PO-R0-1406

Page 2
(188PO) MODEL CS8110 SALTWATER SYSTEM ENGLISH 7.5” X 10.3” PANTONE 295U 06/28/2013
English 188
PO
SAVE THESE INSTRUCTIONS
English
Page 2
Warnings............................................................................... 3
Parts References.................................................................. 4-5
Product Information & Specifications................................ 6
Setup Instructions................................................................ 7-11
Salt & Pool Water Volumes...................................................12
Intex Pools Salt Table........................................................... 13
Intex Pools Cyanuric Acid Table..........................................14
Intex Pools Operating Time Table........................................15
Non-Intex Pools Salt Table................................................... 16
Non-Intex Pools Cyanuric Acid Table................................. 16
Non-Intex Pools Operating Time Table................................16
Operating Instructions......................................................... 17-18
LED Code Chart.................................................................... 19
Maintenance.......................................................................... 20-22
Long Term Storage............................................................... 22
Pool Maintenance and Chemical Definitions..................... 23
Troubleshooting Guide........................................................ 24-25
General Aquatic Safety........................................................ 26
Limited Warranty................................................................... 27
TABLE OF CONTENTS

Page 2
(188PO) MODEL CS8110 SALTWATER SYSTEM ENGLISH 7.5” X 10.3” PANTONE 295U 06/28/2013
English 188
PO
SAVE THESE INSTRUCTIONS
English
Page 3
WARNING
•To reduce the risk of injury, do not permit children to use this product. Always supervise
children and those with disabilities.
•Children must stay away from this product and all electrical cords.
•Assembly and disassembly by adults only.
•Risk of electric shock. Connect only to a grounding type receptacle, this product is provided
with a ground-fault circuit interrupter. If replacement of the plug or cord is needed, use only
identical replacement parts.
•Always unplug this product from the electrical outlet before removing, cleaning, servicing or
making any adjustment to the product.
• Theunitisprovidedwithaground-faultcircuitinterrupter(GFCI).TotesttheGFCI,pushthe 
test button. TheGFCIshouldinterruptpower.Push the reset button, power should be restored.
 IftheGFCIfailstooperateinthismanner.TheGFCIisdefective.IftheGFCIinterruptspower
to the pump without the test button being pushed, a ground current is flowing, indicating the
possibility of an electric shock. Do not use this pump. Disconnect the pump and have the
problem corrected by a qualified service representative before using.
•Do not bury the electrical cord. Locate the cord where it will not be damaged by lawn mowers,
hedge trimmers and other equipment.
•To reduce the risk of electric shock, the supply cord cannot be replaced. If the cord is
damaged, the appliance should be replaced immediately.
•To reduce the risk of electric shock, do not use extension cords, timers, plug adaptors or
converter plugs to connect unit to electric supply; provide a properly located outlet.
•Do not attempt to plug in or unplug this product while standing in water or when your hands are
wet.
• Donotuseanapplianceleakagecurrentinterrupter(ALCI)inplaceofaGFCIsincetheALCI 
will not protect people.
• Positionthisproductawayfromthepool,soastopreventchildrenfromclimbingonitand 
accessing the pool.
•Do not operate this product when the pool is occupied.
• Thisproductisintendedtobeusedonlyforthepurposesdescribedinthemanual!
FAILURE TO FOLLOW THESE WARNINGS MAY RESULT IN PROPERTY
DAMAGE, ELECTRIC SHOCK, ENTANGLEMENT OR OTHER SERIOUS
INJURY OR DEATH.
IMPORTANT SAFETY RULES
Read,UnderstandandFollowAllInstructionsCarefullyBeforeInstallingandUsingthisProduct.
READ AND FOLLOW ALL INSTRUCTIONS
For portable Above-Ground-Pools only
This product is for use with storable pools only. Do not use with permanently-installed pools. A
storable pool is constructed so that it is capable of being readily disassembled for storage and
reassembled to its original integrity. A permanently-installed pool is constructed in or on the ground
or in a building such that it cannot be readily disassembled for storage.
These product warnings, instructions and safety rules provided with the product represent some common
risks of water recreation devices and do not cover all instances of risk and danger. Please use common
sense and good judgement when enjoying any water activity.
CAUTION

Page 2
(188PO) MODEL CS8110 SALTWATER SYSTEM ENGLISH 7.5” X 10.3” PANTONE 295U 06/28/2013
English 188
PO
SAVE THESE INSTRUCTIONS
English
Page 4
PARTS REFERENCE
Beforeassemblingyourproduct,pleasetakeafewminutestocheckthecontents
and become familiar with all the parts.
NOTE: Drawings for illustration purpose only. Actual product may vary. Not to scale.
Operation is subject to the following two conditions: (1) this device may not cause interference,
and (2) this device must accept any interference, including interference that may cause
undesired operation of the device.
Changes or modifications not expressly approved by the party responsible for compliance could
void the user’s authority to operate the equipment.
ThisequipmenthasbeentestedandfoundtocomplywiththelimitsforClassBdigitaldevice,
pursuanttopart15oftheFCCRules.Theselimitsaredesignedtoprovidereasonable
protection against harmful interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of
the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and the receiver.
•Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
•Consult the dealer or an experienced radio/TV technician for help.
1
13
6
11
7
4
5
9
8
10
2
12 3
16
18
17

Page 2
(188PO) MODEL CS8110 SALTWATER SYSTEM ENGLISH 7.5” X 10.3” PANTONE 295U 06/28/2013
English 188
PO
SAVE THESE INSTRUCTIONS
English
Page 5
When ordering parts, be sure to quote the model number and part numbers.
REF. NO.
DESCRIPTION QTY.
SPARE
PART
NO.
COMMON
PARTS
PARTS FOR
CONNECTION
TO FILTER
PUMPS WITH
1-1/4” (32MM)
HOSE SIZE
1  ADAPTORAWITHTHREADEDCOLLAR(OPTIONAL) 1 10849
2 O-RINGA 1 10712
3SCREW 2 11519
4 ELECTROLYTIC CELL(O-RINGCINCLUDED) 1 11577
5 COPPER ELECTRODE 1 11579
6TITANIUM ELECTRODE 1 11581
7 FLOWSENSOR 1 11460
8 CONNECTORHOSEWITHTHREADEDFITTINGS 1 10720
9 THREADEDADAPTORB(OPTIONAL) 1 10722
10 CELL COVER 2 11131
11 ELECTROLYTIC CELL NUT 1 11582
12 L-SHAPEO-RING 1 11228
13 COPPER ELECTRODE NUT 1 11580
14 CHLORINE TEST STRIPS 1 19635
15 COPPER TEST STRIPS 1 11254
16 TITANIUMELECTRODEO-RING 1 11585
17 COPPERELECTRODEO-RING 1 11586
18 CONTROL STATION 111589EG
PARTS REFERENCE (continued)
Beforeassemblingyourproduct,pleasetakeafewminutestocheckthecontents
and become familiar with all the parts.

Page 2
(188PO) MODEL CS8110 SALTWATER SYSTEM ENGLISH 7.5” X 10.3” PANTONE 295U 06/28/2013
English 188
PO
SAVE THESE INSTRUCTIONS
English
Page 6
This product is specially designed for above ground pools. It will destroy the bacteria,
oxidize bather organics and control algae, which provide a safe, clean and comfortable
swimming pool.
Commonsalt(sodiumchloride)ismadeupoftwoelements,sodiumandchloride.Duringthe
installation of your Saltwater System, a measured quantity of salt is dissolved in the pool water
to make it slightly salty. The pool water flows through the Saltwater System ’s electrolytic cell
to produce chlorine. The chlorine dissolves in the water and instantly starts destroying bacteria
and algae. It also oxidizes all other organic materials.
Low voltage direct current is applied to the copper electrode, and copper ions are generated
and dissolved instantly in the water. Copper is an effective algaecide, which will prevent
algae from growing in the pool.
HOW THE CHLORINE IS GENERATED
Power: 110 - 120 Volt AC
Amperage: 0.6A
Wattage: 65W
 IdealSaltLevel: 3000ppm(partspermillion)
Maximum Chlorine Output/hour: 5 grams/hour
Copper Ionizer Output Current: 175 mA
 MinimumFlowRate: 700~4000gallons/hour(2650-15140liters/hour)
Limited Warranty: see “Limited Warranty”
HOW COPPER IONS ARE GENERATED
PRODUCT SPECIFICATIONS
Copper electrodes
Hose from
Filter Pump
Flow Sensor
Electronic
Control Station Power Supply
Electrolytic Cell
Power Switch
Hose Returning
Water to Pool

Page 2
(188PO) MODEL CS8110 SALTWATER SYSTEM ENGLISH 7.5” X 10.3” PANTONE 295U 06/28/2013
English 188
PO
SAVE THESE INSTRUCTIONS
English
Page 7
SETUP INSTRUCTIONS
1. Assembletheabove-ground-pool(AGP)anditsfilterpumpaccordingtotheirinstallation
instructions.
2. Take the Saltwater System and its accessories out of the packaging.
3. Place the Saltwater System in line after the filter pump.
4. Connect the connector hose (8) to the Saltwater System inlet.
Connecting the system to pump and pool with 1-1/4” (32mm) connections/hoses:
The saltwater system features 1-1/2” (38mm) connections. It is accordingly supplied with
adaptors A (1) and B (9) for connecting to the small 1-1/4” (32mm) diameter connections/
hoses. Install as follows:
Drawing #1
IMPORTANT
• TheSaltwaterSystemrequiresaseparatefilterpump[700~4000gph(2650~15140
lph)] to drive the water and function properly.
• TheSaltwaterSystemmustbeinstalledasthelastpieceofpoolequipmentinthe
water return line to the pool as displayed in Drawing #1. This location extends the
life of the titanium plates.
WATER TO
POOL
WATERFROM
POOL
FILTER
PUMP
SWIMMINGPOOL
ID1-1/4”(32mm)
HOSE
ID 1-1/4”
(32mm)HOSE
19
9
8
SALTWATER
SYSTEM

Page 2
(188PO) MODEL CS8110 SALTWATER SYSTEM ENGLISH 7.5” X 10.3” PANTONE 295U 06/28/2013
English 188
PO
SAVE THESE INSTRUCTIONS
English
Page 8
SETUP INSTRUCTIONS (continued)
1. Godirectlytostep2ifyourpoolisempty.Ifyourabove-ground-poolisfilledwithwater,
unscrew the strainer grids from the strainer connectors and insert the black hat-like plugs
into the connectors, before installing the saltwater pool system.
2. Connect the adaptor A (1) to the electrolytic cell (4) outlet as shown in Drawing #1. Tighten
securely.
3. Disconnect the water return hose from the filter pump connection and connect it to the
adaptor A (1)ontheSaltwaterSystemwithahoseclamp.(seeDrawing#1)
4. ConnectadaptorB(9) to the connector hose (8).Tightensecurely.(seeDrawing#1)
5. ConnectadaptorB(9) tofilterpumpoutlet(lowerconnection).Tightensecurely.
6. Remove the black hat-like plugs that prevent water from flowing out of the pool. Now,
return the strainer grids to the strainer connectors.
8
9
1
4
8
9
Filter
Pump

Page 2
(188PO) MODEL CS8110 SALTWATER SYSTEM ENGLISH 7.5” X 10.3” PANTONE 295U 06/28/2013
English 188
PO
SAVE THESE INSTRUCTIONS
English
Page 9
SETUP INSTRUCTIONS (continued)
Connecting the system to pump and pool with 1-1/2” (38mm) connections/hoses:
Pump and pool with 1-1/2” (38mm) connections do not require the adaptors A (1) or B (9).
Install as follows:
Drawing #2
1. Godirectlytostep2ifyourpoolisempty.Ifyourabove-ground-poolisfilledwithwater,
close the plunger valves before installing the Saltwater System.
2. Disconnect the water return hose from the filter pump connection and connect it to the
Saltwater System outlet.
3. Connect the connector hose (8) to the filter pump outlet connection.
4. Open the plunger valves to allow the water to flow.
FILTER
PUMP
ID1-1/2”(38mm)
HOSE
ID1-1/2”(38mm)
HOSE
SALTWATER
SYSTEM
SWIMMINGPOOL
WATER TO
POOL
PLUNGER
VALVE
WATERFROM
POOL
8

Page 2
(188PO) MODEL CS8110 SALTWATER SYSTEM ENGLISH 7.5” X 10.3” PANTONE 295U 06/28/2013
English 188
PO
SAVE THESE INSTRUCTIONS
English
Page 10
SETUP INSTRUCTIONS (continued)
Connecting the system to other types of pump (with different type of thread or no
thread):
The Saltwater System can also be adapted to other filter pumps with different thread or those
without a thread on the connection.
Connection to 1-1/4” (32mm) hose:
1. ConnectoneendofadaptorB(9) to the connector hose (8). Tighten securely.
2. Now,connecttheotherendofadaptorB(9) to the filter pump outlet. Tighten securely.
Connection to 1-1/2” (38mm) hose with clamp:
1. Connect the connector hose (8) to the filter pump outlet connection with a large hose
clamp. Tighten securely.
ID1-1/4”(32mm)
CONNECTION
SALTWATER SYSTEM
FILTERPUMP
89
LARGEHOSE
CLAMP
FILTERPUMP
ID1-1/2”(38mm)
CONNECTION
SALTWATER SYSTEM
8

Page 2
(188PO) MODEL CS8110 SALTWATER SYSTEM ENGLISH 7.5” X 10.3” PANTONE 295U 06/28/2013
English 188
PO
SAVE THESE INSTRUCTIONS
English
Page 11
SETUP INSTRUCTIONS (continued)
Connecting the system to other types of pool
After you have connected the Saltwater System to the pump, connect it to the pool. This
is depicted in Drawings #1 and #2.
Followingarethecommonconnectiontypes:
Connection to 1-1/4” (32mm) connectors:
1. Connect the adaptor A (1) to the electrolytic cell (4) outlet. Tighten securely.
2. The adapter A (1) is now fitted to the Saltwater System. The following step is to connect the
water return hose to the adaptor A (1) with a hose clamp.
Connection to 1-1/2” (38mm) connectors without thread:
1. Connect the adaptor A (1) to the electrolytic cell (4) outlet. Tighten securely.
2. With the adaptor A (1) fixed to the Saltwater System, connect the water return hose to the
adaptor, using a large hose clamp.
HOSE CLAMP
1
ID1-1/4”(32mm)
HOSE
SALTWATER SYSTEM
LARGEHOSECLAMP
1
ID1-1/2”(38mm)
HOSE
SALTWATER SYSTEM

Page 2
(188PO) MODEL CS8110 SALTWATER SYSTEM ENGLISH 7.5” X 10.3” PANTONE 295U 06/28/2013
English 188
PO
SAVE THESE INSTRUCTIONS
English
Page 12
SALT & POOL WATER VOLUMES
• Whichkindofsalttouse:
Use only Sodium Chloride Salts
Useonlysodiumchloride(NaCl)saltthatisatleast99.8%pure.Itisalsoacceptabletouse
waterconditioningsaltpellets(thecompressedformsofevaporatedsalt).However,itwilltakea
longer time for them to dissolve.
Do not use iodized or yellow (yellow prussiate of soda) colored salt.
Salt is added to the pool water and the electrolytic cell uses the salt to create chlorine. The purer
the salt the better the performance of the electrolytic cell.
• OptimumSaltLevels
Theidealsaltlevelinthepoolwaterisbetween2500-3500ppm(partspermillion).Theoptimal
level is 3000 ppm. A too low salt level will reduce the efficiency of the Saltwater System and
resultinlowchlorineproduction.Ahighsaltlevelmaygenerateasaltytastetothepoolwater(this
mayoccuratasaltlevelabove3500-4000ppm).Toohighasaltlevelmaydamagethepower
supply and cause corrosion to the pool metal fixtures and accessories. The Salt Table page of
this manual, shows the correct dosage of salt needed. The salt in the pool is constantly recycled.
The loss of salt is due only to pool water being physically removed from the pool. Salt is not lost
due to evaporation.
• AddingSalt
1. Switch the filter pump on to start the water circulation.
2. Keep the Saltwater System turned off.
3. Determinetheamountofsalttobeadded(see“SaltTable”).
4. Evenly spread the proper amount of salt around the inside perimeter of the pool.
5. Avoid clogging the filter. Do not add salt through the skimmer.
6. Brushthepoolbottomtospeedupthedissolvingprocess.Donotallowsalttopileuponthe
bottom of the pool. Run the filter pump 24 consecutive hours to thoroughly dissolve the salt.
7. After 24 hours and if all the salt is dissolved, turn on the Saltwater System, press button
until you hear a “beep”, code “00” flashing and set the saltwater pool system to desired
 operatingtime(see“OperatingTimeTable”).
• RemovingSalt
Iftoomuchsalthasbeenadded,theunitwillbeepanddisplay“Code92”(see“AlarmCodes”).
You will need to lower the salt concentration. The only way to do so, is to partially drain the pool
andrefillitwithfreshwater.Drainandrefillapproximately20%ofthepool’swateruntilthe“Code
92” disappears.
• PoolVolumeCalculation
Rectangular Length x Width x Average Depth x 7.5 Length x Width x Average Depth
Circular Length x Width x Average Depth x 5.9 Length x Width x Average Depth x 0.79
Oval Length x Width x Average Depth x 6.0 Length x Width x Average Depth x 0.80
Types of Pool Gallons
(poolsizeinfeet)
Cubic Meters
(poolsizeinmeters)

Page 2
(188PO) MODEL CS8110 SALTWATER SYSTEM ENGLISH 7.5” X 10.3” PANTONE 295U 06/28/2013
English 188
PO
SAVE THESE INSTRUCTIONS
English
Page 13
INTEX POOLS SALT TABLE
This table shows the amount of salt needed to achieve and maintain the optimal 3000 ppm
salt level.
Pool Size
Water Capacity
(Calculated at 90% for
Frame Pool and 80% for
Easy Set & Oval Pool)
Salt Needed for
Startup
3.0g/L (3000ppm)
Salt Needed when
Low Salt Detected
(CODE “91”)
(Gals) (Liters) (Lbs) (Kgs) (Lbs) (Kgs)
INTEX ABOVE GROUND POOLS (AGP’s)
EASY SET®
POOL
457cmx84cm(15'x33") 2587 9792 65 30 20 10
457cmx91cm(15'x36") 2822 10681 65 30 20 10
457cmx107cm(15'x42") 3284 12430 80 35 20 10
457cmx122cm(15'x48") 3736 14141 95 45 25 10
488cmx107cm(16'x42") 3754 14209 95 45 25 10
488cmx122cm(16'x48") 4273 16173 110 50 30 15
488cmx132cm(16'x52") 4614 17464 115 50 30 15
549cmx107cm(18'x42") 4786 18115 120 55 30 15
549cmx122cm(18'x48") 5455 20647 135 60 35 15
CIRCULAR
METAL
FRAME POOL
457cmx91cm(15'x36") 3282 12422 80 35 20 10
457cmx107cm(15'x42") 3861 14614 100 45 25 10
457cmx122cm(15'x48") 4440 16805 110 50 30 15
488cmx122cm(16'x48") 5061 19156 125 55 35 15
549cmx122cm(18'x48") 6423 24311 160 75 40 20
ULTRA FRAME®
POOL
488cmx122cm(16'x48") 5061 19156 125 55 35 15
549cmx122cm(18'x48") 6423 24311 160 75 40 20
SEQUOIA SPIRIT®
POOL SET
478cmx124cm(15'8"x49") 4440 16805 110 50 30 15
508cmx124cm(16'8"x49") 5061 19156 125 55 35 15
OVAL FRAME
POOL
305cmx549cmx107cm(10'x18'x42") 2885 10920 70 30 20 10
366cmx610cmx122cm(12'x20'x48") 4393 16628 110 50 30 15
RECT. ULTRA
FRAME POOL
274cmx457cmx122cm(9'x15'x48") 3484 13187 90 40 25 10
274cmx549cmx132cm(9'x18'x52") 4545 17203 115 50 30 15
305cmx610cmx132cm(10'x20'x52") 5835 22085 145 65 40 20

Page 2
(188PO) MODEL CS8110 SALTWATER SYSTEM ENGLISH 7.5” X 10.3” PANTONE 295U 06/28/2013
English 188
PO
SAVE THESE INSTRUCTIONS
English
Page 14
INTEX POOLS CYANURIC ACID TABLE
Cyanuric acid is a chemical that reduces the loss of chlorine in water due to ultraviolet rays.
To maintain maximum performance, we recommend that the cyanuric acid level be
maintained at approximately 1% of the salt, i.e. 100 Lbs (45 Kgs) salt x1% = 1 Lbs (0.45 Kgs)
cyanuric acid. If the pool water is dirty, filthy or grimy, DO NOT add chlorine stabilizer (cyanuric
acid) as this will slowdown the sanitation time of the device. Under this condition you must
BOOST your pool water, refer to BOOST cycle steps. Once the pool water has been restored
to clear and clean conditions you may add cyanuric acid.
Pool Size
Water Capacity (Calculated at
90% for Frame Pool and 80%
for Easy Set & Oval Pool)
Cyanuric Acid Needed for
Startup
0.03g/L (30ppm)
(Gals) (Liters) (Lbs) (Kgs)
INTEX ABOVE GROUND POOLS (AGP’s)
EASY SET®
POOL
457cmx84cm(15'x33") 2587 9792 0.6 0.3
457cmx91cm(15'x36") 2822 10681 0.7 0.3
457cmx107cm(15'x42") 3284 12430 0.8 0.4
457cmx122cm(15'x48") 3736 14141 0.9 0.4
488cmx107cm(16'x42") 3754 14209 0.9 0.4
488cmx122cm(16'x48") 4273 16173 1.1 0.5
488cmx132cm(16'x52") 4614 17464 1.2 0.5
549cmx107cm(18'x42") 4786 18115 1.2 0.5
549cmx122cm(18'x48") 5455 20647 1.4 0.6
CIRCULAR
METAL
FRAME POOL
457cmx91cm(15'x36") 3282 12422 0.8 0.4
457cmx107cm(15'x42") 3861 14614 1.0 0.4
457cmx122cm(15'x48") 4440 16805 1.1 0.5
488cmx122cm(16'x48") 5061 19156 1.3 0.6
549cmx122cm(18'x48") 6423 24311 1.6 0.7
ULTRA FRAME®
POOL
488cmx122cm(16'x48") 5061 19156 1.3 0.6
549cmx122cm(18'x48") 6423 24311 1.6 0.7
SEQUOIA SPIRIT®
POOL SET
478cmx124cm(15'8"x49") 4440 16805 1.1 0.5
508cmx124cm(16'8"x49") 5061 19156 1.3 0.6
OVAL FRAME
POOL
305cmx549cmx107cm(10'x18'x42") 2885 10920 0.7 0.3
366cmx610cmx122cm(12'x20'x48") 4393 16628 1.1 0.5
RECT. ULTRA
FRAME POOL
274cmx457cmx122cm(9'x15'x48") 3484 13187 0.9 0.4
274cmx549cmx132cm(9'x18'x52") 4545 17203 1.1 0.5
305cmx610cmx132cm(10'x20'x52") 5835 22085 1.5 0.7

Page 2
(188PO) MODEL CS8110 SALTWATER SYSTEM ENGLISH 7.5” X 10.3” PANTONE 295U 06/28/2013
English 188
PO
SAVE THESE INSTRUCTIONS
English
Page 15
INTEX POOLS OPERATING TIME TABLE (WITH CYANURIC ACID)
Pool Size
Water Capacity (Calculated at
90% for Frame Pool and 80%
for Easy Set & Oval Pool)
Operating Time (hours)
at different ambient/air
temperatures
Intex Filter
pump
Operating
Time
(hours)
(Gals) (Liters)
10 - 19°C
(50 - 66°F)
20 - 28°C
(68 - 82°F)
29 - 36°C
(84 - 97°F)
INTEX ABOVE GROUND POOLS (AGP’s)
EASY SET®
POOL
457cmx84cm(15'x33") 2587 9792 2 3 4 6
457cmx91cm(15'x36") 2822 10681 3 3 4 6
457cmx107cm(15'x42") 3284 12430 3 4 5 6
457cmx122cm(15'x48") 3736 14141 4 4 5 6
488cmx107cm(16'x42") 3754 14209 4 4 5 6
488cmx122cm(16'x48") 4273 16173 4 5 6 8
488cmx132cm(16'x52") 4614 17464 5 5 6 8
549cmx107cm(18'x42") 4786 18115 5 5 6 8
549cmx122cm(18'x48") 5455 20647 6 6 7 8
CIRCULAR
METAL
FRAME POOL
457cmx91cm(15'x36") 3282 12422 3 4 5 6
457cmx107cm(15'x42") 3861 14614 4 4 5 6
457cmx122cm(15'x48") 4440 16805 5 5 6 8
488cmx122cm(16'x48") 5061 19156 5 6 7 8
549cmx122cm(18'x48") 6423 24311 7 7 8 12
ULTRA FRAME®
POOL
488cmx122cm(16'x48") 5061 19156 5 6 7 8
549cmx122cm(18'x48") 6423 24311 7 7 8 12
SEQUOIA SPIRIT®
POOL SET
478cmx124cm(15'8"x49") 4440 16805 5 5 6 8
508cmx124cm(16'8"x49") 5061 19156 5 6 7 8
OVAL FRAME
POOL
305cmx549cmx107cm(10'x18'x42") 2885 10920 3 3 4 6
366cmx610cmx122cm(12'x20'x48") 4393 16628 4 5 6 8
RECT. ULTRA
FRAME POOL
274cmx457cmx122cm(9'x15'x48") 3484 13187 3 4 5 6
274cmx549cmx132cm(9'x18'x52") 4545 17203 5 5 6 8
305cmx610cmx132cm(10'x20'x52") 5835 22085 6 7 8 12
IMPORTANT
The filter pump running time should be 1 hour longer than the required operating time of the
Saltwater System.

Page 2
(188PO) MODEL CS8110 SALTWATER SYSTEM ENGLISH 7.5” X 10.3” PANTONE 295U 06/28/2013
English 188
PO
SAVE THESE INSTRUCTIONS
English
Page 16
SALT TABLE FOR COMMON NON-INTEX POOLS
Water Capacity Salt Needed for Startup
Salt Needed when
Low Salt Detected
(CODE “91”)
(Gals) (Liters) (Lbs) (Kgs) (Lbs) (Kgs)
2000 7500 50 20 10 5
4000 15000 100 45 25 10
6000 22500 150 65 40 20
7000 26500 175 80 55 20
Salt Needed for Startup
(Lbs)
Salt Needed for Startup
(Kgs)
Salt Needed when
Low Salt Detected (Lbs)
Salt Needed when
Low Salt Detected (Kgs)
WaterCapacity(Gals)x0.025
WaterCapacity(Liters)x0.003 WaterCapacity(Gals)x0.0067 WaterCapacity(Liters)x0.0008
OPERATING TIME TABLE FOR COMMON NON-INTEX POOLS (WITH CYANURIC ACID)
Water Capacity
Operating Time (hours)
at different ambient/air temperatures
(Gals) (Liters) 10 - 19°C
(50 - 66°F)
20 - 28°C
(68 - 82°F)
29 - 36°C
(84 - 97°F)
2000 7500 2 2 3
4000 15000 4 5 6
6000 22500 7 7 8
7000 26500 7 8 9
CYANURIC ACID TABLE FOR COMMON NON-INTEX POOLS
Water Capacity
Cyanuric Acid Needed for Startup
0.03g/L (30ppm)
(Gals) (Liters) (Lbs) (Kgs)
2000 7500 0.50 0.23
4000 15000 1.00 0.45
6000 22500 1.50 0.68
7000 26500 1.75 0.80
SALT CALCULATION FORMULA FOR ALL POOLS

Page 2
(188PO) MODEL CS8110 SALTWATER SYSTEM ENGLISH 7.5” X 10.3” PANTONE 295U 06/28/2013
English 188
PO
SAVE THESE INSTRUCTIONS
English
Page 17
OPERATION INSTRUCTIONS
1. Turn on the filter pump.
2. Start up the unit:
Plug the power cord into the
electrical outlet and test the
 GFCI/RCD(circuitbreaker).
 Switchontheunit.Flashingcode“00” 
appears on the electronic control station’s
LED, indicating that the unit is ready to be
programmed.
3. Set operating hours for Saltwater system:
With code “00” flashing, press button to
set the desired operating hours. See the
“Operating Time Table” for the required
operating hours related to each pool size.
Pressing will increase the time from 01
to 12 hours maximum. If you have selected
too many hours keep pressing to repeat
the cycle. The built-in timer will now activate
your Saltwater System, at the same time
each day, for the number of hours you have set.
NOTE: The Saltwater System will not operate if the filter pump is not operating.
 Makesuretoprogramyourfilterpump(orstartitmanually)foroperationbeginning5
minutes before the saltwater system and finishing 15 minutes after the saltwater system.
4. Lockkeypadcontrols:
With the desired hour value showing, press button until you
 heara“beep”.Agreen“WORKING”indicatoronthecontrolpanel
will light up within a few seconds to indicate that the saltwater system
has started chlorine production. Locking the control buttons into this
setting prevents unauthorized changing of the operating cycle.
NOTE: If you forget to lock the keypad controls, the system will
automatically lock it and start working 1 minute later.
5. Readjust operating time if necessary:
The operating hours can be re-adjusted if necessary.
Press button until you hear a “beep” to unlock the keypad and the
current programmed time will flash. Repeat steps 3 to 4.
6 . Test the copper concentration in the pool water.
The Saltwater System recommends a copper level of 0.1 to 0.2 ppm.
This is easily tested by the copper ion test strips provided. If the test
result is 0.1~0.2 ppm, go directly to step 8.
(1to12hoursmaxpercycle)
OK
0
Copper (ppm)
0.1 0.2 0.5 0.9 1.3

Page 2
(188PO) MODEL CS8110 SALTWATER SYSTEM ENGLISH 7.5” X 10.3” PANTONE 295U 06/28/2013
English 188
PO
SAVE THESE INSTRUCTIONS
English
Page 18
7. Boost cycle
•Ifthetestresultisbelow0.1ppm,pressandhold“BOOST”buttonfor5
seconds until the indicator lights up and the LED display “80”. This
indicates that the saltwater system has started copper ion and more
 chlorinesanitizerproduction.Youcanpressandholdthe“BOOST”
button for another 5 seconds until the indicator is off, which will cancel
 theBoostcycle.
Note: Once the system has started copper ion and more chlorine
sanitizer production, the boost button can’t be re-set until the power
switch is off.
•The boost operating hours is 8 times the amount of time programmed into the system, i.e. if your
saltwater system operating time is 3 hours, the boost procedure will run 8 x 3 = 24 hours. After
boost procedure has been completed, the system will automatically switch to the normal
working mode.
•Once the boost is operating, check whether the filter pump operating hours have been set
 properly.Forexample,theboostoperatingtimeis16hours,thefilterpumpshouldbesetto
run for 17 hours at least. Increase the filter pump operating time if necessary.
Note: If an Intex filter pump is attached to the system, set the pump switch to on “I” position.
•Afteraheavyrainorifthepoolisdirty,pressthe“BOOST”buttontoshockthepoolagain.
8. Test pool water regularly:
Once the copper level appears to be balanced, test the pool water every week to maintain
the proper sanitizer level. It’s very important that the free chlorine is between 0.5-3.0
ppm and copper ion concentration is between 0.1~0.2 ppm. When the copper level is below
0.1 ppm, repeat step 7.
NOTE: A High copper ion concentration may cause blonde hair to exhibit a green hair. To
prevent this, wear a swimming cap during swimming, and wash hair with special shampoo
 afterusingthepool.See“TroubleshootingGuide”.
9. Stand-by/power saving mode:
•When the cycle ends, the green “SLEEP” indicator on the control panel
lights up and the LED display flashes “93”. The system is now in
 Stand-Bymode.Afterawhile,itshutsdownandsetsitselfinaPower
Saving mode. The system will automatically turn itself back on in 24
hours, starting its daily cycle of chlorine production.
•The “SLEEP” indicator stays on, while the system is in the Power Saving
mode. The LED display however, goes blank after 5 minutes. Press any
 button(or)toviewthelastLEDcode.
OPERATION INSTRUCTIONS (continued)

Page 2
(188PO) MODEL CS8110 SALTWATER SYSTEM ENGLISH 7.5” X 10.3” PANTONE 295U 06/28/2013
English 188
PO
SAVE THESE INSTRUCTIONS
English
Page 19
LED CODE CHART
LED Reading Definitions
80 BoostMode
 00 Stand-ByMode(Start-up)
 01 MinimumOperatingHour(1hourremaining)
 02 OperatingHours(2hoursremaining)
 03 OperatingHours(3hoursremaining)
 04 OperatingHours(4hoursremaining)
 05 OperatingHours(5hoursremaining)
 06 OperatingHours(6hoursremaining)
 07 OperatingHours(7hoursremaining)
 08 OperatingHours(8hoursremaining)
 09 OperatingHours(9hoursremaining)
 10 OperatingHours(10hoursremaining)
 11 OperatingHours(11hoursremaining)
 12 MaximumOperatingHours(12hoursremaining)
 90 AlarmCode(LowPumpFlow/NoPumpFlow)
 91 AlarmCode(LowSaltLevel)
 92 AlarmCode(HighSaltLevel)
 93 Stand-ByMode(OperatingProcessfinished)
 “BLANK” NoPoweror“PowerSavingMode”waitingtostartnext
Saltwater System cycle.
IMPORTANT
When Code “90” alarm is shown, ensure the timer of the filter pump is set one (1)
hour longer than the Saltwater System.
If the filter pump does not have a built-in timer, the filter pump needs to be turned
on/off manually every day.

Page 2
(188PO) MODEL CS8110 SALTWATER SYSTEM ENGLISH 7.5” X 10.3” PANTONE 295U 06/28/2013
English 188
PO
SAVE THESE INSTRUCTIONS
English
Page 20
MAINTENANCE
IMPORTANT
Unplug the power cord before cleaning your system. Also close the plunger valves
onyourpoolorinserttheblackhat-likeplugsinthestraineropeningtoprevent
waterspillage.Aftercompletingallmaintenancetasks,youmustplugthepower
cordbackinandopentheplungervalvesorremovetheplugs.
Flow Sensor Cleaning
1. In a counter-clockwise motion unscrew the collar of the flow sensor (7) and remove it from
the electrolytic cell conduit. See “Part Reference”.
2. If deposits and debris are seen on the surface of the flow sensor, then use a garden hose
to wash it off.
3. If flushing with water does not remove the deposits, use a plastic brush to clean the surface
and the hinge if necessary. Do not use a metal brush.
4. After the flow sensor has been inspected and cleaned, align the locator notch on the flow
sensor to the connection ridge in the conduit. Now turn the collar in a clockwise motion,
tightening the sensor back into its position. Do not overtighten.
Electrolytic Cell Cleaning
Theelectrolyticcellhasaselfcleaningfunctionincorporatedintotheelectroniccontrol's
programming. In most cases this self cleaning action will keep the cell working at optimum
efficiency.Ifthepoolwaterishard(highmineralcontent)thecellmayrequireperiodicmanual
cleaning. To maintain maximum performance, we recommend that you open and visually
inspect the electrolytic cell monthly. The following steps provide instructions on how to clean
your cell.
Inspection and cleaning:
1. Switch off the unit, unplug the power cord from the electrical socket.
2. For filter pumps with 1-1/4” (32mm) hose size -To prevent water from flowing out of the
pool, unscrew the strainer grids from the strainer connectors and insert the hat-like plugs
into the strainer connectors.
For filter pumps with 1-1/2” (38mm) hose size - Turn both plunger valve handles fully
clockwise until they stop. This closes the valve, prevents the water from flowing out of the
pool.
Connection Ridge
Locator Notch
Hinge
